2AX87-US100BW10000mAh Power Bank Ultimate with Wireless Charger

Output US100BW User Manual 1. Introduc�on 2. Product informa�on Input Type -C:5V/3A9V/2A Wireless charging: 10W / 7.5W /5W USB:5V/3A, 9V/2.22A, 12V/1.5A Type-C:5V/3A, 9V/2.22A,12V/1.5A ABS+PC Polymer lithium ba�ery 10000mAh 220g 143*68.7*17.4mm 0-45°C -20~50°C Transport & Storage temperatures Use temperature Size Net weight Capacity Ba�ery Material 3. Product Sketches 4. Methods of use 1). Wireless charging Part USB output interface LED indicator Wireless sensor area Type-C input interface Power switch 2). Wired charging DC input for this product 75% Charged A�erpressing the bu�on to turn on the power bank, when the wireless charging func�on stand by, the red LED flashes, and put your mobile phone to wireless charging are a, when the blue LED indicator lights up, it means wireless charging func�on working. When green and blue LED lights up together, it means wireless fast charging func�on working. The product wireless charging function can only be used when connected to external power supply The product with PD,QC3.0 and wireless func�on, it’s our company’s private model, with appearance patent, built-in high capacity ba�ery. It uses intelligent MCU control to achieve fast charging of mobile phones by adjus�ng different output voltages and currents. Support wireless charging at the same �me Connect one end of the USB line (USB-Micro/USB-Type C/Type C-Type C cable with the fast charge func�on) with the output interface of this product, the other end connected to the mobile phone or other equipment, press the bu�on, that is to start charging. The Green LED light up means the fast charging func�on start. The data line Type-C USB end up the input interface, the other end is connected with the QC 3.0 or PD type adapter to charge