8寸超薄人脸体温检测识别终端 8-inch ultra-thin Face Recognition Body Temperature Detection Terminal 适用于闸机、壁挂式、桌面式、落地式安装 Suitable for Brake machine, wall-mounted, desktop, floor-mounted installation 型号： 适用于办公区域、酒店、通道闸机、写字楼、学校、商场、商店、社区、建筑工地等公共服 务及管理项目等需要用到人脸门禁的场所。 Model: Suitable for office areas, hotels, passage gates, office buildings, schools, shopping malls,shops, communities, construction sites and other public services and management projects where face access control is required. 产品特性Product Features 1、宽动态单目活体防伪，彻底解决各类照片在各种载上的欺骗； 1. Wide dynamic monocular living anti-counterfeiting, completely solving the deception of various photos on various uploads; 2、支持LED智能补光； 2. Support LED intelligent fill light; 3、支持串口、韦根26、34输出，输出内容支持配置； Support serial port, Wiegand 26-bit, 34-bit output, and support output content configuration; 3、实时体温监控，体温公差范围精准到0.3°,体温检测距离0.3-0.5米; Real-time body temperature monitoring, and body temperature tolerance range is accurate to 0.3 °, body temperature detection distance is 0.3-0.5 meters; 4、支持设备本地存储万人库： Support the device to store thousands of people locally （a) 云平台设备支持同时储存5万张人脸照片（小于400KB）、100万条识别记录(0.45KB）， 2万现场抓拍照片； The cloud platform device supports the simultaneous storage of 50,000 face photos (less than 400KB), 1 million identification records (0.45KB), and 20,000 live capture photos; （b）局域网设备支持同时储存2万张人脸照片（照片按100KB计算）、100万条识别记录 （含最近1万张现场抓拍照片）。 The LAN device supports simultaneous storage of 20,000 face photos (the photo is calculated based on 100KB) and 1 million recognition records (including the recent 10,000 live capture photos). 1、1:N人脸识别，人脸库支持20000张人脸，top1命中率99.99%； 1: N face recognition, the face database supports 20,000 faces, and the top1 percentage of hits is 99.99%; 2、1：1人证比对准确率99%以上； The accuracy ratio of 1: 1 personal identification is over 99%; 3、识别速度快：Fast recognition （a)人脸跟踪与检测耗时20ms左右； Face tracking and detection takes about 20ms; （b) 人脸特征提取耗时200ms左右； Face feature extraction takes about 200ms; （c) 活体检测人脸比对耗时0.2ms; The live detection of face identification takes 0.2ms; （d) 特征比对耗时0.5ms（10000人脸库多次识别取平均值）； Feature identification takes 0.5ms (multiple recognition of 10,000 face database takes average); 4、支持陌生人检测，陌生人等级可配置； Support stranger detection, stranger level can be configured; 5、支持人脸识别或陌生人检测时的现场照片保存; Support live photo saving on face recognition or stranger detection; 6、支持HTTP方式的接口对接； Support HTTP port connection; 7、支持公网、局域网使用部署方式； Support public network and local area network management 8、支持屏幕显示内容配置； Support screen display of content configuration 9、支持识别距离配置。 Support identifying distance configuration 环境要求： Environmental Requirements: 使用过程中应避免的情况： Conditions to be avoided during use： ①传感器在室外使用时受环境影响较大，应在室内环境使用 ①The sensor should be used in indoor environment because it is greatly influenced by the environment when used outdoors ②由于红外传感器的特性，在使用环境中，如传感器正对窗户、空调、暖气 片等高温物体，会严重影响测量准确性 ②Because of the characteristic of infrared sensor, the accuracy of measurement will be seriously affected in the application environment, such as the sensor facing the window, air conditioner, radiator and other high temperature objects 产品规格表Product Specification Table 产品型号 Product model 类别 Category 性能 Performance 摄像头camera 分辨率 Resolution 200W 类型Types RGB+红外RGB + IR 光圈Aperture 4.0mm 焦距Focus 0-2米0 to 2 meters 白平衡White balance 自动Auto 屏幕Screen 尺寸size 8英寸，全视角IPS液晶屏 8-inch, full-view IPS LCD screen 分辨率Resolution 1280*800，亮度500cd 1280 * 800, brightness 500cd 处理器Processor CPU 4核cores，RK3288 内存RAM DDR3 2GB ISP 图像处理Image Processing 内置双路ISP Built-in dual-channel ISP 本地储存Local storage Tf卡 Tf card 8GB 配件Accessories 补光灯Fill light 红外、LED灯 Infrared, LED lights 读卡模块（预留） Card reader module (Reserved) IC/ID读卡器、身份证阅读器 热成像体温检测模块IC / ID card reader, ID card reader and thermal imaging temperature detection module 网络模块Network module 支持有线，2.4Gwifi 接口 Port 音频Audio 一路音频line out 1 Audio line out USB接口USB port USB2.0 micro2个 USB2.0 and 2micros 串口232 Serial port 232 2路RS232接口，1路WG输 入、1路WG输出 2 RS232 ports, 1 WG input, and with WG output 韦根接口Wiegand port 2.5mmX2PIN 复位接口Reset port 侧面孔位、外接按键 Lateral pore position, external buttons OTG接口OTG port 1路 In Channel 1 功能 Functions 本地离线使用 Offline locally use 本地2W人脸库20 thousand local face database 人脸检测Face Detection 支持同时检测跟踪5个人 Support simultaneous detection and tracking of 5 people 1：N人脸识 1: N face recognition 支持万分之一的误识率，99% 的通过率 Support one in 10,000 error recognition with 99% pass rate 1:1 支持选配刷卡模块，身份证模 块可实现1:1人脸比对 Support optional card swiping module, ID card module which can realize 1: 1 face identification 陌生人检测 Stranger detection 支持 Support 识别距离调整 Distance recognition adjustment 支持 Support 远程升级 Remote upgrade 支持Support 设备接口 Device port 设备管理、权限管理、人员/ 照片管理，记录查询等 Including equipment management, access control, personnel or photo management, record query, etc. 常规参数 General parameters 防护等级 Protection level 使用于半室外或纯室外 For semi-outdoor or pure outdoor use 电源Power DC12V 工作温度 Operating temperature -10°C-60°C 工作湿度 Working humidity 10%-90% 静电Static electricity 4K/8K 电池辐射Battery radiation 无频点超标Not exceeded 功耗 Power consumption 5W MAX 设备重量Equipment weight 约1.6KG About3.5 lbs 设备尺寸Equipment size 373.7*135*85mm 产品规格表 Product Specification Table 模块 Modules 功能 Functions 简介 Introductions 显示界面 Display interface 开机界面 Boot interface 中性（可定制）Neutral (customizable) 验证界面 Verification interface 1、包括显示请打卡提示、网络信号（是 否绑定/联网）、时间、日期、星期； 2 、网络连接异常的弹窗提示，通知显示， 身份证信息，验证成功或者失败提示可定 制 3、版本号，人数，底库图片数量。 1. Including display of prompt ‘Please punch in’ , network signal (whether it is bound / connected), time, date, weekday; 2. Pop-up prompts for abnormal network connection, notification display, ID card information, and prompts for successful or failed verification , which can be customized 3. Including the version number, the number of people, and the number of pictures in database. 菜单界面 菜单样式以及人机交互，如何进入其他 Menu interface 模块，管理等。 Menu style and human-computer interaction, how to enter other modules, management, etc. 用户管理 User Management 用户添加 User added 本地应用上增加人员 Add people to local apps 用户删除 User delete 本…
