SD-C9 搜电小程序进入方式微信内点击 + 号 -> 扫一扫 -> 扫描搜电租 借设备二维码 -> 进入小程序； 可通过扫描机柜 / 设备二维码，直接 进入租借充电宝界面。 注：设备类型可分为：机柜、八宝、 彩宝、三宝、密码线；此操作指南以租借彩宝为例。 Small program search electricity into the way WeChat click - > +. Scan - > scan qr code - > search electricity rental equipment into small program; By scanning the two-dimensional code of the cabinet/equipment, you can directly enter the interface of renting charging treasure. Note: Equipment types can be divided into: cabinet, Eight treasure, Color treasure, three treasure, password line; This operational guidelines to rent color treasure as an example. 机柜电源线接入电源，启动机柜，将充电宝装入卡槽即可。The power line of the cabinet can be connected to the power supply, the cabinet can be started, and the charging treasure can be put into the card slot. 在微信 -> 发现 -> 小程序，里面搜索搜电找到并打开； 打开小程序后，可查看附近可租借商铺站点及可租借可租还剩余槽位，点击并前往租借。 注：初次进入搜电小程序时需要获取你的位置信息，如拒绝获取位置，将无法使用地图功能， 无法查看附近可租借商铺站点，仅能通过扫描租借设备二维码进行租借。 In WeChat-> found - > small program, which search power to find and open; After opening the applet, you can view the nearby shops and shops that can be rented and the remaining slots that can be rented. Click and go to rent. Note: enter search electric small progr am for the first time need to get your location information, such as refusing to get position, w ill not be able to use the m ap function, can't see can rent shops nearby sites, can only by scanning bar codes on loan loan equipment. 充电宝租借方式 免押金租借 微信支付分 >550 ，且已商家开通免押金支付 功能 点击免押金租借，进入微信支付分页面，申 请使用微信支付分的“免押租借充电宝”服务； 注：收费规则由商铺决定，并未统一规定。 Charging treasure to loan from the deposit loan WeChat pay > 550, and have been merchants from deposit payment functions click from the deposit loan, enter WeChat pay tabs, apply for to use WeChat pay points "no foregift borrow charging treasure" service; Note: The charge rules are determined by the shop, there is no uniform regulation. 押金租借 押金充值完毕后点击“返回”按 钮，进入充电宝租借中页面；押金会在用户中心的我的钱包中显示。 注：以实际租借时页面的押金金 额为准。 Deposit loan deposit prepaid phone after click the "back" button, enter the charging treasure on loan in the page; The deposit will be displayed in my wallet in the user center. Note: The amount of deposit on the actual rental page shall prevail. 归还设备 租借完成后，请将充电宝按照指示方向推入设备空槽位，等待订单提示已完成且扣款成功即可 离开现场； 如有问题，请及时联系商铺管理人员 / 咨询在线客服 / 拨打 400 客服热线。 Return on loan after the completion of the equipment, please charging tr easure according to the directions into the empty slots, waiting for your order prompt has been completed and can be successfully left the scene; If you have any questions , please contact the store management staff/consult online customer service/call the 400 customer service hotline. 我的客服 在租借过程中遇到任何问题，都可以先查看帮助中心是否能帮您解决；如果帮助中心帮不到 您，请联系在线客服或致电 400-8017-010 ，客服小姐姐 / 小哥哥们都会第一时间帮您解决。 如有其它不同意见需要反馈，可点击“问题反馈”，根据分类选择要反馈的问题，填写完成 后提交即可，后台会有客服专员来处理 ~My customer service any problems encountered in the process of loan, can first s ee if help center can help you to solve; If the help center can't help you, please contact the online custom er service or call 400-8017-010. The little sisters/brothers in the customer service will help you solve the problem at the first time. If you have other different opinions and need feedback, y ou can click "Problem feedback", select the question you want to feedback according to the classification, fill in and submit it after completion, and the customer service s pecialist will deal with the background ~ FCC WarningThis device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turningthe equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:· Reorient or relocate the receiving antenna.· Increase the separation between the equipment and receiver.· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.· Consult the dealer or an experienced radio/TV technician for help.Radiation Exposure StatementThis equipment complies with FCC radiation exposure limits set forth for an uncontrolledenvironment. This equipment should be installed and operated with minimum distance 20cmbetween the radiator and your body.

Shenzhen Zhumang Technology Corporation Agent Authorization Company: Shenzhen Zhumang Technology Corporation Address: Floor 10, Financial Technology Building A, No. 11, Keyuan Road, Yuehai Sub-district, Nanshan, Shenzhen, China Product Name: Stackable multifunction charging station Trade Mark: / Model Number(s): SD-C9, SD-C9 A1B1, SD-C9 A1B2, SD-C9 A1B3, SD-C9 A1B4, SD-C9 A1B5, SD-C9 A1B6, SD-C9 A1B7, SD-C9 A1B8 FCC ID: 2AWTASD-C9 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021-03-08 Name: zhaodong Sheng Title: Quality Manager Company: Shenzhen Zhumang Technology Corporation

Shenzhen Zhumang Technology Corporation Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021-03-08 Subject; Request for Confidentiality FCC ID: 2AWTASD-C9 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements For U-NII Devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: zhaodong Sheng Title: Quality Manager

