2AWXQ-CA-1500CA Essential Micro Docking Station

Quick Start Guide www.CyberAcoustics.com CA P/N: DS1500 Rev. A00 2020-09 Micro Docking Station In the Package Quick-Start Guide Micro Docking Station CA Essential Micro Docking Station Quick Start Guide www.CyberAcoustics.com Micro Docking Station CA P/N: DS1000 Rev. A00 2020-09 Table of Contents Using the CA Essential Micro Docking Station with Your Laptop Using CA Essential Micro Docking Station with an Optional USB Type C AC Power Adapter (Not Included) to Wirelessly Charge your Device Using CA Essential Micro Docking Station with your Laptop and an Optional USB Type C AC Power Adapter (Not Included) Configurations and Power Delivered to CA Essential Micro Docking Station Ports Technical Specifications Frequently Asked Questions Contacting Customer Support Safety and Precautions Pages 1 2 3 4 5 6 - 7 8 9 - 11 Page 1 Step 1: Insert the end of the USB Type C Docking Station Cable into the USB Type C port on your Laptop as show below. Using the CA Essential Micro Docking Station with Your Laptop USB Type A Gen 2 Port USB Type C Connection HDMI Connection to a TV or Monitor Step 2: Connect your Peripherals to the CA Essential Micro Docking Station. Step 3: Place your device supporting Wireless charging on the top of the CA Essential Micro Docking Station. Note: Power available for the attached peripherals and wirelessly charging are dependent on the power supplied by your Laptop. For specic congurations supported and power delivered for the Qi Wirelessly Charger, USB and HDMI ports see page 4. Qi Wireless Charger Page 2 Using CA Essential Micro Docking Station with an Optional USB Type C AC Power Adapter (Not Included) to Wirelessly Charge your Device Step 2: Insert the female end of the AC Power Cable into the connector on the AC Power Adapter as shown and connect the other end of the AC Power Cable in a power source. Step 1: Insert the USB Type C cable of the AC Power Adapter into the USB Type C port on the CA Essential Micro Docking Station. - Standalone wirelessly charging for your devices that support wireless charging (AC Power Adapter purchased separately). Qi Wireless Charger Step 3: Place your device supporting Wireless charging on the top of the CA Essential Micro Docking Station. Page 3 Using CA Essential Micro Docking Station with your Laptop and an Optional USB Type C AC Power Adapter (Not Included) - Power your Laptop computer with the CA Essential Micro Docking Station as well as slowly charge the battery on your laptop. - Connect your peripherals to the CA Essential Micro Docking Station and wirelessly charge your devices. USB Type A Gen 2 Port USB Type C Connection to USB Type C AC Power Adapter HDMI Connection to a TV or Monitor Step 1: Connect CA Essential Micro Docking Station to an USB Type C AC Power Adapter (Purchased separately) as shown on Page 2. Step 2: Connect CA Essential Micro Docking Station to your Laptop. Insert the end of the USB Type C Docking Station Cable into the USB Type C port on your Laptop as show below. Step 3: Connect your Peripherals to the CA Essential Micro Docking Station. Note: Power available for the attached peripherals and wireless charging are dependent on the power supplied by the type of USB Type C AC Power Adapter used. For specic congurations supported and power delivered for the Qi Wireless Charger, the USB and HDMI ports see page 4. Step 4: Place your device supporting wireless charging on the top of the CA Essential Micro Docking Station. Qi Wireless Charger The CA Essential Micro Docking Station supports the connection of peripherals with USB Type A connection, USB Type C connection, a HDMI connection and the charging of your smartphone with the built in Qi Wireless Charger. Depending on how the CA Essential Micro Docking Station receives power, from your laptop or an optional USB Type C Power Adapter, the functionality of the CA Essential Micro Docking Station will vary. Connecting the CA Essential Micro Docking Station to your Laptop for Power (See instructions on page 1) Some Laptops will have a power limitation when connecting the CA Essential Micro Docking Station to your laptop. The limitation of power from the Laptop may not allow the Qi Wireless Charger, USB Type A port, USB Type C port and the HDMI port to be used simultaneously. On these Laptops the Qi Wireless Charger will be disabled when the USB Type A port and USB Type C port are being used. Connecting the CA Essential Micro Docking Station to an Optional USB Type C Power Adapter for Power (See instructions on page 3) When connecting a USB Type C Power Adapter (Sold separately) to the CA Essential Micro Docking Station for power the USB Type A port, USB Type C port, HDMI port and Qi Wireless Charger can all be used at the same time. The time it takes to charge your device with the built in Qi Wireless Charge will vary depending on the power supplied by the USB Type C Power Adapter. Note: When using all the ports on the CA Essential Micro Docking Station and the Qi Wireless Charging at the same time the temperature of the CA Essential Micro Docking Station may become high. If the temperature becomes to high remove the smartphone from the Qi Wireless Charger until the temperature reduces. Congurations and Power Delivered to CA Essential Micro Docking Station Ports Page 4 Page 5 Technical Specication Interface Specication - USB Type A: Supports USB3.1 Gen1 and Gen2 - USB Type C: Supports USB3.1 Gen1 and Gen2 (Power Delivery with USB Data and DP ALT mode) - HDMI: Support HDMI2.0 with HDCP2.3 - Power Delivery: Supports PD3.0 without Fast Power Role Swap - Video output maximum resolutions: - 1 x HDMI 2.0b (2 lanes DP HMR3, 3840 x 2160 @ 60Hz) - 1 x DisplayPort 1.4 (4 lanes DP1.4, 3840 x 2160 @ 60Hz) - Supports HDR10 - Supports DP1.4 with DPCP - Video behavior: If video devices are connected to both the HDMI and the USB Type C ports, the priority is to the HDMI port. Video Output Resolution - Supports 5W Qi wireless charger. - USB Bus Power: Supports 15W (5V/3A) an…

