2AX46-SWL100Wireless Audio Dongle

1. Connect your mobile device to your Swivl. 2. Power everything on and open the Swivl app. 3. Update app and firmware if prompted. 4. Connect your Link to your Swivl’s USB port. 5. Visit swivl.com/setup for additional help. Pair your Link Warranty. This product is guaranteed against manufacturing defects for one (1) year from the original date of purchase. Swivl’s sole obligation in the event of such defects during this period is to repair or replace the defective part or product with a comparable part or product. This is done at Swivl’s sole discretion. Except for such replacement, the sale, or other handling of this product is without warranty, condition or other liability even though the defect or loss is caused by negligence or other fault. Damage resulting from use, misuse, accvident, or normal wear and tear is not covered by this or any warranty. Swivl assumes no liability for incidental or consequential damages relating to or resulting from the use of this product or any of its parts. When servicing your warranty request, Swivl may require you to furnish proof of purchase. Visit swivl.com/warranty for details. Carrying and handling. Product contains sensitive components. Do not drop, disassemble, microwave, burn, paint or insert foreign objects into device. Do not use if damaged. Radio frequency interference. This product uses 1.9Ghz wireless technology for wireless audio transmission. High saturation of similar technology in the immediate vicinity may degrade audio. Avoid water. Do not expose this product to water or rain, or handle near wet locations. Do not spill food or liquid on the product. In the case that it gets wet, unplug any cables and allow it to fully dry before 1/6 swivl turning it back on again. Damage due to liquid is not covered. Avoid operation. Do not use this product while driving. Use of this product may be prohibited while travelling in aircraft as it emits radio frequencies during operation. Acceptable temperatures. The product is designed to be used between 0 degrees and 40 degrees C (32 degrees and 104 degrees F). It can be stored between -20 degrees and 50 degrees C (-4 degrees and 122 degrees F). Low or high temperature conditions might lead the product to temporarily stop working, or working properly. Allow unit to return to room temperature after storage at high or low temperatures before operation. RF exposure information and statement. The SAR limit is 1.6 W/kg averaged over one gram of tissue. The device has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for properly worn on the body is 0.21W/kg. This device was tested for typical body-worn operations kept 0 mm from the body. To maintain compliance with FCC/ ISED RF exposure requirements, use accessories that maintain a 0 mm separation distance. The use of accessories that do not satisfy these requirements may not comply with FCC/ISED RF exposure requirements, and should be avoided. La limite SAR est de 1,6 W / kg en moyenne sur un gramme de tissu. L’appareil a également été testé par rapport à cette limite SAR. La valeur DAS la plus élevée 2/6 rapportée dans le cadre de cette norme lors de la certification du produit pour un port correct sur le corps est 0,21 W / kg. Cet appareil a été testé pour des opérations typiques portées sur le corps, gardées à 0 mm du corps. Pour maintenir la conformité avec les exigences d’exposition RF de la FCC / ISED, utilisez des accessoires qui maintiennent une distance de séparation de 0 mm. L’utilisation d’accessoires qui ne satisfont pas à ces exigences peut ne pas être conforme aux exigences d’exposition aux RF de la FCC / ISED et doit être évitée. Body-worn operation. This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 0 mm must be maintained, including the antenna. Accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna. Cet appareil a été testé pour des opérations typiques portées sur le corps. Pour se conformer aux exigences d’exposition RF, une distance de séparation minimale de 0 mm doit être maintenue, y compris l’antenne. Les accessoires utilisés par cet appareil ne doivent contenir aucun composant métallique. Les accessoires portés sur le corps qui ne satisfont pas à ces exigences peuvent ne pas êtrve conformes aux exigences d’exposition aux RF et doivent être évités. Utilisez uniquement l’antenne fournie ou une antenne approuvée. 3/6 FCC statement. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna, increase the separation between the equipment and receiver, connect the equipment into an outlet on a circuit different from that to which the receiver is connected, consult the…

Text truncated - open the document above for the full version.

