2AWRT-YJL-IR01Touro Internet Radio Black

HOME AUDIO • CAMBRIDGE Touro Internet Radio User Manual EN 2 3 4 6 7 9 10 11 13 15 15 16 18 21 22 22 23 What’sIntheBox?.............................................................................................................. ControlsAndFunctions...................................................................................................... InstructionsGuide............................................................................................................... BasicOperation................................................................................................. GettingStarted- ProductSet-up................................................................... ControlyourradiowithOktivApp.................................................................. InternetRadio& Podcasts............................................................................... Spotify& MusicPlayer..................................................................................... FMRadio............................................................................................................ Bluetooth........................................................................................................... AUX IN (Line In)................................................................................................. DualAlarm& SleepTimer................................................................................ SystemSettings................................................................................................ Troubleshooting.................................................................................................................. Specification........................................................................................................................ Warranty............................................................................................................................... SafetyInformation.............................................................................................................. Contents EN 3 What’s in the Box? Box Contents A.Majority Touro Internet Radio B.Power Cable C.UserManual A C B EN 4 Majority Touro – Front View Controls & Functions 1.Standby/Mode button 2.Menu/Info button 3.FAV button 4.BACK button 5.Tuning + 6.Tuning – 7.Navigation Dial/Volume/OK/Scan 8.Alarm 9.Sleep/Snooze 10.Radio Display 11.Speaker 2 3 4 1 5 6 7 8 9 10 11 EN 5 Majority Touro –Back View Controls & Functions 12. 13. 14. 15.LINE Input PortRadio FM Telescopic Antenna OFF/ON Button DC IN –Power Cable Port 16.USB Playback Port 13 12 1415 16  EN 6 *Please note that the instructions within this manual will refer to radio buttons e.g. (Ref* number*) in accordance with the diagrams on pages 4-5. Connection and Preparation Remove all packaging and prepare your Majority Touro for use. Insert the power adaptor to the back of the device into its port(Ref.14) and plug the other end into power