2AX5E-KF102Remote Control

Remote Control Manual Wireless range If using as part of the Shed and Garage Alarm system, the range of these parts is a minimum of 1 metre, up to a maximum of 70 metres. System activity Please note, when the red light is visible, the product is in processing mode and will not accept further instruction (such as entering of your PIN code). Operation 1. To pair the unit to the main Shed and Garage device MH105, open the battery cover and press the Learn button. Take the Main Unit, remove the battery cover and also press the Learn button on this unit. When the device beeps twice, the pairing has been successful and the alarm can be switched on and off via the remote. 2. If the red light keeps flashing, the battery is low and requires replacing. NOTE: Please repeat this action for pairing the Door Contact also. Battery precautions • Use only CR2032 batteries. • Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment. Incorrect polarity may cause damage to the unit. • Do not mix old and new batteries. • If the alarm is not used for long periods of time, remove the batteries to prevent damage to the unit or injury from possible battery leakage. • Please only use alkaline batteries. KKFF110022RReemmootteeccoonnttrroollooppeerraattiioonnmmaannuuaall WWiirreelleessssrraannggee If using as part of an extended system the range of these parts is a minimum of 1 meter, up to a maximum of 70meters. SSyysstteemmaaccttiivviittyy Please note, when the red light is on the product is processing, so no operation will work (for example, you will not be able to enter your PIN) Product diagram: OOppeerraattiioonn:: 1，Open battery cover，press learn button to send PIN code, select different models of alarms，open the battery cover and press the learn button to learn the code from each other。When you heard the device beep twice, the network is successfully build, and the alarm can be switchedON and OFF by remote control normally. 2，This device is a wirefree accessories designed to work with,a Master unit. PressNO/OFFto control the system accordingly. 3, The red light keeps flashing,this is the‘low battery’indicator. Replace the unit’s batteries. BBaatttteerryypprreeccaauuttiioonnss When using this product follow these precautions at all times; •Use only the appropriate size batteries •Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment. Incorrect polarity may cause damage to the unit •Do not mix old and new batteries •If the alarm is not used for long periods of time,remove the batteries to prevent damage to the unit or injury from possible battery leakage •Do not recharge batteries not intended to be recharged. Always follow the manufacturers directions •Please only use alkaline batteries LED ON OFF LEARN CR2032 Battery 1 2 3 4 5 MODEL NO: KF102 Trusted every day www.yalehome.co.uk Security & Risk Communications Limited, Parkway Business Centre, Ballymount, Dublin, Ireland, 24 ASSA ABLOY Opening Solutions UK & Ireland School Street, Willenhall West Midlands, WV13 3PW UK Version 1A WARNING Do not ingest the battery, Chemical Burn Hazard (The remote control supplied with) This product contains a coin/button cell battery. If the coin/ button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. Declaration of Conformity (RED) Hereby, we, Dongguan Houjie Mosaic Electronics Factory declare that the radio equipment KF102/YSGA02-W is in compliance with Radio Equipment Directive (RED) 2014/53/EU. The relevant harmonized test standards are listed: RF: ETSI EN 300 220-1V3.1.1 (2017-02), ETSI EN 300 220-2 V3.2.1 (2018-06) EMC: ETSI EN 301489-1 V2.2.3(2019-11), ETSI EN 301489-3 V2.1.1(2019-03), EMF: EN 62479:2010;EN 50663:2017 LVD: EN IEC 62368-1:2020+A11:2020 This product can be used in the European market without restriction, meet the requirements of article 10(2) and 10(10) Certificate holder：Dongguan Houjie Mosaic Electronics Factory Shima Industrial Estate, Dajing, Houjie Town, Dongguan 523000, Guangdong, China – FCCComplianceStatement ThisdevicehasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice, pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferenceinresidentialinstallations.Thisequipmentgeneratesusesandcan radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradioandtelevisionreception. However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis devicedoescausesuchinterference,whichcanbeverifiedbyturningthedeviceoffandon,the userisencouragedtoeliminatetheinterferencebyoneormoreofthefollowingmeasures: –Re-orientorre-locatethereceivingantenna. –Increasethedistancebetweenthedeviceandthereceiver. –Connectthedevicetoanoutletonacircuitdifferentfromtheonethatsuppliespowertothe receiver. –Consultthedealeroranexperiencedradio/TVtechnician. WARNING!Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsible forcompliancecouldvoidtheuser’sauthoritytooperatetheequipment. ThisdevicecomplieswithFCCRulesPart15).Operationissubjecttotwoconditions:(1)This devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencethat maybereceivedorthatmaycauseundesiredoperation.

