2AWXTAIRGRMP70801AIR BASE station

GLOBTEL GIGARAY 70/80 GHZ USER MANUAL AND TECHNICAL SPECIFICATIONS AIR GIGARAY 70 GHz Technical Specification Proprietary & Confidential Maribor, 25 June, 2020 Page 2 of 32 CONTENT 1. FOREWORD ......................................................................................... 3 2. GLOBTEL GIGARAY SOLUTION ................................................................... 5 2.1. General Description ......................................................................... 5 2.1.1. BASE STATION THROUGHPUT ......................................................... 5 2.1.2. SPECTRUM ............................................................................... 6 2.1.3. Base station ............................................................................. 6 2.1.3.1 Sector Antenna ....................................................................... 6 2.1.3.2 General technical specification for base station ................................ 7 2.1.4. DOCSIS platform ........................................................................ 7 2.1.5. LATENCY ................................................................................. 8 3. NETWORK SCHEMATICS ........................................................................... 9 4. PROTOCOLS AND TECHNOLOGY ................................................................ 10 5. BASE STATION INSTALLATION MANUAL ........................................................ 11 5.1 Base station sector ......................................................................... 11 5.1.1. Technical specifications .............................................................. 12 5.1.2. Base station sector assembly ........................................................ 13 5.2 Antenna mounting .......................................................................... 18 5.3 Antenna positioning ........................................................................ 20 5.3.1 Azimuth antenna positioning ........................................................ 20 5.3.2 Elevation antenna positioning ....................................................... 21 5.4 Connections ................................................................................. 24 5.4.1 Pre-Installation requirement summary checklist ................................. 25 5.4.2 Connecting units....................................................................... 26 5.4.3 N-connector installation manual .................................................... 27 5.4.4 M23 Power connector installation manual (outdoor MP side) ................... 28 5.4.5 M23 Power connector installation manual (indoor CPS side) ................... 29 5.4.6 Power supply cable wiring scheme ................................................. 30 5.4.7 RJ45 connector installation with AMPHENOL RJF 6B ............................. 31 5.4.8 Recommended installation steps.................................................... 32 AIR GIGARAY 70 GHz Technical Specification Proprietary & Confidential Maribor, 25 June, 2020 Page 3 of 32 1. FOREWORD IMPORTANT!!!! Before you is a highly technical transmitting device intended to be used on telecommunication towers. Please be aware of following notices and notes. NOTICE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTICE: Changes or modifications made to this equipment not expressly approved by (manufacturer name) may void the FCC authorization to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. NOTE: AIR BASE station INSTALLATION MANUAL covers the initial hardware installation, system maintenance. The procedures described in this manual are intended to help service technicians to install and do initial AIR base station start up. Users who perform these tasks should be familiar with AIR hardware and cabling, wiring practices, and safety precautions. DANGER: Do not intend to do unauthorized repairs. “Danger” do not do repairs when the units are on power. Power off the unit and disconnect the power cable. Not following the procedure permits the existence of a hazard that could result in death or serious bodily injury if the safety instruction is not observed. Improper repair of the units may result in safety hazards. Be sure to fasten screws securely with the right screwdriver. If a screw is not fully fastened, it could come loose, creating a danger of a short circuit, which could cause overheating, smoke or fire. Radiofrequency Radiation Exposure: This device is used on a fixed location in an area not accessible to the general public and only accessible to highly skilled and trained engineers. The radiated output power of the device is far below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact during normal operation is minimized. This equipment should be installed and operated with a minimum distance of 2m between the radiator and your body. AIR GIGARAY 70 GHz Technical Specification Proprietary & Confidential Maribor, 25 June, 2020 Page 4 of 32 AIR GIGARAY 7080G BS This device complies with Part 15 of the FCC Rules. Operat…

Text truncated - open the document above for the full version.