socket. Ensure the switch button at the back of the radio has been switched to 'ON' (Ref.13). Standby Mode To set the radio to ‘Standby Mode’ or to power on while in Standby Mode, press and hold the Standby/Mode button (Ref.1) for 2-3 seconds. Radio Antenna Ensure that the radio antenna is fully extended before scanning FM radio stations to get the best possible radio signal reception available at your location. Presets Presets are stored on the unit and cannot be accessed from other radios. The number of presets for each mode are FM - 20; FM- 20,and 10 in total for the Internet Radios and Podcasts. To store a preset, press and hold the ‘FAV’ button for 2-3 seconds (Ref.3). The display will show the 'Save the Preset' screen. Select an empty space number to save the current playing station. To recall a preset, press (do not hold) the ‘FAV’ button (Ref.3), and select one of the saved preset stations. When a preset station is playing a star icon is showingat the bottom of thescreen. Basic Operation EN 7 First Time Setup Connecting to a network •A broadband connection in combination with a wireless access point, router, or ͣʧ˰ʧ˓Ǹͅڑ˷ɤʹΨ̇ͅˋڑɒɤΤʧɆɤռڠ •The network device needs to support Wi-‰ʧڑԻԘԎԐռԏԏڑǸՍȿՍʊՍ˷ԼڑΨʧͅɤ˓ɤͣͣڑڠɆ̇˷˷ɤɆʹʧ̇˷ռڠ Make sure your wireless network is set and you have the WEP, WPA or WPA2 security password to activate the connection with the Majority Touro. You may also use the Wi-Fi Protected Setup (WPS) function for easy pairing between the network device and the radio. Check if the light indicators on the network device have the appropriate ͣʹǸʹ΃ͣռڠ When powering the device up for the first time, you will be appointed to change the language. Rotate the Navigation Dial(Ref.7) to select the menu language you want from the list and press the Navigation Dial/'OK' button (Ref.7) to confirm your selection. The privacy policy will be displayed right after. Press the Navigation Dial/'OK' button (Ref.7) ʹ̇ڑɆ̇˷ʅʧͅ˰ڑǸ˷ɒڑɆ̇˷ʹʧ˷΃ɤռڠ ƙʔɤڑɒɤΤʧɆɤլͣڑƋɤʹ΃̻ڑLjʧύǸͅɒڑΨʧ˓˓ڑǸ΃ʹ̇˰ǸʹʧɆǸ˓˓ζڑ˓Ǹ΃˷Ɇʔڑʹ̇ڑʊ΃ʧɒɤڑζ̇΃ڑʹʔ̇ͅ΃ʊʔڑʹʔɤڑ̻̇ͅɆɤͣͣռڠ Ƌɤ˓ɤɆʹڑլǕ_ƋլڑǸ˷ɒڑɆ̇˷ʅʧͅ˰ڑʹ̇ڑ̻̇ͅɆɤɤɒռڠڑ If you select 'NO,' the next window will ask to you choose if you want to start the Ƌɤʹ΃̻ڑLjʧύǸͅɒڑʹʔɤڑ˷ɤαʹڑʹʧ˰ɤڑζ̇΃ڑ̻̇ΨɤͅڑʹʔɤڑͅǸɒʧ̇ڑ̇˷ռڠڑ Setting the date and time - Select the clock format such as: '12' for 12-hour display format or '24' for 24-hour display format. If you select the 12-hour format, the display ͣʔ̇Ψͣڑլģլڑʧ˷ڑʹʔɤڑ˰̇ͅ˷ʧ˷ʊڑ̇ͅڑլŶģլڑʧ˷ڑʹʔɤڑǸʅʹɤͅ˷̇̇˷ڑǸʅʹɤͅڑʹʔɤڑʹʧ˰ɤռڠ Please note: ‘AM’ / PM' displays only if you have chosen the 12-hour time format. Ƌɤ˓ɤɆʹڑլģլڑʅ̇ͅڑʹʔɤڑ˰̇ͅ˷ʧ˷ʊڑʔ̇΃ͣͅڑ̇ͅڑլŶģլڑʅ̇ͅڑʹʔɤڑǸʅʹɤͅ˷̇̇˷ڑʔ̇΃ͣͅռڠ Once selected, the following options will be displayed on the radio screen to choose ʅ̇ͅ˰տڑƥ̻ɒǸʹɤڑʅ̇ͅ˰ڑ‰ģջڑƥ̻ɒǸʹɤڑʅ̇ͅ˰ڑīɤʹΨ̇ͅˋڑ̇ͅڑī̇ڑƥ̻ɒǸʹɤռڠ Please Note: If you choose 'Update from Network', you must indicate your time zone ʧ˷ڑʹʔɤڑ˷ɤαʹڑΨʧ˷ɒ̇Ψռڠ Next, switch 'Daylight Saving' to 'ON' during summertime, otherwise select 'OFF’. If you choose 'No Update', you will have to enter the date and ti…

