2AWCQ-ITB05Bluetooth Output Decoding Upgrade Cable

ITB01 Arc Bluetooth Output Decoding Upgrade Cable Manual Buttons and interfaces 1.Buttons and Functions Bluetooth pairing In the off state, long press the power button for 4 seconds, until the red and blue light flashes Power On In the off state, press and hold the key 2 for 1.5 seconds Power off Long press the key 2 for 2 seconds in the power on state Play / Tentative Click the key 2 Activate voice assistant Double-click on key 2 Call / hang up Click key 2 when calling Volume adjustment Click key 1 to increase volume; click key 3 to decrease volume Track switching Long press key 1 for next song; long press key 3 for previous song Pairing method: keep the device off, long press the power button for 3.5s, the red and blue lights flash Interface： 1.TypeC charging interface 1. 0.78 2Pin 2. mmcx Specification： 1. Charging input: 5V 500ma 2. Audio output: the highest level output is 2.0v 3.SNR: 120dB 4.TNR: 0.001% 5. Battery capacity:> 280mAh 6. Working time: 9 hours 7. Supported formats: SBC; AAC; APTX; APTX-HD 8.BT version: 5.0 Package Include： 1.ITB01 * 1 2.Charging cable * 1 3.Instruction manual * 1 4.Warranty card * 1 5.Storage bag * 1 FCC Warning a、§ 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. b、§ 15.21 Changes or modification warning. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. c、§ 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Differences Description We Ikko audio technology (sz) co., LTD state: Product： Bluetooth Output Decoding Upgrade Cable Model Name： ITB05, ITB01s; ITB03; ITB07; ITB01 Arcs; ITB03s; ITBX; ITX03; ITX05; ITX07 Brand Name： ikko FCC ID： 2AWCQ-ITB05 The electrical circuit design, layout, components used and internal wiring for above models are identical, Only different in model name. Sincerely, Company: Ikko audio technology (sz) co., LTD Title: PM E-mail: [email protected] Name: Edison Du Signature

Page 1 of 7 Report No.: STS2004308 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: ITB05 Photo 1 Photo 2 Photo 3 Page 2 of 7 Report No.: STS2004308 Photo 4 Page 3 of 7 Report No.: STS2004308 Photo 5 Photo 6 Page 4 of 7 Report No.: STS2004308 Photo 7 Photo 8 Page 5 of 7 Report No.: STS2004308 Photo 9 Photo 10 Page 6 of 7 Report No.: STS2004308 Photo 11 Photo 12 Page 7 of 7 Report No.: STS2004308 Photo 13

Label Size:20*7mm The label is engraved on the shell Bluetooth Output Decoding Upgrade Cable Model name: ITB05 FCC ID: 2AWCQ-ITB05

Page 1 of 4 Report No.: STS2004308 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: ITB05 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2004308 Photo 3 Photo 4 BT Antenna Page 3 of 4 Report No.: STS2004308 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2004308 Photo 7