the product, the Green LED light up means the fast charge func�on start. Fast charge, Digital Power indicator US100BW WIRELESS POWER BANK User Manual PO. Number: x Version: 1 Date: 2020-09-02 & tĂƌŶŝŶŐ ^ƚĂƚĞŵĞŶƚ ŚĂŶŐĞƐ Žƌ ŵŽĚŝĨŝĐĂƚŝŽŶƐ ŶŽƚ ĞdžƉƌĞƐƐůLJ ĂƉƉƌŽǀĞĚ ďLJ ƚŚĞ ƉĂƌƚLJ ƌĞƐƉŽŶƐŝďůĞ ĨŽƌ ĐŽŵƉůŝĂŶĐĞ ĐŽƵůĚ ǀŽŝĚ ƚŚĞ ƵƐĞƌ͛Ɛ ĂƵƚŚŽƌŝƚLJ ƚŽ ŽƉĞƌĂƚĞ ƚŚĞ ĞƋƵŝƉŵĞŶƚ͘ dŚŝƐ ĞƋƵŝƉŵĞŶƚ ŚĂƐ ďĞĞŶ ƚĞƐƚĞĚ ĂŶĚ ĨŽƵŶĚ ƚŽ ĐŽŵƉůLJ ǁŝƚŚ ƚŚĞ ůŝŵŝƚƐ ĨŽƌ Ă ůĂƐƐ  ĚŝŐŝƚĂů ĚĞǀŝĐĞ͕ ƉƵƌƐƵĂŶƚ ƚŽ WĂƌƚ ϭρ ŽĨ ƚŚĞ & ZƵůĞƐ͘ dŚĞƐĞ ůŝŵŝƚƐ Ăƌ Ğ ĚĞƐŝŐŶĞĚ ƚŽ ƉƌŽǀŝĚĞ ƌĞĂƐŽŶĂďůĞ ƉƌŽƚĞĐƚŝŽŶ ĂŐĂŝŶƐƚ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ŝŶ Ă ƌĞƐŝĚĞŶƚŝĂů ŝŶƐƚĂůůĂƚŝŽŶ͘ dŚŝƐ ĞƋƵŝƉŵĞŶƚ ŐĞŶĞƌĂƚĞƐ ƵƐĞƐ ĂŶĚ ĐĂŶ ƌĂĚŝĂƚĞ ƌĂĚŝŽ ĨƌĞƋƵĞŶĐLJ ĞŶĞƌŐLJ ĂŶĚ͕ ŝĨ ŶŽƚ ŝŶƐƚĂůůĞĚ ĂŶĚ ƵƐĞĚ ŝŶ ĂĐĐŽƌĚĂŶĐĞ ǁŝƚŚ ƚŚĞ ŝŶƐƚƌƵĐƚŝŽŶƐ͕ ŵĂLJ ĐĂƵƐĞ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ƚŽ ƌĂĚŝŽ ĐŽŵŵƵŶŝĐĂƚŝŽŶƐ͘ ,ŽǁĞǀĞƌ͕ ƚŚĞƌĞ ŝƐ ŶŽ ŐƵĂƌĂŶƚĞĞ ƚŚĂƚ ŝŶƚĞƌĨĞƌĞŶĐĞ ǁŝůů ŶŽƚ ŽĐĐƵƌ ŝŶ Ă ƉĂ ƌƚŝĐƵůĂƌ ŝŶƐƚĂůůĂƚŝŽŶ͘ /Ĩ ƚŚŝƐ ĞƋƵŝƉŵĞŶƚ ĚŽĞƐ ĐĂƵƐĞ ŚĂƌŵĨƵů ŝŶƚĞƌĨĞƌĞŶĐĞ ƚŽ ƌĂĚŝŽ Žƌ ƚĞůĞǀŝƐŝŽŶ ƌĞĐĞƉƚŝŽŶ͕ ǁŚŝĐŚ ĐĂŶ ďĞ ĚĞƚĞƌŵŝŶĞĚ ďLJ ƚƵƌŶŝŶŐ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ŽĨĨ ĂŶĚ ŽŶ͕ ƚŚĞ ƵƐĞƌ ŝƐ ĞŶĐŽƵƌĂŐĞĚ ƚŽ ƚƌLJ ƚŽ ĐŽƌƌĞĐƚ ƚŚĞ ŝŶƚĞƌĨĞƌĞŶĐĞ ďLJ ŽŶĞ Žƌ ŵŽƌĞ ŽĨ ƚŚĞ ĨŽůůŽǁŝŶŐ ŵĞĂƐƵƌĞƐ͗ ‐‐ ZĞŽƌŝĞŶƚ Žƌ ƌĞůŽĐĂƚĞ ƚŚĞ ƌ ĞĐĞŝǀŝŶŐ ĂŶƚĞŶŶĂ͘ ‐‐ /ŶĐƌĞĂƐĞ ƚŚĞ ƐĞƉĂƌĂƚŝŽŶ ďĞƚǁĞĞŶ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ĂŶĚ ƌĞĐĞŝǀĞƌ͘ ‐‐ ŽŶŶĞĐƚ ƚŚĞ ĞƋƵŝƉŵĞŶƚ ŝŶƚŽ ĂŶ ŽƵƚůĞƚ ŽŶ Ă ĐŝƌĐƵŝƚ ĚŝĨĨĞƌĞŶƚ ĨƌŽŵ ƚŚĂƚ ƚŽ ǁŚŝĐŚ ƚŚĞ ƌĞĐĞŝǀĞƌ ŝƐ ĐŽŶŶĞĐƚĞĚ͘ ‐‐ ŽŶƐƵůƚ ƚŚĞ ĚĞĂůĞƌ Žƌ ĂŶ ĞdžƉĞƌŝĞŶĐĞĚ ƌĂĚŝŽͬds ƚĞĐŚŶŝĐŝĂŶ ĨŽƌ ŚĞůƉ͘ dŚŝƐĚĞǀŝĐĞĐŽŵƉůŝĞƐǁŝƚŚƉĂƌƚϭρŽĨƚŚĞ&ZƵůĞƐ͘KƉĞƌĂƚŝŽŶŝƐƐƵďũĞĐƚƚŽƚŚĞĨŽůůŽǁŝŶŐƚǁŽĐŽŶĚŝƚŝŽŶƐ͗ ;ϭͿdŚŝƐĚĞǀŝĐĞŵĂLJŶŽƚĐĂƵƐĞŚĂƌŵĨƵůŝŶƚĞƌ ĨĞƌĞŶĐĞ͕ĂŶĚ;ϮͿƚŚŝƐĚĞǀŝĐĞŵƵƐƚĂĐĐĞƉƚĂŶLJŝŶƚĞƌĨĞƌĞŶĐĞƌĞĐĞŝ ǀĞĚ͕ŝŶĐůƵĚŝŶŐŝŶƚĞƌĨĞƌĞŶĐĞƚŚĂƚŵĂLJĐĂƵƐĞƵŶĚĞƐŝƌĞĚŽƉĞƌĂƚŝŽŶ͘