Text truncated - open the document above for the full version.

HUIZHOUHUIYANGYAJIALIELECTRONICSCO.,LTD CoveredEquipmentCertificationAttestationLetter 1/22/2024 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA ATTN.:ReviewingEngineer FCCID:2AWRT-YJL-IR01 HUIZHOUHUIYANGYAJIALIELECTRONICSCO.,LTDcertifiesthattheequipmentfor whichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. HUIZHOUHUIYANGYAJIALIELECTRONICSCO.,LTDcertifiesthat,asofthedateof thefilingoftheapplication,theapplicantisnotidentifiedontheCoveredListasanentity producing“covered”equipment. Signed: Printedname: COLINLIN Title:MarketingManager CompanyName:HUIZHOUHUIYANGYAJIALIELECTRONICSCO.,LTD Date:1/22/2024

DATE:2024-01-22 FederalCommunicationsCommission Authorization&EvaluationDivision 7345OaklandMillsRoad Columbia,Maryland21046 AuthoritytoActasAgent Onourbehalf,IappointJasonWuofGlobalUnitedTechnologyServicesCo.,Ltd.and No.123-128,TowerA,JinyuanBusinessBuilding,No.2,LaodongIndustrialZone, XixiangRoad,BaoanDistrict,Shenzhen,Guangdong,Chinatoactasouragentinthe preparationofthisapplicationforequipmentcertification.Icertifythatsubmitted documentsproperlydescribethedeviceorsystemforwhichequipmentcertificationis sought.Ialsocertifythateachunitmanufactured,importedormarketed,asdefinedinthe FederalCommunicationsCommission’sregulationswillhaveaffixedtoitalabelidentical tothatsubmittedforapprovalwiththisapplication. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonour behalf,Iacknowledgethatallresponsibilityforcomplyingwiththetermsandconditions forcertification,stillresideswithHUIZHOUHUIYANGYAJIALIELECTRONICSCO.,LTD andLoujiao,XintangVillage,QiuchangTown,HuiyangDistrict,Huizhou,Guangdong, China Signature: Name:COLINLIN Title: MarketingManager Company:HUIZHOUHUIYANGYAJIALIELECTRONICSCO.,LTD

Differences Declaration To whom concern, We company HUIZHOU HUIYANG YAJIALI ELECTRONICS CO.,LTD hereby declares: The product models 1000002957, YJL-IR01, YJL-IR02, YJL-IR03, WJ-IR01, WJ-IR02, WJ-IR03, 1000002954 are identical in the same PCB layout, interior structure and electrical circuits, The differences are appearance color and model name for commercial purpose. Authorized signature: Date: 2023-02-28

DATE : 2024-01-22 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AWRT-YJL-IR01 Product Name: Majority Touro Internet Radio Black Request for Confidentiality To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Sch ematic Diagram Block Diagram Operational Descr iption In additional to above mentioned docu ments, in order to co mply with the marke ting regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensu ring that busi ness se nsi tive information remains co nfidential until the act ual marke ting of newly authorized device s, we request Short Term Confidentiality of the following attach ment(s); External Photos Test Setup Photos Internal Photos Use r Manual For 45 days, pursu ant to Public Notice DA 04-1705. OR For 180 days pursu antto KDB 726920 D01. It is our underst anding that all measu rement test reports, FCC ID label format and co rresp ondence during the ce rtifica tion review proce ss ca nnot be granted as co nfidential docu ments and this information will be available for public review once the grant of equipment authoriza tion is issu ed. Signature: Name: COLIN LIN Title: Marke ting Manager Company: HUIZH OU HUIYANG YAJI ALI ELECTR ONICS CO.,LTD

Page 1 of 4 Page 2 of 4 Page 3 of 4 Page 4 of 4

Ir01 铭 牌贴纸 size:49.5*29.5*0.05mm 6 FCC ID: 2AWRT-YJL-IR01  Input Voltage: DC 6.0V 1.0A

Label location:

Page 1 of 6 Page 2 of 6 Page 3 of 6 Page 4 of 6 Page 5 of 6 Page 6 of 6

FCC ID: 2AWRT-YJL-IR01 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: 2AWRT-YJL-IR01 Test Result of RF Exposure Evaluation Mode Antenna gain (dBi) Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm2) Result BLE -0.18 2.34 1.71 0.00033 1.00 PASS WIFI 2.4G -0.18 15.33 34.12 0.0065 1.00 PASS BLE and WIFI Simultaneous Transmission: BLE + WIFI =(0.00033/1)+(0.0065/0.525)=0.0068<1 The max power density is less than MPE exempt limit, so it is compliance.

Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 26 AppendixA: 20dB Emission Bandwidth Test Result Test Mode Antenna Frequency[MHz] 20db EBW[MHz] FL[MHz] FH[MHz] DH5 Ant1 2402 0.996 2401.502 2402.498 DH5 Ant1 2441 0.963 2440.505 2441.468 DH5 Ant1 2480 0.969 2479.523 2480.492 2DH5 Ant1 2402 1.305 2401.343 2402.648 2DH5 Ant1 2441 1.332 2440.325 2441.657 2DH5 Ant1 2480 1.308 2479.340 2480.648 3DH5 Ant1 2402 1.335 2401.319 2402.654 3DH5 Ant1 2441 1.293 2440.334 2441.627 3DH5 Ant1 2480 1.323 2479.331 2480.654 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 26 DH5-Ant1-2480 2DH5-Ant1-2402 2DH5-Ant1-2441 2DH5-Ant1-2480 3DH5-Ant1-2402 3DH5-Ant1-2441 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 26 / 3DH5-Ant1-2480 / Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 26 AppendixB: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] DH5 Ant1 2402 0.88416 2401.5462 2402.4304 DH5 Ant1 2441 0.88548 2440.5484 2441.4339 DH5 Ant1 2480 0.85027 2479.5679 2480.4181 2DH5 Ant1 2402 1.1943 2401.3868 2402.5811 2DH5 Ant1 2441 1.1858 2440.3948 2441.5806 2DH5 Ant1 2480 1.1827 2479.3980 2480.5807 3DH5 Ant1 2402 1.1812 2401.3990 2402.5802 3DH5 Ant1 2441 1.1827 2440.3930 2441.5757 3DH5 Ant1 2480 1.1720 2479.3991 2480.5711 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 5 of 26 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 DH5-Ant1-2480 2DH5-Ant1-2402 2DH5-Ant1-2441 2DH5-Ant1-2480 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 6 of 26 3DH5-Ant1-2402 3DH5-Ant1-2441 / 3DH5-Ant1-2480 / Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 7 of 26 AppendixC: Maximum conducted output power Test Result Test Mode Antenna Frequency[MHz] Conducted Peak Power[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 -1.4 ≤30 PASS DH5 Ant1 2441 -0.91 ≤30 PASS DH5 Ant1 2480 -0.14 ≤30 PASS 2DH5 Ant1 2402 0.77 ≤20.97 PASS 2DH5 Ant1 2441 1.16 ≤20.97 PASS 2DH5 Ant1 2480 2 ≤20.97 PASS 3DH5 Ant1 2402 1.06 ≤20.97 PASS 3DH5 Ant1 2441 1.61 ≤20.97 PASS 3DH5 Ant1 2480 2.34 ≤20.97 PASS Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 8 of 26 DH5-Ant1-2480 2DH5-Ant1-2402 2DH5-Ant1-2441 2DH5-Ant1-2480 3DH5-Ant1-2402 3DH5-Ant1-2441 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 9 of 26 / 3DH5-Ant1-2480 / Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 10 of 26 AppendixD: Carrier frequency separation Test Result TestMode Antenna Frequency[MHz] Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1.004 ≥0.996 PASS 2DH5 Ant1 Hop 1.176 ≥0.888 PASS 3DH5 Ant1 Hop 0.982 ≥0.890 PASS Test Graphs DH5-Ant1-Hop 2DH5-Ant1-Hop / 3DH5-Ant1-Hop / Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 11 of 26 AppendixE: Time of occupancy Test Result TestMode Antenna Frequency[MHz] BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH5 Ant1 Hop 2.888 106.67 0.308 ≤0.4 PASS DH1 Ant1 Hop 0.383 320 0.123 ≤0.4 PASS DH3 Ant1 Hop 1.639 160 0.262 ≤0.4 PASS 2DH5 Ant1 Hop 2.884 106.67 0.308 ≤0.4 PASS 2DH1 Ant1 Hop 0.385 320 0.123 ≤0.4 PASS 2DH3 Ant1 Hop 1.637 160 0.262 ≤0.4 PASS 3DH5 Ant1 Hop 2.885 106.67 0.308 ≤0.4 PASS 3DH1 Ant1 Hop 0.384 320 0.123 ≤0.4 PASS 3DH3 Ant1 Hop 1.635 160 0.262 ≤0.4 PASS Note: DH5/2DH5/3DH5:TotalHops=1600/79/6*0.4*79 DH5/2DH5/3DH5: Time of occupancy= TotalHops * ( BurstWidth) /1000 DH3/2DH3/3DH3:TotalHops=1600/79/4*0.4*79 DH3/2DH3/3DH3: Time of occupancy= TotalHops * ( BurstWidth) /1000 DH1/2DH1/3DH1:Tot…

