2AWWB-TD01Wireless charger

Fingering Installation Steps Fingering Installation Steps Fingering Installation Steps 1.3 m Double-sided paper torn 2.Stick the fingers in the middle of the phone coil and clean the surface of the phone before bonding to make the two more secure. 2.Adjust the screw cap to the optimal active state 。 3.Press and hold the lock switch open to insert the bracket into the air outlet and loosen the lock switch to lock the air outlet. (* Lock not too strong to avoid damage to support and outlet strips) 。 Step to Use wireless charger 1.Input: The TYPEC connection line is connected to the device, and the finger button cell phone has been installed into the TX slot to charge the state. (* QC3.0 adapter is recommended to avoid incompatibility with the device) Model:TD01 Wireless Charger User Guide 手指扣安装步骤 1.撕去3M离型纸。 2.将手指扣粘贴在手机线圈中间。(请在粘合前清洁手 机表面，让两者更加牢固） 3.按下支架固定开关打开，将托架插入空气出风口，并 松开固定开关锁住出风口（*锁紧不可用力过大，避免 损坏支架或出风口条） 使用无线充电器步骤 1.输入：将TYPEC连接线连接到设备上，并将安装手指扣的 手机出入TX卡槽内进行充电。（*建议使用QC3.0适配器， 避免与此产品识别不兼容） 型号:TD01 车载无线快充 使用说明 感谢您购买和使用此产品！ 请仔细阅读本操作说明，并在使用前妥善保管 产品规格 适用装配 快速无线充电器 输入： 5V, 2A/9V, 2A/12V, 1.67A 输 出： 5W/10W/15W 充电效率：70% 本产品兼容QI标准的所有移动通讯设备。 ! 无线充工作状态 以下情况可能导致故障，如充电慢，停止充电，充电区域 温度过高等。 1.适配器不符合标准/适配器与产品不兼容。 2.充电电缆不合格。 3.手机外壳偏厚（推荐厚度2MM以内） 4.内置无线充电器线圈位置与无线发射充电器位置不一致。 5.手机背面有金属/磁铁。 6.手机本身不支持无线充电功能。 ！ 注意 1.请将充电器原理水或其它液体 2.如果您需要清洁充电器，请确保它没有与电源连接。 3.使用环境温度为-20~45°C。 充电器安装步骤 1.按照箭头安装3部分。 1.将螺帽调整到最佳活动状态。 