2AWG2-WF82LED wireless wave-activate light bars

≥ ≤ ≥ ≤ Wave sensor LED Light bar 17.8W x 0.87 Ø in / 451W x 22.1 Ø mm Double-side, foam adhesive tape Rechargeable power pack 39 in / 100 cm USB cable 0.47 in / 12 mm mounting screws 0.79 in / 20 mm mounting screws 1. 1 in / 28 mm anchors Mounting clips Set the switch to position A. The unit will unit detects the wave signals. Set the switch to channel 1 (position B) or channel 2 (position C). Set the switch of other units to be linked to the same channel. Linked units set to the same channel will turn linked units detects the wave signals. (Fig. 1) Westinghouse warrants that this product (the "Product") will be free from defects in material and workmanship for a period of one (1) year from the date of purchase (the "Warranty Period"). For defects reported during the Warranty Period, Westinghouse will, at its discretion, and subject to Westinghouse’s product support analysis, either repair or replace defective Product. Replacement parts and products will be new or serviceably used, comparable in function and performance to the original part and warranted for the remainder of the original Warranty Period. Westinghouse’s LIABILITY HEREUNDER IS EXPRESSLY LIMITED TO REPLACEMENT OR REPAIR OF THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED BY LAW, WESTINGHOUSE SHALL NOT BE LIABLE TO ANY PURCHASER OF THE PRODUCT OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, CONSEQUENTIAL OR EXEMPLARY DAM- AGES, INCLUDING BUT NOT LIMITED TO, LOST PROFITS, PROPERTY DAMAGE OR PERSONAL INJURY RELATED IN ANY WAY TO THE PRODUCT HOWSOEVER CAUSED, EVEN IF WESTINGHOUSE HAD KNOWLEDGE OF THE POSSIBILITY OF SUCH DAMAGES. THE WARRANTIES SET FORTH HEREIN ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUD- ING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABIL- ITY AND FITNESS FOR A PARTICULAR PURPOSE, AND THOSE ARISING FROM COURSE OF DEALING, USAGE OR TRADE PRACTICE. IN THE EVENT THAT ANY APPLICABLE LAWS IMPOSE WARRANTIES, CONDITIONS OR OBLIGATIONS THAT CANNOT BE EXCLUDED OR MODIFIED, THIS PARAGRAPH SHALL APPLY TO THE GREATEST EXTENT ALLOWED BY SUCH LAWS. This Limited Warranty is made solely for the benefit of the original purchaser of the Product from Westinghouse or its approved reseller or distributor and is not assignable or transferable. To make a warranty claim, the purchaser must: (1) request and obtain a return merchandise authorization ("RMA") number and return location information (the "Return Location") from Westinghouse Support by emailing [email protected] or by calling 1-833-990-2624; and (2) send the Product, including RMA number and receipt to the Return Location provided. DO NOT SEND IN PRODUCT WITHOUT FIRST OBTAINING AN RMA FROM WESTING- HOUSE SUPPORT. THE ORIGINAL PURCHASER IS RESPONSIBLE (AND MUST PREPAY) ALL PACKAGING AND TRANSPORTATION COSTS TO SHIP PRODUCTS FOR WARRANTY SERVICE. NOTWITHSTANDING THE ABOVE, THIS LIMITED WAR- RANTY IS VOID AND DOES NOT APPLY TO PRODUCTS THAT: (a) were misused, mishandled, subjected to abuse or careless handling, accident, improperly stored, or operated under conditions of extreme voltage, temperature, shock, or vibration installed, operated or maintained; (c) are/were modified without the express written consent of Westinghouse; (d) have been disassembled, altered or repaired by any- one other than Westinghouse; (e) had defects which were reported after the Warran- ty Period. THIS LIMITED WARRANTY DOES NOT COVER: (1) normal wear and tear; Westinghouse serial and/or lot number is missing, altered, or defaced. [email protected] (North America) 1-833-990-2624 M-F 9 AM to 5 PM Eastern Standard Time Camelion North America Inc. 2572 Daniel-Johnson Boulevard | 2 nd Floor Laval, QC, H7T 2R3 Canada Made in China D10040 Westinghouse WF82 10008 1:1 June 15, 2020 Instruction manual 3pk LED Wireless Wave Actived Light Bar Instruction Manual - English/French For more information contact: [email protected] , WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are trademarks of Westinghouse Electric Corporation. Used under license by Camelion Battery Co., Ltd. All Rights Reserved. Before installation, make sure the surface you intend to mount the product on is free of moisture, oil, grease, dust and dirt to ensure proper adhesion. Test painted surfaces. Adhesive tape may damage surface when removing. DOUBLE-SIDED FOAM ADHESIVE TAPE: Mark the desired area Ù want to install. Remove the protective paper liner from one side of the tape and secure to the back of the mounting clip. Then remove the protective paper liner from the other side of the tape and se- cure to where you want to install. DRYWALL SURFACE MOUNTING ANCHOR SCREW: Place the mounting clip over the desired mounting location and mark the center of the holes to be drilled. Drill two pilot holes anchors. Place the mounting plate over the holes and screw in the WOOD SURFACE MOUNTING SCREW: Place the mounting plate over the desired mounting location and mark the center of the holes to be drilled. Then place the mounting clip over the marks Next attach the power pack to the LED light bar. Turn the power pack counter-clockwise to lock up the light bar. Insert the LED light bar with the power pack into the mounting clips. Your LED light bar is ready to be used. Plug one end of the USB cable into the power pack’s output port and the other end of the cable to the device which needs to be charged. When the device is fully charged, disconnect the USB cable from the device and the power pack. Re-connect the power pack to the light bar and turn the power pack counter-clockwise to locked position. Wave hand below the sensor once (1) to turn ON the LED light bar. Wave again below the sensor to turn OFF the LED light bar. When the light is on, hold your hand under the sensor to dim the light. Lower your hand when the desired brightness is attained. STEPLESS DIMMING: Dimming cycle will continuously dim from full brightness (100%) to low (10%) until your hand is moved…

