2AWGP24G-01MODEL2.4G Wireless Module

1 2.4G Wireless Module USER MANUAL 2.4G-01 MODEL Summary 2.4G wireless key control module works in fitness equipment or other equipment requiring wireless control, with strong anti-interference and automatic matching function. The module is divided into transmitting and receiving, which can realize the function of two switches, and has the function of pairing and electric quantity indicating. TX function overview 1. When pairing, press the keys 1 and 2 at the same time, and enter the pairing mode for 30 seconds, until the LED flashes normally, then the receiver is powered on, and the transmitter is close to the receiver, if pairing is successful. If the pairing is not successful within 60 seconds, exit the broadcast pairing function. 2. When the battery voltage is lower than 2.7V, the transmitter sends the identification code to Rx. When the battery voltage is lower than 2.4V, the LED at the transmitter flashes every second. TX technical parameters Supply voltage DC2.5V~3.3V 2 Working peak current 18MA Standby current 5uA working temperature -20~80°C Pairing frequency 2.4G Normal operating frequency 2.4G modulation mode GFSK M odule size TX13*25MM FCC regulatory compliance statement §15.19 Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. §15.21 Information to user Warning: changes or modifications not expressly appr oved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure compliance statement This Module complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Labelling Instruction for Host Product Integrator 3 Please notice that if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: contain FCC ID: 2AWGP24G-01MODEL ” any similar wording that expresses the same meaning may be used. § 15.19 Labelling requirements shall be complied on end user device. Labelling rules for special device, please refer to §2.925, § 15.19 (a)(5) and relevant KDB publications. For E-label, please refer to §2.935. Installation Notice to Host Product Manufacturer The OEM integrator is responsible for ensuring that the end-user has no manual instruction to remove or install module. The module is limited to installation in mobile application, a separate approval is required for all other operating configurations, including portable configurations with respect to §2.1093 and difference antenna configurations. A ntenna Change Notice to Host manufacturer If you desire to increase antenna gain and either ch ange antenna type or use same antenna type certified, a Class II permissive change application is required to be filed by us, or you (host manufacturer) can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application. F CC other Parts, Part 15B Compliance Requirements for Host product manufacturer This modular transmitter is only FCC authorized for the specific rule parts listed on our grant, host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. Host manufacturer in any case shall ensure host product which is installed and operating with the module is in compliant with Part 15B requirements. Please note that For a Class B or Class A digital device or peripheral, the instructions furnished the user manual of the end-user product shall include statement set out in §15.105 Information to the user or such similar statement and place it in a prominent location in the text of host product manual. Original texts as following: For Class B Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. For Class A Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which ca…

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name SHENZHEN JIPULSE TECHNOLOGY CO., LTD Address 201, No. 20, Xijing Road, Gushu community, Xixiang street, Bao'an District, Shenzhen 518000, China Grantee Code 2AWGP FCC ID 2AWGP24G-01MODEL Authorized Contact Name Bruce Yang Contact Email [email protected] Contact Phone +8613510161626 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to en sure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillanc e of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: Print Name: Bruce Yang Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

SHENZHEN JIPULSE TECHNOLOGY CO., LTD Date: 2020-5-20 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: 2AWGP24G-01MODEL To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch and Keny Xu in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with SHENZHEN JIPULSE TECHNOLOGY CO., LTD This authorization is valid until further written notice from the applicant. Print Name: Bruce Yang Title: Manager Signature: On behalf of Company: SHENZHEN JIPULSE TECHNOLOGY CO., LTD Telephone: +8613510161626 E-mail: [email protected]

SHENZHEN JIPULSE TECHNOLOGY CO., LTD TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: 2AWGP24G-01MODEL LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Print Name: Bruce Yang Title: Manager Signature: On behalf of Company: SHENZHEN JIPULSE TECHNOLOGY CO., LTD Telephone: +8613510161626 E-mail: [email protected]