QA-FR-172-A FCC Confidential Authorization 2020/12/29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2AX46-SWL100 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Swivl hereby requests long-term con fidential treatment of information accompanying this app lication as outlined below: Block Diagram Schematics Operation Description As well as short-term (180 days) confidential treatment of information accompanying this application as outlined below: Internal Photos User’s Manual External Photos Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Amith Vijaykumar Electrical Engineer Swivl 1450 El Camino Real, Menlo Park, CA 94025

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 1 of 4 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 2 of 4 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 3 of 4 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 4 of 4

SWIVL * 1450 EL CAMINO REAL * MENLO PARK, CA, USA * +1 888 837-6209 (T) * WWW.SWIVL.COM swivl TM 1: 1 LINK REAR LABEL - SERIAL NUMBER MC-0060003 KEITH 06.16.20 FIRST RELEASE FOR MP 01 03 MC-00600 02 06.16.20 03 UPDATED FCC & IC INFO 12.09.20 UPDATED FCC & IC INFO, REMOVED ‘CONTAINS’ Model: SWL100 FCC ID: 2AX46-SWL100 IC: 26786-SWL100 Designed in California by Swivl Assembled in China, Patent Pending MC-00600 N136 2031E0001 (SCALE 5X) 14.8 36.8 R0.4 (4X) 12.30.20 Model: SWL100 FCC ID: 2AX46-SWL100 IC: 26786-SWL100 Designed in California by Swivl Assembled in China, Patent Pending MC-00600 N136 2031E0001 SERIAL NUMBER, EFFRA FONT, CENTRE JUSTIFIED - 2031 (SEQUENTIAL: 2031, 2032...2052) FOR PRODUCTION YEAR AND WEEK - E (EVERMUCH) - 0001(SEQUENTIAL SERIAL NO: 0001-9999) NOTES: (UNLESS OTHERWIS E SPECIFIED) 1. INTERPRET DRAWING PER ASME Y14.100-2004 2. MATERIAL: ADHESIVE BACKED BLACK PMS 6C 0.1MM POLYESTER (OR APPROVED EQUIVLENT) LABEL STOCK 3. FINISH: ABRASION PROOF PRINTING 4. DEBUR ALL SHARP EDGES. 5. TOLERANCES: 0.0 +/-0.2 MM 0.00 +/-0.1 MM 0.000 +/-0.05 MM ANGLES +/-1.0 DEG. 6. ALL DIMENSIONS APPLY AFTER FINISH. 7. DRAWING CONTAINS CRITICAL TO FUNCTION DIMENSIONS ONLY. USE THE CAD FILE OF SAME REVISION AS DRAWING CONTROL FOR OTHER FEATURES. IN THE CASE OF A DIFFERENCE BETWEEN THE CAD FILE AND THE DRAWING, USE THE CAD FILE. 8. PARTS TO BE PLACED IN POLY BAG. BAG TO BE MARKED WITH: PART NUMBER; CURRENT REVISION; QUANTITY; P.O. NUMBER; MANUFACTURING DATE; AND VENDOR. 9. SERIAL NUMBER FORMAT: YYWWM#### YY - LAST TWO DIGITS OF CURRENT YEAR WW - CALENDAR WEEKS OF MANUFACTURE M - MANUFACTURER'S CODE #### - SEQUENTIAL NUMBER EXAMPLE: 2031E0001

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 1 of 4 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 2 of 4 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 3 of 4 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: R2011043-RF Page 4 of 4 Antenna 1 Antenna 0

