2AWS3CCM10404715CMM10404715

Koenig & Bauer Coding GmbH

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: May 09, 2021
Application Purpose: Original Equipment
Date of Application: May 09, 2021
Equipment Note: CMM10404715
Frequency Range: 13.56000000 - 13.56000000
Company: Koenig & Bauer Coding GmbH
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Coding Technical Manual CCM10404715 Page 1 of 10 Coding Technical Manual 2020/04 Revision 1.3 Technical Manual Consumables Control Module (CCM10404715) Coding Technical Manual CCM10404715 Page 2 of 10 Coding Technical Manual 2020/04 Contents 1. Introduction .......................................................................................................................................... 3 2. System Overview ................................................................................................................................. 4 3. Installation ............................................................................................................................................ 5 4. Operation .............................................................................................................................................. 6 5. Compliance Statements ........................................................................................................................ 7 1. Technical Specification ........................................................................................................................ 9 2. Glossary ............................................................................................................................................. 10 Coding Technical Manual CCM10404715 Page 3 of 10 Coding Technical Manual 2020/04 1. Introduction This document is the user manual for the Koenig & Bauer Coding GmbH Consumables Control Module (short: CCM 10404715). This module is only used in the alphaJET 5 continuous inkjet printer (short AJ5; host product). This module reads the RFID Tags on the consumables to ensure the correct types are used. Read data is provided to the AJ5 printer. Figure 1 grouted CCM10404715 with cable and connector Coding Technical Manual CCM10404715 Page 4 of 10 Coding Technical Manual 2020/04 2. System Overview The CCM10404715 reads data from the RFID Tags on the consumable bottles of the AJ5 printer. The consumable bottles are filled with ink or solvent. Not each solvent can be used with each ink. So the read data prevents the printer from using incorrect ink / solvent combinations. In addition the data read by CCM10404715 provide the operation parameters of the consumables to AJ5 printer. The module is designed for use in the AJ5 printer only. It’s electronic is grouted. The module with cable is resistant against dust and fluids (especially solvents like MEK (Methyl Ethyl Ketone); ethanol and acetone). The CMM10404715 is connected to the printer via a connector (WR- MPC3) with a special pinning. This prevents the module from use in other devices than AJ5 printers. Data read from the Tag is shown in Printer’s GUI. Coding Technical Manual CCM10404715 Page 5 of 10 Coding Technical Manual 2020/04 3. Installation The CCM10404715 is installed following these steps: - Insert CCM10404715 in the bottle cage on the front door. - Use two screws to fix CCM10404715 in the bottle cage - Connect the CCM10404715’s cable to the AJ5 printer Figure 2 CCM10404715installed in bottle cage. After installation you can power up the AJ5 printer See AJ5 user manual for more information. The 5V power source from the printer to the CCM10404715 is limited to 1A under all operating conditions. All safety standards according to IEC/EN 62368-1 are met. Coding Technical Manual CCM10404715 Page 6 of 10 Coding Technical Manual 2020/04 4. Operation The CCM10404715 reads the data from the tags on the consumables cyclic. It also recognizes when a tag is missing. With each add of a consumable, the AJ5 printer increments a counter on the RFID tag. So the printer recognizes when a consumable is empty and generates a message for the user to change the consumable. The level of the consumables is shown in GUI (in percent) Changing a consumable bottle requires the following steps: - Open the front door - Screw up the cap from the empty consumable bottle and remove it (with tube) - Remove the bottle from bottle cage (After a while the printer should recognize the bottle is removed) - Take a new, full consumable bottle (be careful to take a compatible ink or solvent type) and insert it in the bottle cage. Insure that the RFID tag is on the correct side near to the CCM10404715 (After a while the AJ5 printer should recognize the new bottle). - Screw up the cap from the new bottle and insert the cap with tube from the Printer. - Close the cap - Close the front door - Confirm in the Printer’s GUI that the consumable has been changed Coding Technical Manual CCM10404715 Page 7 of 10 Coding Technical Manual 2020/04 5. Compliance Statements USA The CCM10404715 has been tested to FCC 15.209 radiated limits for a class A digital device. The CCM10404715 will be installed within the printer which is tested as a Class A digital device. This device complies with Part 15 of the FCC Rules. Operating is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Coding Technical Manual CCM10404715 Page 8 of 10 Coding Technical Manual 2…

Text truncated - open the document above for the full version.

