2AXAZ-LMC001Pet treat camera

1 Pet treat camera User Manual Dongguan Langmeng Intelligence Technology CO., LTD 2020.8 2 Catalogue 1. Product introduction .....................................................................................................................................3 2. Parameter table ...............................................................................................................................................3 3. Features ..............................................................................................................................................................4 Real-time HD Video ..................................................................................................................................4 Two-way audio interaction .....................................................................................................................4 Pet treat tossing ..........................................................................................................................................4 Feeding less amount, more times ........................................................................................................5 Good sealing, Keep fresh .........................................................................................................................5 4. Instruction manual ..........................................................................................................................................6 Initial mounting and setup ......................................................................................................................6 Wireless network connection .................................................................................................................7 Pour in pet treats ........................................................................................................................................7 Use mobile app to interact with pets ..................................................................................................8 Pet treats tossing button .........................................................................................................................8 5.Product model list of pet treat camera ....................................................................................................9 3 1． Product introduction The pet treat camera is designed and made by Dongguan LM intelligence tech Ltd. As a new generation of pet intelligence product mainly serves for pet owners, it is especially suitable for those who frequently separate with their pet (say, at work or travelling). Main function of this product includes real-time HD Video on cell phone, Two-way audio interact and remote-controlled pet treat tossing. 2. Parameter table Dimensions Units：mm Net weight 1.5kg Packaging weight 1.8kg Volume 400ml Video Video quality：1080P FOV：130°（diagonal） Focal length：2.8mm Power supply 12V,2A Power adapter 100-240V 50-60HZ 0.5A Wireless network 2.4Hz WiFi 5GHz Wifi Placement setup Mount on wall, place on table or stand on floor Mobile operating system requirement Android 4.2 or above IOS 10.2 or above 4 3. Features Figure 3-1. Appearance of pet treat camera The appearance of pet treat camera is demonstrated in figure 3-1, its main function could be described as below: Real-time HD Video Through internal video transmission module (with 1080p resolution) it would be easy for the pet owner to see pets on their mobile phone. A wide-angle lens configuration ensures relatively large range at home could be covered. The pet treat camera also capable to see pets at lowlight or night environment, through its auto switch high-brightness Infrared bulb. Two-way audio interaction Pet owners could call their pets remotely with the dual-track speaker inside the pet treat camera. Also, a sensitive microphone allows pet owner to hear their pets on their mobile phone. Pet treat tossing Main function of pet treat tossing module is to eject pet treats stored inside. Once trigger, pet treats would be thrown out in a curve trajectory, for the purpose of attracting pets and make them come to the pet camera. 5 Figure 3-2. Pet treat tossing schematic diagram The schematic diagram of pet treat tossing process is shown in Figure 3-2. Specifically, the vertical FOV of camera lens is 70°. If the pet treat camera is placed in the height of 1-1.5m, it would be able to eject pet treats to a distance about 1.2-1.5m, followed a curve trajectory which briefly shown on Figure 3-2 (the red line). Meanwhile, the camera lens is designed with a tilt angle of approximate 18°, this angle is demonstrated with a relative angle between main optical axis and the horizontal line (the orange angle). Thus, this will ensure the pet treats being thrown falling into the right middle of camera vision. Since pet treats will attract pets, pet owner will conveniently be able to watch their pets with the best vision angle. Feeding less amount, more times Comparing with most pet feeders, the pet treat camera is capable of tossing much less amount each time, which means one pack with a mere 100g pet snack could be divided into about 30 triggers. Having more fun with less food, and also prevent pets from being overweight. Good sealing, Keep fresh The top cover of storage space is made of food-grade silicon, also with good sealing design， pet treats stored will remain fresh and delicious even the product is placed in high humidity environment. 6 4. Instruction manual Initial mounting and setup First, plug in the power adapter, which is shown in figure 4-1 Figure 4-1. Power adapter of the pet treat camera The detail of three recommendation ways of mounting the product is listed in the table below: Mount ing w ay detail Stand on the floor Mount on wall Place on table How to fix Anti-slip silicon foot pad to fix on flat surface (foot pads are shown in figure 4-2) Latch structure designed on the back and a wall hanging hoo…

Text truncated - open the document above for the full version.

