User Manual rPAD Model: RM-TFR8 Table of Contents Getting started .................................................................................................................................... 1 Device layout ............................................................................................................................... 1 Buttons ......................................................................................................................................... 1 Technical Specification ................................................................................................................ 2 Package contents ........................................................................................................................ 3 Power on your device .................................................................................................................. 3 Power off your device .................................................................................................................. 3 Card Reading ............................................................................................................................... 4 Basics ................................................................................................................................................. 5 Home Screen Overview ............................................................................................................... 5 Status & notifications ................................................................................................................... 6 Quick settings .............................................................................................................................. 7 Profiles .................................................................................................................................. 7 Add & switch users ................................................................................................................ 7 Change or delete users ......................................................................................................... 7 Connect & transfer .............................................................................................................................. 8 Wi-Fi networks ............................................................................................................................. 8 Turn Wi-Fi power on/off ......................................................................................................... 8 Connect to networks ............................................................................................................. 8 Micro-USB cables ........................................................................................................................ 8 Bluetooth ...................................................................................................................................... 9 Turn Bluetooth power on/off .................................................................................................. 9 Connect devices .................................................................................................................... 9 Manage devices .................................................................................................................... 9 Let devices find your device .................................................................................................. 9 Data use ..................................................................................................................................... 10 Near Field Communication (NFC) Technology ........................................................................... 10 Airplane mode .............................................................................................................................11 Settings ............................................................................................................................................. 12 Wi-Fi Settings ............................................................................................................................. 12 Bluetooth Settings ...................................................................................................................... 12 Data Usage Settings .................................................................................................................. 12 More Settings ............................................................................................................................. 12 NFC Settings .............................................................................................................................. 13 Storage Settings ........................................................................................................................ 13 Application Manager .................................................................................................................. 14 Location Settings ....................................................................................................................... 14 Backup & reset ........................................................................................................................... 14 Backup and Restore ............................................................................................................ 14 Factory Data Reset ............................................................................................................. 14 Date & Time Settings ................................................................................................................. 15 About Phone .............................................................................................................................. 15 Copyright Information..........................................................…

Text truncated - open the document above for the full version.

Remark Holdings, Inc. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.06.08 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, Remark Holdings, Inc. hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature Name: Ming-Yang Tang

Differences Description We Remark Holdings, Inc. state: Product： rPAD Model Name： RM-TFR8, RM-TFR8-XXXX Trade Name: FCC ID: 2AWI7RMTFR8 The electrical circuit design, layout, components used and internal wiring for above models are identical, only different in different software versions and configurations. XXXX:Represents different software versions and configurations The first X represents A~Z, which means different operation configuration modes. a. stand-alone version that can be used alone, b. multi-machine version that needs to be used in combination. The last three XXX represents 0-9, different numbers represent different system software versions, and different software version does not produce a difference between EMI and RF. Signatory Date 2020-06-08 Signature Name: Ming-Yang Tang Title: Product Manager Company: Remark Holdings, Inc. Address: 800 South Commerce Street - Las Vegas NV 89109

Remark Holdings, Inc. TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.06.08 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (rPAD / RM-TFR8, RM-TFR8-XXXX /FCC ID: 2AWI7RMTFR8) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Ming-Yang Tang Signature:

Page 1 of 5 Report No.: STS2005006 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: RM-TFR8 Photo 1 Photo 2 Page 2 of 5 Report No.: STS2005006 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2005006 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2005006 Photo 7 Photo 8 Photo 9 Page 5 of 5 Report No.: STS2005006

SN 60.00 mm 40.00 mm Model: RM-TFR8 Rating: DC 12V 2A rPAD MADE IN CHINA 12-2018 FCC ID: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interfer ence that may cause undesired operation. MADE IN CHINA FCC ID: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interfer ence that may cause undesired operation. Model: RM-TFR8 Rating: DC 12V 2A rPAD 2AWI7RMTFR8 2AWI7RMTFR8 Date PVC paster

Page 1 of 8 Report No.: STS2005006 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: RM-TFR8 Photo 1 Photo 2 NFC Antenna BT/WIFI Antenna Page 2 of 8 Report No.: STS2005006 Photo 3 Photo 4 Page 3 of 8 Report No.: STS2005006 Photo 5 Photo 6 Page 4 of 8 Report No.: STS2005006 Photo 7 Photo 8 Page 5 of 8 Report No.: STS2005006 Photo 9 Photo 10 Page 6 of 8 Report No.: STS2005006 Photo 11 Photo 12 Page 7 of 8 Report No.: STS2005006 Photo 13 Photo 14 Page 8 of 8 Report No.: STS2005006 Photo 15 Photo 16