Cover Letter(s)

Koenig & Bauer Coding GmbH Postfach 11 03 97205 Veitshöchheim Benzstraße 11 97209 Veitshöchheim Tel: 0931 9085-0 Fax: 0931 9085-100 [email protected] coding.koenig-bauer.com Date: Our reference: Tel: +49 931 9085- Fax: +49 931 9085- Your letter of: Your reference: Managing Directors: Oliver Volland German Stuis Registered Office: Veitshöchheim Municipal Court (Amtsgericht) Würzburg Trade Register B 62 VAT Reg. No.: DE271 194906 EORI No: DE7651554 WEEE Reg.-NR: DE 74320044 Commerzbank AG IBAN: DE37 7908 0052 0307 8899 00 BIC: DRESDEFF790 Sparkasse Mainfranken EURO-Account: IBAN: DE35 7905 0000 0046 5861 86 USD-Account: IBAN: DE81 7905 0000 0300 0140 57 BIC: BYLADEM1SWU VR-Bank eG IBAN: DE25 7909 0000 0006 1680 00 BIC: GENODEF1WU1 Limited Modular Approval Request for Model: CCM10404715 FCC ID: 2AWS3CCM10404715 Dear Madam/Sir, The following attestation addresses the requirements to support limited modular approval: Modular approval requirement Yes No* (a) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly  (b) The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal  (c) The module must contain power supply regulation on the module  (d) The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Section 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b)  (e) The module must demonstrate compliance in an stand-alone configuration  (f) The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements))  (g) The module must comply with all specific rules applicable to the transmitter. The grantee must provide comprehensive instructions to explain compliance requirements  (h) The module must comply with RF exposure requirements  *Please provide a detailed explanation if the answer is “No”. 10.03.2021 CS -262 -100 2AWS3 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 2 The module is designed for, and can only work in combination with the host, called AJ5. Shielding and power regulation is provided by the AJ5. The module is mounted permanently inside the AJ5 und connected to the AJ5 by a special cable and connector. Sincerely, i.A. Christian Schmitt, Qualitymanager

Cover Letter(s)

External Photos

Photos of CCM10404715 Page 1 of 8 Coding Technical Manual 2021/03 Revision 1.1 Photos of Consumables Control Module (CCM10404715) Photos of CCM10404715 Page 2 of 8 Coding Technical Manual 2021/03 Contents 1. Photos of PCB CCM10404715 ............................................................................................................ 3 2. Photos of Module and Installation ....................................................................................................... 4 3. Photos of Module and Host Device Typeplate .................................................................................... 7 Photos of CCM10404715 Page 3 of 8 Coding Technical Manual 2021/03 1. Photos of PCB CCM10404715 Picture 1 Top View of CCM10404715 Picture 2 Bottom View of CCM10404715 Photos of CCM10404715 Page 4 of 8 Coding Technical Manual 2021/03 Picture 3 Side View of CCM10404715 2. Photos of Module and Installation Picture 4 Module CCM10404715 Photos of CCM10404715 Page 5 of 8 Coding Technical Manual 2021/03 Picture 5 Installed CCM10404715 Photos of CCM10404715 Page 6 of 8 Coding Technical Manual 2021/03 Picture 6 Installed CCM10404715 Picture 7 Installed CCM10404715 Photos of CCM10404715 Page 7 of 8 Coding Technical Manual 2021/03 3. Photos of Module and Host Device Typeplate Picture 8 Typeplate of CCM10404715 Picture 9 Typeplate of Host Device alphaJET 5 Photos of CCM10404715 Page 8 of 8 Coding Technical Manual 2021/03 Picture 10 Typeplate of Host Device alphaJET 5 Picture 11 Typeplate of Host Device alphaJET 5