Text truncated - open the document above for the full version.

Luxshare Precision Industry (Chuzhou) Co., Ltd.. Gentlemen: Cover Letter-Wireless Charger Approval Date: 2020-11-13 There’s a Wireless Charging Pad that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, Wireless Charging Pad, with its designed features and specified description, meets special requirements for KDB 680106 D01 section 5.2 requirements. Company: Luxshare Precision Industry (Chuzhou) Co., Ltd. Product Name: CA Essential Micro Docking Station Model Number: DS1500 IC: 26312-CA1500 RSS 216 Section 4 Requirements Product Technical Specification Result a) Power transfer frequency is less that 1 MHz 120-130kHz Complied b) Output power from each primary coil is less than or equal 5 Watts 5 watts Complied c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils Complied d) Client device is inserted in or placed directly in contact with the transmitter Complied e) Mobile exposure conditions only Complied f) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Please refer to RF exposure report. Complied Sincerely, Print Name: Jim Xu Title: EPM Signature: On behalf of Company: Luxshare Precision Industry (Chuzhou) Co., Ltd. Telephone: +86 550 2171868-5479 Email: [email protected]

Luxshare Precision Industry (Chuzhou) Co., Ltd. Date: 2020.09.16 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: ZAWXQ-CA-1500 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Luxshare Precision Industry (Chuzhou) Co., Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Jim Xu Title: EPM Signature: On behalf of Company: Luxshare Precision Industry (Chuzhou) Co., Ltd. Telephone: +86 5502171868 EXT 5479

Luxshare Precision Industry (Chuzhou) Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Company Name： Luxshare Precision Industry (Chuzhou) Co., Ltd. Address：No.8 Yongyang road, National Economic and Technologic Development Zone, Chuzhou, China Regarding: Confidentiality Request regarding application for FCC ID: ZAWXQ-CA-1500 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code) Title: EPM Company Name: Luxshare Precision Industry (Chuzhou) Co., Ltd.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Luxshare Precision Industry (Chuzhou) Co., Ltd. Address No.8 Yongyang road, National Economic and Technologic Development Zone, Chuzhou City, Anhui China Grantee Code 2AWXQ FCC ID 2AWXQ-CA-1500 Authorized Contact Name Jim Xu Contact Email [email protected] Contact Phone +86 5502171868 EXT 5479 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1)labeling the equipment with the exact FCC ID as specified in this application, (2)compliance statement labeling pursuant to the applicable rules, (3)compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1)the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2)the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3)the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2020.09.19 Print Name: Title: EPM *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 4 Page 1 of 4 External Photos Applicant: Luxshare Precision Industry (Chuzhou) Co., Ltd. Address of Applicant: No.8 Yongyang road, National Economic and Technologic Development Zone,Chuzhou City, Anhui China Equipment Under Test (EUT): Product Name: CA Essential Micro Docking Station Model No.: DS1500 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 4 Page 2 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 4 Page 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 4 Page 4 of 4 End

Label location

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 4 Page 1 of 4 Internal Photos Applicant: Luxshare Precision Industry (Chuzhou) Co., Ltd. Address of Applicant: No.8 Yongyang road, National Economic and Technologic Development Zone,Chuzhou City, Anhui China Equipment Under Test (EUT): Product Name: CA Essential Micro Docking Station Model No.: DS1500 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 4 Page 2 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 4 Page 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 4 Page 4 of 4 End

