2AXDMTMS30DUALTYPEBVehicle Control Terminal

TMS3.0 (Vehicle Control Terminal) Installation Manual version 3.1 This manual describes how to install the product. Read carefully this manual before using this product and install the product according to guideline. And after reading this manual, keep it well and, if the person in charge is changed, be sure to hand over this manual to the successor and let he/she use the product correctly. The content and image in this manual can be changed without notice by reason of product’s function improvement or etc. The content of this manual is protected by copyright. Therefore, do not change the content of this manual without permission of our company. Copyright © 2016 Issued by DASAN Networks TMS3.0 Internal Confidential Installation Manual 2 Revision history of document Version Date Description V1.0 2019-02-19 Initial release V2.0 2019-07-01 2 nd release - Type A removed LTE Connector V3.0 2020-09-14 3 rd release - Add FCC/CE/IC requirement - Iridium/GPS/WiFi Connector changed - LED Specification changed V3.1 2020-09-16 4 th release - Changed PMN TMS3.0 Internal Confidential Installation Manual 3 Contents 1. Precautions In Product Handling ..................................................... 6 2. System Overview ................................................................................ 9 3. Product Interface & Specification .................................................... 10 3.1 Classification By Product ..................................................................... 10 3.2 Product Specification ........................................................................... 13 3.3 Product Interface ................................................................................. 13 3.4 Product Antenna Specification ............................................................. 15 3.5 LED Specification ................................................................................ 15 4. Installation Preparation .................................................................... 17 4.1 Installation Method ............................................................................... 17 TMS3.0 Internal Confidential Installation Manual 4 Illustrations Fig. 2.1 Front/Rear View Fig. 3.1 Overall Shape Of TMS3.0 Type-A .................................................................. 10 Fig. 3.2 Overall Shape Of TMS3.0 Type-B ................................................................... 11 Fig. 3.3 Overall Shape Of TMS3.0 Type-C ................................................................... 11 Fig. 3.4 Overall Shape Of TMS3.0 Type-D .................................................................. 12 Fig. 3.5 Front Common Connector Shape Of TMS3.0 ............................................... 13 Fig. 3.6 Rear Connector Shape Of TMS3.0 Type-A .................................................... 14 Fig. 3.7 Rear Connector Shape Of TMS3.0 Type-B .................................................... 14 Fig. 3.8 Rear Connector Shape Of TMS3.0 Type-C .................................................... 14 Fig. 3.9 Rear Connector Shape Of TMS3.0 Type-D .................................................... 14 Fig. 4.1 Installation Block Diagram Of TMS3.0 .......................................................... 17 Fig. 4.2 Mounting Example of TMS3.0 ....................................................................... 18 TMS3.0 Internal Confidential Installation Manual 5 Tables Tab. 3.1 TMS3.0 Classification By Product .............................................................. 10 Tab. 3.2 TMS3.0 Product Specification ................................................................... 13 Tab. 3.3 TMS3.0 Interface Specification .................................................................. 15 Tab. 3.4 TMS3.0 Antennal Specification .................................................................. 15 Tab. 3.5 TMS3.0 LED Specification ......................................................................... 16 TMS3.0 Internal Confidential Installation Manual 6 1. Precautions In Product Handling Read carefully the following contents before handling this product and use this product cor- rectly according to guidelines. And after understanding precautions well, keep this manual well and let manager or user use this manual before and after installing product or before handling product. If the person in charge is changed, be sure to hand over this manual to the successor and let he/she use product correctly. Installation Qualifying Condition Only the person who is qualified for handling designated installation equipment or only skilled technician can install this product. Prohibition Of Product Disassembly Disassembly of this product can cause loss of life and property by electric shock, breakdown, malfunction, static electricity, etc. Do not disassemble, repair, remodel this product recklessly. If repair is needed, call Helpdesk (+82-1588-7080). Strict Observance Of Operation Condition This product normally operates in the condition described in product specification. However, if the product keeps operating in condition that it is close to the minimum or maximum value, a probability of loss of life and property increases. Therefore, be sure to predict/check environ- mental change that each condition range may not approach the minimum or maximum value, and manage that the equipment may operate in median value of operation condition range. Maintaining Cleanliness Of Installation Place Be sure to tidy up product installation place before and after installation, and do not leave working tools or components alone on the moving path to prevent accident. TMS3.0 Internal Confidential Installation Manual 7 FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera…

Text truncated - open the document above for the full version.

