73 Specific Absorption Rate (SAR) information: This Smart Phonemeets the government's requirements for exposure to radio waves. The guide lines are basedon standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Smart Phone (FCC ID: 2AX4YM30 ) has also been tested against this SAR limit The highest SAR value reported under this standard during product certification is 1.398W/kg when properly worn on the body. This device was tested for typicalbody-worn operations with the back of the Smart Phone kept 10mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0.1cm separation distance between the user's body andthe back of the Smart Phone. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided very high volume, prolonged listening to a mobile phone can damage your hearing. 73 1) FCC 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2）FCC 15.21 Warning: Changes or modifications to this unit not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 3) FCC 15.105 For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Label: 1,OpentheSmartPhonemaininterfaceandfindtheSettingsinthefigure Step1 2，ClicktheAboutphone Step2 3，ClicktheAboutphoneLegalinformationandclicktheCertification, thefinallabelisshowninthefigure Step3

D O D G EE U S ER M AN U AL T H A N K S F O R C H OO S I N G D O OG EE PR O D UC T S S C A N T H E Q R C O DE FO R M O R E FUN C T I O N I NF OR M A T I O N

Page 211 of 240 Report No.: AiTSZ-260313004FW1 Page 212 of 240 Report No.: AiTSZ-260313004FW1 Page 213 of 240 Report No.: AiTSZ-260313004FW1 Page 214 of 240 Report No.: AiTSZ-260313004FW1 Page 215 of 240 Report No.: AiTSZ-260313004FW1 Page 216 of 240 Report No.: AiTSZ-260313004FW1 Page 217 of 240 Report No.: AiTSZ-260313004FW1 Page 218 of 240 Report No.: AiTSZ-260313004FW1 Page 219 of 240 Report No.: AiTSZ-260313004FW1 Page 220 of 240 Report No.: AiTSZ-260313004FW1 Page 221 of 240 Report No.: AiTSZ-260313004FW1 Page 222 of 240 Report No.: AiTSZ-260313004FW1 Page 223 of 240 Report No.: AiTSZ-260313004FW1 Page 224 of 240 Report No.: AiTSZ-260313004FW1 Page 225 of 240 Report No.: AiTSZ-260313004FW1 Page 226 of 240 Report No.: AiTSZ-260313004FW1 Page 227 of 240 Report No.: AiTSZ-260313004FW1 Page 228 of 240 Report No.: AiTSZ-260313004FW1 Page 229 of 240 Report No.: AiTSZ-260313004FW1 Page 230 of 240 Report No.: AiTSZ-260313004FW1 Page 231 of 240 Report No.: AiTSZ-260313004FW1 Page 232 of 240 Report No.: AiTSZ-260313004FW1 Page 233 of 240 Report No.: AiTSZ-260313004FW1 Page 234 of 240 Report No.: AiTSZ-260313004FW1 Page 235 of 240 Report No.: AiTSZ-260313004FW1 Page 236 of 240 Report No.: AiTSZ-260313004FW1 Page 237 of 240 Report No.: AiTSZ-260313004FW1 Page 238 of 240 Report No.: AiTSZ-260313004FW1 Page 239 of 240 Report No.: AiTSZ-260313004FW1 Appendix E. Justification of the extended calibration If dipoles are verified in return loss (<-20dB, within 20% of prior calibration for below 3GHz, and <-8dB, within 20% of prior calibration for 5GHz to 6GHz), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Head 835MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -42.84 - 50.5 - Feb. 21, 2024 -42.803 0.09 50.592 0.092 Feb. 20, 2025 -42.812 0.07 50.584 0.084 Feb. 19, 2026 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 1800MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -24.53 - 44.8 - Feb. 21, 2024 -24.545 0.06 44.809 0.009 Feb. 20, 2025 -24.540 0.04 44.805 0.005 Feb. 19, 2026 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 1900MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -23.28 - 46.2 - Feb. 21, 2024 -23.518 1.02 46.516 0.316 Feb. 20, 2025 -23.512 1.00 46.511 0.311 Feb. 19, 2026 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 2450MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -29.27 - 53.6 - Feb. 21, 2024 -29.39 0.41 53.742 0.142 Feb. 20, 2025 -29.30 0.10 53.730 0.130 Feb. 19, 2026 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Page 240 of 240 Report No.: AiTSZ-260313004FW1 <Head 2600MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -25.57 - 54.5 - Feb. 21, 2024 -25.248 1.26 54.653 0.153 Feb. 20, 2025 -25.237 1.30 54.642 0.142 Feb. 19, 2026 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 5200MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -9.64 - 25.80 - Feb. 21, 2024 -9.1819 4.75 25.891 0.091 Feb. 20, 2025 -9.1720 4.85 25.874 0.074 Feb. 19, 2026 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 5800MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -14.91 - 38.53 - Feb. 21, 2024 -14.349 3.76 38.715 0.185 Feb. 20, 2025 -14.334 3.86 38.710 0.180 Feb. 19, 2026 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. ※※END OF THE REPORT※※