External Photos

PAGE 1 OF 5 EMCCons DR. RAŠEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 980535CCD Telephone: +49 9194 7262-0 Telefax: +49 9194 7262-199 Mail: [email protected] Web: http://www.emcc.de ANNEX 2 TO TEST REPORT # EMCC-980535CCD, 2020-09-04 EXTERNAL PHOTOGRAPHS OF EQUIPMENT UNDER TEST EQUIPMENT UNDER TEST: Trade Name: alphaJET 5 Type/Model: HS 1040.6308 Serial Number(s): EUT #1: MI5050-000001 Application: Inkjet printer for industrial applications FCC ID: 2AWS3CCM10404715 Manufacturer: Koenig&Bauer Coding GmbH Address: Benzstraße 11 97209 Veitshoechheim GERMANY Phone: +49 931 9085-262 E-Mail: [email protected] RELEVANT STANDARD(S) : 47 CFR Part 15 C RSS-210 Issue 10 MEASUREMENT PROCEDURE: : ANSI C63.10-2013 ILLUSTRATION LIST ANNEX 2 Photograph A2-1: EUT #1: MI5050-000001 front 2 Photograph A2-2: EUT #1: MI5050-000001 back 2 Photograph A2-3: EUT #1: MI5050-000001 left 3 Photograph A2-4: EUT #1: MI5050-000001 right 3 Photograph A2-5: EUT #1: MI5050-000001 label 4 Photograph A2-6: EUT #1: MI5050-000001 label of potted RFID PCB 4 Photograph A2-7: EUT #1: MI5050-000001 top of potted RFID PCB 5 Photograph A2-8: EUT #1: MI5050-000001 top of potted RFID PCB 5 Annex 2 to Test Report # EMCC-980535CCD Page 2 of 5 Issue Date: 2020-09-04 Test on Koenig&Bauer Coding GmbH HS 1040.6308 to 47 CFR Part 15 C © EMCCons DR. RAŠEK GmbH & Co. KG 980535CCD Photograph A2-1: EUT #1: MI5050-000001 front Photograph A2-2: EUT #1: MI5050-000001 back Annex 2 to Test Report # EMCC-980535CCD Page 3 of 5 Issue Date: 2020-09-04 Test on Koenig&Bauer Coding GmbH HS 1040.6308 to 47 CFR Part 15 C © EMCCons DR. RAŠEK GmbH & Co. KG 980535CCD Photograph A2-3: EUT #1: MI5050-000001 left Photograph A2-4: EUT #1: MI5050-000001 right Annex 2 to Test Report # EMCC-980535CCD Page 4 of 5 Issue Date: 2020-09-04 Test on Koenig&Bauer Coding GmbH HS 1040.6308 to 47 CFR Part 15 C © EMCCons DR. RAŠEK GmbH & Co. KG 980535CCD Photograph A2-5: EUT #1: MI5050-000001 label Photograph A2-6: EUT #1: MI5050-000001 label of potted RFID PCB Annex 2 to Test Report # EMCC-980535CCD Page 5 of 5 Issue Date: 2020-09-04 Test on Koenig&Bauer Coding GmbH HS 1040.6308 to 47 CFR Part 15 C © EMCCons DR. RAŠEK GmbH & Co. KG 980535CCD Photograph A2-7: EUT #1: MI5050-000001 top of potted RFID PCB Photograph A2-8: EUT #1: MI5050-000001 top of potted RFID PCB

ID Label/Location Info

Label and Label Location of CCM10404715 Page 1 of 3 Coding Technical Manual 2021/04 Revision 1.1 Label and Label Location of Consumables Control Module (CCM10404715) Label and Label Location of CCM10404715 Page 2 of 3 Coding Technical Manual 2021/04 Contents 1. Photos of Module and Label ................................................................................................................ 3 Label and Label Location of CCM10404715 Page 3 of 3 Coding Technical Manual 2021/04 1. Photos of Module and Label Picture 1 Module CCM10404715 with Label Picture 2 Label of CCM10404715