FCC ID : 2AWCQ-ITB05 RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID : 2AWCQ-ITB05 Maximum measured transmitter power. BT5.0+EDR The Worst Case Mode 2402-2480MHz Detector PEAK GFSK 2.4±1dBm π/4-DQPSK 5.1±1dBm 8DPSK 5.6±1dBm Remark: The worst case gain of the antenna is 0Bi. 0Bi logarithmic terms convert to numeric result is nearly 1 Mode Frequen cy (GHz) Maxinum Peak Conducted Output Power (dBm) Tune up Power (dBm) Tune up Power (mW) Result Limit GFSK 2.402 3.15 3.4 2.188 0.678 3 π/4-DQPSK 2.402 6.07 6.1 4.074 1.263 3 8DPSK 2.402 6.51 6.6 4.571 1.417 3 Threshold at which no SAR required is 1.417 ≤ 3.0for 1-g SAR, Separation distance is 5mm.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2004308W02 Issued for Ikko audio technology (sz) co., LTD 70, 2F, Block B, Digital Building of Garden City No.1079, Nan Hai Road, Nanshan District, Shenzhen, China Product Name: Bluetooth Output Decoding Upgrade Cable Brand Name: ikko Model Name: ITB05 Series Model: ITB01s; ITB03; ITB07; ITB01 Arcs; ITB03s; ITBX; ITX03; ITX05; ITX07 FCC ID: 2AWCQ-ITB05 Test Standard: FCC Part 15.247 S T L A B S Page 2 of74Report No.: STS2004308W02 TEST RESULT CERTIFICATION Applicant’s Name ................... : Ikko audio technology (sz) co., LTD Address .................................. : 70, 2F, Block B, Digital Building of Garden City No.1079, Nan Hai Road, Nanshan District, Shenzhen, China Manufacture's Name .............. : Ikko audio technology (sz) co., LTD Address .................................. : 70, 2F, Block B, Digital Building of Garden City No.1079, Nan Hai Road, Nanshan District, Shenzhen, China Product Description Product Name ........................ : Bluetooth Output Decoding Upgrade Cable Brand Name ........................... : ikko Model Name ........................... : ITB05 SeriesModel ........................... : ITB01s; ITB03; ITB07; ITB01 Arcs; ITB03s; ITBX; ITX03; ITX05; ITX07 Test Standards ....................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................... : Date of receipt of test item ......... : 29 Apr. 2020 Date (s) of performance of tests : 29 Apr. 2020 ~ 09 May 2020 Date of Issue ............................. : 11 May 2020 Test Result ................................. : Pass Testing Engineer : (ChrisChen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of74Report No.: STS2004308W02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.6 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 13 2.7 EQUIPMENTS LIST 14 3.EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 4.1 LIMIT 31 4.2 TEST PROCEDURE 31 4.3 TEST SETUP 31 4.4 EUT OPERATION CONDITIONS 31 4.5 TEST RESULTS 32 5. NUMBER OF HOPPING CHANNEL 47 5.1 LIMIT 47 5.2 TEST PROCEDURE 47 5.3 TEST SETUP 47 5.4 EUT OPERATION CONDITIONS 47 5.5 TEST RESULTS 48 6. AVERAGE TIME OF OCCUPANCY 49 6.1 LIMIT 49 6.2 TEST PROCEDURE 49 6.3 TEST SETUP 49 6.4 EUT OPERATION CONDITIONS 49 6.5 TEST RESULTS 50 7. HOPPING CHANNEL SEPARATION MEASUREMEN 56 Page 4 of74Report No.: STS2004308W02 Table of Contents Page 7.1 LIMIT 56 7.2 TEST PROCEDURE 56 7.3 TEST SETUP 56 7.4 EUT OPERATION CONDITIONS 56 7.5 TEST RESULTS 57 8. BANDWIDTH TEST 63 8.1 LIMIT 63 8.2 TEST PROCEDURE 63 8.3 TEST SETUP 63 8.4 EUT OPERATION CONDITIONS 63 8.5 TEST RESULTS 64 9. OUTPUT POWER TEST 70 9.1 LIMIT 70 9.2 TEST PROCEDURE 70 9.3 TEST SETUP 71 9.4 EUT OPERATION CONDITIONS 71 9.5 TEST RESULTS 72 10. ANTENNA REQUIREMENT 73 10.1 STANDARD REQUIREMENT 73 10.2 EUT ANTENNA 73 Page 5 of74Report No.: STS2004308W02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 11 May 2020 STS2004308W02 ALL Initial Issue Page 6 of74Report No.: STS2004308W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(iii) Number of Hopping Frequency PASS -- 15.247(a)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2)All tests are according to ANSI C63.10-2013. Page 7 of74Report No.: STS2004308W02 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U,where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±6.7dB 4 All emissions, radiated1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±4.43dB 7 Conducted Emissi…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: STS2004308 DSS Setup photo Model name: ITB05 DSS conduction DSS radiation L Page 2 of 2 Report No.: STS2004308 DSS radiation H