Text truncated - open the document above for the full version.

Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 17 of 26 DH5-Ant1-Hop_2402 DH5-Ant1-Hop_2480 2DH5-Ant1-Hop_2402 2DH5-Ant1-Hop_2480 3DH5-Ant1-Hop_2402 3DH5-Ant1-Hop_2480 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 18 of 26 AppendixH:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 0~Reference -1.56 -1.56 --- PASS DH5 Ant1 2402 30~1000 -1.56 -59.56 ≤-21.56 PASS DH5 Ant1 2402 1000~26500 -1.56 -50.05 ≤-21.56 PASS DH5 Ant1 2441 0~Reference -1.17 -1.17 --- PASS DH5 Ant1 2441 30~1000 -1.17 -61.05 ≤-21.17 PASS DH5 Ant1 2441 1000~26500 -1.17 -50.44 ≤-21.17 PASS DH5 Ant1 2480 0~Reference -0.40 -0.40 --- PASS DH5 Ant1 2480 30~1000 -0.40 -61.85 ≤-20.4 PASS DH5 Ant1 2480 1000~26500 -0.40 -49.37 ≤-20.4 PASS 2DH5 Ant1 2402 0~Reference -1.73 -1.73 --- PASS 2DH5 Ant1 2402 30~1000 -1.73 -60.79 ≤-21.73 PASS 2DH5 Ant1 2402 1000~26500 -1.73 -50.78 ≤-21.73 PASS 2DH5 Ant1 2441 0~Reference -1.27 -1.27 --- PASS 2DH5 Ant1 2441 30~1000 -1.27 -61.58 ≤-21.27 PASS 2DH5 Ant1 2441 1000~26500 -1.27 -50.71 ≤-21.27 PASS 2DH5 Ant1 2480 0~Reference -0.86 -0.86 --- PASS 2DH5 Ant1 2480 30~1000 -0.86 -62.39 ≤-20.86 PASS 2DH5 Ant1 2480 1000~26500 -0.86 -49.6 ≤-20.86 PASS 3DH5 Ant1 2402 0~Reference -1.68 -1.68 --- PASS 3DH5 Ant1 2402 30~1000 -1.68 -62.26 ≤-21.68 PASS 3DH5 Ant1 2402 1000~26500 -1.68 -49.2 ≤-21.68 PASS 3DH5 Ant1 2441 0~Reference -1.24 -1.24 --- PASS 3DH5 Ant1 2441 30~1000 -1.24 -61.97 ≤-21.24 PASS 3DH5 Ant1 2441 1000~26500 -1.24 -50.45 ≤-21.24 PASS 3DH5 Ant1 2480 0~Reference -0.50 -0.50 --- PASS 3DH5 Ant1 2480 30~1000 -0.50 -60.16 ≤-20.5 PASS 3DH5 Ant1 2480 1000~26500 -0.50 -50.91 ≤-20.5 PASS Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 19 of 26 Test Graphs DH5-Ant1-2402-0~Reference DH5-Ant1-2402-30~1000 DH5-Ant1-2402-1000~26500 DH5-Ant1-2441-0~Reference DH5-Ant1-2441-30~1000 DH5-Ant1-2441-1000~26500 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 20 of 26 DH5-Ant1-2480-0~Reference DH5-Ant1-2480-30~1000 DH5-Ant1-2480-1000~26500 2DH5-Ant1-2402-0~Reference 2DH5-Ant1-2402-30~1000 2DH5-Ant1-2402-1000~26500 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 21 of 26 2DH5-Ant1-2441-0~Reference 2DH5-Ant1-2441-30~1000 2DH5-Ant1-2441-1000~26500 2DH5-Ant1-2480-0~Reference 2DH5-Ant1-2480-30~1000 2DH5-Ant1-2480-1000~26500 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 22 of 26 3DH5-Ant1-2402-0~Reference 3DH5-Ant1-2402-30~1000 3DH5-Ant1-2402-1000~26500 3DH5-Ant1-2441-0~Reference 3DH5-Ant1-2441-30~1000 3DH5-Ant1-2441-1000~26500 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 23 of 26 3DH5-Ant1-2480-0~Reference 3DH5-Ant1-2480-30~1000 / 3DH5-Ant1-2480-1000~26500 / Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 24 of 26 AppendixI: Duty Cycle Test Result TestMode Antenna Frequency[MHz] ON Time [ms] Period [ms] Duty Cycle [%] Duty Cycle Factor[dB] DH5 Ant1 2402 2.88 3.74 77.01 1.13 DH5 Ant1 2441 2.88 3.76 76.60 1.16 DH5 Ant1 2480 2.88 3.74 77.01 1.13 2DH5 Ant1 2402 2.88 3.74 77.01 1.13 2DH5 Ant1 2441 2.88 3.76 76.60 1.16 2DH5 Ant1 2480 2.88 3.74 77.01 1.13 3DH5 Ant1 2402 2.88 3.74 77.01 1.13 3DH5 Ant1 2441 2.88 3.74 77.01 1.13 3DH5 Ant1 2480 2.88 3.74 77.01 1.13 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 25 of 26 Test Graphs NTNV-DH5-Ant1-2402 NTNV-DH5-Ant1-2441 NTNV-DH5-Ant1-2480 NTNV-2DH5-Ant1-2402 NTNV-2DH5-Ant1-2441 NTNV-2DH5-Ant1-2480 Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 26 of 26 NTNV-3DH5-Ant1-2402 NTNV-3DH5-Ant1-2441 / NTNV-3DH5-Ant1-2480 / ------End------

