2AXBV-WX-01Car Wireless Charger Phone Holder

Car Wireless Charger Phone Holder WX-01 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device must operate with a minimum distance of 20 cm between the radiator and user body. FCC Statement

Shenzhen Hengyehui Technology Company Limited No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Tel: +86-15013833396 E-mail: [email protected] Series Models Description Date: 2020/09/04 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: 2AXBV-WX-01 Dear Sir/Madam, We, Shenzhen Hengyehui Technology Company Limited Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only color and model number is different for these model: Product name: Car Wireless Charger Phone Holder Model no.: WX-01, WX-01A, WX-01B Sincerely, Name: Zibiao Zheng Company: Shenzhen Hengyehui Technology Company Limited Address: No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Phone: +86-15013833396 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/09/04 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AXBV-WX-01 WX-01, WX-01A,WX-01B For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Zibiao Zheng Company: Shenzhen Hengyehui Technology Company Limited Address: No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Phone: +86-15013833396 Fax: N/A E-Mail: [email protected]

Shenzhen Hengyehui Technology Company Limited No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Tel: +86-15013833396 E-mail: [email protected] Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 09/04/2020 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AXBV-WX-01 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Zibiao Zheng Company: Shenzhen Hengyehui Technology Company Limited Address: No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Phone: +86-15013833396 Fax: N/A E-Mail: [email protected]

FCC ID: 2AXBV-WX-01 FCC ID: 2AXBV-WX-01 FCC ID: 2AXBV-WX-01

FCC ID: 2AXBV-WX-01 FCC ID: 2AXBV-WX-01

FCC ID: 2AXBV-WX-01 Antenna

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20200828014-1-5-2 2AXBV-WX-01 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Aug. 28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Hengyehui Technology Company Limited Address ............................................ : No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Car Wireless Charger Phone Holder Trade Mark ....................................... : OHLPRO, PLDHPRO Manufacturer .................................... : Shenzhen Hengyehui Technology Company Limited Model/Type reference....................... : WX-01 Listed Models .................................. : WX-01A,WX-01B Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : DC 5V/2A or 9V/1.67A Result................................................ : PASS Report No.: GTS20200828014-1-5-2 Page 2 of 12 T E S T R E P O R T Test Report No. : GTS20200828014-1-5-2 Aug. 28, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Car Wireless Charger Phone Holder Model /Type : WX-01 Listed Models : WX-01A,WX-01B Applicant : Shenzhen Hengyehui Technology Company Limited Address : No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Manufacturer : Shenzhen Hengyehui Technology Company Limited Address : No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200828014-1-5-2 Page 3 of 12 Contents 1 S U M M A R Y ............................................................................ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Special Accessories 4 1.5 Modifications 5 2 T E S T E N V I R O N M E N T .............................................................. 6 2.1 Address of the test laboratory 6 2.2 Test Facility 6 2.3 Environmental conditions 6 2.4 Summary of measurement results 7 2.5 Statement of the measurement uncertainty 7 2.6 Equipments Used during the Test 7 3 T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 8 3.1 Applicable Standard 8 3.2 Limit 8 3.3 Test Setup 8 3.4 Measurement Procedure 9 3.5 Test Result of E and H field Strength 9 1.1. Equipment Approval Considerations 11 1.2. Conclusion 11 4 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 12 Report No.: GTS20200828014-1-5-2 Page 4 of 12 1 S U M M A R Y 1.1 General Remarks Date of receipt of test sample : Aug. 05, 2020 Testing commenced on : Aug. 06, 2020 Testing concluded on : Aug. 17, 2020 1.2 Product Description Product Name: Car Wireless Charger Phone Holder Model/Type reference: WX-01 Hardware version: V1.0 Software version: V1.0 Test samples ID: GTS20200828014-1-5# Power supply: DC 5V/2A or 9V/1.67A Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 AC/DC Adapter (9V/1.67A) + EUT + Wireless charger tester (Load 10W) Record Mode 2 AC/DC Adapter (9V/1.67A) + EUT + Wireless charger tester (Load 7.5W) Record Mode 3 AC/DC Adapter (9V/1.67A) + EUT + Wireless charger tester (Load 5W) Record Mode 4 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 10W) Pre-tested Mode 5 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 7.5W) Pre-tested Mode 6 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 5W) Pre-tested Note: All test modes were pre-tested, but we only recorded the worst case in this report. 1.4 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is listed as follow: Description Manufacturer Model Technical Parameters Certificate Provided by Adapter CHENYANG ELECT…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20200828014-1-5 2AXBV-WX-01 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Aug. 28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Hengyehui Technology Company Limited Address ............................................ : No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Car Wireless Charger Phone Holder Trade Mark ....................................... : OHLPRO, PLDHPRO Manufacturer .................................... : Shenzhen Hengyehui Technology Company Limited Model/Type reference....................... : WX-01 Listed Models .................................. : WX-01A,WX-01B Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : DC 5V/2A or 9V/1.67A Result................................................ : PASS Report No.: GTS20200828014-1-5 Page 2 of 24 T E S T R E P O R T Test Report No. : GTS20200828014-1-5 Aug. 28, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Car Wireless Charger Phone Holder Model /Type : WX-01 Listed Models : WX-01A,WX-01B Applicant : Shenzhen Hengyehui Technology Company Limited Address : No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Manufacturer : Shenzhen Hengyehui Technology Company Limited Address : No.20-2 workshop, Xinmu Avenue, Xinmu community, Pinghu street, Longgang District, Shenzhen City, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200828014-1-5 Page 3 of 24 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Description of the test mode 5 2.4 Special Accessories 5 2.5 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 8 4 T E S T C O N D I T I O N S AN D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Occupied Bandwidth 17 4.4 Antenna Requirement 18 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 19 6 PH O T O S O F T H E E U T ........................................................... 20 Report No.: GTS20200828014-1-5 Page 4 of 24 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C (Section 15.207): Conducted limits. FCC Rules and Regulations Part 15 Subpart C (Section 15.209): Radiated emission limits; general requirements. ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: GTS20200828014-1-5 Page 5 of 24 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Aug. 05, 2020 Testing commenced on : Aug. 06, 2020 Testing concluded on : Aug. 17, 2020 2.2 Product Description Product Name: Car Wireless Charger Phone Holder Model/Type reference: WX-01 Hardware version: V1.0 Software version: V1.0 Test samples ID: GTS20200828014-1-5# Power supply: DC 5V/2A or 9V/1.67A Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna 2.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 AC/DC Adapter (9V/1.67A) + EUT + Wireless charger tester (Load 10W) Record Mode 2 AC/DC Adapter (9V/1.67A) + EUT + Wireless charger tester (Load 7.5W) Pre-tested Mode 3 AC/DC Adapter (9V/1.67A) + EUT + Wireless charger tester (Load 5W) Pre-tested Mode 4 AC/DC…

Text truncated - open the document above for the full version.

FCC ID: 2AXBV-WX-01