Internal Photos

PAGE 1 OF 3 EMCCons DR. RAŠEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 980535CCD Telephone: +49 9194 7262-0 Telefax: +49 9194 7262-199 Mail: [email protected] Web: http://www.emcc.de ANNEX 3 TO TEST REPORT # EMCC-980535CCD, 2020-09-04 INTERNAL PHOTOGRAPHS OF EQUIPMENT UNDER TEST EQUIPMENT UNDER TEST: Trade Name: alphaJET 5 Type/Model: HS 1040.6308 Serial Number(s): EUT #1: MI5050-000001, Application: Inkjet printer for industrial applications FCC ID: 2AWS3CCM10404715 Manufacturer: Koenig&Bauer Coding GmbH Address: Benzstraße 11 97209 Veitshoechheim GERMANY Phone: +49 931 9085-262 E-Mail: [email protected] RELEVANT STANDARD(S) : 47 CFR Part 15 C RSS-210 Issue 10 MEASUREMENT PROCEDURE: : ANSI C63.10-2013 ILLUSTRATION LIST ANNEX 3 Photograph A3-1: EUT (SN: EUT #1: MI5050-000001), Top Internal View of RFID PCB 2 Photograph A3-2: (EUT #1: MI5050-000001), Bottom View of PCB of RFID PCB 2 Photograph A3-3: (EUT #1: MI5050-000001), Internal view (Ink and solvent door) 3 Annex 3 to Test Report # EMCC-980535CCD Page 2 of 3 Issue Date: 2020-09-04 Test on Manufacturer Type/Model to 47 CFR §§ 15.107 / 15.109 © EMCCons DR. RAŠEK GmbH & Co. KG 980535CCD Photograph A3-1: EUT (SN: EUT #1: MI5050-000001), Top Internal View of RFID PCB Photograph A3-2: (EUT #1: MI5050-000001), Bottom View of PCB of RFID PCB Annex 3 to Test Report # EMCC-980535CCD Page 3 of 3 Issue Date: 2020-09-04 Test on Manufacturer Type/Model to 47 CFR §§ 15.107 / 15.109 © EMCCons DR. RAŠEK GmbH & Co. KG 980535CCD Photograph A3-3: (EUT #1: MI5050-000001), Internal view (Ink and solvent door)

