2AXEK-X88Smart Battery Camera

Smart Battery Camera Operation Instruction Contents 1.P acking lis t---------------------------------------01 2.Pr oduct appearanc e---------------------------02 3.Quick start ---------------------------------------04 4.S et up the camera------------------------------ 06 5.Ins tall the camera---------------------------------11 6.Share the camera---------------------------------14 7.Charge the camera------------------------------17 8.Indicator light status --------------------------18 9.P roduc t specificatio n------------------------18 10.Firmware upgrade -------------------------19 11.F CC warning-----------------------------------19 12.F AQ-------------------------------------------21 Packing list 01 1. Camera*1 2. Br ack et*1 3. Mounting kit*1 4. U SB charging cable *1 5. Operation instruc tion *1 6. Screw f or br ack et*1 02 Product appearance Infr ar ed lamp Lens Indic ator light Human body infr ar ed sensor MIC Wi-Fi antenna Whit e light Quick start The smart battery camer a supports battery-powered supply and AC-po wer ed supply. 1. Do wnlo ad and install the App The wireless smar t battery came ra supports Android and iOS App . For your bes t experience, ple ase scan the QR code belo w with your mobile pho ne, ins tall the app , and follo w the instruc tion t o c omplete the user regis tr ation. Do wnlo ad App Android Download Download App Store Scan QR code or go to the link to download and ins tall the App：http s://www.vic ohome.io/do wnlo ad/ 04 2. Add the device Sign in to the A pp connect to Wi-Fi and add the device according to the prompts (plea se bring the device close 05 Set up the camera Click the "Add Camera Now" in the App and enter the Wi-Fi 1) network name and pa ssw ord tha t you want the came ra to connect. 06 2) To ensure a longer distance connection, the camera only supports the 2.4Ghz Wi-Fi with strong er wall pene tration capabil ity and does not support Wi-Fi for enterp rise l evel authentic atio n c urrentl y. Ple ase ensure tha t the entered W i-Fi meets the requir ements. After completion, click "Continue" to g ener ate the QR code f or p airing the camer a. 07 3) Aft er pr essing the camer a swit ch for 3 sec onds, the camer a will turn on. The camer a will emit the sc anning sound "Ding Dong Ding Dong" aft er it is tur ned on (if you do not hear it, ple ase double click the power button). Power button about 7 inches (20cm) 4) Tak e the lens of the camer a facing the QR code gener ated on Vic oHome about 20 cm (7 inches) until you he ar a "Ding" sound. 08 5) Aft er a while, the camer a will giv e out a pr omp t sound of a successful conne ctio n. At this moment, please set the name for the de vic e on the App and selec t the loc ation you want to plac e the devic e. Click "Continue" to c omplete the pairing. 09 P ossible problems with binding: When you hear the "Wi-Fi Password Error", ple ase check whe ther the Wi-Fi passw ord you ent ered in the App is correct; When you hear the "Authentication error", ple ase ensure tha t your Wi-Fi network is not an ent erp rise -le vel network, and the de vice supports on ly the network wi th the secu rit y level bel ow W PA-2; When you hear the "Wi-Fi not found", ple ase check whe ther you selec t or ent er the corr ect Wi-Fi name, and plac e the device near the Wi-Fi rout er and ensu re tha t the router is powe red on. Ple ase note that 5Ghz Wi-Fi canno t be searched b y the de vice; When you hea r the "Retrieving IP timeout", it ind icate s tha t the number of devices connected to the rout er in your home is too many to c onnec t more de vices. Please remove some of the connec ted devices tha t are not commonly used or restart the rout er to clear the unconnected devic es. You m ay need to cont act the r outer a dminis trato r; When you hear the "Cloud service connection fail", ple ase check whe ther your rout er is connec ted properl y to the external network . When you hear this err or promp t,it is common on the condition of network disc onnection or tha t the sel ected rout er in your home is a loc al area network server. Ple ase ensure tha t the network c onnection is normal, and try to temporaril y turn off the firewall to 10 connec t ag ain. Install the camera You can plac e the camer a on a shelf or other surf ac es to use, or y ou c an install it on a wall t o use. (1) Select a g ood spot f or your camer a Selec t a good spo t for your camer a, ple ase ins tall the camer a in a position wher e it s vie w is no t blocked and ensure tha t it is within the cover ag e of the Wi-Fi ne tw ork . The PIR infr ar ed sen sor is more sen sitiv e to move ments across the came ra's field of vie w than move ments toward or away from the 11 camer a. (2) Install the brack et Fix the camer a to the desir ed loc ation. You can dir ec tly plac e ceiling by scr ews. height About 6 ft ommended Rec For outdoor use, please ins tall the camer a upside down to max imiz e the waterproof perf ormance and the human 12 br ack et b y a screw . 2) Fix the camer a 13 When you want to let other family members or friends vie w the camer a, you can use this featur e. Only the admin user and manage the settings for the camer a. The shar ed user s hav e limited access rights. Share the camera (1) S teps f or Admin User 1) Find the camer a y ou w ant t o share on the App Homepag e , then tap the "Share" butt on. You can also tap the camer a "Camera Se tting" icon, then tap the "Share" button; 14 2) Tap "Camera sharing", a QR code for sharing will be gener ated. 15 (2) S tep s f or Shared U ser For the family membe rs or friends you want to shar e, find "Add friend's came ra" on the Homepage to enter the scan code page, the n scan QR code generared on the admin's phone, then send the access r equest t o the admin user. 16 Charge the camera The App will remind you to char ge your camer a when the bat te ry is low. Plea se use the Mic ro USB cable to plug into the 5V/1.5A char ging adap ter to char ge the camer a. During char ging, the camer a's …