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201001048602 Page: 1 of 12 Keny Xu EMC Laboratory Manager Human Exposure Report Application No.: SZEM2010010486CR (KSEM2009001186CR) FCC ID: 2AWXQ-CA-1500 Applicant: Luxshare Precision Industry (Chuzhou) Co., Ltd. Address of Applicant: No.8 Yongyang road, National Economic and Technologic Development Zone, Chuzhou City, Anhui China Manufacturer: Luxshare Precision Industry (Chuzhou) Co., Ltd. Address of Manufacturer: No.8 Yongyang road, National Economic and Technologic Development Zone, Chuzhou City, Anhui China Factory: LUXSHARE – ICT(Viet Nam)LTD Address of Factory: Lot E, Quang Chau Industrial Park, Quang Chau Village, Viet Yen District, Bac Giang Province, Viet Nam Equipment Under Test (EUT): EUT Name: CA Essential Micro Docking Station Model No.: DS1500 Standards: 47 CFR PART 1, Subpart I, Section 1.1310 Date of Receipt: 2020-09-11 Date of Test: 2020-10-09 to 2020-10-16 Date of Issue: 2020-10-20 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048602 Page: 2 of 12 Revision Record Version Description Date Remark 00 Original 2020-10-20 / Authorized for issue by: Foray Chen /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048602 Page: 3 of 12 2 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 CONTENTS .............................................................................................................................................................. 3 3 GENERAL INFORMATION ................................................................................................................................... 4 3.1 DETAILS OF E.U.T. ..................................................................................................................................................... 4 3.2 DESCRIPTION OF SUPPORT UNITS ............................................................................................................................... 4 3.3 TEST LOCATION ......................................................................................................................................................... 5 3.4 TEST FACILITY ........................................................................................................................................................... 5 3.5 DEVIATION FROM STANDARDS ................................................................................................................................... 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS........................................................................................................ 5 4 EQUIPMENTS USED DURING TEST .................................................................................................................. 6 5 TEST RESULTS ...................................................................................................................................................... 7 5.1 RF EXPOSURE TEST .................................................................................................................................................... 7 5.2 Test Procedure .................................................................................................................................................. 8 5.3 Measurement Data ............................................................................................................................................ 8 6 PHOTOGRAPHS ................................................................................................................................................... 10 6.1 TEST PHOTOS ............................................................................................................................................................ 10 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048602 Page: 4 of 12 3 General Information 3.1 Details of E.U.T. Power supply: DC 5V 3A /DC 20V 4.5A Wireless charging:5W Serial Number N/A Firmware Version: N/A Test voltage: AC 120V/60Hz Antenna Type: Inductive Loop Coil Antenna Modulation Type: FSK Operation Frequency: 120kHz to 130kHz Wireless Output: 5W 3.2 Description of Support Units The EUT has been tested with associated equipment below. Description Manufacturer Model No. Serial No. MACBOOK PRO APPLE A1989 C02Y4AV9JHCD Load N/A N/A N/A Adapter MI ADC6502 MA1000002683898Y04TJ Mobile Phone Apple Iphone 12 N/A Parameter of MACBOOK PRO: MACBOOK PRO Rated Input AC100V-240V 50/60Hz 1500mA Rated Output DC5V by Type-c USB port Parameter of Adapter: Adapter Rated Input AC100V-240V 50/60Hz 1800mA Rated Output 20V,4.5A SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048602 Page: 5 of 12 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Shenzhen, Guangdong, China. 518057. Tel: +86 755 2601 2053 Fax: +86 755 2671 0594 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM201001048601 Page: 1 of 19 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM2010010486CR (KSEM2009001186CR) FCC ID: 2AWXQ-CA-1500 Applicant: Luxshare Precision Industry (Chuzhou) Co., Ltd. Address of Applicant: No.8 Yongyang road, National Economic and Technologic Development Zone, Chuzhou City, Anhui China Manufacturer: Luxshare Precision Industry (Chuzhou) Co., Ltd. Address of Manufacturer: No.8 Yongyang road, National Economic and Technologic Development Zone, Chuzhou City, Anhui China Factory: LUXSHARE – ICT(Viet Nam)LTD Address of Factory: Lot E, Quang Chau Industrial Park, Quang Chau Village, Viet Yen District, Bac Giang Province, Viet Nam Equipment Under Test (EUT): EUT Name: CA Essential Micro Docking Station Model No.: DS1500 Standard(s) : 47 CFR Part 18 Date of Receipt: 2020-09-11 Date of Test: 2020-10-09 to 2020-10-16 Date of Issue: 2020-10-20 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048601 Page: 2 of 18 Revision Record Version Description Date Remark 00 Original 2020-10-20 / Authorized for issue by: Foray Chen /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048601 Page: 3 of 18 2 Test Summary Emission Part Item Standard Method Requirement Result Conducted Emissions at Mains Terminals (150kHz-30MHz) 47 CFR Part 18 FCC OST/MP-5:1986 Class B Pass Radiated Emissions (Magnetic field Strength) (9kHz- 30MHz) 47 CFR Part 18 FCC OST/MP-5:1986 Class B Pass Radiated Emissions (30MHz-1GHz) 47 CFR Part 18 FCC OST/MP-5:1986 Class B Pass SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048601 Page: 4 of 18 3 Contents Page 1 COVER PAGE ............................................................................................................................................. 