Text truncated - open the document above for the full version.

2020-05-28 Federal Communications Commission 445 12th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Camelion North America Inc. FCC ID: 2AWG2-WF82 To Whom It May Concern: We, Camelion North America Inc. hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number 2AWG2-WF82 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 2020-05-19. The Limited Agency Agreement expires on 2021-05-19, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Sign: Claudia Lai Company name: Camelion North America Inc. Title: Director of Brand & Product Management Date: 2020-05-28

Attention: Application Examiner RE: Request for Confidentiality Applicant: Camelion North America Inc. FCC ID: 2AWG2-WF82 To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request is hereby submitted by Camelion North America Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block Diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: Camelion North America Inc. has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] [For FCC certification; delete for TCB certification: The fee for confidentiality has been submitted along with the fee for certification.] If you have questions or need further information, please contact the undersigned. Sincerely, Sign: Email: [email protected] Title: Director of Brand and Product Management Tel: 450-430-2624

2020-05-28 To Whom It May Concern Statement of differences between WF82 and IF82 Models WF82, IF82 are declared identical in terms of electrical and mechanical design. Their difference lies in the model name, which apply for different trademark Camelion: IF82 Westinghouse: WF82 Sign: Claudia Lai Camelion North America Inc. Email: [email protected] Title: Director of Brand and Product Management Tel: 450-430-2624

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Job No.: 200325125GZU-002 Page: 1 of 1 FCC ID: 2AWG2-WF82 RF Exposure Compliance Requirement Calculation formula： E (V/m) = (30*P*G) 0.5/d E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between EUT and antenna (m) Remark: E(V/m)=10 X (dBUV/m) /20 ×10 -6 P=(E*d) 2 /30G in the formula above, d=3m, field strength= 93dBuV/m(max describe by client), G=1.58 so P=0.38mW In KDB 447498 D01 v06: 4.3.1 Standalone SAR test exclusion considerations: The SAR Test Exclusion Threshold is calculated from: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR. The worst case test separation distance is 5mm. The product belongs to standalone portable device base the FCC rule part 2.1091&2.1093. The transmission frequencies of the device are between 100 MHz and 6 GHz. The ERP and SAR Test Exclusion Threshold (mW) are listed below: Transmit frequency (MHz) Output power (mW) SAR Test Exclusion Threshold (mW) 2478 0.38 9.53