Content 1. GeneralInformation ........................................................................................................... 3 1.1 Description of device undertest(EUT) ................................................................. 3 1.2 Testequipment list ............................................................................................... 3 1.3 Testmethodology ................................................................................................ 4 1.4 Isolation measurementSet-upPhoto ................................................................... 4 2. TestSetupPhoto ................................................................................................................ 5 2.1 EUTPhoto ........................................................................................................... 5 2.2 Free-Space ............................................................................................................... 5 3. TestingAmbient Condition ................................................................................................. 6 4. TestResults ....................................................................................................................... 6 5. Antenna 3DPatternsPlots .................................................................................................. 7 Applicant Frontier SmartTechnologies Group Ltd. Product Type VENICE X MODULE Model Number Venice X FS2340 Trade Name 1. GeneralInformation 1.1 Description of device under test(EUT) Applicant Frontier Smart Technologies Group Ltd. First Floor 17 Waterloo Place London SW1Y 4AR UK Manufacturer Frontier Smart Technologies Group Ltd.. First Floor 17 Waterloo Place London SW1Y 4AR UK Product Type VENICE X MODULE Trade Name Model Number Venice X FS2340 Antenna Trade Name Antenna Model Number FS2340 Antenna Type PCB Antenna Antenna Peak Gain (Combined Polarization) -0.18 dBi Polarization Horizontal + Vertical Test Frequency 2402 MHz, 2440 MHz, 2480 MHz 1.2 Test equipmentlist Describe Manufacturer Model Number Serial Number Cal. Date Cal. Period Full Anechoic Wireless Test chamber ETS-Lindgren AMS-8500 N/A N.C.R ----- Test Software EMQuest™ N/A N/A N.C.R ----- Multi-Axis Positioning System (MAPS) EMCO 2090 N/A N.C.R ----- Turn Table EMCO 2015 N/A N.C.R ----- Dual Polarization Horn ETS-Lindgren 3164-08 00099207 N.C.R ----- Communication Antenna EMCO 3102 69235 N.C.R ----- Switch Control Mainframe Agilent 3499A MY42003188 N.C.R ----- ENA Series Network Analyzer Agilent E5071B MY42402996 Jan19,2020 2 years Sleeve Dipole EMCO 3126-2500 00092001 Mar,19,2020 1 year Note: N.C.R. = No Calibration Request. 1.3 Test methodology The “great circle” cut method, whereby the Measurement Antenna remains fixed and the EUT is rotated about two axes in sequential order。 The radiated RF performance of the Equipment Under Test (EUT) is measured by sampling the radiated transmit power of the mobile at various locations surrounding the device. A three-dimensional characterization of the 'transmit' performance of the EUT is pieced together by analyzing the data from the spatially distributed measurements. Data points taken every 15 degrees in the theta and in the phi axes are deemed sufficient to fully characterize the EUT's Far-Field radiation pattern and total radiated power All of the measured power values will be integrated 1.4 Isolation measurement Set-upPhoto 2. Test SetupPhoto 2.1 EUT Photo 2.2 Free-Space EUT Photograph: 3. Testing AmbientCondition Temperature ： 22 °C Relative Humidity ： 60 % Shield Dimensions ： 7.4m(L) * 3.66m (W) * 3.66m (H) Frequency Range ： 700 MHz to 6 GHz 4. TestResults Frequency [MHz] Peak Gain[dBi] 2402 -2.3 2440 -1.216 2480 -0.18 5. Antenna 3D PatternsPlots Free-Space Total GAIN, Top View,2402.0 MHz Free-Space Total GAIN, Bottom View,2402.0 MHz Free-Space Total GAIN, Top View,2440.0 MHz Free-Space Total GAIN, Bottom View,2440.0 MHz Free-Space Total GAIN, Top View,2480.0 MHz Free-Space Total GAIN, Bottom View,2480.0 MHz --- END---