Product Specification Applicable Devices Fast Wireless Charger Input： 5V, 2A/9V, 2A/12V, 1.67A Output： 5W/10W/15W Charging Efficiency:70% & tĂƌŶŝŶŐ ^ƚĂƚĞŵĞŶƚ ŚĂŶŐĞƐ Žƌ ŵŽĚŝĨŝĐĂƚŝŽŶƐ ŶŽƚ ĞdžƉƌĞƐƐůLJ ĂƉƉƌŽǀĞĚ ďLJ ƚŚĞ ƉĂƌƚLJ ƌĞƐƉŽŶƐŝďůĞ ĨŽƌ ĐŽŵƉůŝĂŶĐĞ ĐŽƵůĚ ǀŽŝĚ ƚŚĞ ƵƐĞƌ͛Ɛ ĂƵƚŚŽƌŝƚLJ ƚŽ ŽƉĞƌĂƚĞ ƚŚĞ ĞƋƵŝƉŵĞŶƚ͘ dŚŝƐ ĞƋƵŝƉŵĞŶƚ ŚĂƐ ďĞĞŶ ƚĞƐƚĞĚ ĂŶĚ ĨŽƵŶĚ ƚŽ ĐŽŵƉůLJ ǁŝƚŚ ƚŚĞ ůŝŵŝƚƐ ĨŽƌ Ă ůĂƐƐ  ĚŝŐŝƚĂů ĚĞǀŝĐĞ͕ ƉƵƌƐƵĂŶƚ ƚŽ WĂƌƚ ϭρ ŽĨ ƚŚĞ & ZƵůĞƐ͘ dŚĞƐĞ ůŝŵŝƚƐ Ăƌ Ğ ĚĞƐŝŐŶĞĚ ƚŽ ƉƌŽ ǀŝĚĞ ƌĞĂƐŽŶĂďůĞ ƉƌŽƚĞĐƚŝŽŶ ĂŐĂŝŶƐƚ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ŝŶ Ă ƌĞƐŝĚĞŶƚŝĂů ŝŶƐƚĂůůĂƚŝŽŶ͘ dŚŝƐ ĞƋƵŝƉŵĞŶƚ ŐĞŶĞƌĂƚĞƐ ƵƐĞƐ ĂŶĚ ĐĂŶ ƌĂĚŝĂƚĞ ƌĂĚŝŽ ĨƌĞƋƵĞŶĐLJ ĞŶĞƌŐLJ ĂŶĚ͕ ŝĨ ŶŽƚ ŝŶƐƚĂůůĞĚ ĂŶĚ ƵƐĞĚ ŝŶ ĂĐĐŽƌĚĂŶĐĞ ǁŝƚŚ ƚŚĞ ŝŶƐƚƌƵĐƚŝŽŶƐ͕ ŵĂLJ ĐĂƵƐĞ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ƚŽ ƌĂĚŝŽ ĐŽŵŵƵŶŝĐĂƚŝŽŶƐ͘ ,ŽǁĞǀĞƌ͕ ƚŚĞƌĞ ŝƐ ŶŽ ŐƵĂƌĂŶƚĞĞ ƚŚĂƚ ŝŶƚĞƌĨĞƌĞŶĐĞ ǁŝůů ŶŽƚ ŽĐĐƵƌ ŝŶ Ă ƉĂ ƌƚ ŝĐƵůĂƌ ŝŶƐƚĂůůĂƚŝŽŶ͘ /Ĩ ƚŚŝƐ ĞƋƵŝƉŵĞŶƚ ĚŽĞƐ ĐĂƵƐĞ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ƚŽ ƌĂĚŝŽ Žƌ ƚĞůĞǀŝƐŝŽŶ ƌĞĐĞƉƚŝŽŶ͕ ǁŚŝĐŚ ĐĂŶ ďĞ ĚĞƚĞƌŵŝŶĞĚ ďLJ ƚƵƌŶŝŶŐ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ŽĨĨ ĂŶĚ ŽŶ͕ ƚŚĞ ƵƐĞƌ ŝƐ ĞŶĐŽƵƌĂŐĞĚ ƚŽ ƚƌLJ ƚŽ ĐŽƌƌĞĐƚ ƚŚĞ ŝŶƚĞƌĨĞƌĞŶĐĞ ďLJ ŽŶĞ Žƌ ŵŽƌĞ ŽĨ ƚŚĞ ĨŽůůŽǁŝŶŐ ŵĞĂƐƵƌĞƐ͗ ‐‐ ZĞŽƌŝĞŶƚ Žƌ ƌĞůŽĐĂƚĞ ƚŚĞ ƌ ĞĐĞŝǀŝŶŐ ĂŶƚ ĞŶŶĂ͘ ‐‐ /ŶĐƌĞĂƐĞ ƚŚĞ ƐĞƉĂƌĂƚŝŽŶ ďĞƚǁĞĞŶ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ĂŶĚ ƌĞĐĞŝǀĞƌ͘ ‐‐ ŽŶŶĞĐƚ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ŝŶƚŽ ĂŶ ŽƵƚůĞƚ ŽŶ Ă ĐŝƌĐƵŝƚ ĚŝĨĨĞƌĞŶƚ ĨƌŽŵ ƚŚĂƚ ƚŽ ǁŚŝĐŚ ƚŚĞ ƌĞĐĞŝǀĞƌ ŝƐ ĐŽŶŶĞĐƚĞĚ͘ ‐‐ ŽŶƐƵůƚ ƚŚĞ ĚĞĂůĞƌ Žƌ ĂŶ ĞdžƉĞƌŝĞŶĐĞĚ ƌĂĚŝŽͬds ƚĞĐŚŶŝĐŝĂŶ ĨŽƌ ŚĞůƉ͘ dŚŝƐĚĞǀŝĐĞĐŽŵƉůŝĞƐǁŝƚŚƉĂƌƚϭρŽĨƚŚĞ&ZƵůĞƐ͘KƉĞƌĂƚŝŽŶŝƐƐƵďũĞĐƚƚŽƚŚĞĨŽůůŽǁŝŶŐƚǁŽĐŽŶĚŝƚŝŽŶƐ͗ ;ϭͿdŚŝƐĚĞǀŝĐĞŵĂLJŶŽƚĐĂƵƐĞŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ͕ĂŶĚ;ϮͿƚŚŝƐĚĞǀŝĐĞŵƵƐƚĂĐĐĞƉƚĂŶLJŝŶƚĞƌĨĞƌĞŶĐĞƌĞĐĞŝ ǀĞĚ͕ŝŶĐůƵĚŝŶŐŝŶƚĞƌĨĞƌĞŶĐĞƚŚĂƚŵĂLJĐĂƵƐĞƵŶĚĞƐŝƌĞĚŽƉĞƌĂƚŝŽŶ͘