RF Exposure Report FCC ID: 2AWI7RMTFR8 RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) F= Frequency in MHz Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. EUT Operation condition EUT was enabled to transmit and receive at lowest, middle and highest channels. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. BR + EDR Mode 2402-2480MHz Detector PEAK GFSK 5±1dBm π/4-DQPSK 5±1dBm 8DPSK 5±1dBm ANT Gain (G) Antenna gain : 3.4dBi (gain of antenna in linear scale=2.188) Protocol ANT Gain ( gain of antenna in linear scale ) Channel Frequency ( MHz ) Output Power to Antenna ( dBm ) Output Power to Antenna ( mW ) Power Density ( mW / cm ² ) Limit ( mW / cm ² ) GFSK 2 . 188 2402 1 π / 4 - DQPSK 2 . 188 2402 1 8 DPSK 2 . 188 2402 1 6 3 . 9811 0 . 00173 6 3 . 9811 0 . 00173 5 3 . 1623 0 . 00138 BLE Mode 2402-2480MHz Detector PEAK GFSK 4±1dBm ANT Gain (G) Antenna gain : 3.4dBi (gain of antenna in linear scale=2.188) Protocol ANT Gain ( gain of antenna in linear scale ) Channel Frequency ( MHz ) Output Power to Antenna ( dBm ) Output Power to Antenna ( mW ) Power Density ( mW / cm ² ) Limit ( mW / cm ² ) GFSK 2 . 188 2440 1 5 3 . 1623 0 . 00138 2.4G WIFI Mode 802.11b/g/n20/n40:2412-2462MHz Detector PEAK 802.11b 14±1dBm 802.11g 17±1dBm 802.11n20 16±1dBm 802.11n40 16±1dBm ANT Gain (G) Antenna gain : 3.4dBi (gain of antenna in linear scale=2.188) Protocol ANT Gain ( gain of antenna in linear scale ) Channel Frequency ( MHz ) Output Power to Antenna ( dBm ) Output Power to Antenna ( mW ) Power Density ( mW / cm ² ) Limit ( mW / cm ² ) 802 . 11 b 2 . 188 2437 1 802 . 11 g 2 . 188 2437 1 802 . 11 n 20 2 . 188 2437 1 802 . 11 n 40 2 . 188 2437 1 18 63 . 0957 0 . 02748 18 63 . 0957 0 . 02748 17 50 . 1187 0 . 02183 17 50 . 1187 0 . 02183 Note: The Bluetooth and WLAN shares the same module and antenna, they can not transmit at the same time.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2005006W04 Issued for Remark Holdings, Inc. 800 South Commerce Street - Las Vegas NV 89109 Product Name: rPAD Brand Name: Model Name: RM-TFR8 Series Model: RM-TFR8-XXXX FCC ID: 2AWI7RMTFR8 Test Standard: FCC Part 15.225 S T L A B S Page 2 of 30 Report No.: STS2005006W04 TEST REPORT CERTIFICATION Applicant’s Name ................. : Remark Holdings, Inc. Address .................................. : 800 South Commerce Street - Las Vegas NV 89109 Manufacture's Name ............ : Shanghai DianZe Intelligent Technology Co., Ltd. Address .................................. : Room 401, Building A, No.1272 Tongpu Road, Putuo District, Shanghai, P.R.C Product Description Product Name ........................ : rPAD Brand Name ......................... : Model Name........................... : RM-TFR8 Series Model .......................... : RM-TFR8-XXXX Test Standards ..................... : FCC Part15.225 Test Procedure....................: ANSI C63.10: 2013, ANSI C63.4: 2014 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, thidocument only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 11 May 2020 Date (s) of performance of tests.............. : 11 May 2020 ~ 10 June 2020 Date of Issue ........................................... : 11 June 2020 Test Result ............................................... : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 30 Report No.: STS2005006W04 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 2.2 DESCRIPTION OF THE TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 12 3.4 EUT OPERATING CONDITIONS 12 3.5 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 15 4.1 RADIATED EMISSION LIMITS 15 4.2 TEST PROCEDURE 17 4.3 TEST SETUP 18 4.4 EUT OPERATING CONDITIONS 18 5. FREQUENCY TOLERANCE 25 5.1 REQUIREMENT 25 5.2 TEST PROCEDURE 25 5.3 TEST SETUP 25 5.4 EUT OPERATION CONDITIONS 25 5.5 TEST RESULTS 26 6. 20DB BANDWIDTH 27 6.1 APPLIED PROCEDURES / LIMIT 27 6.2 TEST PROCEDURE 27 6.3 TEST SETUP 27 6.4 EUT OPERATION CONDITIONS 27 6.5 TEST RESULTS 28 Page 4 of 30 Report No.: STS2005006W04 TABLE OF CONTENTS Page 7. ANTENNA REQUIREMENT 29 7.1 STANDARD REQUIREMENT 29 7.2 EUT ANTENNA 29 APPENDIX 1- PHOTOS OF TEST SETUP 30 Page 5 of 30 Report No.: STS2005006W04 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 15.225 , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.209 15.225(a)(b)(c)(d) Radiated Emission PASS -- 15.225(e) Frequency Tolerance PASS -- 15.203 Antenna Requirement PASS -- 15.215 20dB Bandwidth PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.4-2014 and ANSI C63.10-2013. 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±6.7dB 4 All emissions, radiated 1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±4.43dB 7 Conducted Emission (150KHz-30MHz) ±5dB Page 6 of 30 Report No.: STS2005006W04 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name rPAD Trade Name Model Name RM-TFR8 Serial Model RM-TFR8-XXXX Model Difference XXXX:Represents different software versions and configurations The first X represents A~Z, which means different operation configuration modes. a. stand-alone version that can be used alone, b. multi-machine version that needs to be used in combination. The last three XXX represents 0-9, different numbers represent different system software versions, different software version does not produce a difference between EMI and RF. Product Description The EUT is a rPAD Operation Frequency: 13.56MHz Modulation Type: ASK Antenna Designation: Please see Note 2. Antenna Gain (dBi) 3.4dBi Adapter 1. Model: BI24-120200-AdU Input: 100-240VAC 50/60HZ 0.8A Output: 12VDC2A 2. Model: XSG-1202000HUS Input: 100-240VAC 50/60HZ 0.8A Output: 12VDC2A Hardware version number V1.32 Software version number N/A Connecting I/O Port(s) Please see Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications o…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2AWI7RMTFR8 DSS&DTS&DXX Setup photo Model name: RM-TFR8 DSS&DTS&DXX conduction DSS&DTS&DXX radiation L Page 2 of 2 FCC ID: 2AWI7RMTFR8 DSS&DTS radiation H DXX Loop antenna
