2AXCE-WIC501Wireless Charger

WIC501 Wireless Charger Product Instruction Manual 01 / Product Parameters Model: WIC501 Input: 5V*2A/9V*2A/12V*2A Output: 5V*1A / 9V*1.67A /12V*1.2A Frequency: 110KHz~205KHz Ambient temperature: -5°C－40°C 02 / Operation Method 1. Install the Wupi wireless chargers WIC501 on the Wupi motorcycles bracket, and insert the USB terminal into the USB charger interface of the Wupi motorcycles. 2. In order to start wireless charging for the phone，please make sure the wireless receiving position of phone is placed correctly on the transmitting range of the wireless charger,then press the USB switch of the Wupi wireless chargers to start charging(Usually the wireless receiving position is at the center of the phone); 3. When the charging is completed or the charging needs to be stopped, press the USB switch of theWupi wireless charger again, and the indicator light will go out. Note: This wireless charger is not limited to use on motorcycles only. 03/ Indicator LED Stand-by Blue light always on Working--Fast charging Red light always on Working--Slow charging Blue light flashes Metal foreign objects detected or Insufficient input powerout or deviation from the right position Red light flashes 04/ Notes: 1. Please make sure the phone is placed on the center of the wireless charger. Deviation from the center will decrease the charging efficiency or interrupt the charging. 2. It should be less than 4mm for the thickness of the phone case, and there should be no foreign metal objects in the charging area between the phone and wireless charger. Otherwise, the charging efficiency will be decreased, or the charging could be interrupted, even it could lead to latent danger. 3. It is highly recommended that the ambient temperature should be below 28 degrees Celsius (82.4 degrees Fahrenheit) during the charging period. it could decrease charging efficiency or lead to interruption for the higher ambient temperature. 05/ Safety tips 1. Do not put foreign metal objects in the charging area between the phone and wireless charger, which will lead to latent danger. 2. Do not put magnetic stripe cards (such as credit cards, telephone cards, bank cards, etc.) or some medical equipment (such as pacemakers or hearing aids) together with this product, which may cause damage to the magnetic stripe or abnormal operation of the equipment. 3. Do not apply heavy pressure and place it out of reach of children or animals. 4. Do not disassemble, refit and repair the wireless charger by oneself, otherwise it will not be able to carry out normal after-sale service. 06/ Warranty The warranty of this product is twelve months. Failure or damage not caused by human factors, please contact the purchasing channel or Brand side for after-sales service under warranty. The warranty does not apply to the following: 1.Damage caused by force majeure. 2.Failure or damage of the product caused by human factors. 3.Warranty expired. FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device must operate with a minimum distance of 20 cm between the radiator and user body.

Chengdu Wupi Technology Co, Ltd. Add: No. 18, 1st Floor, Building 6, No. 85, Jiujin Street, Wuhou District, Chengdu, China Tel: +86 13666239238 Fax: +86 028-64749884 Date: 2020-09-14 Dear Sir/Madam, We, Chengdu Wupi Technology Co, Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Wireless Charger Model no.: WIC501, WID503, WIE911, WIF211, WIG620, WIH815 FCC ID: 2AXCE-WIC501 Sincerely, Name: Zhongkai Shen Company: Chengdu Wupi Technology Co, Ltd. Address: No. 18, 1st Floor, Building 6, No. 85, Jiujin Street, Wuhou District, Chengdu, China Phone: +86 13666239238 Fax: +86 028-64749884 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/09/14 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AXCE-WIC501 WIC501, WID503, WIE911, WIF211, WIG620, WIH815 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Zhongkai Shen Company: Chengdu Wupi Technology Co, Ltd. Address: No. 18, 1st Floor, Building 6, No. 85, Jiujin Street, Wuhou District, Chengdu, China Phone: +86 13666239238 Fax: +86 028-64749884 E-Mail: [email protected]