Shenzhen Dongyuda Technology Co. LTD Agent Authorization Company : Shenzhen Dongyuda Technology Co. LTD Address: 2 / F, No. 11, Tongfuyu Industrial Zone, Xinhe Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China Product Name: Wireless charger Model Number(s): TD01, TD02, TD03, TD04, TD05, TD06, TD07, TD08, TD09, TD10 Product Description: Wireless charger We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: D ate: Jul. 13, 2020 Name: gengxiong he Title: General manager Company: Shenzhen Dongyuda Technology Co. LTD

Letter of Declaration Company: Shenzhen Dongyuda Technology Co. LTD Address: 2 / F, No. 11, Tongfuyu Industrial Zone, Xinhe Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China Product Name: Wireless charger Model Number: TD01 FCC Identifier: 2AWWB-TD01 Compliant with KDB680106 D01 RF Exposure Wireless Charging Apps v03 section 5,b： (1) Power transfer frequency is less than 1 MHz. -The device operate in the frequency range 125KHz. (2) Output power from each primary coil is less than or equal to 15 watts. -The maximum output power of the primary coil is 15W (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow c oupling only between individual pairs of coils. -The transfer system including only single primary coil. (4) Client device is placed directly in contact with the transmitter. -The EUT is placed directly in contact with the transmitter (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). - Yes, The product is only mobile device. (6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. - The EUT meet the conditions. Name: gengxiong he Date: Jul. 13, 2020 Title: General manager Signature of applicant:

Shenzhen Dongyuda Technology Co. LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jul. 13, 2020 Subject; Request for Confidentiality FCC ID: 2AWWB-TD01 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: gengxiong he Title: General manager

Model Difference Declaration To Whom It May Concern, We, Shenzhen Dongyuda Technology Co. LTD(Wireless charger) Trademark:N/A; Model Number: TD01, TD02, TD03, TD04, TD05, TD06, TD07, TD08, TD09, TD10 ;All model’s the function, software and electric c ircuit are the same, only with a product model named different for commercial purpose. Test sample model: TD01. Please contact me if you have any question. Name: gengxiong he Date:Jul. 13, 2020 Title: General manager Signature of applicant:

Annex A External Photos Test Model No.: TD01 Page 1 of 4 Test Model No.: TD01 Page 2 of 4 Test Model No.: TD01 Page 3 of 4 Test Model No.: TD01 Page 4 of 4

FCC ID LABEL: Label Location Width: 2cm Long: 4cm FCC ID: 2AWWB-TD01 Product name: Wireless charger Model No.: TD01 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

Annex B Internal Photo Test Model No.: TD01 Page 1 of 3 Test Model No.: TD01 Page 2 of 3 Antenna Test Model No.: TD01 Page 3 of 3