Dongguan Langmeng Intelligence Technology CO., LTD Statement Product: Pet treat camera FCC ID: 2AXAZ- LMC001 Model: LMC-001, LMC-002, LMC-003, LMC-004 All models are all identical in interior structure, electrical circuits and components, and just model names and color are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, signature : name / title : Jingyuan Wang / R & D Engineer Contact information / address: 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China

C5266091_X8_Ed.1 1/1 Letter of Authorization Dongguan Langmeng Intelligence Technology CO., LTD Company: Dongguan Langmeng Intelligence Technology CO., LTD Address: 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China Product Name: Pet treat camera Model Number: LMC-001, LMC-002, LMC-003, LMC-004 FCC Identifier: 2AXAZ- LMC001 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jingyuan Wang Date: 2020.8.26 Title: R & D Engineer Signature of applicant:

C5266091_X10_Ed.1 1/1 Dongguan Langmeng Intelligence Technology CO., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020-8-26 Subject: Request for Confidentiality FCC ID: 2AXAZ- LMC001 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jingyuan Wang Title: R & D Engineer

C5266091_X13_Ed.1 1/1 Dongguan Langmeng Intelligence Technology CO., LTD FCC Software Configuration Control Declaration Date: 2020-8-26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product/ Model Number: Pet treat camera/ LMC-001, LMC-002, LMC-003, LMC-004 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Signature of applicant Name: Jingyuan Wang Title: R & D Engineer

Annex A External Photos Report No.: HK2007312218‐1E/2E/3E Page 1 of 5 Report No.: HK2007312218‐1E/2E/3E Page 2 of 5 Report No.: HK2007312218‐1E/2E/3E Page 3 of 5 Report No.: HK2007312218‐1E/2E/3E Page 4 of 5 Report No.: HK2007312218‐1E/2E/3E Page 5 of 5

Size：L4 cm * W3 cm

Annex B Internal Photo Report No.: HK2007312218-1E/2E/3E Page 1 of 7 Report No.: HK2007312218-1E/2E/3E Page 2 of 7 Report No.: HK2007312218-1E/2E/3E Page 3 of 7 Report No.: HK2007312218-1E/2E/3E Page 4 of 7 Report No.: HK2007312218-1E/2E/3E Page 5 of 7 Report No.: HK2007312218-1E/2E/3E Page 6 of 7 Report No.: HK2007312218-1E/2E/3E Page 7 of 7 Antenna

FCC RF Exposure EUT Description: Pet treat camera Model No.: LMC‐001, LMC‐002, LMC‐003, LMC‐004 FCC ID: 2AXAZ‐LMC001 1. Limits According to KDB 447498 D01 General RF Exposure Guidance v06 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm ar e determined by: [(max power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)]·[√ f(GHz)]≤3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, Where: Result=P/D*√F F= the RF channel transmit frequency in GHz P=Maximum turn‐up power in mw D=Min. te st separation distance in mm 2. Test Result of RF Exposure Evaluation 2.4G Output power （dBm） Tune Up Power （dBm） Max Tune Up power dBm/mW Min test separati on distance mm Result Limit SAR Test Exclusion 2.4Gwifi 8.49 7.5±1 8.5/7.079 5 2.193 3.0 Pass 5.2Gwifi 5.38 4.5±1 5.5/3.548 5 1.618 3.0 Pass 5.8Gwifi 5.43 4.5±1 5.5/3.548 5 1.709 3.0 Pass Note: PK Output power= conducted power. Conducted power see the test report HK2007312218‐1E/2E/3E , antenna gain=3dBi Per KDB 447498 D01, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. The test exclusion threshold is 2.222 which is<= 3, SAR testing is not required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f (GHz) ] f (GHz) is the RF channel transmit frequency in GHz Distance=5mm Note: 2.4G WIFI and 5G WiFi cannot transmit at the same time

Report No.: HK2007312218-2E FCC TEST REPORT T est report On Behalf of Dongguan Langmeng Intelligence Technology CO., LTD For Pet treat camera Model No.: LMC-001, LMC-002, LMC-003, LMC-004 FCC ID: 2AXAZ-LMC001 Prep ared for : Dongguan Langmeng Intelligence Technology CO., LTD 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Aug. 10, 2020 ~Aug. 17, 2020 Date of Report: Aug. 17, 2020 Report Number: HK2007312218-2E Report No.: HK2007312218-2E Page 2 of 62 TEST RESULT CERTIFICATION Applicant’s name .................. : Dongguan Langmeng Intelligence Technology CO., LTD Address .................................. : 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China Manufacture's Name ............ : Dongguan Langmeng Intelligence Technology CO., LTD Address .................................. : 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China Product description Trade Mark: N/A Product name ............................ : Pet treat camera Model and/or type reference . : LMC-001, LMC-002, LMC-003, LMC-004 Standards .............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.407 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Aug. 10, 2020 ~Aug. 17, 2020 Date of Issue ........................................... : Aug. 17, 2020 Test Result ............................................... : Pass Prepared by: Project Engineer Reviewed by: Project Supervisor Approved by: Technical Director Report No.: HK2007312218-2E Page 3 of 62 TABLE OF CONTENTS 1. Test Result Summary ............................................................................... 5 1.1. TEST PROCEDURES AND RESULTS ............................................................................................... 5 1.2. TEST FACILITY .................................................................................................................................. 5 1.3. MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. EUT Description ........................................................................................ 7 2.1. GENERAL DESCRIPTION OF EUT ................................................................................................... 7 2.2. OPERATION FREQUENCY EACH OF CHANNEL ........................................................................................... 8 2.3. OPERATION OF EUT DURING TESTING .................................................................................................... 8 2.4. DESCRIPTION OF TEST SETUP ....................................................................................................... 9 3. Genera Information ................................................................................. 10 3.1. TEST ENVIRONMENT AND MODE ............................................................................................................ 10 3.2. DESCRIPTION OF SUPPORT UNITS ........................................................................................................ 11 4. Test Results and Measurement Data .................................................... 12 4.1. CONDUCTED EMISSION ........................................................................................................................ 12 4.2. MAXIMUM CONDUCTED OUTPUT POWER .............................................................................................. 16 4.3. 6DB EMISSION BANDWIDTH ................................................................................................................. 19 4.4. 26DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ............................................................................ 20 4.5. POWER SPECTRAL DENSITY ................................................................................................................ 27 4.6. BAND EDGE ......................................................................................................................................... 34 4.7. SPURIOUS EMISSION ........................................................................................................................... 48 4.8. FREQUENCY STABILITY MEASUREMENT ................................................................................................ 56 ANTENNA REQUIREMENT ...................................................................................................................... 59 4.9. PHOTOGRAPHS OF TEST SETUP ........................................................................................................... 60 4.10. PHOTOS OF THE EUT ..................................................................................................................... 62 Report No.: HK2007312218-2E Page 4 of 62 ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release Aug. 17, 2020 Jason Zhou Report No.: HK2007312218-2E Page 5 of 62 1. Test Result Summary 1.1. TEST PROCEDURES AND RESULTS Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emissi…

