2AXBX-NSXXAutomated dispensing cabint

OperatinginstructionsofAutomated dispensingcabinet Safety statement: If you are using our product for the first time, please read the user's manual carefully to understand the performance of the product, reasonable allocation of resources, make our product the most successful choice in your project implementation. To avoid possible danger, please use this equipment according to the regulation. In case of damage, non-professionals do not open maintenance, please contact the company in a timely manner after sales. High Voltage Hazard: The working voltage of this product is 100V-240V AC. EARTHING: This product is connected to the earth through the ground wire of the power supply. Please make sure the earthing conductor is well grounded. Electromagnetic interference: the equipment should be away from magnets, motors and transformers. Keep the equipment in a dry and clean environment. If liquid is involved, unplug the plug immediately. Keep away from inflammable and explosive dangerous goods. It is forbidden for liquid and metal fragments to penetrate into the machine, so as not to cause safety accidents. Product Overview: Automated dispensing cabinet is mainly used in ward, nurse station, operating room and other occasions. Streamline the cumbersome process for medical staff to collect medicines and improve work efficiency. The whole process is traceable and controlled, protected by multiple means of protection, optimized design and operation guidelines to ensure the safety of drugs and their use. Specification parameters: configurationMain CabinetAuxiliary cabinet operating systemwindows7/ CPU configurationIntel Core i5/ Performance configuration DDR3/8G,500G/ Display15.6 ", 1920*1080/ Communication methodsLAN network communicationCAN protocol communication Other interfaceUSB3.0*4 + USB2.0*5 ， RS232*2/ Monitory point11 The video store2Share with main cabinet Function module Face recognition, RFID card reader, finger vein recognition, code reader / Weighing sensor Standard 3Kg sensor (optional 6Kg sensor) Standard 3Kg sensor (optional 6Kg sensor) Electronic tags Standard 3.12-inch OLED display (optional LCD display) Standard 3.12-inch OLED display (optional LCD display) Store the medicine pill boxes 6 floors, 4 pieces per floor (customizable)7 floors, 4 for each floor (customizable) Material1.5mm thick carbon steel plate1.5mm thick carbon steel plate Surface treatmentSheet metal powder medical whiteSheet metal powder medical white The power supply100V-240V AC100V-240V AC Power consumption<200W<120W size650mm(L)*525mm(W)*2093mm(H)650mm(L)*525mm(W)*2093mm(H) Structuraldiagram： Touchscreen Monitorypoint kit Readthecodeeditor Electronictags Movablecasters Referstotheveininstrument Temperatureandhumidity display Facerecognition Cardreader Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF exposure compliance statement: This device has been evaluated to meet the general RF exposure requirement Warranty Card Company:__________________________________________________________ Tel:______________________________________________________________ Name:_____________________________________________________________ Add:______________________________________________________________ E-mail:___________________________________________________________ Product Info:_____________________________________________________

Shenzhen RuiYiBo Science & Technology Crop.Ltd Agent Authorization Company: Shenzhen RuiYiBo Science & Technology Crop.Ltd Address: 15/F, Building 7A, Baoneng Science&Technology Park, Qingxiang Road, Longhua District, Shenzhen, China Product Name: Automated dispensing cabint Model Number(s): N Serial, NR, CM, CV, CH, LM, LR, EH, ES, RH, RM, RG, FH Product Description: Automated dispensing cabint We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Aug. 23, 2020 Name: QianXiaoting Title: manager Company: Shenzhen Longhua Tianwangzhi Technology Manufacture

Shenzhen RuiYiBo Science & Technology Crop.Ltd Date: Aug. 23, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2AXBX-NSXX To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: QianXiaoting Title: manager

Difference statement 2020-08-17 We Shenzhen RuiYiBo Science & Technology Crop.Ltd declar that the products we applied for FCC ID certification have multiple models(N Serial, NR, CM, CV, CH, LM, LR, EH, ES, RH, RM, RG, FH), but all models have the same functionality, software and electronics, only the model names may differ. So test sample model: N Serial Name/title: QianXiaoting/ manager Tel:0755-26506355 Email:[email protected] Signature

SIZE:8*15cm PRODUCT : Automated dispensing cabint Model No. : N Serial FCC ID : 2AXBX-NSXX FCC NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Input voltage : Factory number : Date of manufacture :