Page 1 of 21 Report No.: HK2006091308-1E FCC TEST REPORT Test report On Behalf of Shenzhen Dongyuda Technology Co. LTD For Wireless charger Model No.: TD01, TD02, TD03, TD04, TD05, TD06, TD07, TD08, TD09, TD10 FCC ID: 2AWWB-TD01 Prepared for : Shenzhen Dongyuda Technology Co. LTD 2 / F, No. 11, Tongfuyu Industrial Zone, Xinhe Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Jun. 10, 2020 ~Jun. 17, 2020 Date of Report: Jun. 17, 2020 Report Number: HK2006091308-1E Page 2 of 21 Report No.: HK2006091308-1E TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Dongyuda Technology Co. LTD Address ................................. : 2 / F, No. 11, Tongfuyu Industrial Zone, Xinhe Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China Manufacture's Name ............ : Shenzhen Dongyuda Technology Co. LTD Address ................................. : 2 / F, No. 11, Tongfuyu Industrial Zone, Xinhe Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China Product description Trade Mark: N/A Product name ........................... : Wireless charger Model and/or type reference : TD01, TD02, TD03, TD04, TD05, TD06, TD07, TD08, TD09, TD10 Standards ............................. : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Jun. 10, 2020 ~Jun. 17, 2020 Date of Issue ........................................... : Jun. 17, 2020 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 21 Report No.: HK2006091308-1E Table of Contents Page 1 . TEST SUMMARY 5 1.1 TEST PROCEDURES AND RESULTS 5 1.2 TEST FACILITY 5 1.3 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 General Description of EUT 6 2.2. Carrier Frequency of Channels 7 2.3 Operation of EUT during testing 7 2.4 Description of Test Setup 7 2.5 Measurement Instruments List 8 3. CONDUCTED EMISSION TEST 9 3.1 Block Diagram of Test Setup 9 3.2 Conducted Power Line Emission Limit 9 3.3 Test Procedure 9 4. Occupied Bandwidth 12 4.1 Block Diagram of Test Setup 12 4.2 Rules and specifications 12 4.3 Test Procedure 12 4.4 Test Result 13 5. RADIA TED EMISSIONS 14 5.1 Block Diagram of Test Setup 14 5.2 Rules and specifications 15 5.3 Test Procedure 16 5.4 Test Result 16 6 ANTENNA REQUIREMENT 19 7. PHOTOGRAPH OF TEST 20 7.1 Radiated Emission 20 8 PHOTOS OF THE EUT 21 Page 4 of 21 Report No.: HK2006091308-1E ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release Jun. 17, 2020 Jason Zhou Page 5 of 21 Report No.: HK2006091308-1E 1. TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS DESCRIPTION OF TEST section number RESULT CONDUCTED EMISSIONS TEST 15.207 COMPLIANT RADIATED EMISSION TEST 15.209 COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT 15.215 COMPLIANT ANTENNA REQUIREMENT 15.203 COMPLIANT Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2 TEST FACILITY Test Firm : Shenzhen HUAK Testing Technology Co., Ltd. Address 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China 1.3 MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 6 of 21 Report No.: HK2006091308-1E 2. GENERAL INFORMATION 2.1 General Description of EUT Equipment Wireless charger Model Name TD01 Serial No. TD02, TD03, TD04, TD05, TD06, TD07, TD08, TD09, TD10 Model Difference All model’s the function, software and electric circuit are the same, only with a product model named different. Test sample model: TD01 Trade Mark N/A FCC ID 2AWWB-TD01 Antenna Type Coil Antenna Antenna Gain 0dBi Operation frequency 125KHz Number of Channels 1 Modulation Type ASK/FSK Power Source Input: 5V, 2A/9V, 2A/12V, 1.67A Ouput: 5W/10W/15W Power Rating Input: 5V, 2A/9V, 2A/12V, 1.67A Ouput: 5W/10W/15W Page 7 of 21 Report No.: HK2006091308-1E 2.2. Carrier Frequency of Channels Operation Frequency each of channel Channel Frequency 1 125KHz 2.3 Operation of EUT during testing Operating Mode The mode is used: Transmitting mode 2.4 Description of Test Setup Operation of EUT during conducted testing and Radiation testing: AC Plug Adapter information Model: HW-059200CHQ Input: 100-240V, 50-60Hz, 0.5A Output: 5VDC, 2A Mobile phone information Model: Samsung S6 The sample was placed (0.8m below 1GHz, 1.5m above 1GHz) above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown…

Text truncated - open the document above for the full version.