Chengdu Wupi Technology Co, Ltd. No. 18, 1st Floor, Building 6, No. 85, Jiujin Street, Wuhou District, Chengdu, China Tel: +86 13666239238 Fax: +86 028-64749884 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/14/2020 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AXCE-WIC501 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Zhongkai Shen Company: Chengdu Wupi Technology Co, Ltd. Address: No. 18, 1st Floor, Building 6, No. 85, Jiujin Street, Wuhou District, Chengdu, China Phone: +86 13666239238 Fax: +86 028-64749884 E-Mail: [email protected]

FCC ID: 2AXCE-WIC501 FCC ID: 2AXCE-WIC501 FCC ID: 2AXCE-WIC501

FCC ID: 2AXCE-WIC501 FCC ID: 2AXCE-WIC501 Input: 5V*2A/ 9V*2A/ 12*2A Output: 5V*1A/ 9V*1.67A/ 12*1.2A Frequency:110KHz~205KHz Temperature:-5°C-40°C

FCC ID: 2AXCE-WIC501 Antenna

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20200831004-1-3-2 2AXCE-WIC501 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Sep. 08, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Chengdu Wupi Technology Co, Ltd. Address ............................................ : No. 18, 1st Floor, Building 6, No. 85, Jiujin Street, Wuhou District, Chengdu, China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Wireless Charger Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen EnPassion Technology Ltd. Model/Type reference....................... : WIC501 Listed Models .................................. : WID503, WIE911, WIF211, WIG620, WIH815 Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : DC 5V/2A or 9V/2A or 12V/2A Result................................................ : PASS Report No.: GTS20200831004-1-3-2 Page 2 of 12 T E S T R E P O R T Test Report No. : GTS20200831004-1-3-2 Sep. 08, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Wireless Charger Model /Type : WIC501 Listed Models : WID503, WIE911, WIF211, WIG620, WIH815 Applicant : Chengdu Wupi Technology Co, Ltd. Address : No. 18, 1st Floor, Building 6, No. 85, Jiujin Street, Wuhou District, Chengdu, China Manufacturer : Shenzhen EnPassion Technology Ltd. Address : B01, 23/F, Tower A, Financial Technology Building, Keyuan Road, Nanshan District, Shenzhen, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200831004-1-3-2 Page 3 of 12 Contents 1 S U M M A R Y ............................................................................ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Special Accessories 4 1.5 Modifications 5 2 T E S T E N V I R O N M E N T .............................................................. 6 2.1 Address of the test laboratory 6 2.2 Test Facility 6 2.3 Environmental conditions 6 2.4 Summary of measurement results 7 2.5 Statement of the measurement uncertainty 7 2.6 Equipments Used during the Test 7 3 T E S T C O N D I TI O N S A N D R E S U L T S ............................................. 8 3.1 Applicable Standard 8 3.2 Limit 8 3.3 Test Setup 8 3.4 Measurement Procedure 9 3.5 Test Result of E and H field Strength 9 1.1. Equipment Approval Considerations 11 1.2. Conclusion 11 4 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 12 Report No.: GTS20200831004-1-3-2 Page 4 of 12 1 S U M M A R Y 1.1 General Remarks Date of receipt of test sample : Aug. 15, 2020 Testing commenced on : Aug. 16, 2020 Testing concluded on : Sep. 06, 2020 1.2 Product Description Product Name: Wireless Charger Model/Type reference: WIC501 Hardware version: YPS-15W-ONECOIL01 Software version: 1.1.0200907MKMX Test samples ID: GTS20200831004-1-3# Power supply: DC 5V/2A or 9V/2A or 12V/2A Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 AC/DC Adapter (12V/2A) + EUT + Wireless charger tester (Load 15W) Record Mode 2 AC/DC Adapter (12V/2A) + EUT + Wireless charger tester (Load 10W) Record Mode 3 AC/DC Adapter (12V/2A) + EUT + Wireless charger tester (Load 5W) Record Mode 4 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 15W) Pre-tested Mode 5 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 10W) Pre-tested Mode 6 AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 5W) Pre-tested Mode 7 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 15W) Pre-tested Mode 8 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 10W) Pre-tested Mode 9 AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 5W) Pre-tested Note: All test modes were pre-tested, but we only recorded the worst case in this report. Report No.: GTS20200831004-1-3-2 Page 5 of 12 1.4 Special Accessories Follow auxiliary equipment(s) test wit…