SHENZHEN JIPULSE TECHNOLOGY CO., LTD Cover Letter-Modular Approval FCC ID: 2AWGP24G-01MODEL Date: 2020-5-20 Gentlemen: There’s an 2.4G-01MODEL that would like to have your authorization as a modular approval. The specific product as below, 2.4G-01MODELwith its designed features and specified description, meets special requirements for Full modular approval on FCC KDB996369 by cross-reference list below. Company SHENZHEN JIPULSE TECHNOLOGY CO., LTD Model Name 2.4G-01model Model Number 2.4G-01model FCC ID 2AWGP24G-01MODEL Requirement of FCC KDB996369 Comply（Y/N） 1.The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo. 2.The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. Please see the Schematic Diagram. 3.The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4.The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the test report. 5.The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test board, Please see test report and setup photo SHENZHEN JIPULSE TECHNOLOGY CO., LTD 6.The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2AWGP24G-01MODEL” or “Contains FCC ID: 2AWGP24G-01MODEL” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7.The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8.The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Thank you. Y SHENZHEN JIPULSE TECHNOLOGY CO., LTD Sincerely, Print Name: Bruce Yang Title: Manager Signature: On behalf of Company: SHENZHEN JIPULSE TECHNOLOGY CO., LTD Telephone: +8613510161626 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 External Photos for SZEM2005003546CR FCC ID: 2AWGP24G-01MODEL SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 EUT Constructional Details Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3