Co m Ad d Long Pr o Mo d Pr o We act We an d issu our Sig Na m Title Com mpany: She dress: 4th F ggang Distric oduct Name del Numbe oduct Desc authorize M on our beha declare tha d certificatio ues concern behalf shal nature: me: e: mpany: S enzhen U-An Floor, Block C ct, Shenzhen e: 10000mAh er(s): US100 ription: 100 MiCOM Lab alf on all ma at MiCOM L n of equipm ning the app ll have the s Vicky HE Engineerin Shenzhen Shenzhen Agen ngel Technol C, Phase 2 O n City, Guang h Power Ban 0BW 000mAh Pow bs Inc., 575 atters conce Labs Inc. is ment to the r proval applic same effect ng director U-Angel Te U-Angel Te nt Auth ogy Co., Ltd Of Hongmen gdong Provin nk Ultimate w wer Bank Ulti Boulder Co erning the c allowed to f regulatory a cation. Any t as acts of chnology C echnology horizat . Industrial Pa nce, China with Wireless imate with W ourt, Pleasa certification forward all i agencies as and all acts our own. Co., Ltd. Co., Ltd. tion ark, No.399, s Charger Wireless Char anton, Califo of above na information s required a s carried ou Date: Jihua Road, rger ornia 94566 amed equip related to t nd to discu ut by MiCOM Nov. 19, 20 , Jihua Stree 6, USA, to pment. the approva ss any M Labs on 020 et, al

Office o Federa 7435 O Columb USA Subjec t FCC ID To Wh o Pursua are req u docume These d propriet might b It is ou r corresp docume authoriz Sincer e Signat u Name: V Title: E of Engineeri l Communic Oakland Mills bia, MD 210 t; Request f D: 2AX87-US om It May C nt to the pro uesting the ents from pu documents tary informa be harmful to Schema Block D Parts Lis Operatio Tune-up r understand pondence du ents and thi zation is iss ely, ure: Vicky HE ngineerin g Sh ing Techno cations Com s Road 046 for Confiden S100BW Concern, ovisions of t Commissio ublic disclos contain det ation in ope o our comp atic Diagram iagram st onal Descri p Procedure ding that all uring the ce s informatio sued. g director enzhen U- logy mmission ntiality the Commis on to withho sure indefin tailed syste ration of th e any and wo m ption e l measurem ertification re on will be av -Angel Tec ssion’s rule old the follow nitely. m and equi e equipmen ould give co ment test rep eview proce vailable for hnology Co s Title 47 S wing attach pment desc nt. The publ ompetitors a ports, FCC ess cannot public revi e o., Ltd. Sections §0. hment(s) as criptions an ic disclosu r an unfair ad ID label for be granted ew once the Date: Nov. 457 and §0 confidentia d are consi re of these d vantage in mat and as confide n e grant of eq 19, 2020 0.459, we al dered as documents the market . ntial quipment .

