2AX6K-MT1622Wireless charger with bluetooth

21 冲 29clll MT1622 INSTRUCT！。N MANUAL 。PERATI。N: Connect the device to a power source using the included USB cable. 3 x AM batteries can be installed as a temporary back-up power source to keep the clock running during a power outage. 1 x Button Cell battery {CR2032) will hold the set time {without display), should the AM batteries become depleted. GENERAL TIME/DATE SETTINGS: 1.Long press "SET' to enter general setting mode, then short press “ SET ” to scroll through each setting option below. 2. While YEAR is flashing, short press "UP" or “ DOWN ” to adjust the number. 3.Short press “ SET". While MONTH is flashing, short press “ UP" or “ DOWN ” to adjust the number. 4.Sho民press “ SET'.While DAY is flashing, short press “ UP ’ · or “ DOWN" to adjust the number. 5. Short press “ SET'. While 24Hr/12Hr is flashing, short press "UP" or “ DOWN ” to switch between 24Hr or 12Hr. 6. Sho民press “ SET'.While HOUR is flashing, short press “ UP ” or"DOWN ” to adjust the number. 7. Sho民press “ SET'.While MINUTE is flashing, short press “ UP ” or"DOWN ” to adjust the number. 8. Short press “ SET ” one final time to finish se忧ing.If there is no operation for 20 seconds, the setting mode will shut off and clock will return to display mode. DISPLAY。PTI。NS: Short press “ UP ” to scroll through display options: temperature, date, or seconds can be displayed next to the hours and minutes. BRIGHTNESS SETIING: Short press “ DOWN ” to scroll through 4 brightness settings: L 1, L2, L3, L4. TEMPERATURE DISPLAY: Long press “ DOWN" to switch temperature display between °C｛Celsius) and 。F{Fahrenheit). 舍Temperaturerange: 0°C－50 。 C(32 。 F-122 。 F). • Temperature detection cycle: 60 seconds • Accuracy: +/-1°C（1.8 。 F) ALARM CL。CKSETIING: 1. Short press “ SET ” to display Alarm A 1. Sho『tpress “ UP" or “ DOWN ” to switch Alarm A 1 on "On ” 。『0仔 “ ··”． 2. Long press “ SET ’ to adjust HOUR for Alarm A 1. While HOUR is blinking, short press “ UP ” 。r"DOWN ” toadjust the number. 3.Short press “ SET ” to 叫ustMINUTE for Alarm A 1. While MINUTE is blinking, short press "UP ” or “ DOWN ” to adjust the number. 4.Sho『tpress “ SET ” to scroll through and display Alarms A2 and A3. Repeat step 1-3 to set each alarm. 5.Sho『tpress “ SET' to exit setting mode. If there is no operation for 20 seconds, the se饥ingmode will shut off and clock will return to display mode. p。WERSAVINGM。DE: 1. Long press "UP ” ， when “Sound ” shows up on display, short press "UP' ’ or°COWN" to turn touch control on or o何． 2.When power saving mode is on, display will shut off after 15 seconds if the device is not being used. To activate the display, simply tap the top of the clock or short press any button on the control panel. 3.When power saving mode is o何 ， displaywill remain on. WIRELESS PH。NECHARGING: 1. Place your phone on top of the clock with the display screen facing up and it will start charging automatically. 2. Charging function only operates when the clock is powered using a USB cable. 3.The charger only works with phones that have the wireless charging function. 4.The charging function will not work on phones with a thicker臼阔 ， a support ring on the back, or other backside obstruction. 5. Specs of the wireless charger - *Input: 5V/2A *Output: 5V/1A WIRELESS SPEAKER: 1. Tum on Bluetooth on your phone I tablet I audio device and connect to BT201-AUDIO to activate the speaker. 2. Specs of speaker - *Bluetooth 5.0 *Output: 40/3W *Play Range：呈10meter (33 feet) CAUTION & SAFETY: 1. Do not expose to moisture, sunlight, or other heat sources. 2. Keep away from children and ensure all adults who use this product read and follow these instructions and warnings. 3. Battery must be recyc怆dand disposed of properly. 4. Operation temperature range between 32年and113 。 F 5. Use correct voltage charge, 5V only. FCC Part15: CAUTION: Risk of Fire and Burns. Do Not Open, Crush, Heat Above 45 ° C /113 。 F or lncine『ate.Follow Manufacturer ' s Instructions. ATIENTION: Risque d' incendie et de brulures. Ne pas incinerer, ouvrir ou endommager, ne pas exposer a une chaleur au-dessus de 45 ° C / 113 。 F.Merci de suivre les instructions du fabricant. IMP。RTANTSAFETY INSTRUCTIONS WARNING • When using this product, basic pre臼utionsshould always be followed, including the following: 1.Read all the instructions before using the product. 2. To reduce the risk of injury, close supervision is necessary when the product is used near children. 3. Do not put fingers or hands into the product. 4. Do not expose the product to rain or snow. 5. Use of a power supply or charger not recommended or sold by the product manufacturer may result in a risk of fire or 叫uryto persons. 6. Do not use the product in excess of its output rati『1g.Overloading outputs above rating may result in a 『iskof fire or叫ury to persons. 7. Do not use the product that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury. 8. Do not disassemble the product. Take it to a qualified service person when service or repair is required. Incorrect reassembly may result in a risk of fire on injury to persons. 9. Do not expose the product to fire or excessive temperatures. Exposure to fire or temperatu『e above 100 ·c may cause an explosion. 10.Have serviαng performed by a qualified repair person using only identical repla饵mentpa白.This will ensure that the safety of the product is maintained. FCC Warning Statement Ch anges or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rul es. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, m…