Authorization Letter To: Shenzhen LCS Compliance Testing Laboratory Ltd. 101, 201 Building A and 301 Building C, Juji Industrial Park, Yabianxueziwei Shajing Street, Baoan District, Shenzhen, 518000, P.R.C. Date: 2021-03-11 Sample Description: Stackable multifunction charging station Model: SD-C9, SD-C9 A1B1, SD-C9 A1B2, SD-C9 A1B3, SD-C9 A1B4, SD-C9 A1B5, SD-C9 A1B6, SD-C9 A1B7, SD-C9 A1B8 Model Declaration: PCB board, structure and internal of these model(s) are the same, the only difference is "4 mobile power loads" and "32 mobile power loads", which only affect the output power of the power supply voltage and are tested for differences. Shenzhen Zhumang Technology Corporation Sheng zhaodong Quality Manager

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 7 External Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 7 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 7 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 4 of 7 Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 5 of 7 Fig.9 Fig.10 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 6 of 7 Fig.11 Fig.12 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 7 of 7 Fig.13 Fig.13 The difference between "4 mobile power loads" and "32 mobile power loads" is only the number of charging bins, and the internal structure of the charging bins is exactly the same.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 1 LABEL AND LOCATION (Size: L3.0m x 2.0cm) Material: Tagboard Glue: adhesive sticker Font color: White Label color: Black Label Location Stackable multifunction charging station Model No.: SD-C9 FCC ID: 2AWTASD-C9

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 12 Internal Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 12 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 12 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 4 of 12 Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 5 of 12 Fig.9 Fig.10 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 6 of 12 Fig.11 Fig.12 WIFI Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 7 of 12 Fig.13 Fig.14 GSM/LTE Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 8 of 12 Fig.15 Fig.16 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 9 of 12 Fig.16 Fig.17 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 10 of 12 Fig.18 Fig.19 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 11 of 12 Fig.20 Fig.21 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD-C9 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 12 of 12 Fig.20 Fig.21 The difference between "4 mobile power loads" and "32 mobile power loads" is only the number of charging bins, and the internal structure of the charging bins is exactly the same.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD‐C9 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 7 Maximum Permissible Exposure Report 1. Product Information FCC ID: 2AWTASD‐C9 Product name Stackable multifunction charging station Test Model SD‐C9 Hardware Version 4C2 Software Version M1.0.7R Power supply Input: 100‐240V~, 50/60Hz, 1.5A Max Output: 5V 2A Max (per. layer) Max. TotalOutput:80W Operation frequency 2.412‐2.462GHz for 2.4G WIFI Channel Number 11 channels for 20MHz bandwidth (2412~2462MHz) Channel Spacing 5MHz Antenna Description PCB Antenna1.5 dBi Support Band GSM 850 (U.S.‐Band) PCS 1900 (U.S.‐Band) Release Version R99 GPRS Class Class 12 EGPRS Class Class 12 Type Of Modulation GMSK for GSM/GPRS; 8PSK for EGPRS Antenna Description Internal Antenna 0 dBi (max.) For GSM 850; 1.5dBi (max.) For PCS 1900. Support Band E‐UTRA Band 2(U.S.‐Band) E‐UTRA Band 4(U.S.‐Band) E‐UTRA Band 5(U.S.‐Band) E‐UTRA Band 12(U.S.‐Band) E‐UTRA Band 13(U.S.‐Band) E‐UTRA Band 14(U.S.‐Band) E‐UTRA Band 66(U.S.‐Band) E‐UTRA Band 71(U.S.‐Band) Internal Antenna 1.5dBi (max.) For E‐UTRA Band 2; 1.5dBi (max.) For E‐UTRA Band 4; 0dBi (max.) For E‐UTRA Band 5; 1.5dBi (max.) For E‐UTRA Band 12; 1.5dBi (max.) For E‐UTRA Band 13; 1.5dBi (max.) For E‐UTRA Band 14; 1.5dBi (max.) For E‐UTRA Band 66; 1.5dBi (max.) For E‐UTRA Band 71. LTE Release Version R8 Type Of Modulation QPSK/16QAM Antenna Description Internal Antenna; 1.5dBi (max.) Power Class Class 3 Extreme temp. Tolerance 0°C to +50°C Extreme vol. Limits 108VAC to 132VAC (nominal: 120VAC) Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Device SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD‐C9 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 7 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far‐field plane‐wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane‐wave equivalent power density SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AWTASD‐C9 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 7 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97‐01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information SD‐C9 can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Notes Antenna PCBAntenna 2400 MHz –5850MHz1.5dBiWiFi Antenna Antenna Internal Antenna 1850~1910 MHz1.5 dBiGSM/ LTEAntenna Antenna Internal Antenna 1710~1755 MHz1.5 dBiLTE Antenna Antenna Internal Antenna 824~849 MHz0 dBiGSM/LTE Antenna Antenna Internal Antenna 669~716 MHz1.5 dBiLTE Antenna Antenna Internal Antenna 777~787 MHz1.5 dBiLTE Antenna Antenna Internal Antenna 788~798 MHz1.5 dBiLTE Antenna Antenna…
