2AX9V-T10208Wireless remote

First READ THIS MANUAL. If you still need help, call us from 8 am - 5 pm (EST) Monday – Friday. 800-334-2004 Note: At this time, we provide Phone Support in English only. If you have any questions or difficulty installing this product, we are here to help! INSTALLATION AND OPERATING INSTRUCTIONS T10208 Electric Anchor Winch TRAC Anchor Winch Limited Warranty LIMITED WARRANTY: Camco warrants this product to be free from defects in material and workmanship under normal use and service conditions for 12 months from the date of first purchase. Camco’s liability is limited solely to the replacement of any defective product returned to us. To the extent allowable by law, Camco makes no other warranty, either expressed or implied, nor assumes any liability for incidental or consequential damages resulting from the use of this product or for breach of warranty of merchantability or fitness for a particular purpose. Submit warranty claims to Camco Manufacturing, 121 Landmark Drive, Greensboro, NC 27409. GENERAL SAFETY INFORMATION - Throughout this manual potential safety hazards will be noted with the following terms. Please read and understand these terms before operating the product. DANGER WARNING CAUTION Danger means a hazard that WILL cause death or serious injury if the warning is ignored. Warning means a hazard that COULD cause death or serious injury if the warning is ignored. Caution means a hazard that MAY cause minor or moderate injury if warning is ignored. It may also mean hazard that will only cause property damage. Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain this anchor winch. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for future reference. CAUTION Always raise the anchor before moving the boat. Do NOT drag the anchor with the boat’s power. This will cause product damage or injury. Do NOT use the anchor winch to pull the boat to the anchor position. Motor the boat toward the anchor while retrieving the anchor rope. DANGER SAFETY CABLE USE - When the boat is being trailered, the anchor must be placed in the boat and secured. If the anchor breaks free during trailering, it could cause serious damage and/or injury. Attach Safety Cable Snap-Hook around anchor shackle to secure the anchor when boat is underway. Item Name: TRAC Pontoon 35-G3 Anchor Winch Instructions New RM#: 895237 Old RM#: n/a Colors: 1/1 black Coating: none Size: 8 pg booklet. 8.5 x 11 folded size - saddle stitch Stock: 60 lb bond Notes: Date Released: #820 Perforated Line Glue Area 895237#820 This anchor winch, intended for Fresh Water use, retrieves and deploys river and mushroom anchors using anchor rope. It features power-up, power-down, and AutoDeploy operation from a switch that is located on the winch cover and from a wireless remote controller, which can be installed near the boat’s helm. 895237 69004 Angler 30 G3 instructions.indd 1895237 69004 Angler 30 G3 instructions.indd 18/24/20 11:00 AM8/24/20 11:00 AM DANGER Rope breakage. 1.Never allow anyone to be positioned between anchor and winch. If rope breaks it could snap back and cause injury. 2.If the included anchor roller is ever replaced it must be replaced by a closed loop anchor roller to prevent the anchor line from snapping onto the boat deck in the event the rope breaks. 3.Always use an anchor rope with minimum 500 pound break strength for this product. Never substitute cable for rope. 4.This product is intended to lift short shanked river & mushroom anchors. Do not attempt to lift objects overhead. 5.Inspect entire rope for weak or worn condition. Replace worn rope with anchor rope with a min. 500 lb break strength. DANGER Electrical shock and fire hazards. 1.Do not use electrical wire sizes smaller than 12 AWG (gauge) with a 105-C temperature rating. Using wire that is too small could result in overloading and a fire. Larger gauge wire is permitted. 2.Use the supplied circuit breaker or a 20 amp in-line fuse when installing this winch. 3.Always disconnect the battery lead wires from the battery before attempting to install, relocate, or service the winch. DANGER Cruising and boat trailering hazards. As a precaution, when the boat is cruising the anchor must be secured with the safety cable provided. When the boat is being trailered, the anchor must be placed inside the boat or tow vehicle. If the anchor breaks free during cruising or trailering, it could cause serious damage and/or injury. WARNING Entanglement hazards. 1.Never place any object or tool in the rope spool while retrieving or deploying the anchor. The tool or object could become tangled in the rope resulting in serious injury and/or damage to the winch. 2.Do not wear loose fitting clothing, scarves, or neck ties during the operation of the winch. Loose clothing may become caught in moving parts resulting in injury or death. 3.Do not operate the winch under the influence of drugs and/or alcohol. CAUTION Storage and maintenance. For storage, it is best to disconnect positive wire from battery. DANGER Connecting the winch to battery power. Do not use wire sizes smaller than 12 AWG with 105-degree C rated insulation. Using wire that is insufficient could result in overloading and a fire. The use of larger diameter wire is encouraged and can improve the flow of electrical current. If longer wire is required, use the next larger wire size (10 AWG) for your installation. Use the supplied circuit breaker or an in-line 20-amp fuse. Using incorrect circuit breakers may result in fire. Always disconnect battery wires from the battery before attempting to install, relocate, or service the winch. CAUTION ROPE INSTALLATION Anchor rope is pre-installed, but when you need to install new rope, insert the rope through the hole located on the inside of the spool/drum and tie an overhand knot on the out…

Text truncated - open the document above for the full version.