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. SAR TEST REPORT For Swivl, Inc. 1450 El Camino Real Menlo Park, CA 94025 FCC ID: 2AX46-SWL100 IC: 26786-SWL100 Report Type: Original Report Product Type: Swivl Link Report Number: R2011043-20B Report Date: 2021-02-05 Reviewed By: Alvin Huang Lab Mana ger Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F., West Wing, Third Phase of Wanli Industrial Building, Shihua Road, Futian Free Trade Zone, Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: R2011043-20B SAR Test Report 2 of 56 Attestation of Test Results EUT Information EUT Description Swivl Link Tested Model SWL100 FCC ID 2AX46-SWL100 IC 26786-SWL100 Serial Number R2011043-SA-S1 Test Date 2020/12/10 MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) DECT(ANT 0) 1g Body SAR 0.10 1. 6 DECT(ANT 1) 1g Body SAR 0.21 Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques RSS-102 Issue 5 March 2015 Radio Frequency (RF) Exposure Compliance of Radio communication Apparatus (All Frequency Bands). IEC 62209-2:2010 Human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices-Human models, instrumentation, and procedures-Part 2: Procedure to determine the specific absorption rate (SAR) for wireless communication devices used in close proximity to the human body (frequency range of 30 MHz to 6 GHz) KDB procedures KDB 447498 D01 General RF Exposure Guidance v06. KDB 648474 D04 Handset SAR v01r03. KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in FCC 47 CFR part 2.1093 and has been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: R2011043-20B SAR Test Report 3 of 56 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 EUT DESCRIPTION ................................................................................................................................................... 5 TECHNICAL SPECIFICATION ......................................................................................................................................... 5 REFERENCE, STANDARDS, AND GUIDELINES ................................................................................................. 6 SAR LIMITS ................................................................................................................................................................ 7 FACILITIES ................................................................................................................................................................. 8 DESCRIPTION OF TEST SYSTEM .......................................................................................................................... 9 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 15 EQUIPMENTS LIST & CALIBRATION INFORMATION ................................................................................................... 15 SAR MEASUREMENT SYSTEM VERIFICATION ............................................................................................. 16 LIQUID VERIFICATION ............................................................................................................................................... 16 SYSTEM ACCURACY VERIFICATION .......................................................................................................................... 17 EUT TEST STRATEGY AND METHODOLOGY ................................................................................................. 19 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS ............................................................................. 19 TEST DISTANCE FOR SAR EVALUATION ................................................................................................................... 19 SAR EVALUATION PROCEDURE ................................................................................................................................ 20 CONDUCTED OUTPUT POWER MEASUREMENT .......................................................................................... 21 PROVISION APPLICABLE ............................................................................................................................................ 21 TEST PROCEDURE ..............................................................................................................................…

Text truncated - open the document above for the full version.

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15D MEASUREMENT AND TEST REPORT For Swivl, Inc. 1450 El Camino Real Menlo Park, CA 94025 FCC ID: 2AX46-SWL100 Report Type: Original Report Product Type: Swivl Link Re port Number: R2011043-00 Re port Date: 2021-02-09 Reviewed B y: Jacob Kong RF Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F., West Wing, Third Phase of Wanli Industrial Building, Shihua Road, Futian Free Trade Zone, Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: R2011043-00 FCC Part 15D Page 2 of 48 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS ........................................................................................................ 6 EXTERNAL I/O CABLE .................................................................................................................................................. 6 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 7 TEST EQUIPMENT LIST ........................................................................................................................................... 8 FCC §1.1307(B) & §2.1093 - RF EXPOSURE INFORMATION .............................................................................. 9 APPLICABLE STANDARD .............................................................................................................................................. 9 TEST RESULT ............................................................................................................................................................... 9 FCC§15.317 & §15.203 - ANTENNA REQUIREMENT ......................................................................................... 10 APPLICABLE STANDARD ............................................................................................................................................ 10 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 10 FCC§15.315 & §15.207 - CONDUCTED EMISSIONS ............................................................................................ 11 APPLICABLE STANDARD ............................................................................................................................................ 11 EUT SETUP ................................................................................................................................................................ 11 EMI TEST RECEIVER SETUP ....................................................................................................................................... 11 TEST PROCEDURE ...................................................................................................................................................... 12 CORRECTED FACTOR & MARGIN CALCULATION ....................................................................................................... 12 TEST DATA ................................................................................................................................................................ 12 FCC§15.323 (A) - EMISSION BANDWIDTH .......................................................................................................... 15 APPLICABLE STANDARD ............................................................................................................................................ 15 TEST PROCEDURE ........................................…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: R2011043-RF Page 1 of 1 EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions - Side View

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: R2011043-20B Page 1 of 3 APPENDIX B EUT TEST POSITION PHOTOS Liquid depth ≥ 15cm Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 Body Front Setup Photo 5mm Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: R2011043-20B Page 2 of 3 Body Back Setup Photo Body Left Setup Photo 5mm 5mm Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: R2011043-20B Page 3 of 3 Body Right Setup Photo Body Top Setup Photo 5mm 5mm