RF Exposure Info

RF exposure Info – SAR exclusion Document Device Under Test Designation: alphaJET Type: HS 1040.6308 Serial number: EUT #1: MI5050-000001 Device CMM10404715 FCC ID 2AWS3CCM10404715 Manufacturer: Koenig & Bauer Coding GmbH Test Plan: Calculation following KDBs Relevant Standards: KDB 447498 D01, KDB412172 Responsible for the Report: 07.12.2020 Christian Schmitt (Qualitymanager) Date Name (Job Title) Signature Test report: RF Exposure Object: alphaJET Issue Date: 07.12.2020 Page 1/6 Test Report Koenig & Bauer Coding GmbH alphaJET Contents ............................................................................................................................................... 0 0. REVISION HISTORY .......................................................................................................... 2 1. FCC Standalone SAR Test Exclusion of 13.56 MHz Transmitter ......................................... 3 1.1. Considerations in Section 4.3.1. c) of KDB447498 D01 ................................................ 3 1.2. Step a) Threshold result from the Formula in Section 4.3.1 a) ...................................... 3 1.3. Step b) Threshold result from Formula in Section 4.3.1. b) 1); ...................................... 3 1.4. Step c) 1) Threshold result from Formula in Section 4.3.1 c) 1); >50mm and <200mm 3 1.5. SAR Exclusion Result (1g Head or Body) ..................................................................... 4 2. FCC Determination of the Equivalent Isotropically Radiated Power (EIRP) of an RF Transmitting System (KDB412172) ............................................................................................ 5 3. Technical Data of RFID Module ........................................................................................... 6 Test report: RF Exposure Object: alphaJET Issue Date: 07.12.2020 Page 2/6 Test Report Koenig & Bauer Coding GmbH alphaJET 0. REVISION HISTORY Project number Issue date Chapter Description 2020-09-07 n.a. Initial issue 2020-12-07 all Format changes Test report: RF Exposure Object: alphaJET Issue Date: 07.12.2020 Page 3/6 Test Report Koenig & Bauer Coding GmbH alphaJET 1. FCC Standalone SAR Test Exclusion of 13.56 MHz Transmitter 1.1. Considerations in Section 4.3.1. c) of KDB447498 D01 <100 MHz – Separation Distance <=50 mm or Separation distance >50 mm and <200 mm The 1g head or body SAR test exclusion thresholds fo <100 MHz are determined by the following steps: 1.2. Step a) Threshold result from the Formula in Section 4.3.1 a) [(max power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [sqrt(f(GHz)] <= 3.0 for 1g SAR - f(GHz) is the RF channel transmit frequency in GHz - Power and distance are rounded to the nearest mW and mm before calculation - The result is rounded to une decimal place for comparison - When the maximum test separation distance is <5 mm, a distance of 5 mm is applied. Step b) requires formula to be rearranged to give power allowed at numeric threshold at 50 mm test separation distance and Step c) requires f(GHz) to be set to 100MHz (0.1 GHz) giving: [Power threshold] / [50mm] * [sqrt(0.1)] <= 3.0 Step a) Power threshold <= (3.0 * 50 ) / sqrt(0.1) = 474.3mW 1.3. Step b) Threshold result from Formula in Section 4.3.1. b) 1); Power threshold at test separation in mW = [Power threshold at 50mm] + [(Test separation distance – 50mm) * (f(MHz)/150)] - f(MHz) = is the RF channel transmit frequency in MHz - Power and distance are rounded to the nearest mW an mm before calculation - The result is rounded to one decimal place for comparison Power threshold = 474.3 mW + [(test separation distance – 50 mm) * (f(MHz)/150)]mW Steb c) requires f(MHz) to be set do 100 MHz giving: Power threshold = 474.3 MHz + [(test separation distance – 50 mm) * 100 / 150] mW 1.4. Step c) 1) Threshold result from Formula in Section 4.3.1 c) 1); >50mm and <200mm Threshold result from Formula in Section 4.3.1 b) 1) is multiplied by [1+log(100/f(MHz))] Test report: RF Exposure Object: alphaJET Issue Date: 07.12.2020 Page 4/6 Test Report Koenig & Bauer Coding GmbH alphaJET Power threshold = [474.3 mW + (test separation distance – 50mm) * (100/150)] * [1+log(100/f(MHz))] - f(MHz) is the RF channel transmit frequency in MHz - Power and distance are rounded to the nearest mW and mm before calculation - The result ist rounded to one decimal place for comparison 1.5. SAR Exclusion Result (1g Head or Body) Frequency (MHz) Maximum Power (Tune up value)** (mW) Test separation distance (mm)* SAR Exclusion Power Threshold from Section 4.3.1 c) (mW) SAR Test Exclusion (Yes/No) 13.56 0.0000044 77 624.2 Yes *Test separation distance: Measured minimum distance from antenna to any part of the body of a user according to 4.1. f). **Tune up value is the maximum declared output power of the device derived from FCC Determination of the Equivalent Isotropically Radiated Power (EIRP) given in the measurement and calculation in Section 2 of this document. The SAR exclusion threshold has been evaluated using the formula described above from information supplied by the Manufacturer. Based on the calculation above, the EUT os categorically excluded from SAR testing. Test report: RF Exposure Object: alphaJET Issue Date: 07.12.2020 Page 5/6 Test Report Koenig & Bauer Coding GmbH alphaJET 2. FCC Determination of the Equivalent Isotropically Radiated Power (EIRP) of an RF Transmitting System (KDB412172) Section 2.2 Direct calculation from the DUT power measured in a radiated test configuration Section 2.2 states: When the DUT power is measured using a radiated test configuration, the EIRP can be directly determined using the field strength (linear) approach by applying Equotation: EIRP = Pt x Gt = (E x d)²/30 - EIRP is the Equivalent Isotropically Radiated Power in Watts - Pt is the transmittel output power in Watts (not required) - Gt is the numeric gain of the transmitting antenna (unitless, not required) - E is the electrical field s…

Text truncated - open the document above for the full version.