Product Label FCC ID: 2AWGP24G-01MODEL 58.00mm

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Internal Photos for SZEM2005003546CR FCC ID: 2AWGP24G-01MODEL SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 EUT Constructional Details Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354603 Page: 1 of 7 Keny Xu EMC Laboratory Manager geRF Exposure Evaluation Report Application No.: SZEM2005003546CR Applicant: SHENZHEN JIPUSLE TECHNOLOGY CO., LTD Address of Applicant: 201, No. 20, Gushu Xijing Road, Gushu community, Xixiang street, Bao’an District, Shenzhen 518000 China Manufacturer: SHENZHEN JIPUSLE TECHNOLOGY CO., LTD Address of Manufacturer: 201, No. 20, Gushu Xijing Road, Gushu community, Xixiang street, Bao’an District, Shenzhen 518000 China Factory: SHENZHEN JIPUSLE TECHNOLOGY CO., LTD Address of Factory: 201, No. 20, Gushu Xijing Road, Gushu community, Xixiang street, Bao’an District, Shenzhen 518000 China Equipment Under Test (EUT): Product Name: 2.4G Wireless Module Model No.: 2.4G-01, SPD200 ♣ ♣ ♣♣ ♣ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: KINGPULSE FCC ID: 2AWGP24G-01MODEL Standards: 47 CFR PART 1, Subpart I, Section 1.1307 47 CFR PART 1, Subpart I, Section 1.1310 47 CRF PART 2, Subpart J, Section 2.1091 KDB 447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2020-05-08 Date of Test: 2020-05-14 to 2020-07-24 Date of Issue 2020-08-27 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354603 Page: 2 of 7 1 Version Revision Record Version Chapter Date Modifier Remark 01 2020-08-27 Original Authorized for issue by: Damon Su /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354603 Page: 3 of 7 2 Contents Page 1 COVER PAGE ........................................................................................................................................ 1 2 VERSION ................................................................................................................................................ 2 3 CONTENTS ............................................................................................................................................ 3 4 GENERAL INFORMATION ..................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ............................................................................................................. 4 4.2 TEST LOCATION .................................................................................................................................... 5 4.3 TEST FACILITY ...................................................................................................................................... 5 4.4 DEVIATION FROM STANDARDS ................................................................................................................. 5 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................ 5 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER .............................................................................. 5 5 RF EXPOSURE EVALUATION ............................................................................................................... 6 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ............................................................................................. 6 5.1.1 Limits .......................................................................................................................................... 6 5.1.2 Test Procedure ........................................................................................................................... 6 5.1.3 EUT RF Exposure Evaluation ...................................................................................................... 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354603 Page: 4 of 7 3 General Information 3.1 General Description of EUT Power Supply: DC 3V. Operation Frequency: 2405-2477MHz Modulation Type: GFSK Number of Channels: 52 Antenna Type: PCB Antenna Antenna Gain: 0dBi Frequency List Channel No. Frequency Channel No. Frequency Channel No. Frequency Channel No. Frequency 1 2405 16 2429 34 2453 52 2477 2 2406 17 2430 35 2454 / / 3 2407 18 2431 36 2455 / / 4 2409 19 2433 37 2457 5 2410 20 2434 38 2458 6 2411 21 2435 39 2459 7 2413 22 2437 40 2461 8 2414 23 2438 41 2462 9 2415 24 2439 42 2463 10 2417 25 2441 43 2465 11 2418 26 2442 44 2466 12 2419 27 2443 45 2467 13 2421 28 2445 46 2469 14 2422 29 2446 47 2470 15 2423 30 2447 48 2471 16 2425 31 2449 49 2473 17 2426 32 2450 50 2474 18 2427 33 2451 51 2475 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354603 Page: 5 of 7 3.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. 3.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Tech…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354602 Page: 1 of 45 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM2005003546CR Applicant: SHENZHEN JIPUSLE TECHNOLOGY CO., LTD Address of Applicant: 201, No. 20, Gushu Xijing Road, Gushu community, Xixiang street, Bao'an District, Shenzhen 518000 China Manufacturer: SHENZHEN JIPUSLE TECHNOLOGY CO., LTD Address of Manufacturer: 201, No. 20, Gushu Xijing Road, Gushu community, Xixiang street, Bao'an District, Shenzhen 518000 China Factory: SHENZHEN JIPUSLE TECHNOLOGY CO., LTD Address of Factory: 201, No. 20, Gushu Xijing Road, Gushu community, Xixiang street, Bao'an District, Shenzhen 518000 China Equipment Under Test (EUT): EUT Name: 2.4G Wireless Module Model No.: 2.4G-01, SPD200 ♣ ♣ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: KINGPULSE FCC ID: 2AWGP24G-01MODEL Standard(s) : 47 CFR Part 15, Subpart C 15.249 Date of Receipt: 2020-05-08 Date of Test: 2020-05-14 to 2020-07-24 Date of Issue: 2020-08-01 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354602 Page: 2 of 45 Revision Record Version Chapter Date Modifier Remark 01 2020-08-01 Original Authorized for issue by: Damon Su /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354602 Page: 3 of 45 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.249 N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass 20dB Bandwidth 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Field Strength of the Fundamental Signal (15.249(a)) 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.5&6.6 47 CFR Part 15, Subpart C 15.249(a) Pass Restricted Band Around Fundamental Frequency 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.4&6.5&6.6 47 CFR Part 15, Subpart C 15.205 & 15.249(d) & 15.209 Pass Radiated Emissions 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.4&6.5&6.6 47 CFR Part 15, Subpart C 15.209 & 15.249 (a),(d) Pass Declaration of EUT Family Grouping: Model No.: 2.4G-01, SPD200 Only the model 2.4G-01 was tested, since according to the declaration from the applicant, the electrical circuit design, layout, components used, internal wiring and functions were identical for the above models, with only difference on model No. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500354602 Page: 4 of 45 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 5 4.1 DETAILS OF E.U.T. ......................................................................................................................... 5 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 5 4.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 6 4.4 TEST LOCATION ............................................................................................................................. 7 4.5 TEST FACILITY ............................................................................................................................... 7 4.6 DEVIATION FROM STANDARDS ......................................................................................................... 7 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 7 5 EQUIPMENT LIST ............................................................................................................................... 8 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................11 6.1 ANTENNA REQUIREMENT ................................................................................................................11 6.1.1 Test Requirement: ..................................................................................................................11 6.1.2 Conclusion ..............................................................................................................................11 7 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................12 7.1 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ........................................................12 7.1.1 E.U.T. Operation .....................................................................................................................12 7.1.2 Measurement Procedure and Data .........................................................................................12 7.2 20DB BANDWIDTH .........................................................................................................................15 7.2.1 E.U.T. Operation .......................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 4 Setup Photos for SZEM2005003546CR FCC ID: 2AWGP24G-01MODEL SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 4 1 Photographs 1.1 Conducted Emissions at AC Power Line (150kHz-30MHz) Test Setup SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 4 1.2 Restricted Band Around Fundamental Frequency Test Setup SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 4 1.3 Radiated Emissions Test Setup
