2AX2YS10Wireless Dog Fence

S28, S10 1. Instructions for use The transmitter 1, plug in the power DC5V, the screen has a digital display, the boot. 2, gear adjustment, press the "+-" key, gear 100-990 feet. 3, the dog out of the transmitter signal transmission range, the receiver will issue a warning. Warning mode: vibrate for 3-5 seconds and then electrostatically shock f or 3-5 seconds. After two cycles, the receiver vibrates and reminds the dog to retur n to the active area with a buzzing sound. 4, when not in use, directly shut down. receiver 1. Press on/key, and the indicator blinks three times, that is, the machine is turned on. 2. When charging, plug in the DC5V power supply, and the indicator light flashes q uickly. When fully charged, the indicator light is steady on. 3. When the power is short, the indicator blinks slowly. 4. When not in use, press the on key to turn off the light. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) thi s device may not cause harmful interference, and (2) thi s device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance co ul d void the user's authority to operate the equipment. NOTE: This equipment has bee n tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed t o provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or r elocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be u sed in portable exposure condition without restriction

SunSun Electronic Technology Inc. Agent Authorization Company: SunSun Electronic Technology Inc. Ltd.Address: 1942 Broadway Street STE 314C Boulder, CO 80302 Product Name: Wireless Dog Fence Model Number(s): S10, S28 Product Description: Wireless Dog Fence We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-06-07 Name: Chen Haolang Title: Manager Company: SunSun Electronic Technology Inc.

SunSun Electronic Technology Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022/06/07 Subject; Request for Confidentiality FCC ID: 2AX2YS10 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chen Haolang Title: Manager

SunSun Electronic Technology Inc. Model Difference Data：2022.06.07 • Product description: Small night light remote control Model name: S10, S28 Trade Name: N/A FCC ID: 2AX2YS10 All the model are the same circuit and RF module, except model names . Regards Sincerely Client’s signature : Client’s name / title : Chen Haolang （Manager） Contact information / address：1942 Broadway Street STE 314C Boulder, CO 80302

External Photos

Model: S10 FCC ID: 2AX2YS10 Label Location

Internal Photos ANT

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220519025RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 29 TEST REPORT Compiled by: Reviewed by: Approved by: Chen Zheng Arron Liu Bin Mei / Director The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Wireless Dog Fence FCC ID: 2AX2YS10 Trademark: N/A Model Number: S10, S28 Prepared For: SunSun Electronic Technology Inc. Address: 1942 Broadway Street STE 314C Boulder, CO 80302 Manufacturer: SunSun Electronic Technology Inc. Address: 1942 Broadway Street STE 314C Boulder, CO 80302 Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: Floor 1&2, Building A, No. 26 of Xinhe Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong China Sample Received Date: May. 10, 2022 Sample tested Date: May. 10, 2022 to May. 19, 2022 Issue Date: May. 19, 2022 Report No.: CTB220519025RFX Test Standards FCC Part15.231 ANSI C63.10:2013 Test Results PASS Remark: This is 433MHz radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220428025RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 29 TABLE OF CONTENT Test Report Declaration Page 1. VERSION............................................................ 3 2. TEST SUMMARY ..................................................... 4 3. MEASUREMENT UNCERTAINTY ....................................... 5 4. PRODUCT INFORMATION AND TEST SETUP ........................... 6 4.1 Product Information ..................................................... 6 4.2 Test Setup Configuration ................................................ 6 4.3 Support Equipment ..................................................... 6 4.4 Test Mode ............................................................. 7 4.5 Test Environment ....................................................... 7 5. TEST FACILITY AND TEST INSTRUMENT USED ......................... 8 5.1 Test Facility ............................................................ 8 5.2 Test Instrument Used ................................................... 8 6. AC POWER LINE CONDUCTED EMISSION ............................. 11 6.1 Block Diagram Of Test Setup............................................ 11 6.2 Limit ................................................................. 11 6.3 Test procedure ........................................................ 11 6.4 Test Result ........................................................... 13 7. RADIATED EMISSION ............................................... 15 7.1 Block Diagram Of Test Setup............................................ 15 7.2 Limit ................................................................. 15 7.3 Test procedure ........................................................ 16 7.4 Test Result ........................................................... 18 8. DWELL TIME ....................................................... 22 8.1 Block Diagram Of Test Setup............................................ 22 8.2 Limit ................................................................. 22 8.3 Test procedure ........................................................ 22 8.4 Test Result ........................................................... 23 9. OCCUPIED BANDWIDTH ............................................. 24 9.1 Block Diagram Of Test Setup............................................ 24 9.2 Limit ................................................................. 24 9.3 Test procedure ........................................................ 24 9.4 Test Result ........................................................... 25 10. ANTENNA REQUIREMENT ........................................... 26 11. EUT PHOTOGRAPHS ................................................ 27 12. EUT TEST SETUP PHOTOGRAPHS ................................... 28 (Note: N/A means not applicable) Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220428025RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 29 1. VERSION Report N o. Issue Date Description Approved CTB220519025RFX May. 19, 2022 Original Valid Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220428025RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 29 2. TEST SUMMARY The Product has been tested according to the following specifications: Test Item Test Requirement Test method Result AC Power Line Conducted Emission 47 CFR Part 15 Subpart C Section 15.207 ANSI C63.10-2013 N/A Radiated Emission 47 CFR Part 15 Subpart C Section 15.209; 15.231(b) ANSI C63.10-2013 PASS Dwell Time 47 CFR Part 15 Subpart C Section 15.231 (a) ANSI C63.10-2013 PASS Occupied Bandwidth 47 CFR Part 15 Subpart C Section 15.231(c) ANSI C63.10-2013 PASS Antenna requirement 47 CFR Part 15 Subpart C Section 15.203 ANSI C63.10-2013 PASS Note:N/A is test does not applicable since deivce is powered by battery. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB220428025RFX Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 5 of 29 3. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the Product as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Item Uncertainty Occupancy bandwidth U=±54.3Hz Conducted output power Above 1G U=±1 .0 dB Conducted output power below 1G U=±0.9dB Power Spectral Density , Conduction U=±1.0dB Conduction spurious emissions U=±2.8dB Out of band emission U=±54Hz 3m camber Radiated spurious emission(9KHz-30MHz) U=±4.8dB 3m camber Radiated spurious emission(30MHz-1GHz) U=±4.3dB 3m …

Text truncated - open the document above for the full version.

Radiated Emission Below 1G Above 1GHz Conducted emissions