Test Report

EMtrE. trR.RAÉEK PAGEl OT 77 TEST REPORT # EMCC-980535CCD, 2020-09-04 EQUIPMENT UNDERTEST: Trade Name: Type/Model: Serial Number(s): Application: FCC ID: Manufacturer: Address: Phone: E-Mail: RETEVANT STANDARD(S) : MEASUREMENT PROCEDURE: TEST REPORT PREPARED BY: Dominik Krüger EMCCONS DR. RASEK GMbH & CO. KG Boelwiese 8 91320 Ebermannstadt Germany Phone: +499]-947262-0 Fax: +4991947262-199 E-Mail: [email protected] Tested alphaJET 5 HS 1_040.6308 EUT #1: M15050-000001 lnkjet printer for industrial applications 2AWS3CCML040477s Koenig&Bauer Coding GmbH Benzstraße 11 97209 Veitshoechheim GERMANY +49 93L9085-262 christian.sch [email protected] 47 CFR Part 15 C RSS-210 lssue 10 RSS-Gen lssue 5 ANSr C63.10-2013 Approved: "M P /ar^u Dominik Krüger Reinhard Sauerschell EMCCons DR. RASEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 980535CCD ( DAKKS Telephone: +49 9L947262-0 Telefax: +49 91947262L99 Mail: [email protected] Web: www.emcc.de Deutsche Akkred¡tierungsstelle D-Pr-12067-01,03 D-PL-12067-O1-O4 Test Report # EMCC-980535CCD Issue Date: 2020-09-04 Page 2 of 60 Test on Koenig&Bauer Coding GmbH alphaJET 5 to 47 CFR Part 15 C 980535CCD CONTENTS PAGE 0 REVISION HISTORY 4 1 GENERAL INFORMATION 5 Purpose 5 1.1 Limits and Reservations 5 1.2 Test Laboratory 5 1.3 Customer and Manufacturer 5 1.4 Dates and Test Location 6 1.5 Ordering Information 6 1.6 Climatic Conditions 6 1.7 2 PRODUCT DESCRIPTION 7 Equipment Under Test (EUT) 7 2.1 Intended Use 8 2.2 EUT Peripherals/Simulators 8 2.3 Mode of operation during testing and test setup 9 2.4 Modifications required for compliance 9 2.5 3 TEST RESULTS SUMMARY 10 4 DETAILED TEST RESULTS 11 Antenna Requirement 11 4.1 4.1.1 Regulation 11 4.1.2 Test Result 12 AC Power Line Conducted Emissions 13 4.2 4.2.1 Regulation 13 4.2.2 Test Procedures 15 4.2.3 Test Setup 16 4.2.4 Detailed Test Data with antenna connected 17 4.2.5 Detailed Test Data with dummy load in lieu of antenna 18 4.2.6 Test Result 19 Radiated Emissions 20 4.3 4.3.1 Radiated Emissions 9 kHz – 30 MHz 20 4.3.2 Radiated Emissions 30 MHz – 1000 MHz 28 4.3.3 Radiated Emissions above 1000 MHz 35 Spectrum Mask 42 4.4 4.4.1 Regulation 42 4.4.2 Test Procedures 42 4.4.3 Test Setup 43 4.4.4 Measurement Plot(s) 44 4.4.5 Test Result 44 Occupied Bandwidth 45 4.5 4.5.1 Regulation 45 4.5.2 Test Procedures 46 4.5.3 Test Setup 47 Test Report # EMCC-980535CCD Issue Date: 2020-09-04 Page 3 of 60 Test on Koenig&Bauer Coding GmbH alphaJET 5 to 47 CFR Part 15 C 980535CCD 4.5.4 Measurement Plots 48 4.5.5 Test Result 49 Carrier Frequency Stability vs Temperature 50 4.6 4.6.1 Regulation 50 4.6.2 Test Procedures 50 4.6.3 Test Setup 51 4.6.4 Test Result 52 Carrier Frequency Stability vs Supply Voltage 54 4.7 4.7.1 Regulation 54 4.7.2 Test Procedures 54 4.7.3 Test Setup 55 4.7.4 Test Result 56 5 TEST INSTRUMENTS 57 6 MEASUREMENT UNCERTAINTY 59 7 LIST OF ANNEXES 60 Test Report # EMCC-980535CCD Issue Date: 2020-09-04 Page 4 of 60 Test on Koenig&Bauer Coding GmbH alphaJET 5 to 47 CFR Part 15 C 980535CCD 0 REVISION HISTORY Project number Issue date Chapter Description 980535CCD 2020-09-04 n.a. Initial issue Test Report # EMCC-980535CCD Issue Date: 2020-09-04 Page 5 of 60 Test on Koenig&Bauer Coding GmbH alphaJET 5 to 47 CFR Part 15 C 980535CCD 1 GENERAL INFORMATION Purpose 1.1 The purpose of this report is to show compliance with the 47 CFR §15.225 and ISED RSS-210 requirements for the certification