FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequen cy ene rgy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tur ning the eq uipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is conne cte d. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the f ollowing two conditions: This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimu m distance 20cm between the radiator and your body.

SC Soft Pte Ltd Add: 438B Alexandra Road, #01-08 Alexandra Technopark, 119968 Date: 2021-7-19 FCC ID: 2AXBK-SCVBVT65 Dear Sir/Madam, We, SC Soft Pte Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: SCV500+ Model no.: SCV500, SCV500+, SCV500EMV Sincerely, Name/Title： Wan Ting Chan/N/A Company: SC Soft Pte Ltd Address: 438B Alexandra Road, #01-08 Alexandra Technopark, 119968 Phone: +65 67306870 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021-7-19> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AXBK-SCVBVT65 SCV500 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Wan Ting Chan/N/A Company: SC Soft Pte Ltd Address: 438B Alexandra Road, #01-08 Alexandra Technopark, 119968 Phone: +65 67306870 Fax: N/A E-Mail: [email protected]

SC Soft Pte Ltd 438B Alexandra Road, #01-08 Alexandra Technopark, 119968 Date: 2021-7-19 FCC ID: 2AXBK-SCVBVT65 Model Number: SCV500 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, SC Soft Pte Ltd, declare that this EUT (FCC ID: 2AXBK-SCVBVT65) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Wan Ting Chan/N/A Company: SC Soft Pte Ltd Address: 438B Alexandra Road, #01-08 Alexandra Technopark, 119968 Phone: +65 67306870 Fax: N/A E-Mail: [email protected]

FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT GPRS ANTENNA This antenna is a reserved port GPS ANTENNA FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Appendix IFCC ID Label Size for the label: 61.50mm X 31.50mm FCCID:2AXBK-SCVBVT65 Model: SCV500 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 7 Appearance of PCB Photo 8 Appearance of PCB FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 9 Appearance of PCB Photo 10 Appearance of PCB FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 11 Appearance of PCB Photo 12 Appearance of PCB FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 15 Appearance of PCB Photo 16 Appearance of PCB FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 17 Appearance of PCB Photo 18 Appearance of PCB WIFI ANTENNA FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 19 Appearance of PCB Photo 20 Appearance of PCB FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 21 Appearance of PCB Photo 22 Appearance of PCB GPRS ANTENNA FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo 23 Appearance of PCB Photo 24 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TB-MPE182735 Page: 1 of 3 TB-RF-075-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Maximum Permissible Exposure Evaluation FCC ID: 2AXBK-SCVBVT65 1. Client Information Applicant : SC Soft Pte Ltd Address : 438B Alexandra Road, #01-08 Alexandra Technopark, Singapore 119968, Singapore Manufacturer : SC Soft Pte Ltd Address : 438B Alexandra Road, #01-08 Alexandra Technopark, Singapore 119968, Singapore 2. General Description of EUT EUT Name : SCV500+ Models No. : SCV500+, SCV500EMV Sample ID : 20210622-21-02 Product Description : Frequency Bands: 802.11b/g/n(HT20): 2412MHz~2462MHz GPRS 850: 824.20MHz-848.80MHz GPRS 1900: 1850.20MHz-1909.80MHz Antenna Type: Internal Antenna Antenna Gain: 2dBi Power Rating : Input Voltage Range: DC 9V to 38V Software Version : Android 7.1, Android 4.4, Linux 3.4, Linux 4.4 Hardware Version : SCV500+ V3.0.0 Note: More test information about the EUT please refer the RF Test Report. Report No.: TB-MPE182735 Page: 2 of 3 TB-RF-075-1.0 MPE Calculations for GSM 1. Antenna Gain: 2 dBi Internal Antenna 2. EUT Operation Condition: Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 3. Exposure Evaluation: Equation from page 18 of OET Bulletin 65, Edition 97-01 S=(PG)/4πR 2 Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna 4. Simultaneous transmission MPE Considerations According to KDB447498 :All transmitters and antennas in the host must be either evaluated for MPE compliance, by measurement or computational modeling, or qualify for the standalone MPE test exclusion in section 7.1.Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density. Limits for General Population/ Uncontrolled Exposure As specified in Table 1B of 47 CFR 1.1310- Limits for Maximum Permissible Exposure Frequency Range (MHz) Power density (mW/ cm 2 ) 300-1,500 F/1500 1,500-100,000 1.0 Note: For 300-1500MHz the worst Limit is 0.54947mW/cm 2 =(824.2/1500)mW/cm 2 This means that: ∑ of MPE ratios ≤ 0.54947 Report No.: TB-MPE182735 Page: 3 of 3 TB-RF-075-1.0 5. Test Result: Worst Maximum MPE Result Mode N TX Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/ cm 2 ) [S] 2.4G WiFi 1 18.521 18 ±1 19 2 20 0.025 GPRS 850 1 30.320 30 ±1 31 2 20 0.39696 GPRS 1900 1 28.370 28 ±1 29 2 20 0.25046 Note: 300-1500MHz:The worst MPE is calculated as 0.54947mW / cm 2 < limit 824.2/1500=0.54947 mW/cm 2 . So, RF exposure limit warning or SAR test are not required. 6. Summary simultaneous transmission information Synchronization transmit 2.4G+ GPRS 850 2.4G+ GPRS 1900 7. Summary simultaneous transmission results Maximum Simultaneous transmission MPE Ratios is 2.4G and GPRS 850: Maximum MPE ratio 2.4G Maximum MPE ratio GPRS 850 ∑MPE ratios Limit Results 0.025 0.39696 0.42196 0.54947 PASS 8. Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. Note For a more detailed features description, please refer to the RF Test Report. -----END OF REPORT------