C5266091_X8_Ed.1 1/1 Camco Mfg Inc.. Company: Camco Mfg Inc. Address: 121 Landmark Drive Greensboro, NC 2740 Product Name: Wireless remote Model Number: T10208 FCC Identifier: 2AX9V-T10208 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Yo yo Date: Oct, 20. 2020 Title: Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Camco Mfg Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: Nov, 23. 2020 Subject: Request for Confidentiality FCC ID: 2AX9V-T10208 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Yo yo Title: Manager

Page 1 of 3 Report No.:FCS202009050 External photos Photo 1 Photo 2 Page 2 of 3 Report No.:FCS202009050 Photo 3 Photo 4 Page 3 of 3 Report No.:FCS202009050 Photo 5 Photo 6

Label and Label Location FCC ID:2AX9V-T10208 L*W: 10mm*5mm Black label and white font

Page 1 of 3 Report No.:FCS202009050 Internal photos Photo 1 Photo 2 Antenna HS1527 Page 2 of 3 Report No.:FCS202009050 Photo 3 Photo 4 Page 3 of 3 Report No.:FCS202009050 Photo 5 Photo 6

Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com FCC Test Report Report No: FCS202009050W01 Issued for Applicant: Camco Mfg Inc. Address: 121 Landmark Drive Greensboro, NC 27409 Product Name: Wireless remote Brand Name: N/A Model Name: T10208 Series Model: NA FCC ID: 2AX9V -T10208 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Page 2 of 29 Report No.:FCS202009050W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com TEST RESULT CERTIFICATION Applicant’s Name ...................: Camco Mfg Inc. Address ..................................: 121 Landmark Drive Greensboro, NC 27409 Manufacture's Name ..............: HON SHUN PLASTIC FTY.LTD. Address ..................................: PING HU TOWN, #239 PING HU STREET,SHEN ZHEN CITY, CHINA Zip code 518111 Product Description Product Name ........................: Wireless remote Brand Name .........................: N/A Model Name ...........................: T10208 Series Model ..........................: N/A Test Standards .......................: FCC Rules and Regulations Part 15 Subpart C, Section 231 Test Procedure .......................: ANSI C63.10:2013 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ............................. : Date (s) of performance of tests : Oct, 08. 2020 ~ Oct, 20. 2020 Date of Issue ............................ : Oct, 20. 2020 Test Result ................................ : Pass Tested by : (Scott Shen) Reviewed by : (Duke Qian) Approved by : (Kait Chen) Page 3 of 29 Report No.:FCS202009050W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.4 EQUIPMENTS LIST 11 3 CONDUCTED EMISSION MEASUREMENT 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 13 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 15 4.3 TEST SETUP 16 4.4 TEST RESULTS 17 5. TRANSMITTER TIME 22 5.1 LIMIT 22 5.2 TEST PROCEDURE 22 5.3 TEST SETUP 22 5.4 TEST RESULTS 22 6. 20 DB BANDWIDTH TEST 24 6.1 LIMIT 24 6.2 TEST PROCEDURE 24 6.3 TEST SETUP 24 6.4 TEST RESULTS 25 7. DUTY CYCLE 26 7.1 LIMIT 26 7.2 TEST PROCEDURE 26 7.3 TEST SETUP 26 Page 4 of 29 Report No.:FCS202009050W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Table of Contents Page 7.4 TEST RESULTS 27 8 ANTENNA REQUIREMENT 29 7.1 STANDARD REQUIREMENT 29 7.2 EUT ANTENNA 29 Page 5 of 29 Report No.:FCS202009050W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Revision History Rev. Issue Date Effect Page Contents 00 Oct, 20. 2020 All Initial Issue Page 6 of 29 Report No.:FCS202009050W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 1. SUMMARY OF TEST RESULTS FCC Part 15.231,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission NA -- 15.209, 15.231(b) Radiated Emission PASS -- 15.231(a) (1) Transmitter time PASS -- 15.231(c) 20dB Bandwidth PASS 15.231 Duty cycle PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) All tests are according to ANSI C63.10-2013 Page 7 of 29 Report No.:FCS202009050W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 1.1 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.71dB 2 Unwanted Emissions, conducted ±2.98 dB 3 Conducted Emission (9KHz-150KHz) ±4.13 dB 4 Conducted Emission (150KHz-30MHz) ±4.74 dB 5 All emissions,radiated(<1G) 30MHz-1000MHz ±3.2 dB 6 All emissions,radiated (1GHz -18GHz) ±3.66 dB 7 All emissions,radiated (18GHz -40GHz) ±4.31 dB Page 8 of 29 Report No.:FCS202009050W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye…

Text truncated - open the document above for the full version.

Page 1 of 1 Report No.:FCS202009018 Blow 1GHz for radiated emission test setup Above 1GHz for radiated emission test setup