Test report no.: 1-0796/20-01-01_AnnexA Page 1 of 6 Annex A This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorized: Thomas Vogler Lab Manager Radio Communications & EMC Test report no.: 1-0796/20-01-01_AnnexA Page 2 of 6 Ext er nal p ho t o s o f t he EUT Photo 1: Photo 2: Test report no.: 1-0796/20-01-01_AnnexA Page 3 of 6 Photo 3: Photo 4: Test report no.: 1-0796/20-01-01_AnnexA Page 4 of 6 Photo 5: Photo 6: Test report no.: 1-0796/20-01-01_AnnexA Page 5 of 6 Photo 7: Photo 8: Test report no.: 1-0796/20-01-01_AnnexA Page 6 of 6 Do cume nt hist o r y Version Applied changes Date of release Initial release 2020-10-02 final version 2020-10-02

Test report no.: 1-0796/20-01-01_AnnexB Page 1 of 14 Annex B This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorized: Thomas Vogler Lab Manager Radio Communications & EMC Test report no.: 1-0796/20-01-01_AnnexB Page 2 of 14 Int er nal p ho t o s o f t he EUT Photo 1: Photo 2: Test report no.: 1-0796/20-01-01_AnnexB Page 3 of 14 Photo 3: Photo 4: Test report no.: 1-0796/20-01-01_AnnexB Page 4 of 14 Photo 5: Photo 6: Test report no.: 1-0796/20-01-01_AnnexB Page 5 of 14 Photo 7: Photo 8: Test report no.: 1-0796/20-01-01_AnnexB Page 6 of 14 Photo 9: Photo 10: Test report no.: 1-0796/20-01-01_AnnexB Page 7 of 14 Photo 11: Photo 12: Test report no.: 1-0796/20-01-01_AnnexB Page 8 of 14 Photo 13: Photo 14: Test report no.: 1-0796/20-01-01_AnnexB Page 9 of 14 Photo 15: Test report no.: 1-0796/20-01-01_AnnexB Page 10 of 14 Photo 16: Test report no.: 1-0796/20-01-01_AnnexB Page 11 of 14 Photo 17: Test report no.: 1-0796/20-01-01_AnnexB Page 12 of 14 Photo 18: Test report no.: 1-0796/20-01-01_AnnexB Page 13 of 14 Photo 19: Test report no.: 1-0796/20-01-01_AnnexB Page 14 of 14 Do cume nt hist o r y Version Applied changes Date of release Initial release 2020-09-25 final version 2020-10-02

© CTC advanced GmbH Page 1 of 3 BNetzA - CAB - 02/21 - 102 D - P L - 1 2 0 7 6 - 0 1 - 0 3 Maximum Permissible Exposure (MPE) & Exposure evaluation Report identification number: 1-0796/20-01-07 MPE (FCC_ISED) Certification numbers and labeling requirements FCC ID 2AWXTAIRGRMP70801 ISED number -/- HVIN (Hardware Version Identification Number) -/- PMN (Product Marketing Name) -/- FVIN (Firmware Version Identification Number) -/- HMN (Host Marketing Name) -/- This report is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorised: Thomas Vogler Alexander Hnatovskiy Lab Manager Lab Manager Radio Communications & EMC Radio Communications & EMC Report no.: 1-0796/20-01-07 © CTC advanced GmbH Page 2 of 3 EUT technologies: Technologies: Max. measured EIRP: [dBm] Max. antenna gain: Satellite Uplink 70GHz 35.0 dBm < 19.0 dBi NOTE: For detailed test results see CTC advanced test report 1-0796/20-01-02-A Prediction of MPE limit at given distance - FCC Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG / 4π R 2 where: S = Power density P = Power input to the antenna G = Antenna gain R = Distance to the center of radiation of the antenna PG = Output Power including antenna gain The table below is excerpted from Table 1B of 47 CFR 1.1310 titled “Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure” Frequency Range (MHz) Power Density (mW/cm 2 ) Averaging Time (minutes) 300 -1500 f/1500 30 1500 - 100000 1.0 30 where f = Frequency (MHz) Prediction: worst case Technologies:Satellite Frequency (MHz)70000 PGDeclared max power (EIRP)35dBm RDistance200cm SMPE limit for uncontrolled exposure1 mW/cm 2 Calculated Power density:0.0063mW/cm² Calculated percentage of Limit: 0.63% This prediction demonstrates the following: The power density levels for FCC at a distance of 2m are below the maximum levels allowed by regulations. Report no.: 1-0796/20-01-07 © CTC advanced GmbH Page 3 of 3 Prediction of MPE limit at given distance - ISED RSS-102, general limitations for E- and H- Field Reference levels for general public (uncontrolled environment) exposure to time-varying electric and magnetic fields Prediction: worst case Satellite Frequency 70000 MHz R Distance 200 cm P G Maximum EIRP 35 dBm P G Maximum EIRP 3162.3 mW S Power density 0.06291 W/m² Exclusion Limit from above: 10.00 W/m² Calculated percentage of Limit: 0.63% According to: RSS 102-ISSUE 05 Frequency Range (MHz) Power density (W/m²) Reference Period (minutes) 0.003-10 -- Instantaneous* 0.1-10 -- 6** 1.1-10 -- 6** 10-20 2 6 20-48 8.944 / ƒ 0.5 6 48-300 1.291 6 300-6000 0.02619 × ƒ 0.6834 6 6000-15000 10 6 15000-150000 10 616000 / f 1.2 150000-300000 6.67 × 10 -5 × ƒ 616000 / f 1.2 Note: f is frequency in MHz. * Based on nerve stimulation (NS). ** Based on specific absorption rate (SAR).

BNetzA-CAB-02/21-102 TEST REPORT Test report no.: 1-0796/20-01-02-A Testing laboratory Applicant CTC advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://www.ctcadvanced.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2018-03) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate starting with the registration number: D-PL-12076-01. Globtel Holding d.o.o. Panonska 30 2000 Maribor / SLOVENIA Phone: Contact: Borut Štumberger e-mail: [email protected] Phone: +386 2 620 2 000 Manufacturer Globtel Holding d.o.o. Panonska 30 2000 Maribor / SLOVENIA Test standard/s FCC - Title 47 CFR Part 15 FCC - Title 47 of the Code of Federal Regulations; Chapter I; Part 15 - Radio frequency devices For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: AIR Base Station Model name: AIR GIGARAY 7080G BS FCC ID: 2AWXTAIRGRMP70801 Frequency: 57 – 71 GHz (EUT 70.66 – 70.88 GHz) Antenna: Sector horn antenna V and H polarization, ~19 dBi Power supply: 48 V DC ±15% Temperature range: -30°C to +70°C This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorized: Test performed: Sebastian Janoschka Thomas Vogler Lab Manager Lab Manager Radio Communications & EMC Radio Communications & EMC Test report no.: 1-0796/20-01-02-A © CTC advanced GmbH Page 2 of 49 1 Table of contents 1 Table of contents ..................................................................................................................................... 2 2 General information ................................................................................................................................. 3 2.1 Notes and disclaimer ..................................................................................................................... 3 2.2 Application details ......................................................................................................................... 3 2.3 Test laboratories sub-contracted.................................................................................................. 3 3 Test standard/s, references and accreditations ..................................................................................... 4 4 Test environment ..................................................................................................................................... 4 5 Test item ................................................................................................................................................... 5 5.1 General description ....................................................................................................................... 5 5.2 Additional information................................................................................................................... 5 6 Sequence of testing ................................................................................................................................. 6 6.1 Sequence of testing radiated spurious 9 kHz to 30 MHz ............................................................. 6 6.2 Sequence of testing radiated spurious 30 MHz to 1 GHz............................................................. 7 6.3 Sequence of testing radiated spurious 1 GHz to 18 GHz ............................................................. 8 6.4 Sequence of testing radiated spurious above 18 GHz ................................................................. 9 6.5 Sequence of testing radiated spurious above 50 GHz with external mixers ............................ 10 7 Description of the test setup ................................................................................................................. 11 7.1 Shielded semi anechoic chamber ............................................................................................... 12 7.2 Radiated measurements fully anechoic chamber ...................................................................... 13 7.3 Radiated measurements 18 GHz to 50 GHz in test lab............................................................... 14 7.4 Radiated measurements > 50 GHz in test lab............................................................................. 14 8 Measurement uncertainty ...................................................................................................................... 18 9 Far field consideration for measurements above 18 GHz .................................................................... 19 10 Measurement results .......................................................................................................................... 20 10.1 Summary .................................................................................................................................. 20 11 Measurement results .......................................................................................................................... 21 11.1 Occupied bandwidth (99%, 20 dB Bandwidth) ........................................................................ 21 11.2 Maximum E.I.R.P. / Transmitter Output Power ....................................................................... 23 11.3 Spurious emissions radiated................................................................................................... 26 11.4 Frequency Stability .................................................................................................................. 38 12 Glossary ........................................................................…
