2AWR2JQ2020A27Toy RC Cars Lights And Sounds 2pk

Page 1 of 2 External Photos Page 2 of 2

Page 1 of 1 Label Artwork and Location SIZE: 33mm (W) x 10mm (H) FCC ID ： 2AWR2JQ2020A27 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 2 Internal Photos Page 2 of 2

1 INTERTEK TESTING SERVICES Analysis Report The equipment under test (EUT) is a transmitter for a Toy RC Cars Lights And Sounds 2pk operating at 27.145 MHz which is controlled by a crystal. The EUT is powered by two 1.5V AA batteries. For more detail information pls. refer to the user manual. Antenna Type: integral antenna Antenna Gain: 0dBi Modulation Type: Pulse modulation The nominal conducted output power specified: -40.0dBm (+/- 3dB) The nominal radiated output power (e.r.p) specified: -42.15dBm (+/- 3dB) According to the KDB 447498: The worst-case peak radiated emission for the EUT is 54.0dBuV/m at 3m in the frequency 27.145MHz The EIRP = [(FS*D) ^2 / 30] mW= -41.23dBm The ERP = EIRP – 2.15 = -43.38dBm which is within the production variation. The maximun conducted output power specified is -37.0dBm = 0.0002mW The source- based time-averaging conducted output power = 0.0002* Duty Cycle mW < 0.0002mW (Duty Cycle<100%) The SAR Exclusion Threshold Level for 27.145MHz when the minimum test separation distance is < 50mm: = 474 * [1 + log(100/f(MHz)]/2 = 371.2 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. Transmitter Duty Cycle Calculation The duration of one cycle = 956.5μs Effective period of the cycle = 478.3us DC =478.3us / 956.5μs =0.5001 or 50.01% FCC ID: 2AWR2JQ2020A27

Shantou JiQun plastic toy Co.,Ltd TEST REPORT SCOPE OF WORK RF TESTING–10125925 REPORT NUMBER GZHH00368271-001 ISSUE DATE August 18, 2020 PAGES 16 DOCUMENT CONTROL NUMBER FCC ID_b-227 © 2017 INTERTEK Intertek Report No.: GZHH00368271-001 • The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community GuanHu Subdistrict, LongHua District, Shenzhen, People’s Republic of China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01 November 2017 Page: 1 of 16 FCC ID_b-227 Test Report Shantou JiQun plastic toy Co.,Ltd Application For Certification FCC ID: 2AWR2JQ2020A27 Product Name: Toy RC Cars Lights And Sounds 2pk Model: 10125925 Additional Models: 1012191, JQ2020A Brand Name: FAO Schwarz Transmitter Report No.: GZHH00368271-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [ 10-1-19] Prepared and Checked by: Approved by: Sign on file Terry Tang Assistant Supervisor Jimmy Wen Assistant Manager Date: August 18, 2020 Intertek Report No.: GZHH00368271-001 Version: 01 November 2017 Page: 2 of 16 FCC ID_b-227 Test Report GENERAL INFORMATION Shantou JiQun plastic toy Co.,Ltd MODEL: 10125925 FCC ID: 2AWR2JQ2020A27 Grantee: Shantou JiQun plastic toy Co.,Ltd Grantee Address: NO.5,West,Easter Outer Ring,Fengxiang Street Chenghai Area Shantou,China Contact Person: Jennis Hu Tel: +8613616571662 Manufacturer: Shantou JiQun plastic toy Co.,Ltd Manufacturer Address: NO.5,West,Easter Outer Ring,Fengxiang Street Chenghai Area Shantou,China Model: 10125925 Type of EUT: Transmitter Description of EUT: Toy RC Cars Lights And Sounds 2pk Serial Number: N/A FCC ID : 2AWR2JQ2020A27 Date of Sample Submitted: June 19, 2020 Date of Test: July 1, 2020 Report No.: GZHH00368271-001 Report Date: August 18, 2020 Environmental Conidtions: Temperature: +10 to 40°C Humidity: 10 to 90% Intertek Report No.: GZHH00368271-001 Version: 01 November 2017 Page: 3 of 16 FCC ID_b-227 Test Report SUMMARY OF TEST RESULT Shantou JiQun plastic toy Co.,Ltd MODEL: 10125925 FCC ID: 2AWR2JQ2020A27 TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation (for 2.4GHz Digital) 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength (for 27MHz) 15.227 / RSS-310 3.8 Pass Transmitter Field Strength (for 40MHz) 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for Remote Control) 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for 433MHz) 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement(for 88-108MHz) 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement(for 902- 928MHz or 2.4GHz) 15.249 / RSS-210 A2.9 N/A Transmitter Field Strength and Bandwidth Requirement (for 49MHz) 15.235 / RSS-310 3.9 N/A Receiver / Digital Device Radiated Eissions 15.109 / ICES-003 N/A Digital Device Conducted Emissions 15.107 / ICES-003 N/A Note: 1. The EUT uses an integral antenna, in accordance to section 15.203, is considered sufficient to comply with the provisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. Intertek Report No.: GZHH00368271-001 Version: 01 November 2017 Page: 4 of 16 FCC ID_b-227 Test Report Table of Contents 1.0 General Description ..................................................................................................................................... 5 1.1 Product Description .................................................................................................................................... 5 1.3 Test Methodology ....................................................................................................................................... 5 1.4 Test Facility ......................................................…

Text truncated - open the document above for the full version.

Page 1 of 1 Radiated Photos (EUT was placed in the center of the turntable)
