Lydsto Sweeping and Mopping Robot R5 Instruction manual Tips Please read through this manual before using the product, and keep it properly. Table of contents Product introduction Install Direction for use Connect APP Daily maintenance Basic specification FAQ Trouble removal Safety information � � � �� �� �� �� �� �� Product introduction Host Recharge / Pause ∑Short press to recharge / Pause ∑Short press to start cleaning / Pause ∑Long press to turn on / off ∑Blue: Normal working ∑Red: Abnormal state or low battery ∑Yellow breathing: Charging On off button / Cleaning / Pause Indicator light Laser head impact sensor Laser ranging sensor � Charge touch spot Product introduction Bumper Buttons Surface cover Drop off sensor Charge touch spot Universal wheel Battery cover Driving wheel Main brush Pull-back duct box Side brush Sensor and structure Pull-back duct box Laser sensor � Product introduction Dust collector bin Power Indicator light Signal transmitting area Power Indicator light White light: Normal working, full charge Red light: Abnormity Extinguish: No power Top cover Suction inlet Charging pole plate � Product introduction Accessories list Dust collector bin×1Water dust integrated box×1 Left side brush×2 Right side brush×2 Cleaning brush×1 HEPA filter screen×2 Disposable mop cloth×5 Dust bag×２ Mop cloth support×1 � Mop×1 Install 1.Before starting the machine, please clean the scattered wires, hard objects, sharp objects (such as nails and glass) on the ground and remove the toppable, fragile, valuable and potentially dangerous objects. Avoid personal injury or property damage caused by machine entanglement, jamming, dragging or collision. 2、If the product is used in the hanging environment, please set the guardrail to prevent the equipment from accidentally falling or pushing items to fall, causing personal or property damage. Reminder： 1.During the first cleaning process, it is recommended to follow the host throughout the whole process to help deal with some possible minor problems. After handling, the host can smoothly clean itself in the future cleaning. 2.If some areas do not need to be cleaned or may jam the host, you can set a restricted area in the mobile APP to prevent the host from entering the above areas. 3.Do not let the robot absorb hard or sharp objects (such as decoration waste, glass, nails, etc.), otherwise it may scratch the robot and the ground. � Install 4. Install side brush Let the left brush (L) and the right brush (R) correspond to the letters L and R on the bottom shell respectively. Press down and hear "click" to indicate that the installation is in place. Note: Sunlight will interfere with the return signal, which may cause the host to fail to return the dust collector bin. Ensure that the dust collector has more than 0.5 meters on both sides, and the power cord of the space more than 1.5 meters in front of the dust collector is hanging down to the ground, which may be dragged by the host to causing the dust collector bin to lose power. 2.Place the dust collection treasure against the wall, and ensure that there are no obstacles within 0.5 meters on both sides and 1.5 meters in front. Please wrap the excess wire around the winding board and plug it in. 3.Before use, please first put the host on the dust collection treasure to charge, full before use. Adjacent to wall 0.5m 0.5m 1.5m � Install 5.Start up and charging Long press the ( ) button to start up, wait for the indicator light to be steady on, and charge the host with the dust collector. The language prompt "Charging" indicates successful charging. Note: The device cannot be started due to insufficient power supply. Please place the host on the dust collector and the device will start up automatically. � Direction for us Start up/off Cleaning / Pause Charging Long press ( ) buttons for 3 seconds, indicator lights on, start up successful． When machine stand by, long press ( ) buttons for 3 seconds, indicator lights off, machine shutdown. After start up, short press ( ) buttons on the main host, or control begin cleaning from mobile APP. Automatic mode: After cleaning, the master will automatically return to the dust collector to charge. Manual mode: In the paused state, press the ( ) buttons to start the recharge or the phone APP to start the recharge Vacuum robot should not be used to clean liquid. If the battery is lower than 15%, the cleaning task cannot be performed. Please charge the battery first and then continue the cleaning. When the battery is lower than 15% during the cleaning process, the device will automatically return to the dust collector bin for charging. Please tidy up all kinds of cables on the ground (including the power cable of dust collection treasure) before cleaning to avoid electrical power failure, damage to articles or cables caused by dragging during cleaning. Note: Note: The main host cannot be turned off while charging. Note: If the host does not find the dust collector bin, it will automatically return to thestarting position. Please manually put the host back on the dust collector bin to charge. � Direction for us Automatic cleaning Area of completion Area to be cleaned After starting up, the machine will first plan the cleaning path in the way of edge and then in the way of arch filling, orderly and efficient cleaning of the whole house. After cleaning, the device will automatically return to the dust collector bin to charge (the default cleaning mode of the machine). Suction adjustment Water level adjustment You can choose Quiet, Standard, Strong and MAX by using mobile APP. You can choose High gear, Medium gear and Low gear (The default mode is Medium gear). Appointment cleaning The mobile phone APP can be used to set the scheduled cleaning time. The host will automatically start cleaning at the specified time. The mobile phone APP can be used to set the scheduled cleaning time. T he host will automatically start cleaning at the specified time. � Connect APP Reset …