Text truncated - open the document above for the full version.

Report No.: HK2007312218-3E FCC TEST REPORT T est report On Behalf of Dongguan Langmeng Intelligence Technology CO., LTD For Pet treat camera Model No.: LMC-001, LMC-002, LMC-003, LMC-004 FCC ID: 2AXAZ-LMC001 Prep ared for : Dongguan Langmeng Intelligence Technology CO., LTD 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Aug. 10, 2020 ~Aug. 17, 2020 Date of Report: Aug. 17, 2020 Report Number: HK2007312218-3E Report No.: HK2007312218-3E Page 2 of 61 TEST RESULT CERTIFICATION Applicant’s name .................. : Dongguan Langmeng Intelligence Technology CO., LTD Address .................................. : 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China Manufacture's Name ............. : Dongguan Langmeng Intelligence Technology CO., LTD Address .................................. : 507, B2, BaoHao Winpark, No.15 Industrial road, Songshan lake high-tech development zone, Dongguan, Guangdong Province, China Product description Trade Mark: N/A Product name ............................ : Pet treat camera Model and/or type reference . : LMC-001, LMC-002, LMC-003, LMC-004 Standards .............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.407 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Aug. 10, 2020 ~Aug. 17, 2020 Date of Issue ........................................... : Aug. 17, 2020 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Report No.: HK2007312218-3E Page 3 of 61 TABLE OF CONTENTS 1. Test Result Summary ............................................................................... 5 1.1. TEST PROCEDURES AND RESULTS ............................................................................................... 5 1.2. TEST FACILITY .................................................................................................................................. 5 1.3. MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. EUT Description ........................................................................................ 7 2.1. GENERAL DESCRIPTION OF EUT ................................................................................................... 7 2.2. OPERATION FREQUENCY EACH OF CHANNEL ........................................................................................... 8 2.3. OPERATION OF EUT DURING TESTING .................................................................................................... 8 2.4. DESCRIPTION OF TEST SETUP ....................................................................................................... 9 3. Genera Information ................................................................................. 10 3.1. TEST ENVIRONMENT AND MODE ............................................................................................................ 10 3.2. DESCRIPTION OF SUPPORT UNITS ........................................................................................................ 11 4. Test Results and Measurement Data .................................................... 12 4.1. CONDUCTED EMISSION ........................................................................................................................ 12 4.2. MAXIMUM CONDUCTED OUTPUT POWER .............................................................................................. 16 4.3. 6DB EMISSION BANDWIDTH ................................................................................................................. 18 4.4. 26DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH ............................................................................ 25 4.5. POWER SPECTRAL DENSITY ................................................................................................................ 26 4.6. BAND EDGE ......................................................................................................................................... 33 4.7. SPURIOUS EMISSION ........................................................................................................................... 48 4.8. FREQUENCY STABILITY MEASUREMENT ................................................................................................ 56 4.9. ANTENNA REQUIREMENT ............................................................................................................. 58 4.10. PHOTOGRAPHS OF TEST SETUP ........................................................................................................... 59 4.11. PHOTOS OF THE EUT ..................................................................................................................... 61 Report No.: HK2007312218-3E Page 4 of 61 ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release Aug. 17, 2020 Jason Zhou Report No.: HK2007312218-3E Page 5 of 61 1. Test Result Summary 1.1. TEST PROCEDURES AND RESULTS Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emiss…

Text truncated - open the document above for the full version.