Global United Technology Services Co., Ltd. Report No.: GTS2024010037F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 29 TEST REPORT Applicant: HUIZHOU HUIYANG YAJIALI ELECTRONICS CO.,LTD Address of Applicant: Loujiao, Xintang Village, Qiuchang Town, Huiyang District, Huizhou, Guangdong, China Manufacturer/Factory: HUIZHOU HUIYANG YAJIALI ELECTRONICS CO.,LTD Address of Manufacturer/Factory: Loujiao, Xintang Village, Qiuchang Town, Huiyang District, Huizhou, Guangdong, China Equipment Under Test (EUT) Product Name: Majority Touro Internet Radio Black Model No.: 1000002957, YJL-IR01, YJL-IR02, YJL-IR03, WJ-IR01, WJ- IR02, WJ-IR03, 1000002954 Trade Mark: Majority FCC ID: 2AWRT-YJL-IR01 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: January 04, 2024 Date of Test: January 04-22, 2024 Date of report issued: January 22, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 29 2 Version Version No. Date Description 00 January 22, 2024 Original Prepared By: Date: January 22, 2024 Project Engineer Check By: Date: January 22, 2024 Reviewer Report No.: GTS2024010037F01 Global United Technology Services Co., Ltd. No. 123- …

Text truncated - open the document above for the full version.