FCC ID: 2AX4YM30 Test Positions Left Cheek (Separation distance of 0mm) Left Tilt 15 Degree (Separation distance of 0mm) Right Cheek (Separation distance of 0mm) Right Tilt 15 Degree (Separation distance of 0mm) Front Side (Separation distance of 5mm) Back Side (Separation distance of 5mm) Left Side (Separation distance of 5mm) Right Side (Separation distance of 5mm) FCC ID: 2AX4YM30 Top Side (Separation distance of 5mm) Bottom Side (Separation distance of 5mm)

1.1.PhotoofRadiatedEmissionTest(InSemiAnechoicChamber) 30-1000MHz 1.2.PhotoofPowerLineConductedEmissionTest 1.3.RadiatedEmissionsTestPhotos Above1GHz 1.4.ConductedRFTestPhotos

TotalorpartialreproductionofthisdocumentwithoutpermissionoftheLaboratoryisnotallowed.Page 1 of 45 BTFTestingLab(Shenzhen)Co.,Ltd. 101/201/301,Building1,Block2,TantouIndustrialPark,TantouCommunity,SonggangSubdistrict,Bao'anDistrict,Shenzhen,China Email:[email protected]:+86-755-23146130http://www.btf-lab.comVersion:1/00 RFTestReport For ApplicantName:ShenzhenDOOGEEHengtongTechnologyCO.,LTD Address: B,2/F,BuildingA4,SiliconValleyPowerDigitalIndustrialPark,No.22, LonghuaNewDistrict,Shenzhen,China EUTName: SmartPhone BrandName: DOOGEE ModelNumber: M30 SeriesModelNumber: M30Pro,M30Max,M30Ultra,M30Lite,M30SE,M30Power,M30 Play,M30E,M40,M40Pro,M40Plus,M40ProMax,M40Lite, M40SE,M40Turbo,M40Play FCCID:2AX4YM30 IssuedBy Companyname: BTFTestingLab(Shenzhen)Co.,Ltd. Address: 101/201/301,Building1,Block2,TantouIndustrialPark,Tantou Community,SonggangSubdistrict,Bao'anDistrict,Shenzhen,China Reportnumber: BTF260410R00404 Teststandards: FCCCFRTitle47Part15SubpartE(§15.407) Testconclusion: Pass Dateofsample receipt: 2026-01-28 Testdate: 2026-01-28to2026-04-23 Dateofissue: 2026-04-24 Testby: SeanHe/Tester Preparedby: Approved by: ChrisLiu/ProjectengineerRyan.CJ/EMCmanager Note:Allthetestresultsinthisreportonlyrelatedtothetestingsamples.Whichcanbeduplicatedcompletelyforthelegalusewithapprovalof applicant;itshallnotbereproducedexceptinfullwithoutthewrittenapprovalofBTFTestingLab(Shenzhen)Co.,Ltd.,Alltheobjectionsshouldbe raisedwithinthirtydaysfromthedateofissue.Tovalidatethereport,youcancontactus. ReportNumber:BTF260410R00404 TotalorpartialreproductionofthisdocumentwithoutpermissionoftheLaboratoryisnotallowed.Page 2 of 45 BTFTestingLab(Shenzhen)Co.,Ltd. 101/201/301,Building1,Block2,TantouIndustrialPark,TantouCommunity,SonggangSubdistrict,Bao'anDistrict,Shenzhen,China Email:[email protected]:+86-755-23146130http://www.btf-lab.comVersion:1/00 RevisionHistory VersionIssuedateRevisionscontent R_V02026-04-24Original Note:Oncetherevisionhasbeenmade,thenpreviousversionsreportsareinvalid. ReportNumber:BTF260410R00404 TotalorpartialreproductionofthisdocumentwithoutpermissionoftheLaboratoryisnotallowed.Page 3 of 45 BTFTestingLab(Shenzhen)Co.,Ltd. 101/201/301,Building1,Block2,TantouIndustrialPark,TantouCommunity,SonggangSubdistrict,Bao'anDistrict,Shenzhen,China Email:[email protected]:+86-755-23146130http://www.btf-lab.comVersion:1/00 TableofContents 1Introduction...............................................................................................................................................................5 1.1LaboratoryLocation..........................................................................................................................................5 1.2LaboratoryFacility............................................................................................................................................5 1.3Announcement..................................................................................................................................................5 2ProductInformation..................................................................................................................................................6 2.1ApplicationInformation.....................................................................................................................................6 2.2ManufacturerInformation.................................................................................................................................6 2.3FactoryInformation...........................................................................................................................................6 2.4GeneralDescriptionofEquipmentunderTest(EUT)......................................................................................6 2.5TechnicalInformation.......................................................................................................................................7 3TestInformation........................................................................................................................................................8 3.1TestStandards.................................................................................................................................................8 3.2SummaryofTest..............................................................................................................................................8 3.3UncertaintyofTest............................................................................................................................................9 3.4Additionsto,deviations,orexclusionsfromthemethod..................................................................................9 3.5TestAuxiliaryEquipment..................................................................................................................................9 3.6TestEquipmentList..........................................................................................................................................9 4TestConfiguration..................................................................................................................................................11 4.1Testmode.......................................................................................................................................................11 4.2TestChannelofEUT......................................................................................................................................11 4.3Testprocedure................................................................................................................................................13 4.4Testsoftware..................................................................................................................................................13 4.5TestSetupBlock.............................................................................................…