Dongguan Houjie Mosaic Electronics Factory 2023-02-28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AX5E-KF102) The applicant: Dongguan Houjie Mosaic Electronics Factory certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Print name: Jiarang Mo Title: Manager Signature: Dongguan Houjie Mosaic Electronics Factory 2023-02-28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2AX5E-KF102) The applicant: Dongguan Houjie Mosaic Electronics Factory certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Print name: Jiarang Mo Title: Manager Signature:

Attestation Statements -US agent 2023-02-28 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2AX5E-KF102) Dongguan Houjie Mosaic Electronics Factory, the undersigned, hereby authorize (Baihetian Innovative Solutions) to act as our designated U.S. agent for service of process, Dongguan Houjie Mosaic Electronics Factory accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Baihetian Innovative Solutions) accepts the responsibility to act as designated U.S. agent for service of process, provides an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Information： Company name: Dongguan Houjie Mosaic Electronics Factory Address: Shima Industrial Estate, Dajing, Houjie Town, Dongguan 523000, Guangdong, China FRN: 0030170757 Contact Name: Jiarang Mo Telephone No: +86 769 85449889 Email: [email protected] Signature Jiarang Mo [name] U.S. Agent Information: Company name: Baihetian Innovative Solutions Address: 6837 Chase Rd Dearborn, MI 48126 FRN: 0033401605 Contact Name: Kenneth Young Telephone No: 313-395-3113 Email: [email protected] Signature Kenneth Young [name]

Updated on 2005/02/07 by Kally Chan To : STC (Dongguan) company Limited DECLARATION OF IDENTITY Hereby we: (NameofManufacturer) Basic Model Number: KF102 Basic Brand Name:Remote Control Basic Product Name: Basic Test Report Application Number: Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical to the basic model: New / Additional Model Number(s): MH105 New / Additional Brand Name(s): New / Additional Product Name(s): Except the following(s) : Remarks: Signature with Company Chop : （公司盖章） 2023-02-16 Everything is the same except the model number DATE: Printed Name :Iynn ye

DongguanHoujieMosaicElectronicsFactory AgentAuthorizationLetter 2023-02-28 EurofinsElectricalandElectronicTestingNA,Inc. 914W.PatapscoAvenue Baltimore,MD21230 USA RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorize(TheHongKongStandardsandTestingCentre Limited)toactonourbehalfinallmattersrelatingtoapplicationforequipmentauthorization, includingthesigningofalldocumentsrelatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuse Actof1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, Printname ： JiarangMo Title:Manager Signature:

Dongguan Houjie Mosaic Electronics Factory Long Term Confidentiality Request Letter Date: 2023-02-28 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Remote Control MODEL: KF102 FCC ID: 2AX5E-KF102 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (block diagram/schematics/operational description ) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Print name: Jiarang Mo Title: Manager Signature:

1 View of The Product View of The Product FCC ID:2AX5E-KF102 External Photo 2 View of The Product View of The Product 3 View of The Product View of The Product

3.5cm*1.8cm

1 Inside View of The Product RF antenna Inside View of The Product FCC ID:2AX5E-KF102 Internal Photo 2 View of battery

RF Exposure Test Requirement: FCC 47CFR 15.247(i) FCC ID: 2AX5E-KF102 Test Date: 2023-04-27 Mode of Operation: RF Tx mode Requirements: In 15.247(i), an equipment shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the limits in §§ 1.1310 and 2.1093 of this chapter. Applications to the Commission for construction permits, licenses to transmit or renewals thereof, equipment authorizations or modifications in existing facilities must contain a statement confirming compliance with the limits unless the facility, operation, or transmitter is categorically excluded, as discussed below. Technical information showing the basis for this statement must be submitted to the Commission upon request. According to KDB447498 D04 General RF Exposure Guidance v01, Appendix B B.2 Blanket 1 mW Blanket Exemption The 1 mW Blanket Exemption of § 1.1307(b)(3)(i)(A) applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power of no more than 1mW, regardless of separation distance. Result: Pass The Maximum EIRP = 0.169mW (at frequency = 433.92MHz) < 1mW Remark：EIRP=92.3dBuV/m+20log 3 -104.8-4.7= -7.7dBm = 0.169mW

