2AWB7-RT36AFan Light Remote Control

1 ATTACH YOUR RECEIPT HERE Serial Number _________________________ Purchase Date _________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday. EB14216 ITEM #0599849, 0599656, 0599848 CROSSWINDS II CEILING FAN MODEL #40821, 40823, 40822 Español p. 23 TABLE OF CONTENTS Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Hardware Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Initial Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Standard or Angle Mounting Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Closemount Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Final Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Warning . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 2 3 PACKAGE CONTENTS PARTDESCRIPTIONQUANTITY ADownrod1 BDownrod Pin (preassembled to Downrod [A])1 CDownrod Clip (preassembled to Downrod [A])1 DCanopy1 EMounting Bracket (preassembled to the Canopy [D])1 FCanopy Cover (preassembled to Canopy [D])1 GMotor Assembly1 HSwitch Housing (preassembled to Motor Assembly [G])1 ISwitch Housing Cap (preassembled to Light Kit [J])1 JLight Kit1 KFinial Cap (preassembled to Light Kit [J])1 LFinial (preassembled to Light Kit [J])1 MGlass Bowl1 NBlade Arm5 OBlade5 PRemote Pack1 QBulb3 RBlade Balancing Kit1 SRubber Washer (preassembled to Light Kit [J])1 THex Nut (preassembled to Light Kit [J])1 UMotor Screw (preassembled to Motor Assembly [G])10 + 1 extra VSwitch Housing Screw (preassembled to Switch Housing Cap [I])3 WMounting Bracket Screw (preassembled to Mounting Bracket [E])4 XSet Screw (preassembled to Motor Assembly [G])2 YPhillips-head Closemount Screw (preassembled to Motor Assembly [G])3 A B C D I H G F J K L M NO E P Q R STUVWXY 4 HARDWARE CONTENTS (shown actual size) Plug Button Qty. 1 Wire Connector Qty. 1 +1 extra AABB 5 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. •Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. •Make sure all electrical connections comply with local codes, ordinances, the National Electrical Code, and ANSI/NFPA 70-199. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring. •Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades to the floor and at least 30 in. from the end of the blades to any obstruction. •The net weight of this fan is: 16.4 lbs. DANGER: When using an existing outlet box, make sure the outlet box is securely attached to the building structure and can support the full weight of the fan. Failure to do this can result in serious injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan after installation is complete. WARNING: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp edges. WARNING: Using a full-range dimmer switch to control fan speed will cause a loud humming noise from the fan. To reduce the risk of fire or electric shock, do NOT use a full-range dimmer switch to control the fan speed. WARNING: To reduce the risk of fire, electric shock, or personal injury, mount the fan to an outlet box marked “ACCEPTABLE FOR FAN SUPPORT” and use the mounting screws provided with the outlet box. Most outlet boxes commonly used for the support of lighting fixtures are not acceptable for fan support and may need to be replaced. Consult a qualified electrician if in doubt. Secure the outlet box directly to the building structure. The outlet box and its support must be able to support the moving weight of the fan (at least 35 lbs.). WARNING: To reduce the risk of fire, electric shock, or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12 gauges and/or there is more than one house wire to connect to the two fan lead wires, con…

Text truncated - open the document above for the full version.

Zhongshan Hefeng Electronics Co., Ltd. Agent Authorization Letter 2020-05-19 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (The Hong Kong Standards and Testing Centre Limited) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Print name: Chengchang Fang Title: Chief Technology Signature:

Zhongshan Hefeng Electronics Co., Ltd. Long Term Confidentiality Request Letter Date: 2020-05-19 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT NAME: Fan Light Remote Control / MODEL: RT36A / FCC ID: 2AWB7-RT36A ) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (block diagram/schematics/PCB/BOM/operational description ) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Print name: Chengchang Fang Title: Chief Technology Signature:

1 External Photo FCC ID: 2AWB7-RT36A View of The Product View of The Product 2 View of The Product View of The Product 3 View of The Product View of The Product 4 View of The Product

2AWB7-RT36A

1 Internal Photo FCC ID: 2AWB7-RT36A Inner Circuit Top View Antenna 2 Inner Circuit Bottom View

Test Report Date : 2020-05-16 Page 1 of 21 No. : HMD20050001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Applicant : Zhongshan Hefeng Electronics Co., Ltd. 6/F, Building D, Ou Le Ya Industrial Park, No.19, Jinan Road, Minzhong Town, Zhongshan City, Guangdong Province, China Supplier / Manufacturer : Zhongshan Hefeng Electronics Co., Ltd. 6/F, Building D, Ou Le Ya Industrial Park, No.19, Jinan Road, Minzhong Town, Zhongshan City, Guangdong Province, China Description of Sample(s) : Submitted sample(s) said to be Product: Fan Light Remote Control Brand Name: HF Model No.: RT36A FCC ID: 2AWB7-RT36A Date Samples Received : 2020-04-29 Date Tested : 2020-05-15 to 2020-05-16 Investigation Requested : Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.10:2013 for FCC Certification. Conclusions : The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks : --- _______________________________ LEUNG Kwun Hang, Joey Authorized Signatory Test Report Date : 2020-05-16 Page 2 of 21 No. : HMD20050001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. CONTENT: Cover Page 1 of 21 Content Page 2 of 21 1.0 General Details 1.1 Test Laboratory Page 3 of 21 1.2 Equipment Under Test [EUT] Page 3 of 21 Description of EUT operation 1.3 Date of Order Page 3 of 21 1.4 Submitted Sample(s) Page 3 of 21 1.5 Test Duration Page 3 of 21 1.6 Country of Origin Page 3 of 21 2.0 Technical Details 2.1 Investigations Requested Page 5 of 21 2.2 Test Standards and Results Summary Page 5 of 21 3.0 Test Results 3.1 Emission Page 6-11 of 21 3.2 20dB Bandwidth of Fundamental Emission Page 12-13 of 21 Test Report Date : 2020-05-16 Page 3 of 21 No. : HMD20050001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Appendix A List of Measurement Equipment Page 14 of 21 Appendix B Duty Cycle Correction During 100 msec Page 15-16 of 21 Appendix C Manual Operated Transmitter Transmission Time Page 17 of 21 Appendix D Photograph(s) of Product Page 18-21 of 21 Test Report Date : 2020-05-16 Page 4 of 21 No. : HMD20050001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate, New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: Fan Light Remote Control Manufacturer: Zhongshan Hefeng Electronics Co., Ltd. 6/F, Building D, Ou Le Ya Industrial Park, No.19, Jinan Road, Minzhong Town, Zhongshan City, Guangdong Province, China Brand Name: HF Model Number: RT36A Rating: 3Vd.c. (Two CR2032 batteries in parallel) 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a Fan Light Remote Control. The EUT is operating at 315MHz. Test was conducted under Tx mode. 1.3 Date of Order 2020-04-29 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2020-05-15 to 2020-05-16 1.6 Country of Origin China Test Report Date : 2020-05-16 Page 5 of 21 No. : HMD20050001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.10: 2013 for FCC Certification. This is a manually operated transmitter, Press the button to start sending signals. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.231(a) ANSI C63.10: 2013 N/A 20dB Bandwidth of Fundamental Emission FCC 47CFR 15.231(c) ANSI C63.10: 2013 N/A Radiated Emission…

Text truncated - open the document above for the full version.

1 Test Photo FCC ID: 2AWB7-RT36A Measurement of Radiated Emission Test Set Up (9kHz – 30MHz) Measurement of Radiated Emission Test Set Up (30Hz – 1000MHz) 2 Measurement of Radiated Emission Test Set Up (above 1000MHz)