Text truncated - open the document above for the full version.

FCC ID: 2AXEK-X88 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID: 2AXEK-X88 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT WiFi Antenna FCC ID: 2AXEK-X88 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID: 2AXEK-X88 TB-RF-074-1.0 Appendix IFCC ID Label FCC ID:2AXEK-X88 Model:X88 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2AXEK-X88 TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

FCC ID: 2AXEK-X88 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT FCC ID: 2AXEK-X88 TB-RF-074-1.0 Photo 9 Internal of EUT Photo 10 Internal of EUT FCC ID: 2AXEK-X88 TB-RF-074-1.0 Photo 11 Battery parameters Photo 12 Appearance of PCB FCC ID: 2AXEK-X88 TB-RF-074-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB BLE Antenna

version01 SHENZHEN GENERAL TECHNOLOGY CO. , LTD Declaration concerning Antenna Specification It is hereby declared that the product Model No.: X88 FCC ID: 2AXEK-X88 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB / FPC antenna type(s) described below: Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: Bluetooth LE / PCB Antenna -0.68dBi for 2402-2480MHz; 2.4GWIFI W72 FPC Antenna 2.55dBi for 2412-2462MHz; The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: SHENZHEN GENERAL TECHNOLOGY CO. , LTD Address: Floor 1-3,Building A,Floor 1-4,Building B, No.11 Xiantian Road,Xinsheng Community, Longgang Sub-District,Longgang District ,Shenzhen, China Place: JING JING ZHANG Date: 2022-12-5 Signature:

DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 1 /9 承认书 APPROVALSHEET 客户名称 CUSTOMERNAME: 产品名称 PRODUCTNAME:2.4GW72白色天线L=280mm+端子 客户料号 CUSTOMERP/N: 优比电子料号 YoubiP/N:UB02C280W3D2158AREV:A MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKEDBY: Sam APPROVEDBY:Changxing.Liu DATE:2022-10-27 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 2 /9 ModificationHistory VersionContentRevisionIssuedbyDate AOriginalversionSam2022-10-27 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 3 /9 Content ltemDescription 1.--------------------------------------------------------------------ElectricalSpecification 2.---------------------------------------------------------------TestItemsandEquipment 3.---------------------------------------------------------------------------------SParameter 4.------------------------------------------------------------------------EfficiencyandGain 5.---------------------------------------------------------------------------RadiationPattern 6.-----------------------------------------------------------------MechanicalSpecification DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 4 /9 1.ElectricalSpecification: 2.TestItemsandEquipment CharacteristicsSpecificationsUnit OutlineDimensions12.92x105,L280mm Frequency 2400-2500 MHz Impedance50Ω VSWR≤ 2.0 PolarizationLinearPolarization Gain2.5±0.5 dBi Efficiency>60 % ConnectorTypeMHF-1-Plug Operatingtemperature-20°C~+70°C StorageTemp-20°C~+70°C TestitemsTestequipment SParameter 1.ReturnLoss 2.VSWR Networkanalyzer (AgilentE5071B) Thewholemachineof Passiveparameters 1.Frequency 2.Gain 3.RadiationPattern 1.3Dmicrowavedarkroom (5m*5m*5m) 2.Networkanalyzer (AgilentE5071B) Thewholemachineof Activeparameters 1.TRP 2.TIS 1.3Dmicrowavedarkroom (5m*5m*5m) 2.Comprehensivetestinstrument (CMW500) DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 5 /9 3.SParameter *VoltageStandingWaveRatio(VSWR) ReturnLoss(RL) RL=20*log10[(VSWR+1)/(VSWR-1) 4.EfficiencyandGain Frequency (MHz) 240024502500 Efficiency (%) 66.5372.6169.34 Gain (dBi) 2.392.552.42 Frequency (MHz) ReturnLoss (dB) VSWR 2400/1.75 2450/1.33 2500/1.18 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 6 /9 5.RadiationPattern 5-1Antenna3DRadiationPattern 2400MHz 2450MHz 2500MHz DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 7 /9 5-2Antenna2DRadiationPattern Phi02D Phi902D Theta902D Vertical Plane Horizontal Plane DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 8 /9 6.MechanicalSpecification:

ANTENNA SPECIFICATION Summary ITEM ANT SPEC Model Name 2.4G ANT Horizontal Vertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.73 -0.84 -0.68 -6.15 -3.70 -2.32 MAX. Gain -0.68 Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 38.88mm Manufacture Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.73178 -30.0815 -8.48713 2450 -0.845801 -38.5605 -7.88012 2500 -0.685586 -24.0318 -6.79139 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -6.1530 -24.1420 -13.0295 2450 -3.7054 -26.5836 -10.6700 2500 -2.32122 -30.4301 -9.70536