Antenna Describe Our products don’t have special Antenna, only 1pc single AWG26 with plastic cover cloth 1） KF102：L=110mm。 Antenna gain： 0dBi Antenna type： Linear antenna Supplier: DongGuan JinZaoLi Technology Co Ltd Add: JiaoYiTang Silver Lake Industrial TangXia Town DongGuan, GuangDong, China

Test Report Date : 2022-04-27 Page 1 of 20 No. : HMD23020007 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Applicant : Dongguan Houjie Mosaic Electronics Factory Shima Industrial Estate, Dajing, Houjie Town, Dongguan 523000, Guangdong, China Supplier / Manufacturer : Dongguan Houjie Mosaic Electronics Factory Shima Industrial Estate, Dajing, Houjie Town, Dongguan 523000, Guangdong, China Description of Sample(s) : Submitted sample(s) said to be Product: Remote Control Brand Name: Mosaic Alarm Model No.: KF102 FCC ID: 2AX5E-KF102 Date Samples Received : 2023-02-20 Date Tested : 2023-02-20 to 2023-02-23 Investigation Requested : Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.10:2013 for FCC Certification. Conclusions : The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks : --- Test by: Susu _______________________________ Dr.CHAN Kwok Hung, Brian Authorized Signatory Test Report Date : 2022-04-27 Page 2 of 20 No. : HMD23020007 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. CONTENT: Cover Page 1 of 20 Content Page 2 of 20 1.0 General Details 1.1 Test Laboratory Page 3 of 20 1.2 Equipment Under Test [EUT] Page 3 of 20 Description of EUT operation 1.3 Date of Order Page 3 of 20 1.4 Submitted Sample(s) Page 3 of 20 1.5 Test Duration Page 3 of 20 1.6 Country of Origin Page 3 of 20 2.0 Technical Details 2.1 Investigations Requested Page 5 of 20 2.2 Test Standards and Results Summary Page 5 of 20 3.0 Test Results 3.1 Emission Page 6-11 of 20 3.2 20dB Bandwidth of Fundamental Emission Page 12-13 of 20 Test Report Date : 2022-04-27 Page 3 of 20 No. : HMD23020007 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Appendix A List of Measurement Equipment Page 14 of 20 Appendix B Duty Cycle Correction During 100 msec Page 15-16 of 20 Appendix C Manual Operated Transmitter Transmission Time Page 17 of 20 Appendix D Photograph(s) of Product Page 18-20 of 20 Test Report Date : 2022-04-27 Page 4 of 20 No. : HMD23020007 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate, New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: Remote Control Manufacturer: Dongguag Houjie Mosaic Electronics Factory. Shima Industrial Estate, Dajing, Houjie Town, Dongguan 52300, Guangdong, China Brand Name: Mosaic Alarm Model Number: KF102 Additional Model Number: MH105 Rating: 3.0Vd.c. (“CR2032” size battery×1) 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a Remote Control. The EUT is operating at 433.92 MHz. Test was conducted under Tx mode. 1.3 Date of Order 2023-02-20 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2023-02-20 to 2023-02-23 1.6 Country of Origin China Test Report Date : 2022-04-27 Page 5 of 20 No. : HMD23020007 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.10: 2013 for FCC Certification. This is a manually operated transmitter, Press the button to start sending signals. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.231(a) ANSI C63.10: 2013 N/A 20dB Bandwidth of Fundamental Emission FCC 47CFR 15.231(c) ANSI C63.10: 2013 N/A Radiated Emissions FCC 47CFR 15.209 ANSI C63.10: 2013 N/A Manual Operated Transmitter T…

Text truncated - open the document above for the full version.

1 Test Photo FCC ID: 2AX5E-KF102 Measurement of Radiated Emission Test Set Up (9kHz – 30MHz) Measurement of Radiated Emission Test Set Up (30MHz – 1000MHz) 2 Measurement of Radiated Emission Test Set Up (above 1000MHz)