Annex A External Photos Model: US100BW Page 1 of 3 Model: US100BW Page 2 of 3 Model: US100BW Page 3 of 3

FCC ID LABEL: Ca. 8mm x 10mm Label Location FCC ID: 2AX87-US100BW

Annex B Internal Photo Model: US100BW Page 1 of 3 Antenna Model: US100BW Page 2 of 3 Model: US100BW Page 3 of 3

Page 1 of 8 Report No.: HK2011053328-2E FCC TEST REPORT Test report On Behalf of Shenzhen U-Angel Technology Co., Ltd. For 10000mAh Power Bank Ultimate with Wireless Charger Model No.: US100BW FCC ID: 2AX87-US100BW Prepared for : Shenzhen U-Angel Technology Co., Ltd. 4th Floor, Block C, Phase 2 Of Hongmen Industrial Park, No.399, Jihua Road, Jihua Street, Longgang District, Shenzhen City, Guangdong Province, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Nov. 04, 2020 ~ Nov. 11, 2020 Date of Report: Nov. 11, 2020 Report Number: HK2011053328-2E Page 2 of 8 Report No.: HK2011053328-2E Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 125 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. SUMMARY OF TEST RESULTS 2.1 Test procedures according to the technical standards: FCC KDB680106 D01 RF Exposure Wireless Charging Apps v03 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01v03 (3)(3) Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 All emissions,radiated(<30M)(9KHz-30MHz) ±2.45dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 3 of 8 Report No.: HK2011053328-2E 2.3 Test Instruments Description Brand Model No. Frequency Range Calibrated Date Calibrated Until Broadband Field Meter NARDA NBM-550 - Dec. 26, 2019 Dec. 25, 2020 Magnetic Field Meter NARDA ELT-400 1 – 400kHz Dec. 26, 2019 Dec. 25, 2020 Magnetic Probe NARDA HF-3061 300kHz – 30MHz Dec. 26, 2019 Dec. 25, 2020 Magnetic Probe NARDA HF-0191 27 – 1000MHz Dec. 26, 2019 Dec. 25, 2020 Broadband Field Meter NARDA NBM-550 - Dec. 26, 2019 Dec. 25, 2020 Electric Field Meter COMBINOVA EFM 2005Hz – 400kHz Dec. 26, 2019 Dec. 25, 2020 E-Field Probe NARDA EF-0391 100kHz – 3GHz Dec. 26, 2019 Dec. 25, 2020 E-Field Probe NARDA EF-6091 100MHz – 60GHz Dec. 26, 2019 Dec. 25, 2020 NOTE: 1. The calibration interval of the above test instruments is 12 months . Page 4 of 8 Report No.: HK2011053328-2E 3. MAXIMUM PERMISSIBLE EXPOSURE 3.1 MAXIMUM PERMISSIBLE EXPOSURE Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310, 680106 D01 RF Exposure Wireless Charging Apps v03 Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 5 of 8 Report No.: HK2011053328-2E 4. TEST PROCEDURE a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 15cm, H-field strengths of top side is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. 4.1 TEST SETUP 4.2 RESULT OF MAXIMUM PERMISSIBLE EXPOSURE Page 6 of 8 Report No.: HK2011053328-2E For Full load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.27 1.12 1.42 1.52 1.45 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.26 0.57 0.33 0.14 0.37 1.63 For Half Load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.55 1.27 1.63 1.25 1.74 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.32 0.37 0.56 0.37 0.52 1.63 Page 7 of 8 Report No.: HK2011053328-2E For No load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.75 1.35 1.45 1.63 1.47 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.55 0.48 0.53 0.57 0.36 1.63 Remark: According KDB 680106 D01 RF Exposure Wireless Charging App v03, section 5, b). The aggregate H-field strengths at 15 cm surrou…

Text truncated - open the document above for the full version.