of licence-exempt intentional radiators. Limits and Reservations 1.2 The test results in this report apply only to the particular equipment under test (EUT) as declared in this report. This test report shall not be reproduced except in full without the written permission of EMCCons DR. RAŠEK GmbH & Co. KG. Test Laboratory 1.3 Test laboratory: EMCCons DR. RAŠEK GmbH & Co. KG Address of Labs I, II, III EMCCons DR. RAŠEK GmbH & Co. KG and Head Office: Boelwiese 8 91320 Ebermannstadt GERMANY Address of Labs IV and V: EMCCons DR. RAŠEK GmbH & Co. KG Stoernhofer Berg 15 91364 Unterleinleiter GERMANY Phone: +49 9194 7262-0 Fax: +49 9194 7262-199 E-Mail: [email protected] Web: www.emcc.de Customer and Manufacturer 1.4 Company name: Koenig&Bauer Coding GmbH Street: Benzstraße 11 City: 97209 Veitshoechheim Country: GERMANY Name: Christian Schmitt Fax: +49 931 9085-100 Phone: +49 931 9085-262 E-Mail: [email protected] Test Report # EMCC-980535CCD Issue Date: 2020-09-04 Page 6 of 60 Test on Koenig&Bauer Coding GmbH alphaJET 5 to 47 CFR Part 15 C 980535CCD Dates and Test Location 1.5 Date of Receipt of EUT: 2020-02-10 Test Date: 2020-02-17 to 2020-02-20 Test Location: Lab IV Ordering Information 1.6 Purchase Order: 4500122740 Date: 2019-12-06 Vendor-Number: 7000222 Climatic Conditions 1.7 Date Temperature Relative Humidity Air Pressure Lab Customer attended tests -- °C % hPa -- -- 2020-02-17 22 35 977 IV Mr Schmitt 2020-02-18 22 33 984 IV Mr Schmitt 2020-02-19 22 32 975 IV Mr Schmitt 2020-02-20 22 31 980 IV Mr Schmitt Test Report # EMCC-980535CCD Issue Date: 2020-09-04 Page 7 of 60 Test on Koenig&Bauer Coding GmbH alphaJET 5 to 47 CFR Part 15 C 980535CCD 2 PRODUCT DESCRIPTION Equipment Under Test (EUT) 2.1 The following data is based on customer’s information. Manufacturer: Koenig&Bauer Coding GmbH Type: HS 1040.6308 Application: Inkjet printer for industrial applications No of variants: 1 Serial No(s): EUT #1: MI5050-000001 Firmware Version: EUT #1: 4.0.0.2_01_27 Hardware Version: EUT #1: Mainboard: 002, Baseboard: 0x0004, FPGA: 00.11, Controller: 00.21 FCC ID: 2AWS3CCM10404715 Equipment Class: A Highest internal frequency: 1000 MHz (CPU) Carrier frequency: 13.56 MHz Carrier modulation: ASK Type of tag: Passive Power source: 110 – 230 VAC (50 / 60 Hz) Voltage for testing: 120 VAC 60 Hz Remarks: RFID according to ISO 14443A Port Description Length of cable shielded Remarks AC_In Power input n.a. ☐yes / ☒no X1 Signal line (RS232) Max. 10 m ☒yes / ☐no X2 Signal line (digital I/O) Max. 10 m ☒yes / ☐no X3 Signal line Productsenso…

Text truncated - open the document above for the full version.

Test Setup Photos

Text truncated - open the document above for the full version.

Contact Information

Applicant

Christian Schmitt

[email protected]+49 931 9085Fax: +49 931 9085-100

Test Firm

EMCCons Dr. Rasek GmbH & Co.KGChristian Kreller

[email protected]49-9194-7262-0Fax: 49-9194-7262-199

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	13.56 MHz - 13.56 MHz	-

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Limited Single Modular Approval. The radio part of the module is not shielded. The host integrator installing this module into their product must ensure that the final composite product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter operation and should refer to guidance in KDB 996369. This module is limited to be installed/used in products designed by the grantee.