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-29 Page: 1 of 3 TB-RF-075-1.0 1 A/F., Building.6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao’an, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Maximum Permissible Exposure Evaluation FCC ID: 2AXEK-X88 1. Client Information Applicant : SHENZHEN GENERAL TECHNOLOGY CO., LTD Address : Floor 1-3, Building A, Floor 1-4, Building B, No. 11 Xiantian Road, Xinsheng Community, Longgang Sub-District, Longgang District, Shenzhen, China Manufacturer : SHENZHEN GENERAL TECHNOLOGY CO., LTD Address : Floor 1-3, Building A, Floor 1-4, Building B, No. 11 Xiantian Road, Xinsheng Community, Longgang Sub-District, Longgang District, Shenzhen, China 2. General Description of EUT EUT Name : Smart Battery Camera Models No. : X88 Model Different : ---- Product Description : Operation Frequency: 802.11b/g/n(HT20): 2412MHz~2462MHz Bluetooth LE 5.0: 2402-2480MHz Number of Channel: 802.11b/g/n(HT20):11 channels 40 channels for Bluetooth LE Antenna Gain: -0.68dBi PCB Antenna for Bluetooth LE 2.55dBi FPC Antenna for WiFi Power Rating : Input: DC 5V, 1.5A DC 3.7V by 9000mAh Rechargeable Li-ion battery Software Version : 0.7.10 Hardware Version : CQ121C_C01_V3 Connecting I/O Port(S) : : Please refer to the User's Manual Remark : the evaluation report used the EUT(202204-0397-6-2#). Report No.: TBR-C-202211-0028-29 Page: 2 of 3 TB-RF-075-1.0 MPE Calculations for WIFI 1. EUT Operation Condition: Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 2. Exposure Evaluation: Equation from page 18 of OET Bulletin 65, Edition 97-01 S=(PG)/4πR 2 Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna 3. Simultaneous transmission MPE Considerations According to KDB447498: All transmitters and antennas in the host must be either evaluated for MPE compliance, by measurement or computational modeling, or qualify for the standalone MPE test exclusion in section 7.1. Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. This means that: ∑ of MPE ratios ≤ 1.0 4. Test Result: 2.4G WiFi & Bluetooth LE worst reported. Mode Frequency (MHz) Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/ cm 2 ) [S] Limit of Power Density (mW/ cm 2 ) (S) Bluetoo th LE 2402 -2.25 -2±1 -1 -0.68 20 0.0001 1 2440 -2.782 -3±1 -2 -0.68 20 0.0001 1 2480 -3.007 -3±1 -2 -0.68 20 0.0001 1 Mode Frequency (MHz) Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/ cm 2 ) [S] Limit of Power Density (mW/ cm 2 ) (S) 802.11b 2412 17.807 18±1 19 2.55 20 0.0284 1 2437 17.292 17±1 18 2.55 20 0.0226 1 2462 16.978 17±1 18 2.55 20 0.0226 1 Report No.: TBR-C-202211-0028-29 Page: 3 of 3 TB-RF-075-1.0 802.11g 2412 13.445 13±1 14 2.55 20 0.0090 1 2437 16.705 17±1 18 2.55 20 0.0226 1 2462 15.229 15±1 16 2.55 20 0.0142 1 802.11 n(HT20) 2412 12.764 13±1 14 2.55 20 0.0090 1 2437 16.578 17±1 18 2.55 20 0.0226 1 2462 14.27 14±1 15 2.55 20 0.0113 1 Maximum Simultaneous transmission MPE Ratios for 2.4GHz WiFi and Bluetooth LE. Maximum MPE ratio 2.4GWiFi Maximum MPE ratio Bluetooth LE ∑MPE Limit Results 0.0284 0.0001 0.0285 1.0 PASS 5. Conclusion: As specified in Table 1B of 47 CFR 1.1310- Limits for Maximum Permissible Exposure (MPE), Limits for General Population/ Uncontrolled Exposure Frequency Range (MHz) Power density (mW/ cm 2 ) 300-1,500 F/1500 1,500-100,000 1.0 For 2.4WIFI:2412~2462 MHz and Bluetooth LE MPE limit S: 1mW/ cm 2 The MPE is calculated as 0.0285 < limit 1mW / cm 2 . So, RF exposure limit warning or SAR test are not required. The EUT will only be used with a separation of 20cm or greater between the antenna and nearby persons and can therefore be considered a mobile transmitter per 47 CFR2.1091 (b). The RF Exposure Information page from the manual is included here for reference. Note For a more detailed features description, please refer to the RF Test Report. 6. Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. -----END OF REPORT-----