DASAN Networks, Inc. DASAN Tower, 49, Daewangpangyo-ro644Beon-gil, Bundang-gu, Seongnam-si, South Korea 13493 Date: 10/22/2020 FCC ID: 2AXDMTMS30DUALTYPEB Attestation Letter This device is integrated with the approval modules. LTE/WCDMA/GSM module FCC ID: XMR201903EG25G Satellite module FCC ID: Q639603N The product was designed with certified modules built into the final product without any hardware changes. The only change was to collaborate with the module manufacturer to adjust the tune-up power of the GSM1900. GSM1900 Tx power was adjusted to -3dB. Approval module report was submitted when it was applied for a certification. For GSM850, WCMDA, LTE and IRIDIUM Satellite, the original module test report accurately represents antenna- port conducted test results under the new host application. For GSM1900, new antenna-port conducted test results were reported. USIM installed on the TMS3.0 cannot be detachable due to its structure. The only USIM which is available to be used is Vodafone under Doosan. It is being used as Roaming. Therefore, accessing is not available except for designated carriers. Therefore, a separate SW protection is not supported because the customer is not able to change USIM, and the product is difficult to change carrier. In addition, TDD Band 40 is disabled by S/W at TMS3.0. Sincerely, Kee Ryong Sung Senior Research Engineer

DASAN Networks, Inc. DASAN Tower, 49, Daewangpangyo-ro644Beon-gil, Bundang-gu, Seongnam-si, South Korea 13493 Date: Oct 22, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AXDMTMS30DUALTYPEB including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from DASAN Networks, Inc. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Kee Ryong Sung Senior Research Engineer

DASAN Networks, Inc. DASAN Tower, 49, Daewangpangyo-ro644Beon-gil, Bundang-gu, Seongnam-si, South Korea 13493 Date: Oct 22, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: 2AXDMTMS30DUALTYPEB To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, DASAN Networks, Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give DASAN Networks, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description 5 Tune-up procedure SHORT-TERM 6 Internal Photos 7 External Photos 8 Test-Setup Photos 9 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Kee Ryong Sung Senior Research Engineer

FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID: 2 AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 4 <Antenna> <Antenna>

TMS 3.0 TYPE B () LABEL * For each certification, the certification mark on the label will be changed according to each certification. * The serial number is an example MLNR0WG523A0001

FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID: 2 AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 4 FCC ID: 2 AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 5

FCC ID: 2 AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 6 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 7 FCC ID: 2 AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 8 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 9 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 10 FCC ID: 2 AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 11 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 12 FCC ID: 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB Copyright Ⓒ 2020, DT&C Co., Ltd. View 13 <Antenna>

