INSTRUCTION MANUALROBOTIC VACUUM CLEANERWITH DOCKING STATION BDXRBV660 Printed in China Part No. AL-ML English BDXRBV660 Please read before returning this product for any reason. INSTRUCTION MANUAL ENGLISH ENGLISH P. 1 P. 2 Before operating the Vacuum cleaner, please read all safety andoperating instructions. Save all instructions in a safe place for futurereference.Definitions: Safety Alert Symbols and WordsThisinstructionmanualusesthefollowingsafetyalertsymbolsandwords toalert youtohazardoussituationsandyourriskofpersonalinjuryorpropertyda mage. DANGER :Indicatesanimminentlyhazardoussituationwhich,ifnotavoided, will result in death or serious injury. WARNING : Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION : Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. (Used without word) Indicates a safety related message. NOTICE : Indicates a practice not related to personal injury which, if not avoided, may result in property damage. WARNING: Some householddustcontainschemicals knownto the State of California to cause cancer, birth defects or other reproductive harmsuch as asbestos and lead in lead based paint. WARNING! Readallsafetywarningsandallinstructions .Failuretofollowthewarnings and instructions may result in electric shock, fire and/ or serious injury. WARNING: Toreducetheriskofinjury,readtheinstructionmanual. IMPORTANTSAFETYINSTRUCTIONSWhen using an electrical appliances, basic p recautions should always be followed, includin g the following: WARNING: Toreducetheriskoffire,electricalshockorinjury: • Shock Hazard. To p rotect against risk of electrical shock, do not p ut the vacuum charging base in water or other liquid. • Do not allow to be used as a toy. Never sit or stand on the product. Close attention is necessarywhen used by or near children. • Never modify the product or any part of it. Damage or personal injury could r esult. • Use only as described in this manual. Use only manufacturer’s recommended attachments. • Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,damaged, left outdoors, or dropped into water, return it to a service center. • Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharpedges or corners. Do not run appliance over cord. Keep cord away from heated surfaces. • Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. • Do not allow the cord to hang over the edge of a table or counter or touch hot surfaces. The unitshould be placed or mounted away from sinks and hot surfaces. • Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint,hair, and anythingthat may reduce air flow. • Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts. • Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where theymaybepresent. • Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes. • Do not pick up toxic material (i.e. chlorine bleach, ammonia, drain cleaner, etc.) • Do not vacuum Toner (for laser printer, copy machines etc.) as there is a risk of fire and explosion. • Do not vacuum plaster, cement etc. as the filter can become blocked. • Do not use the vacuum without all the filters fitted. • Do not operate outdoors. While the vacuum is in operation, make sure all doors leading outside areclosed. • Do not incinerate the appliance even if it is severely damaged. The batteries can explode in a fire. • This appliance is intended for household use only and not for commercial or industrial use. Do notoperate on wet floor or moist conditions, e.g bathroom. Water and moisture could damage thecircuit board. • Do not handle charger, including charger plug, and charger terminals with wet hands. • Use only the charger supplied by the manufacturer to recharge. • Plug the charger directly into an electrical outlet. • Use the charger only in a standard electrical outlet (120V/60Hz). • Unplug the charger from outlet before any routine cleaning or maintenance. • Do not look into the air vents when the unit is switched on, as sometimes there is a possibility ofsmall debris being discharged from the air vents, especially after cleaning / replacement of the filters as debris inside the unit can be disturbed. • Make sure that the vacuum can be worked freely in the room (shall not be blocked or overturnedetc...) and make sure that there is nothing that the vacuum can overturn and create a hazard (Clearall candle, Vase (with or without water) and other fragile objects that placed on the floor orfurniture). ENGLISH ENGLISH P.3 P.4 ADDITIONAL SAFETY WARNINGSa) Prevent unintentional starting. Ensure the switch is in the off-position before picking up or carrying the appliance. Carrying the appliance with your finger on the switch or energizing appliance that have the switch on invites accidents. b) Use appliance only with speci fi cally designed battery packs. Use of any other battery packs may create a risk of injury and fire. c) Under abusive conditions, liquid may be ejected from the battery; avoid contact. d) Donotuseabatterypackorappliancethatisdamagedormodi fi ed. Damagedormodified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury. e) Do not expose a battery pack or appliance to fi re or excessive temperature. Exposure to fire or temperature may cause explosion. f) Have servicing performed by a quali fi ed repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. g) Do not modify or attempt to repair the appliance or the battery pack except as indicated in the instructionsforuseandcare. SAVE THESE INSTRUCTIONS Important Safety Instructions fo r All Battery Packs WARNING: Read all safety warnings and all i…