Black solid thermal adhesive NFC ANT

Page 1 of 22 Report No.: HK2008072133-E TEST REPORT Test report On Behalf of Shenzhen RuiYiBo Science & Technology Crop.Ltd For Automated dispensing cabint Model No.: N Serial, NR, CM, CV, CH, LM, LR, EH, ES, RH, RM, RG, FH FCC ID: 2AXBX-NSXX Prepared for : Shenzhen RuiYiBo Science & Technology Crop.Ltd 15/F, Building 7A, Baoneng Science&Technology Park, Qingxiang Road, Longhua District, Shenzhen, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Aug. 03, 2020 -- Aug. 19, 2020 Date of Report: Aug. 19, 2020 Report Number: HK2008072133-E Page 1 of 22 Report No.: HK2008072133-E TEST RESULT CERTIFICATION Applicant’s name .................. : Shenzhen RuiYiBo Science & Technology Crop.Ltd Address ................................... : 15/F, Building 7A, Baoneng Science&Technology Park, Qingxiang Road, Longhua District, Shenzhen, China Manufacture's Name............. : Shenzhen RuiYiBo Science & Technology Crop.Ltd Address ................................... : 15/F, Building 7A, Baoneng Science&Technology Park, Qingxiang Road, Longhua District, Shenzhen, China Product description Trade Mark ............................ : Product name ....................... : Automated dispensing cabint Model and/or type reference .: N Serial, NR, CM, CV, CH, LM, LR, EH, ES, RH, RM, RG, FH Standards............................... : FCC Part 15 Subpart C Section 15.225 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test .......................................... : Date (s) of performance of tests ............ : Aug. 03, 2020 -- Aug. 19, 2020 Date of Issue .......................................... : Aug. 19, 2020 Test Result ............................................. : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 1 of 22 Report No.: HK2008072133-E TABLE OF CONTENTS 1. Test Result Summary ...................................................................................................................4 1.1. TEST FACILITY ......................................................................................................................4 1.2. MEASUREMENT UNCERTAINTY .........................................................................................4 2. EUT Description ............................................................................................................................5 3. Genera Information .......................................................................................................................6 3.1. TEST ENVIRONMENT AND MODE ...............................................................................................6 3.2. DESCRIPTION OF SUPPORT UNITS.............................................................................................6 4. Test Results and Measurement Data..........................................................................................7 4.1. ANTENNA REQUIREMENT ..........................................................................................................7 4.2. CONDUCTED EMISSION .............................................................................................................8 4.3. RADIATED EMISSION MEASUREMENT ......................................................................................11 4.4. OCCUPIED BANDWIDTH ..........................................................................................................17 4.5. FREQUENCY STABILITY ...........................................................................................................19 5. Photos of Test Setup ..................................................................................................................21 6. Photos of EUT .............................................................................................................................23 Page 1 of 22 Report No.: HK2008072133-E 1. Test Result Summary Requirement CFR 47 Section Result Conduction Emission, 0.15MHz to 30MHz §15.207 PASS Radiation Emission §15.225, §15.205, §15.209, §15.35 PASS Occupied Bandwidth §15.215 PASS Antenna requirement §15.203 PASS Frequency stability §15.225 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test ob ject. 4. The test result judgment is decided by the limit of test standard. 1.1. TEST FACILITY Test Firm : Shenzhen HUAK Testing Technology Co., Ltd. Address : 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China FCC designation number : CN1229 test firm registration number : 616276 1.2. MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty = 2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz) = 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 1 of 22 Report No.: HK2008072133-E 2. EUT Description Product Name: Automated dispensing cabint Model/Type reference: N Serial Serial Model: NY, NR, CM, CV, CH, LM, LR, EH, ES, RH, RM, RG, FH Model difference: all models have the same functionality, software and electronics, only the model names may differ. So test sample model: N Serial Trade Mark: FCC ID: 2AXBX-NSXX Modulation: ASK Operation frequency: 13.56MHz Channel number: 1 Channel separation: / Antenna type: Coil Antenna Note: 1. For more details, refer to the…

Text truncated - open the document above for the full version.

Radiated Emission below 30MHz Radiated Emission 30-1000MHz Conduction Emission