FCC ID: Mode Tune-up Max. Power(dBm) ANT Gain (dBi) Duty Factor(dB) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum power density (mW/cm 2 ) Requriment (mW/cm 2 ) GSRS850 (1TX) 824.20 ~ 848.80 35.00 1.84 -9.03 27.81 603.949 0.1202 0.5490 GSRS850 (4TX) 824.20 ~ 848.80 30.00 1.84 -3.01 28.83 763.836 0.1520 0.5490 GSRS1900 (1TX) 1850.20 ~ 1909.80 27.80 2.98 -9.03 21.75 149.624 0.0298 1.0000 GSRS1900 (4TX) 1850.20 ~ 1909.80 26.80 2.98 -3.01 26.77 475.336 0.0946 1.0000 WCDMA850 826.40 ~ 846.60 25.00 1.84 - 26.84 483.059 0.0962 0.5500 WCDMA1700 1712.40 ~ 1752.60 25.00 2.50 - 27.50 562.342 0.1119 1.0000 WCDMA1900 1852.40 ~ 1907.60 25.00 2.98 - 27.98 628.059 0.1250 1.0000 LTE B12 699.70 ~ 715.30 25.00 0.40 - 25.40 346.737 0.0690 0.4660 LTE B13 779.50 ~ 784.50 25.00 1.96 - 26.96 496.593 0.0988 0.5190 LTE B26 814.70 ~ 823.30 25.00 0.70 - 25.70 371.536 0.0740 0.5430 LTE B26(5) 824.70 ~ 848.30 25.00 1.84 - 26.84 483.059 0.0962 0.5490 LTE B4 1710.70 ~ 1754.30 25.00 2.50 - 27.50 562.342 0.1119 1.0000 LTE B25(2) 1850.70 ~ 1914.30 25.00 2.98 - 27.98 628.059 0.1250 1.0000 LTE B41(38) 2498.50 ~ 2687.50 25.00 1.46 - 26.46 442.589 0.0881 1.0000 LTE B7 2502.50 ~ 2567.50 25.00 1.46 - 26.46 442.589 0.0881 1.0000 ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 614 1.63 *100 30 824/f 2.19 / f *180 / f 2 30 27.5 0.073 0.2 30 f / 1500 30 1.0 30 Conclusion : 2AXDMTMS30DUALTYPEB Frequency range (MHz) ▪ Limits for Maximum Permissible Exposure (MPE) 0.3 ~ 1.34 1.34 ~ 30 EIRP= Equivalent Isotropic Radiated Power(mW) Frequency range (MHz) 1,500 ~ 100,000 Note1: Please refer to the operation description for Max tune-u p power. Note2: For GSM, duty factor was applied.- MPE Calculation The exposure condition of this device is compliant with FCC The EUT will only be used with a separation of 20 centimeters o r greater bet ween the antenna and the body o f the user. The MPE sample calculation for this exposure is shown below. EIRP / ( 4 R 2 π ) 603.949 S= Maximum power density(mW/cm 2 ) 30 ~ 300 300 ~ 1,500 R= Distance to the center of the radiation of the antenna(20cm) 0.1202 FCC ID: Mode Tune-up Max. Power(dBm) ANT Gain (dBi) Duty Factor(dB) Maximum EIRP (dBm) Maximum EIRP (mW) Maximum power density (mW/cm 2 ) Requriment (mW/cm 2 ) Satellite 1616.02 ~ 1625.98 33.00 3.65 -10.36 26.29 425.599 0.0847 1.0000 - ~ - ~ - ~ - ~ - ~ - ~ - ~ - ~ - ~ - ~ - ~ - ~ - ~ - ~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 614 1.63 *100 30 824/f 2.19 / f *180 / f 2 30 27.5 0.073 0.2 30 f / 1500 30 1.0 30 Conclusion : 30 ~ 300 300 ~ 1,500 1,500 ~ 100,000 The exposure condition of this device is compliant with FCC R= Distance to the center of the radiation of the antenna(20cm) ▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) 0.3 ~ 1.34 1.34 ~ 30 The EUT will only be used with a separation of 20 centimeters o r greater bet ween the antenna and the body o f the user. The MPE sample calculation for this exposure is shown below. EIRP / ( 4 R 2 π ) 425.599 S= Maximum power density(mW/cm 2 ) 0.0847 EIRP= Equivalent Isot ropic Radiated Power(mW) 2AXDMTMS30DUALTYPEB MPE Calculation Frequency range (MHz) Note1: Please refer to the operation description for Max tune-u p power. Note2: Duty factor was applied.(Duty cycle: 9.2%)- ▪▪ GPRS850(4TX) + Satellite 0.5490 Satellite GSRS850 (4TX) Power Densit y (mW/cm 2 ) 0.0847 - 1.0000 Σ of MPE ratios - - 0.1520 - -- 0.0847 - ---- - Mode - Worst case(MPE ratio) - -- - -- 0.2769 MPE ratio (Power Density/Requirement) 0.2769 The exposure condition of this d evice is compliant with FCC rul es. Conclusion : Σ of MPE ratios ≤ 1 ▪ Requirment = - - 0.3616 -- 0.0847 - 2AXDMTMS30DUALTYPEB FCC ID: RF Exposure Compliance for simultaneous operations Worst case for simultaneous operations - Requirement (mW/cm 2 )