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 1 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 RF Test Data for 2.4G WiFi (Conducted Measurements) General Description of EUT Product Name: SCV500+ Test Model: SCV500 Sample ID: 20210622-21-02 Environmental Conditions Temperature: 23.8°C Relative Humidity: 48% Test Voltage: DC 12V Test Engineer: Huang Jian Ping Note: For a more detailed features description, please refer to the report TB-RF180812. 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT b 2412 Ant1 100 0 0 NVNT b 2437 Ant1 100 0 0 NVNT b 2462 Ant1 100 0 0 NVNT g 2412 Ant1 100 0 0 NVNT g 2437 Ant1 100 0 0 NVNT g 2462 Ant1 100 0 0 NVNT n(HT20) 2412 Ant1 100 0 0 NVNT n(HT20) 2437 Ant1 100 0 0 NVNT n(HT20) 2462 Ant1 100 0 0 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 2 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Test Graphs Duty Cycle NVNT b 2412MHz Ant1 Duty Cycle NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 3 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Duty Cycle NVNT b 2462MHz Ant1 Duty Cycle NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 4 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Duty Cycle NVNT g 2437MHz Ant1 Duty Cycle NVNT g 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 5 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Duty Cycle NVNT n(HT20) 2412MHz Ant1 Duty Cycle NVNT n(HT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 6 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Duty Cycle NVNT n(HT20) 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 7 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 15.569 0 15.569 30 Pass NVNT b 2437 Ant1 15.858 0 15.858 30 Pass NVNT b 2462 Ant1 15.508 0 15.508 30 Pass NVNT g 2412 Ant1 17.888 0 17.888 30 Pass NVNT g 2437 Ant1 18.521 0 18.521 30 Pass NVNT g 2462 Ant1 18.046 0 18.046 30 Pass NVNT n(HT20) 2412 Ant1 16.802 0 16.802 30 Pass NVNT n(HT20) 2437 Ant1 17.227 0 17.227 30 Pass NVNT n(HT20) 2462 Ant1 16.791 0 16.791 30 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 8 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT b 2412 Ant1 9.536 0.5 Pass NVNT b 2437 Ant1 9.578 0.5 Pass NVNT b 2462 Ant1 8.512 0.5 Pass NVNT g 2412 Ant1 15.679 0.5 Pass NVNT g 2437 Ant1 15.696 0.5 Pass NVNT g 2462 Ant1 16.344 0.5 Pass NVNT n(HT20) 2412 Ant1 16.632 0.5 Pass NVNT n(HT20) 2437 Ant1 17.573 0.5 Pass NVNT n(HT20) 2462 Ant1 16.667 0.5 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 9 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Test Graphs -6dB Bandwidth NVNT b 2412MHz Ant1 -6dB Bandwidth NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 10 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 -6dB Bandwidth NVNT b 2462MHz Ant1 -6dB Bandwidth NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 11 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 -6dB Bandwidth NVNT g 2437MHz Ant1 -6dB Bandwidth NVNT g 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 12 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 -6dB Bandwidth NVNT n(HT20) 2412MHz Ant1 -6dB Bandwidth NVNT n(HT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 13 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 -6dB Bandwidth NVNT n(HT20) 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 14 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 4. Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT b 2412 Ant1 13.97257836 NVNT b 2437 Ant1 14.01212374 NVNT b 2462 Ant1 13.99975403 NVNT g 2412 Ant1 16.57511991 NVNT g 2437 Ant1 16.57122808 NVNT g 2462 Ant1 16.58536146 NVNT n(HT20) 2412 Ant1 17.79890561 NVNT n(HT20) 2437 Ant1 17.78984244 NVNT n(HT20) 2462 Ant1 17.79115139 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 15 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Test Graphs OBW NVNT b 2412MHz Ant1 OBW NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 16 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 OBW NVNT b 2462MHz Ant1 OBW NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 17 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 OBW NVNT g 2437MHz Ant1 OBW NVNT g 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 18 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 OBW NVNT n(HT20) 2412MHz Ant1 OBW NVNT n(HT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 19 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 OBW NVNT n(HT20) 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 20 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 5. Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Max PSD (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 -5.737 8 Pass NVNT b 2437 Ant1 -5.767 8 Pass NVNT b 2462 Ant1 -5.905 8 Pass NVNT g 2412 Ant1 -9.149 8 Pass NVNT g 2437 Ant1 -8.371 8 Pass NVNT g 2462 Ant1 -10.325 8 Pass NVNT n(HT20) 2412 Ant1 -7.865 8 Pass NVNT n(HT20) 2437 Ant1 -10.153 8 Pass NVNT n(HT20) 2462 Ant1 -10.423 8 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 21 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Test Graphs PSD NVNT b 2412MHz Ant1 PSD NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 22 of 49 FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 PSD NVNT b 2462MHz Ant1 PSD NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 23 of 49 FCC ID: 2AXBK-SCVBVT65 TB…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC182733 Page: 1 of 38 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Radio Test Report FCC ID: 2AXBK-SCVBVT65 Report No. : TB-FCC182733 Applicant : SC Soft Pte Ltd Equipment Under Test (EUT) EUT Name : SCV500+ Model No. : SCV500 Series Model No. : SCV500+, SCV500EMV Brand Name : SC Soft Sample ID : 20210622-21-01&20210622-21-02 Receipt Date : 2021-06-23 Test Date : 2021-06-24 to 2021-07-19 Issue Date : 2021-07-19 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Witness Engineer : Wade. Lv Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC182733 Page: 2 of 38 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION TEST ........................................................................................... 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 12 5.3 Test Procedure ................................................................................................................... 12 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 13 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 6.2 Test Setup ........................................................................................................................... 14 6.3 Test Procedure ................................................................................................................... 16 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Mode ........................................................................................................ 17 6.6 Test Data ............................................................................................................................. 17 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 Deviation From Test Standard ......................................................................................... 20 7.5 EUT Operating Mode ........................................................................................................ 20 7.6 Test Data ............................................................................................................................. 20 8. BANDWIDTH TEST ................................................................................................................. 21 8.1 Test Standard and Limit .................................................................................................... 21 8.2 Test Setup ........................................................................................................................... 21 8.3 Test Procedure ..…

Text truncated - open the document above for the full version.

FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Above 1 GHz) FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Above 1 GHz) FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo of Setup for Radiated Emission (Below 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) FCC ID: 2AXBK-SCVBVT65 TB-RF-074-1.0 Photo of Setup for Conducted Emission -----END OF REPORT-----
