2AWOH-P07Remote control

FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Shenzhen LEPLE Technology Co.,Ltd 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Tel: (86) 15013868817 Email: [email protected] Date: 2020-06-22 Dear Sir/Madam, We, Shenzhen LEPLE Technology Co.,Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: FCC ID: 2AWOH-P07 Product name: Remote control Model no.: P07, P28, P58, P17, P10, P12, P16 Sincerely, Name: Nick Xu Company: Shenzhen LEPLE Technology Co.,Ltd Address: 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Phone: (86) 15013868817 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/06/22 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AWOH-P07 P07, P28, P58, P17, P10, P12, P16 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Nick Xu Company: Shenzhen LEPLE Technology Co.,Ltd Address: 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Phone: (86) 15013868817 Fax: N/A E-Mail: [email protected]

Shenzhen LEPLE Technology Co.,Ltd 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Tel: (86) 15013868817 Email: [email protected] Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 6/22/2020 To whom it may concern: We, Shenzhen LEPLE Technology Co.,Ltd the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AWOH-P07 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Nick Xu Company: Shenzhen LEPLE Technology Co.,Ltd Address: 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Phone: (86) 15013868817 Fax: N/A E-Mail: [email protected]

FCC ID: 2AWOH-P07 FCC ID: 2AWOH-P07

FCC ID: 2AWOH-P07

FCC ID: 2AWOH-P07 Antenn a FCC ID: 2AWOH-P07

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT FCC PART 15 SUBPART C 15.249 Report Reference No. .....................: FCC ID. .............................................: GTS20200619001-2-10 2AWOH-P07 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : June 20, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen LEPLE Technology Co.,Ltd Address ............................................ : 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Test specification ...........................: Standard ........................................... : 47 CFR FCC Part 15 Subpart C 15.249 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Remote control Trade Mark ....................................... : BENTOPAL Manufacturer .................................... : Shenzhen LEPLE Technology Co.,Ltd Model/Type reference....................... : P07 List Model ......................................... : P28, P58, P17, P10, P12, P16 Ratings ............................................. : DC 3.7V from battery Result................................................ : PASS Report No.: GTS20200619001-2-10 Page 2 of 26 T E S T R E P O R T Test Report No. : GTS20200619001-2-10 June 20, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Remote control Model /Type : P07 Listed Models : P28, P58, P17, P10, P12, P16 Applicant : Shenzhen LEPLE Technology Co.,Ltd Address : 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Manufacturer : Shenzhen LEPLE Technology Co.,Ltd Address : 2nd floor, Building B, Senhainuo Weijian Industrial Park, No.7 Jintai Road, Shiyan Street office, Bao'an District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200619001-2-10 Page 3 of 26 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Special Accessories 6 2.8 Related Submittal(s) / Grant (s) 6 2.9 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 8 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 Conducted Emissions Test 10 4.2 Radiated Emissions and Band Edge 13 4.3 Occupied Bandwidth Measurement 19 4.4 Antenna Requirement 21 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 22 6 P H O T O S O F T H E E U T ........................................................... 23 Report No.: GTS20200619001-2-10 Page 4 of 26 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: GTS20200619001-2-10 Page 5 of 26 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : June 07, 2020 Testing commenced on : June 08, 2020 Testing concluded on : June 15, 2020 2.2 Product Description Product Name: Remote control Model/Type reference: P07 Power supply: DC 3.7V from battery Hardwrae Version: LP07_TX V1.0 Software Version: V1.0 Test samples ID: GTS20200619001-2-10# 2.4GHz wireless Modulation: GFSK Operation frequency: 2410MHz to 2470MHz Channel number: 61 Channel separation: 1 MHz Antenna type: Integral antenna Antenna gain: 1.0dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 3.70V from battery 2.4 Short description of the Equipment under Test (EUT) This is a Remote control. For more details, refer to the user’s manual of the EUT. Report No.: GTS20200619001-2-10 Page 6 of 26 2.5 EUT operation mode The Applicant provides communication tools software to control …

Text truncated - open the document above for the full version.

FCC ID: 2AWOH-P07