Camelion North America Inc. TEST REPORT SCOPE OF WORK EMC TESTING–WF82, IF82 REPORT NUMBER 200325125GZU-001 ISSUE DATE [REVISED DATE] 17-June-2020 [---------------------] PAGES 26 DOCUMENT CONTROL NUMBER FCC Part 15.249-d © 2017 INTERTEK TEST REPORT Block E, No.7-2 Guang Dong Software Science Park, Caipin Road, Guangzhou Science City, GETDD Guangzhou, China Telephone: 86-20-8213 9688 Facsimile: 86-20-3205 7538 www.intertek.com This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Version: 10 June 2019 Page 2 of 26 FCC Part 15.249-d Applicant Name & Address : Camelion North America Inc. 2572 Daniel-Johnson blvd, Suite 206-207, Laval, Quebec, Canada H7T 2R3 Manufacturing Site : Same as applicant Intertek Report No: FCC ID: 200325125GZU-001 2AWG2- WF82 Test standards 47 CFR PART 15 Subpart C: 2019 section 15.249 Sample Description Product : LED Wireless Wave Activated Light Bar Models No. : WF82, IF82 Electrical Rating : Powered by 3.7Vdc (recharged batteries) Chargedby 5Vdc(adaptor) Remark: The device will be sold without adaptor When the device was charging, it cannot work normally Serial No. Not Labeled Date Received : 25 March2020 Date Test Conducted : 25 March 2020-25 May 2020 Prepared and Checked By Daniel He Project Engineer Intertek Guangzhou Approved By: Helen Ma Team Leader Intertek Guangzhou TEST REPORT Intertek Report: No: 200325125GZU-001 Version: 10 June 2019 Page 3 of 26 FCC Part 15.249-d CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION ............................................................................................. 5 2.1 P RODUCT DESCRIPTION ........................................................................................................ 5 2.2 R ELATED SUBMITTAL(S) GRANTS ........................................................................................... 6 2.3 T EST METHODOLOGY .......................................................................................................... 6 2.4 T EST FACILITY ..................................................................................................................... 6 3.0 SYSTEM TEST CONFIGURATION ................................................................................. 6 3.1 J USTIFICATION .................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE ................................................................................................. 7 3.3 S PECIAL ACCESSORIES .......................................................................................................... 7 3.4 M EASUREMENT UNCERTAINTY .............................................................................................. 8 3.5 E QUIPMENT MODIFICATION ................................................................................................. 8 3.6 S UPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 9 4.0 MEASUREMENT RESULTS ........................................................................................ 10 4.1 A NTENNA REQUIREMENT ................................................................................................... 10 4.2 O CCUPIED BANDWIDTH ..................................................................................................... 11 4.3 R ADIATED EMISSION AND BAND EDGES ................................................................................ 14 5.0 TEST EQUIPMENT LIST ............................................................................................. 26 TEST REPORT Intertek Report: No: 200325125GZU-001 Version: 10 June 2019 Page 4 of 26 FCC Part 15.249-d 1.0 TEST RESULT SUMMARY Test ItemTest RequirementTest Method Result Antenna Requirement FCC PART 15 C Section 15.203 FCC PART 15 C Section 15.203 PASS Occupied Bandwidth FCC PART 15 C section 15.215(c) ANSI C63.10: Clause 6.9 PASS Radiated Emission FCC PART 15 C section 15.249 (a), (d) ANSI C63.10: Clause 6.4, 6.5 & 6.6 PASS Band Edges Measurement FCC PART 15 C section 15.249 (d) ANSI C63.10: Clause 6.10 PASS Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency. ANSI C63.10: the detail version is ANSI C63.10:2013 in the whole report. Models WF82, IF82 are declared identical in terms of electrical and mechanical design. Their difference lies in the model name, which apply for different trademark Camelion: IF82 Westinghouse: WF82 So model WF82 was selected for full test. TEST REPORT Intertek Report: No: 200325125GZU…

Text truncated - open the document above for the full version.

1. Radiated Emissions in Restricted Bands: Below 1GHz: Above 1GHz:
