2AWZ8-AIR3TWS EARBUDS

Mobiltelefons bedienen. Wenn Sie klicken, um einen Anruf auf Ihrem Mobiltelefon anzunehmen, wird standardmäßig das eingebaute Mikrofon Ihres Mobiltelefons verwendet. Die Nutzung von WhatsApp, Skype, Wechat und anderer Kommunikationssoftware kann durch die Qualität des Mobilfunknetzes beeinträchtigt werden. 5. warum kann ich die Funktion auf den Ohrhörern nicht nutzen? Für diese Funktion muss das Gerät mit den Ohrhörern gekoppelt werden, um AVRCP (Audio/Video-Fernbedienungs- profil) zu unterstützen. Bitte stellen Sie sicher, dass Ihr Gerät dies unterstützt. MANUEL DE L'UTILISATEUR Mise sous tension : Retirez les deux oreillettes de l'étui de chargement. Mise hors tension : Remettre les deux écouteurs dans l'étui de charge Jumelage des écouteurs l'un avec l'autre : Retirez les deux écouteurs de l'étui de chargement, le témoin lumineux des deux écouteurs clignote alternativement, puis attendez que les deux écouteurs s'appairent automatiquement l'un à l'autre (IMPORTANT). Une fois appariés, le témoin lumineux d'un seul écouteur clignote alternativement. Les écouteurs sont maintenant prêts à se connecter à votre appareil. Après la première connexion réussie, la prochaine fois que vous sortirez les écouteurs de l'étui de chargement, ils s'allumeront automatiquement et se connecteront à l'appareil connecté. Lecture/pause : Appuyez une fois sur le bouton L/R pour lire ou mettre en pause la musique. Chansons précédentes/suivantes : Appuyez deux fois sur le bouton L/R pour changer de musique. Répondre à un appel entrant/terminer un appel : Appuyez deux fois sur la touche L/R pour répondre à un appel entrant. Pendant l'appel, appuyez deux fois sur la touche pour mettre fin à l'appel. Rejeter l'appel : Appuyez longuement sur la touche L/R pendant environ 4 secondes pour rejeter l'appel. Assistant vocal : Appuyez trois fois sur le bouton L/R pour contrôler l'assistant vocal. Remarque : votre appareil doit prendre en charge cette fonction. RÉSOLUTION DES PROBLÈMES 1.Pourquoi une seule oreillette peut-elle jouer de la musique ? 1) Vérifiez d'abord dans la liste de votre téléphone si les écouteurs ont déjà été connectés. Si c'est le cas, veuillez d'abord supprimer ou retirer de la liste tous les appareils que vous avez connectés et désactivez la fonction de recherche sur votre téléphone ( PAS déconnecter, mais supprimer ). Placez les écouteurs dans l'étui de chargement. Répétez ensuite les étapes d'appairage. 2)Si le problème ne peut être résolu par le point 1), retirez les deux écouteurs de l'étui de chargement, appuyez sur les boutons L/R 6 fois en même temps, le voyant lumineux des écouteurs clignotera rapidement, puis remettez les écouteurs dans l'étui de chargement. Répétez ensuite les étapes d'appairage. 2.comment changer la langue de l'annonce vocale en anglais ? Lorsque le message vocal est dans une autre langue, déconnectez les écouteurs du téléphone ou supprimez l'appareil que vous avez connecté de la liste, les écouteurs passeront en mode d'appairage, puis appuyez 5 fois sur le bouton pour basculer la langue sur l'anglais. 3. l'appareil demande un pilote/ne peut pas s'appairer Assurez-vous que votre téléphone autorise les nouvelles connexions et que le nombre maximum d'appareils autorisés n'est pas atteint. L'appareil ne peut être utilisé qu'avec des téléphones intelligents (pour IOS, Android), et ne convient pas aux PC, téléviseurs et consoles de jeux. Certains ordinateurs portables peuvent être directement connectés pour être utilisés, s'ils sont invités à télécharger le pilote ou certaines applications, ils ne sont pas compatibles. 4. pourquoi ne puis-je pas utiliser la fonction mains libres ? Répondez aux appels en utilisant les écouteurs au lieu du téléphone portable. Si vous cliquez pour répondre à un appel sur votre téléphone portable, le microphone intégré de votre téléphone portable est utilisé par défaut. L'utilisation de WhatsApp, Skype, Wechat et d'autres logiciels de communication peut être affectée par la qualité de l'appel sur le réseau cellulaire. 5. pourquoi ne puis-je pas utiliser la fonction des oreillettes ? Cette fonction nécessite que l'appareil soit couplé aux écouteurs pour prendre en charge le profil AVRCP (profil de commande à distance audio/vidéo). Veuillez vous assurer que votre appareil est compatible avec cette fonction. MANUALE D'USO Accensione: Estrarre entrambi gli auricolari dalla custodia di ricarica. Spegnimento: Riporre entrambi gli auricolari nella custodia di ricarica. Accoppiamento degli auricolari tra loro: Estrarre entrambi gli auricolari dalla custodia di ricarica, la spia di entrambi gli auricolari lampeggia alternativamente, quindi attendere che i due auricolari si accoppino automaticamente tra loro (IMPORTANTE). Una volta accoppiati, la spia di un solo auricolare lampeggia alternativamente. Ora gli auricolari sono pronti per essere collegati al dispositivo. Dopo il primo collegamento riuscito, la volta successiva basta estrarre gli auricolari dalla custodia di ricarica per accenderli automaticamente e collegarli al dispositivo connesso. Riproduzione/pausa: Premere una volta il pulsante L/R per riprodurre o mettere in pausa la musica. Brani precedenti/successivi: Premere due volte il tasto L/R per cambiare musica. Risposta alle chiamate in arrivo/Fine chiamata: Premere due volte il pulsante L/R per rispondere alla chiamata in arrivo. Durante la chiamata, premere due volte il pulsante per terminare la chiamata. Rifiutare la chiamata: Premere a lungo il tasto L/R per circa 4 secondi per rifiutare la chiamata. Assistente vocale: premere tre volte il tasto L/R per controllare l'assistente vocale. Nota: il dispositivo deve supportare questa funzione. RISOLUZIONE DEI PROBLEMI 1.Perché solo un auricolare può riprodurre la musica 1) Controllare innanzitutto l'elenco del telefono per verificare se gli auricolari sono già stati collegati in precedenza. In caso affermativo, eliminare o rimuovere tutti i dispositivi collegati dall'elenco e disattivare la funzi…

Text truncated - open the document above for the full version.

1 U.SAuthorizedRepresentativeServiceAgreement Thisagreementismadebetween Companyname:ShenzhenSonunTechnologyCo.,LTD Companyaddress:F3,No.37LangkouIndustrialParkLangkouCommunityDalangStreetLonghua DistrictShenzhen UnifiedsocialcreditID:91440300562753311K Productlink:https://www.temu.com/-m-304747997672.html?goods_id =601099515807832&refer_page_name=bgn_verification&refer_page_id=10017_1721119951 130_xzdf2ipyty&refer_page_sn=10017&_x_enter_scene_type=cate_tab&_x_sessn_id=qjczbu cdr1 Legalrepresentative:JuanruLin Companyphonenumber:+8615889588007 F3,No.37LangkouIndustrialParkLangkouCommunityDalangStreet LonghuaDistrictShenzhen Hereafterreferredtoas“<PartyA>”, and Companyname:MarsRegisterAgentLLC Companyaddress:8932MissionDr#207ROSEMEADCAU.S91770 Contactname:JessiePeng Companyphonenumber:+18185797288 Companye-mail:[email protected] CompanyFax:+18186883208 Hereafterreferredtoas“<PartyB>”, Purposeofagreement •<PartyB>hasitsregisteredplaceofbusinessinUniteStates.hereafterreferredtoas “<AREA>”, •<PartyA>intendstoexportcertainproductsinto<UniteStates>. •<PartyB>iswillingtoassist<PartyA>asitsAuthorizedRepresentativeintheAreafor thecontactsbetween<PartyA>andauthoritiesintheArea. Generalterms •<PartyB>isandshallremainanindependentcontractorandisnot andshallnotbedeemedtobeanemployee,jointventure,partneror franchiseeof<PartyA>foranypurposewhatsoever. •<PartyB>isnotappointed,andthisAgreementshallnotbeinterpretedtoimplyits appointment,as“<PartyA>”nor“importer”,nor“distributor”as thosetermsareusedintheDirectives.<PartyB>assumesno responsibility,andexpresslydisclaims,anyliability Com p an y address: 2 hereunderorimpliedbyLawforthefitness,suitability,marketability, safety,functionality,orlegalcomplianceofany<PartyA>product. •<PartyB>shallnotbeliableforanyfailureofdelayinperformance duetoanycausesbeyond<PartyB>’sreasonablecontrol,includingbut notlimitedto,actsofnature,actsofgovernments, internationalunrest,firesandfloods. Responsibilitiesof <PartyB> • Assistingauthoritiesincommunicationswiththeforeignestablishment, •R espondingtoquestionsconcerningtheforeignestablishment'sdevicesthatare importedorofferedforimportintotheUnitedStates, •A ssistingauthoritiesinschedulinginspectionsoftheforeignestablishmentand •I fauthoritiesareunabletocontacttheforeignestablishmentdirectlyorexpeditiously, authoritiesmayprovideinformationordocumentstotheU.S.agent,andsuchan actionshallbeconsideredtobeequivalenttoprovidingthesameinformationor documentstotheforeignestablishment. Pleasenotethat<PartyB>hasnoresponsibilityrelatedtoreportingof adverseevents. AuthorizedRepresentativeStatus •The<PartyA>herebyappoints<PartyB>asitsexclusiveauthorized representativeintheArea. Obligationsof<PartyA • This agreement will be valid for1 year from <Party A> could choose to renew the agreement by then, otherwise this agreement will be terminated automatically. > •Productrecallsandadvisorynotices;<PartyA>isresponsibleforinitiating andexecutingallactivitiesrelatedtoanyproductrecallsand/oradvisorynotices. •Liability;<PartyB>isreleasedby<PartyA>ofanyliabilityrelatingtothegeneral devices manufacturedby<PartyA>.<PartyA>willbefullyresponsiblefortheperformance ofits productsandwillhold<PartyB>harmlessagainstanyliabilityclaimarisingfrom theuseoftheproductsmanufacturedby<PartyA>.Anyliabilitiesfordamagetoany thirdpartyattributedtoservicestipulatedhereinprovidedby<PartyB>,<Party A>shallbearallliabilitiesfordamageandundertaketoexemptany responsibilitiesof<PartyB>toanythirdparty.Ifitisrequiredfor<PartyB>to employanyexpertandcounsel,especiallytoemploylegalcounseltoprovide 3 consultationandlegalagency,<PartyA>shallbearallrelevantfeescausedbythe employmentandpaysuchfeesinadvanceuponrequestof<PartyB>. •Address/contactreference;Informationof<PartyB>canonlybe usedasU.ScontactAgencyon<PartyA>.<PartyA>shallinform<PartyB> whethertorenewthecontract30daysbeforethecontractexpirationdate. •Payment;<PartyA>shallpaythefeeforAuthorizedRepresentativeservice in3Calendardaysonappointedbankaccountorpaymentcollectingaccount. DurationofAgreement ThisAgreementtakeseffectonthedateofitssigningbybothpartiesandwill automaticallyrenewoneachanniversaryunlessterminated(i)byeitherpartyby writtennoticetotheotherwithanoticeperiodofnotlessthanninety(90)days,or(ii) asprovidedinsection‘Termination’below. Termination “MaterialBreach”inthemeaningofthissectionshallincludebutnotbelimitedto: (a)<PartyA>notproviding<PartyB>informationorsupportpursuanttoanexplicit obligationunderthisAgreement;and (b)<PartyA>’snon-fulfilmentofnationallawrequirementscauses <PartyA>toinfringenationaland/or<AREA>law. TheAgreementmaybeterminatedimmediatelybyapartyuponwrittennoticetothe otherpartyofnolessthan(30)daysstatinggroundsconstitutinggoodcause.Good causeshallbedeemedtoexistifthecircumstanceswouldmakeitunreasonablefor thenon-defaultingpartytocontinueperformingtheAgreement,includingoneor moreofthefollowingevents: •theotherpartyfailstopromptlycureaMaterialBreachofthisAgreementnotlater thanthirty (30)daysafternoticereasonablyspecifyingthebreach,and/orfailstoremedythe consequencesofsuchbreach.Ifthedefaultingpartyfailstocurethedefaultwithin saidtimeframe,thisAgreementterminatesautomaticallywithoutfurthernotice; •theotherpartychronicallyengagesinconductorwithholdscooperationina mannerthatmakesthenon-defaultingparty'sperformanceunderthisAgreement untenable; •theotherpartyceasestoconductbusinessinthenormalcourse;becomesinsolvent; makesageneralassignmentforthebenefitofcreditors;suffersorpermitsthe appointmentofareceiver,trustee,orsimilarofficerforitsbusinessorassets; engagesinfraudulenttransfers;orfilesforbankruptcyorprotectionofcreditors. Ifthecontractisterminated,<PartyA>willbeprohibitedfromcontinuingtouse <PartyB>'sinformation,and<PartyB>willtakenecessarymeasurestorandomly selectandtestthat<PartyB>'sinformationhasnotbeenstolenorabusedinthe UnitedStatesregion.Onceitisdiscoveredthat<PartyA>hasillegallyused<Party B>'saddressandotherinformation,<PartyB>hastherighttoresorttolegalmeans andimposeafineofatleast$6000. 4 <Pa…

Text truncated - open the document above for the full version.

Product specification Quick Reference Date All the technical data and information contained herein are subject to change without prior notice Antenna Layout &module on the system board Antenna Gain Gain Table Antenna module on the system board Frequency2.45GHz*1 Ant. Port Input Pwr. (dBm)0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm)-2.3 (Input pwr – loss pwr) Peak EIRP(dBm)1.3 Directivity (dBi)1(all direction antenna) Efficiency (dB)-2.3 (58.5%) Gain (dBi) 1.7 (Peak Gain XZ-plane) Maximum Power (dBm)1.3 (XY-plane) Minimum Power (dBm)-4(XY-plane) Avg. Power (dBm)-0.5(XY-plane) Max/Min Ratio (dB)5.3(XY-plane) Max/Avg Ratio (dB)1.8(XY-plane) Min/Avg Ratio (dB)-3.5(XY-plane) Average Gain (dB)-0.5 (Avg Gain XY-plane) Unit in dBi @2.44GHz XY-planeXZ-planeYZ-plane Efficiency PeakAvg. PeakAvg.PeakAvg. Module Board 1.3-0.51.7-3.81.1-3.0 58.5% Manufacturer: Shenzhen Sonun Technology Co., LTD Address: F3, No. 37 Langkou Industrial Park Langkou Community Dalang Street Longhua District Shenzhen, China SIZE:4mm X1mm ReturnLoss TheEnvironmentofAntennaRadiationPattern 3Dradiationpatterndiagram XY-planeXZ-planeYZ-plane

Page 1 of 7 Report No.: LGT24F073 Appendix - External Photographs of EUT Constructional Details Model: AIR3 Photo 1 Photo 2 Page 2 of 7 Report No.: LGT24F073 Photo 3 Photo 4 Page 3 of 7 Report No.: LGT24F073 Photo 5 Photo 6 Page 4 of 7 Report No.: LGT24F073 Photo 7 Photo 8 Page 5 of 7 Report No.: LGT24F073 Photo 9 Photo 10 Page 6 of 7 Report No.: LGT24F073 Photo 11 Photo 12 Page 7 of 7 Report No.: LGT24F073 Photo 13 Photo 14

Label FCC ID: 2AWZ8-AIR3

Page 1 of 8 Report No.: LGT24F073 Appendix - Internal Photographs of EUT Constructional Details Model: AIR3 Photo 1 Photo 2 Page 2 of 8 Report No.: LGT24F073 Photo 3 Photo 4 ANT Page 3 of 8 Report No.: LGT24F073 Photo 5 Photo 6 Page 4 of 8 Report No.: LGT24F073 Photo 7 Photo 8 Page 5 of 8 Report No.: LGT24F073 Photo 9 Photo 10 Page 6 of 8 Report No.: LGT24F073 Photo 11 Photo 12 ANT Page 7 of 8 Report No.: LGT24F073 Photo 13 Photo 14 Page 8 of 8 Report No.: LGT24F073 Photo 15 Photo 16 ANT

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: TWS EARBUDS Model Name: AIR3, G6S, G7S, G8S, G9S, S10S, Y50, Y60, Y70, Y80, Y90, E50, E60, E70, E80, E90, AIR1, AIR2, AIR3, Air4, Air5, Pro7, Pro8, Pro9, TW01, TWS02, TWS03, TWS04, TWS05, TWS06, TWS07, TWS08 FCC ID: 2AWZ8-AIR3 Issued For : Shenzhen Sonun Technology Co., LTD F3, No. 37 Langkou Industrial Park Langkou Community Dalang Street Longhua District Shenzhen, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24F073HA01 Sample Received Date: Jun. 14, 2024 Date of Test: Jun. 14, 2024 – Jul. 02, 2024 Date of Issue: Jul. 02, 2024 Report No.: LGT24F073HA01 Page 2 of 9 TEST REPORT CERTIFICATION Applicant: Shenzhen Sonun Technology Co., LTD Address: F3, No. 37 Langkou Industrial Park Langkou Community Dalang Street Longhua District Shenzhen, China Manufacture: Shenzhen Sonun Technology Co., LTD Address: F3, No. 37 Langkou Industrial Park Langkou Community Dalang Street Longhua District Shenzhen, China Product Name: TWS EARBUDS Trademark: N/A Model Name: AIR3, G6S, G7S, G8S, G9S, S10S, Y50, Y60, Y70, Y80, Y90, E50, E60, E70, E80, E90, AIR1, AIR2, AIR3, Air4, Air5, Pro7, Pro8, Pro9, TW01, TWS02, TWS03, TWS04, TWS05, TWS06, TWS07, TWS08 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24F073HA01 Page 3 of 9 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 9 Report No.: LGT24F073HA01 Page 4 of 9 Revision History Rev. Issue Date Revisions 00 Jul. 02, 2024 Initial Issue Report No.: LGT24F073HA01 Page 5 of 9 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: TWS EARBUDS Trademark: N/A Model Name: AIR3 Series Model: G6S, G7S, G8S, G9S, S10S, Y50, Y60, Y70, Y80, Y90, E50, E60, E70, E80, E90, AIR1, AIR2, AIR3, Air4, Air5, Pro7, Pro8, Pro9, TW01, TWS02, TWS03, TWS04, TWS05, TWS06, TWS07, TWS08 Model Difference: Regional naming differences. Frequency Bands: Bluetooth 2402 – 2480 MHz Rating: Input: DC 5V 0.3A Battery: Capacity: 30mAh*2+300mAh*1 Rated Voltage: 3.7V Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT24F073HA01 Page 6 of 9 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT24F073HA01 Page 7 of 9 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT24F073HA01 Page 8 of 9 2.3 TEST RESULT Turn up Result Mode Turn up Power BT-GFSK 3±1dBm BT-π/4-DQPSK 3.5±1dBm BT-8DPSK 3.5±1dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result BT 2402 4.50 2.82 0.874 3 0.291 Pass Note: 1. The estimated SAR≤ 3.0 for 1-g SAR, Separation distance ≤ 5mm, complies with the exemption requirements. Report No.: LGT24F073HA01 Page 9 of 9 APPENDIX I - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Note: Please see the attached AIR3_External Photos and AIR3_Internal Photos. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: TWS EARBUDS Model Name: AIR3, G6S, G7S, G8S, G9S, S10S, Y50, Y60, Y70, Y80, Y90, E50, E60, E70, E80, E90, AIR1, AIR2, AIR3, Air4, Air5, Pro7, Pro8, Pro9, TW01, TWS02, TWS03, TWS04, TWS05, TWS06, TWS07, TWS08 FCC ID: 2AWZ8-AIR3 Issued For : Shenzhen Sonun Technology Co., LTD F3, No. 37 Langkou Industrial Park Langkou Community Dalang Street Longhua District Shenzhen, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT24F073RF01 Sample Received Date: Jun. 14, 2024 Date of Test: Jun. 14, 2024 – Jul. 02, 2024 Date of Issue: Jul. 02, 2024 Report No.: LGT24F073RF01 Page 2 of 78 TEST REPORT CERTIFICATION Applicant: Shenzhen Sonun Technology Co., LTD Address: F3, No. 37 Langkou Industrial Park Langkou Community Dalang Street Longhua District Shenzhen, China Manufacturer: Shenzhen Sonun Technology Co., LTD Address: F3, No. 37 Langkou Industrial Park Langkou Community Dalang Street Longhua District Shenzhen, China Product Name: TWS EARBUDS Trademark: N/A Model Name: AIR3, G6S, G7S, G8S, G9S, S10S, Y50, Y60, Y70, Y80, Y90, E50, E60, E70, E80, E90, AIR1, AIR2, AIR3, Air4, Air5, Pro7, Pro8, Pro9, TW01, TWS02, TWS03, TWS04, TWS05, TWS06, TWS07, TWS08 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT24F073RF01 Page 3 of 78 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 30 4.1 LIMIT 30 4.2 TEST PROCEDURE 30 4.3 TEST SETUP 31 4.4 EUT OPERATION CONDITIONS 31 4.5 TEST RESULTS 31 5. NUMBER OF HOPPING CHANNEL 32 5.1 LIMIT 32 5.2 TEST PROCEDURE 32 5.3 TEST SETUP 32 5.4 EUT OPERATION CONDITIONS 32 5.5 TEST RESULTS 32 6. AVERAGE TIME OF OCCUPANCY 33 6.1 LIMIT 33 6.2 TEST PROCEDURE 33 6.3 TEST SETUP 33 6.4 EUT OPERATION CONDITIONS 33 6.5 TEST RESULTS 33 7. HOPPING CHANNEL SEPARATION MEASUREMEN 34 7.1 LIMIT 34 7.2 TEST PROCEDURE 34 Report No.: LGT24F073RF01 Page 4 of 78 7.3 TEST SETUP 34 7.4 EUT OPERATION CONDITIONS 34 7.5 TEST RESULTS 34 8. BANDWIDTH TEST 35 8.1 LIMIT 35 8.2 TEST PROCEDURE 35 8.3 TEST SETUP 35 8.4 EUT OPERATION CONDITIONS 35 8.5 TEST RESULTS 35 9. OUTPUT POWER TEST 36 9.1 LIMIT 36 9.2 TEST PROCEDURE 36 9.3 TEST SETUP 36 9.4 EUT OPERATION CONDITIONS 36 9.5 TEST RESULTS 36 10. ANTENNA REQUIREMENT 37 10.1 STANDARD REQUIREMENT 37 10.2 EUT ANTENNA 37 APPENDIX I - TEST RESULTS 38 DUTY CYCLE 38 MAXIMUM PEAK CONDUCTED OUTPUT POWER 42 -20DB BANDWIDTH 43 OCCUPIED CHANNEL BANDWIDTH 47 CARRIER FREQUENCIES SEPARATION 51 BAND EDGE 55 BAND EDGE(HOPPING) 60 CONDUCTED RF SPURIOUS EMISSION 65 NUMBER OF HOPPING CHANNEL 72 DWELL TIME 74 APPENDIX II - MEASUREMENT PHOTOS 77 APPENDIX III - PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS 78 Report No.: LGT24F073RF01 Page 5 of 78 Revision History Rev. Issue Date Revisions 00 Jul. 02, 2024 Initial Issue Report No.: LGT24F073RF01 Page 6 of 78 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT24F073RF01 Page 7 of 78 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB 9 Emission Bandwidth ±3.2 % Note: The measurement uncertainty is not included in the test result. Report No.: LGT24F073RF01 Page 8 of 78 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: TWS EARBUDS Trademark…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: LGT24F073 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Right earphone Page 2 of 2 Report No.: LGT24F073 Set-up for Conducted Emission