FCC ID: 2AXDMTMS30DUALTYPEB Report No.: DRTFCC2009-0295(1) IC : 26419-TMS30TYPEB TRF-RF-210(11)171208 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 62 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2009-0295 Sep. 23, 2020 Initial issue JaeHyeok Bang JaeJin Lee DRTFCC2009-0295(1) Oct. 22, 2020 Update the FCC ID JaeHyeok Bang JaeJin Lee FCC ID: 2AXDMTMS30DUALTYPEB Report No.: DRTFCC2009-0295(1) IC : 26419-TMS30TYPEB TRF-RF-210(11)171208 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 62 Table of Contents 1. GENERAL INFORMATION ........................................................ 4 2. INTRODUCTION ........................................................................ 5 2.1 EUT DESCRIPTION ........................................................................................................... 5 2.2 TESTING ENVIRONMENT ................................................................................................ 5 2.3 MEASURING INSTRUMENT CALIBRATION ................................................................... 5 2.4 MEASUREMENT UNCERTAINTY ..................................................................................... 5 2.5 TEST FACILITY ................................................................................................................. 5 3. DESCRIPTION OF TESTS ......................................................... 6 3.1 ERP & EIRP (Effective Radiated Power & Equivalent Isotropic Radiated Power) ..... 6 3.2 PEAK TO AVERAGE RATIO ............................................................................................. 8 3.3 OCCUPIED BANDWIDTH (99 % Bandwidth) ................................................................ 10 3.4 SPURIOUS EMISSIONS AT ANTENNA TERMINAL ...................................................... 11 3.5 BAND EDGE EMISSIONS AT ANTENNA TERMINAL ................................................... 12 3.6 RADIATED SPURIOUS EMISSIONS .............................................................................. 13 3.7 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................... 14 4. LIST OF TEST EQUIPMENT .................................................... 15 5. SUMMARY OF TEST RESULTS .............................................. 16 6. EMISSION DESIGNATOR AND SAMPLE CALCULATION ..... 18 7. TEST DATA .............................................................................. 19 7.1 Conducted OUTPUT POWER ........................................................................................ 19 7.2 PEAK TO AVERAGE RATIO ........................................................................................... 20 7.3 OCCUPIED BANDWIDTH (99 % Bandwidth) ................................................................ 20 7.4 SPURIOUS MISSIONS AT ANTENNA TERMINAL ......................................................... 20 7.5 BAND EDGE EMISSIONS AT ANTENNA TERMINAL ................................................... 20 7.6 EFFECTIVE RADIATED POWER .................................................................................... 21 7.7 EQUIVALENT ISOTROPIC RADIATED POWER ............................................................ 22 7.8 RADIATED SPURIOUS EMISSIONS .............................................................................. 24 7.9 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................... 29 7.9.1 FREQUENCY STABILITY (GPRS1900) ..................................................................... 29 8. TEST PLOTS ........................................................................... 31 8.1 PEAK TO AVERAGE RATIO ......................................................................................... 31 8.2 OCCUPIED BANDWIDTH (99 % Bandwidth) .............................................................. 35 8.3 SPURIOUS EMISSIONS AT ANTENNA TERMINAL .................................................... 43 8.4 BAND EDGE EMISSIONS AT ANTENNA TERMINAL.................................................. 55 FCC ID: 2AXDMTMS30DUALTYPEB Report No.: DRTFCC2009-0295(1) IC : 26419-TMS30TYPEB TRF-RF-210(11)171208 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 62 1. GENERAL INFORMATION Applicant Name : DASAN Networks, Inc. Address(FCC) : DASAN Tower, 49, Daewangpangyo-ro644Beon-gil, Bundang-gu, Seongnam-si, South Korea 13493 Address(IC) : DASAN Tower, 49, Daewangpangyo-ro644Beon-gil, Bundang-gu Seongnam-si/Gyeonggi-do 13493 Korea (Republic Of) FCC ID : 2AXDMTMS30DUALTYPEB IC : 26419-TMS30TYPEB FCC Classification : PCS Licensed Transmitter (PCB) EUT Type : Vehicle Control Terminal Model Name : TMS3.0 (300611-01930) Add Model Name : NA Hardware Version : A1 Software Version : V3.01.002 Serial Number : NA Supplying power : DC 12 V, 24 V Antenna Information : PCB Antenna Mode Tx Frequency (MHz) Emission Designator Note ERP (Max. Power) EIRP (Max. Power) dBm W dBm W GPRS850 824.2 ~ 848.8 247KGXW 32.51 1.782 34.66 2.924 EDGE850 824.2 ~ 848.8 245KG7W 25.45 0.351 27.60 0.575 WCDMA850 826.4 ~ 846.6 4M13F9W 22.57 0.181 24.72 0.296 WCDMA1700 1 712.4 ~ 1 752.6 4M14F9W - - 24.52 0.283 GPRS1900 1 850.2 ~ 1 909.8 248KGXW - - 32.63 1.832 EDGE1900 1 850.2 ~ 1 909.8 248KG7W - - 32.23 1.671 WCDMA1900 1 852.4 ~ 1 907.6 4M15F9W - - 28.90 0.776 Note: For GSM/EDGE 850 and WCMA 850/1700/1900, emission designator was reported based on the original report of certified module. For GSM/EDGE 1900, emission designator was reported based on the new test result. FCC ID: 2AXDMTMS30DUALTYPEB Report No.: DRTFCC2009-0295(1) IC : 26419-TMS30TYPEB TRF-RF-210(11)171208 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 62 2. INTRODUCTION 2.1 EUT DESCRIPTION This EUT contains the following capabilities: 850/1900 GPRS/EDGE, 850/1700/1900 WCDMA/HSUPA, Multi-band LTE and IRIDIUM Satellite communication. 2.2 TESTING ENVIRONMENT Ambient Condition ▪ …