Page 1 of 8 Report No.: HK2006091308-2E FCC TEST REPORT Test report On Behalf of Shenzhen Dongyuda Technology Co. LTD For Wireless charger Model No.: TD01, TD02, TD03, TD04, TD05, TD06, TD07, TD08, TD09, TD10 FCC ID: 2AWWB-TD01 Prepared for : Shenzhen Dongyuda Technology Co. LTD 2 / F, No. 11, Tongfuyu Industrial Zone, Xinhe Community, Fuhai Street, Baoan District, Shenzhen, Guangdong, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Jun. 10, 2020 ~Jun. 17, 2020 Date of Report: Jun. 17, 2020 Report Number: HK2006091308-2E Page 2 of 8 Report No.: HK2006091308-2E Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 125 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. SUMMARY OF TEST RESULTS 2.1 Test procedures according to the technical standards: FCC KDB680106 D01 RF Exposure Wireless Charging Apps v03 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01v03 (3)(3) Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 All emissions,radiated(<30M)(9KHz-30MHz) ±2.45dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 3 of 8 Report No.: HK2006091308-2E 2.3 Test Instruments Description Brand Model No. Frequency Range Calibrated Date Calibrated Until Broadband Field Meter NARDA NBM-550 - Dec. 26, 2019 Dec. 25, 2020 Magnetic Field Meter NARDA ELT-400 1 – 400kHz Dec. 26, 2019 Dec. 25, 2020 Magnetic Probe NARDA HF-3061 300kHz – 30MHz Dec. 26, 2019 Dec. 25, 2020 Magnetic Probe NARDA HF-0191 27 – 1000MHz Dec. 26, 2019 Dec. 25, 2020 Broadband Field Meter NARDA NBM-550 - Dec. 26, 2019 Dec. 25, 2020 Electric Field Meter COMBINOVA EFM 2005Hz – 400kHz Dec. 26, 2019 Dec. 25, 2020 E-Field Probe NARDA EF-0391 100kHz – 3GHz Dec. 26, 2019 Dec. 25, 2020 E-Field Probe NARDA EF-6091 100MHz – 60GHz Dec. 26, 2019 Dec. 25, 2020 NOTE: 1. The calibration interval of the above test instruments is 12 months . Page 4 of 8 Report No.: HK2006091308-2E 3. MAXIMUM PERMISSIBLE EXPOSURE 3.1 MAXIMUM PERMISSIBLE EXPOSURE Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310, 680106 D01 RF Exposure Wireless Charging Apps v03 Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 5 of 8 Report No.: HK2006091308-2E 4. TEST PROCEDURE a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 15cm, H-field strengths of top side is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. 4.1 TEST SETUP 4.2 RESULT OF MAXIMUM PERMISSIBLE EXPOSURE Page 6 of 8 Report No.: HK2006091308-2E For Full load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.29 1.45 1.33 1.74 1.52 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.44 0.63 0.21 0.52 0.42 1.63 For Half Load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.52 1.44 1.63 1.22 1.72 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.47 0.66 0.29 0.33 0.63 1.63 Page 7 of 8 Report No.: HK2006091308-2E For No load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.44 1.73 1.55 1.19 1.42 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.22 0.53 0.44 0.63 0.33 1.63 Remark: According KDB 680106 D01 RF Exposure Wireless Charging App v03, section 5, b). The aggregate H-field strengths at 15 cm surrounding the device and 20 …

Text truncated - open the document above for the full version.

Conducted Emission Radiated Emissions