Page 1 of 22 Report No.: HK2011053328-1E FCC TEST REPORT Test report On Behalf of Shenzhen U-Angel Technology Co., Ltd. For 10000mAh Power Bank Ultimate with Wireless Charger Model No.: US100BW FCC ID: 2AX87-US100BW Prepared for : Shenzhen U-Angel Technology Co., Ltd. 4th Floor, Block C, Phase 2 Of Hongmen Industrial Park, No.399, Jihua Road, Jihua Street, Longgang District, Shenzhen City, Guangdong Province, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Nov. 04, 2020 ~ Nov. 11, 2020 Date of Report: Nov. 11, 2020 Report Number: HK2011053328-1E Page 2 of 22 Report No.: HK2011053328-1E TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen U-Angel Technology Co., Ltd. Address ................................. : 4th Floor, Block C, Phase 2 Of Hongmen Industrial Park, No.399, Jihua Road, Jihua Street, Longgang District, Shenzhen City, Guangdong Province, China Manufacture's Name ............ : Shenzhen U-Angel Technology Co., Ltd. Address ................................. : 4th Floor, Block C, Phase 2 Of Hongmen Industrial Park, No.399, Jihua Road, Jihua Street, Longgang District, Shenzhen City, Guangdong Province, China Product description Trade Mark: N/A Product name ........................... : 10000mAh Power Bank Ultimate with Wireless Charger Model and/or type reference : US100BW Standards ............................. : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Nov. 04, 2020 ~ Nov. 11, 2020 Date of Issue ........................................... : Nov. 11, 2020 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 22 Report No.: HK2011053328-1E Table of Contents Page 1 . TEST SUMMARY 5 1.1 TEST PROCEDURES AND RESULTS 5 1.2 TEST FACILITY 5 1.3 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 General Description of EUT 6 2.3 Operation of EUT during testing 7 2.4 Description of Test Setup 7 3.1 Block Diagram of Test Setup 9 3.2 Conducted Power Line Emission Limit 9 3.3 Test Procedure 9 4. Occupied Bandwidth 12 4.1 Block Diagram of Test Setup 12 4.2 Rules and specifications 12 4.3 Test Procedure 12 4.4 Test Result 12 5. RADIA TED EMISSIONS 14 5.1 Block Diagram of Test Setup 14 5.2 Rules and specifications 15 5.3 Test Procedure 16 5.4 Test Result 16 6 ANTENNA REQUIREMENT 19 7. PHOTOGRAPH OF TEST 20 7.1 Radiated Emission 20 8 PHOTOS OF THE EUT 22 Page 4 of 22 Report No.: HK2011053328-1E ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release Nov. 11, 2020 Jason Zhou Page 5 of 22 Report No.: HK2011053328-1E 1. TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS DESCRIPTION OF TEST section number RESULT CONDUCTED EMISSIONS TEST 15.207 COMPLIANT RADIATED EMISSION TEST 15.209 COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT 15.215 COMPLIANT ANTENNA REQUIREMENT 15.203 COMPLIANT Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2 TEST FACILITY Test Firm : Shenzhen HUAK Testing Technology Co., Ltd. Address 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China 1.3 MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 6 of 22 Report No.: HK2011053328-1E 2. GENERAL INFORMATION 2.1 General Description of EUT Equipment 10000mAh Power Bank Ultimate with Wireless Charger Model Name US100BW Serial No. N/A Model Difference N/A Trade Mark N/A FCC ID 2AX87-US100BW Antenna Type Coil Antenna Antenna Gain 0dBi Operation frequency 125KHz Number of Channels 1 Modulation Type ASK Power Source Input: Type-C:5V/3A 9V/2A Output: USB DC 5V/3A, 9V/2.22A, 12V/1.5A Type-C:DC 5V/3A, 9V/2.22A,12V/1.5A Wireless output: 10W/ 7.5W/ 5W Power Rating Input: Type-C:5V/3A 9V/2A Output: USB DC 5V/3A, 9V/2.22A, 12V/1.5A Type-C:DC 5V/3A, 9V/2.22A,12V/1.5A Wireless output: 10W/ 7.5W/ 5W Page 7 of 22 Report No.: HK2011053328-1E 2.2. Carrier Frequency of Channels Operation Frequency each of channel Channel Frequency 1 125KHz 2.3 Operation of EUT during testing Operating Mode The mode is used: Transmitting mode 2.4 Description of Test Setup Operation of EUT during testing: 120V/60Hz Mobile phones information Model: S6 Input: 5VDC Resistance information Input: 15W 5Ω The sample was placed (0.8m below 1GHz, 1.5m above 1GHz) above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. The worst case is X position Resista…

Text truncated - open the document above for the full version.

Test Model：US100BW Radiated Emission Conducted Emission