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 1 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 RF Test Data for Bluetooth LE (Conducted Measurements) General Description of EUT Product Name: Smart Battery Camera Test Model: X88 Sample ID: 202211-0028-19-2# Environmental Conditions Temperature: 25°C Relative Humidity: 55% Test Voltage: DC 3.7V Test Engineer: Huang jian ping Note: For a more detailed features description, please refer to the report TBR-C-202211-0028-40 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 2 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Contents 1. Duty Cycle ............................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ..................................................................................................................................................... 6 3. -6dB Bandwidth ....................................................................................................................................................................................... 9 4. Occupied Channel Bandwidth ............................................................................................................................................................. 12 5. Maximum Power Spectral Density Level ............................................................................................................................................ 15 6. Band Edge ............................................................................................................................................................................................. 18 7. Conducted RF Spurious Emission ...................................................................................................................................................... 21 8. Restrict Band ......................................................................................................................................................................................... 25 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 3 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT BLE 1Mbps 2402 Ant1 100 0 0 NVNT BLE 1Mbps 2440 Ant1 100 0 0 NVNT BLE 1Mbps 2480 Ant1 100 0 0 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 4 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Test Graphs Duty Cycle NVNT BLE 1Mbps 2402MHz Ant1 Duty Cycle NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 5 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Duty Cycle NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 6 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT BLE 1Mbps 2402 Ant1 -2.25 0 -2.25 30 Pass NVNT BLE 1Mbps 2440 Ant1 -2.782 0 -2.782 30 Pass NVNT BLE 1Mbps 2480 Ant1 -3.007 0 -3.007 30 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 7 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Test Graphs Power NVNT BLE 1Mbps 2402MHz Ant1 Power NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 8 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Power NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 9 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1Mbps 2402 Ant1 1.18 0.5 Pass NVNT BLE 1Mbps 2440 Ant1 1.45 0.5 Pass NVNT BLE 1Mbps 2480 Ant1 1.39 0.5 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 10 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Test Graphs -6dB Bandwidth NVNT BLE 1Mbps 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 11 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 -6dB Bandwidth NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 12 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 4. Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 1Mbps 2402 Ant1 1.414 NVNT BLE 1Mbps 2440 Ant1 1.696 NVNT BLE 1Mbps 2480 Ant1 1.785 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 13 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Test Graphs OBW NVNT BLE 1Mbps 2402MHz Ant1 OBW NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 14 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 OBW NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 15 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 5. Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Max PSD (dBm/3KHz) Limit (dBm/3KHz) Verdict NVNT BLE 1Mbps 2402 Ant1 -10.21 8 Pass NVNT BLE 1Mbps 2440 Ant1 -9.698 8 Pass NVNT BLE 1Mbps 2480 Ant1 -10.068 8 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 16 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 Test Graphs PSD NVNT BLE 1Mbps 2402MHz Ant1 PSD NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 17 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 PSD NVNT BLE 1Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 18 of 27 FCC ID: 2AXEK-X88 TB-RF-074-1.0 6. Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1Mbps 2402 Ant1 -42.22 -20 Pass NVNT BLE 1Mbps 2480 Ant1 -47.49 -20 Pass Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-4…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202211-0028-40 Page: 1 of 35 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Radio Test Report FCC ID: 2AXEK-X88 Report No. : TBR-C-202211-0028-40 Applicant : SHENZHEN GENERAL TECHNOLOGY CO., LTD Equipment Under Test (EUT) EUT Name : Smart Battery Camera Model No. : X88 Series Model No. : ---- Brand Name : ---- Sample ID : 202211-0028-19-1# & 202211-0028-19-2# Receipt Date : 2022-11-25 Test Date : 2022-11-25 to 2022-12-05 Issue Date : 2022-12-05 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Witness Engineer : Seven Wu Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202211-0028-40 Page: 2 of 35 TB-RF-075-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION ....................................................................................................... 13 5.1 Test Standard and Limit .................................................................................................... 13 5.2 Test Setup ........................................................................................................................... 13 5.3 Test Procedure ................................................................................................................... 13 5.4 Deviation From Test Standard ......................................................................................... 14 5.5 EUT Operating Mode ........................................................................................................ 14 5.6 Test Data ............................................................................................................................. 14 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 15 6.1 Test Standard and Limit .................................................................................................... 15 6.2 Test Setup ........................................................................................................................... 17 6.3 Test Procedure ................................................................................................................... 18 6.4 Deviation From Test Standard ......................................................................................... 19 6.5 EUT Operating Mode ........................................................................................................ 19 6.6 Test Data ............................................................................................................................. 19 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 20 7.1 Test Standard and Limit .................................................................................................... 20 7.2 Test Setup ........................................................................................................................... 20 7.3 Test Procedure ................................................................................................................... 21 7.4 Deviation From Test Standard ......................................................................................... 23 Report No.: TBR-C-202211-0028-40 Page: 3 of 35 TB-RF-075-1.0 7.5 EUT Operating Mode ........................................................................................................ 23 7.6 Test Data ............................................................................................................................. 23 8. BANDWIDTH TEST ................................................…

Text truncated - open the document above for the full version.