1 2 TEST SUMMARY ......................................................................................................................................... 3 3 CONTENTS .................................................................................................................................................. 4 4 GENERAL INFORMATION ......................................................................................................................... 5 4.1 DETAILS OF E.U.T. ................................................................................................................................ 5 4.2 DESCRIPTION OF SUPPORT UNITS........................................................................................................... 5 4.3 MEASUREMENT UNCERTAINTY ................................................................................................................ 6 4.4 TEST LOCATION ..................................................................................................................................... 7 4.5 TEST FACILITY ....................................................................................................................................... 7 4.6 DEVIATION FROM STANDARDS ................................................................................................................ 7 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 7 5 EQUIPMENT LIST ....................................................................................................................................... 8 6 EMISSION TEST RESULTS ...................................................................................................................... 10 6.1 CONDUCTED EMISSIONS AT MAINS TERMINALS (150KHZ-30MHZ) ......................................................... 10 6.2 RADIATED EMISSIONS (MAGNETIC FIELD STRENGTH) (9KHZ-30MHZ) ..................................................... 14 6.3 RADIATED EMISSIONS (30MHZ-1GHZ) ................................................................................................. 16 7 TEST SETUP PHOTOGRAPHS ................................................................................................................ 19 8 EUT CONSTRUCTIONAL DETAILS ......................................................................................................... 19 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048601 Page: 5 of 18 4 General Information 4.1 Details of E.U.T. Power supply: DC 5V 3A /DC 20V 4.5A Wireless charging:5W Serial Number N/A Firmware Version: N/A Test voltage: AC 120V/60Hz Antenna Type: Inductive Loop Coil Antenna Modulation Type: FSK Operation Frequency: 120kHz to 130kHz Wireless Output: 5W 4.2 Description of Support Units Description Manufacturer Model No. Serial No. MACBOOK PRO APPLE A1989 C02Y4AV9JHCD Load N/A N/A N/A Adapter MI ADC6502 MA1000002683898Y04TJ Parameter of MACBOOK PRO: MACBOOK PRO Rated Input AC100V-240V 50/60Hz 1500mA Rated Output DC5V by Type-c USB port Parameter of Adapter: Adapter Rated Input AC100V-240V 50/60Hz 1800mA Rated Output 20V,4.5A SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SZEM201001048601 Page: 6 of 18 4.3 Measurement Uncertainty No. Item Measurement Uncertainty 1 Radio Frequency ± 7.25 x 10 -8 2 Duty cycle ± 0.37% 3 Occupied Bandwidth ± 3% 4 Conduction emission ± 3.0dB (150kHz to 30MHz) 5 RF conducted power ± 0.75dB 6 RF power density ± 2.84dB 7 Conducted Spurious emissions ± 0.75dB 8 RF Radiated power ± 4.5dB (Below 1GHz) ± 4.8dB (Above 1GHz) 9 Radiated Spurious emission test ± 4.5dB (Below 1GHz) ± 4.8dB (Above 1GHz) 10 Temperature test ± 1°C 11 Humidity test ± 3% 12 Supply voltages ± 1.5% 13 Time ± 3% Remark: The U lab (lab Uncertainty) is less than U cispr (CISPR Uncertainty), so the test results – compliance…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 4 Page 1 of 4 Test Setup Photos-FCC Applicant: Luxshare Precision Industry (Chuzhou) Co., Ltd. Address of Applicant: No.8 Yongyang road, National Economic and Technologic Development Zone,Chuzhou City, Anhui China Equipment Under Test (EUT): Product Name: CA Essential Micro Docking Station Model No.: DS1500 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS............................................................................................................... 2 2 EQUIPMENT UNDER TEST PICTURES ............................................................ 3 2.1 Conducted Emission Test Setup ....................................................................... 3 2.2 Radiated Emission Test Setup .......................................................................... 3 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 4 Page 3 of 4 2 EQUIPMENT UNDER TEST PICTURES 2.1 Conducted Emission Test Setup 2.2 Radiated Emission Test Setup Below 30MHz SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 4 Page 4 of 4 30MHz to 1GHz End
