2AXFV-ELE0036801FUYL Tower Control Board Module

QUICK START VIDEO INSTRUCTIONS: https://vimeo.com/339043097 What’s required? FUYL Tower 5 Visit our website for detailed instructions. www.lockncharge.com/support (International) www.pclocs.com.au/support (AUS and NZ) x1x1 x1 1 2 OR <2 mins Ready CONNECT ETHERNET CABLE CONNECT TO POWER NOTE: This step is not required if you have decided to not connect your Tower to the Cloud. 3 Press ‘00’ and ‘OK’ to enter the Admin Menu. The default password is ‘31082018’ To restart, select Tower Restart. To proceed to retrieve the portal address, select System Status, then Network status. Record the Portal address. FIREWALL AND PROXY OR OPTIONAL: FITTING WINDOW COVER AddressPortProtocol registry.pclocs.ioTCP 443https a136cfw17adicb-ats.iot.us-west-2. amazonaws.com TCP 8883mqtt time1.google.comUDP 123ntp time2.google.comUDP 123ntp time3.google.comUDP 123ntp time4.google.comUDP 123ntp Ensure that your network firewall or proxy is not blocking outgoing connections to the endpoints listed. Please contact your network administrator if you are unsure of any changes to your network configuration that may be required. 4 RETRIEVE LOCAL HOST ADDRESS Note: If you have powered on your Tower before connecting the ethernet cable to your laptop or port, restart from the Towers display after connecting an ethernet cable. www.lockncharge.com (International) www.pclocs.com.au (Australia and New Zealand) 5 ONBOARD TOWER TO YOUR ACCOUNT 6 LOGIN TO THE CLOUD PORTAL WITH YOUR ACCOUNT www.pclocs.io (Australia and NZ) www.lockncharge.io (International) Connect your Station to the internet Wi-Fi Ethernet Open browser and type the Portal address (local host). Username: admin Password: 31082018 NOTE: Some browsers will report security warnings. The security warnings appear because the FUYL Tower has generated a self-signed certificate to secure your connection. It should be safe to proceed because it is a temporary connection to the local host on the FUYL Tower. Your Account code should have been sent to you via email on sign up. Enter your Account code Enter a Station ‘friendly’ name

QUICK START What’s required? VIDEO INSTRUCTIONS: https://vimeo.com/288109115 FUYL Tower 15 Visit our website for detailed instructions. www.lockncharge.com/support (International) www.pclocs.com.au/support (AUS and NZ) x2 x1 x1x4 x1 x3 1 2 3 OPTIONAL: FITTING WINDOW COVER 40-90mm FIX TOWER TO THE WALL OR NOTE: This step is not required if you have decided to not connect your Tower to the Cloud. INSTALL TOWER FEET CONNECT ETHERNET CABLE MANDATORY Fix FUYL Tower to the wall using the supplied bracket 4 5 CONNECT TO POWER FIREWALL AND PROXY AddressPortProtocol registry.pclocs.ioTCP 443https a136cfw17adicb-ats.iot.us-west-2. amazonaws.com TCP 8883mqtt time1.google.comUDP 123ntp time2.google.comUDP 123ntp time3.google.comUDP 123ntp time4.google.comUDP 123ntp Ensure that your network firewall or proxy is not blocking outgoing connections to the endpoints listed. Please contact your network administrator if you are unsure of any changes to your network configuration that may be required. 6 RETRIEVE LOCAL HOST ADDRESS Note: If you have powered on your Tower before connecting the ethernet cable to your laptop or port, restart from the Towers display after connecting an ethernet cable. Press ‘00’ and ‘OK’ to enter the Admin Menu. The default password is ‘31082018’ To restart, select Tower Restart. To proceed to retrieve the portal address, select System Status, then Network status. Record the Portal address. OR <2 mins Ready www.lockncharge.com (International) www.pclocs.com.au (Australia and New Zealand) 7 ONBOARD TOWER TO YOUR ACCOUNT 8 LOGIN TO THE CLOUD PORTAL WITH YOUR ACCOUNT www.pclocs.io (Australia and NZ) www.lockncharge.io (International) Connect your Station to the internet Wi-Fi Ethernet Open browser and type the Portal address (local host). Username: admin Password: 31082018 NOTE: Some browsers will report security warnings. The security warnings appear because the FUYL Tower has generated a self-signed certificate to secure your connection. It should be safe to proceed because it is a temporary connection to the local host on the FUYL Tower. Your Account code should have been sent to you via email on sign up. Enter your Account code Enter a Station ‘friendly’ name

29 Oxleigh Drive MALAGA, WA 6090 Ph 1300 725 627 ABN 40 151 895 699 CONFIDENTIALITY REQUEST Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/08/17 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457(d) and 0.459 of the Commission’s Rules (47 C.F.R.), we request Long- Term confidentiality for the following product: FCC ID Model name TBA FUYL Tower Control Board Module For the product stated above, we request that the following information be held as Long-Term confidential: Block Diagrams Schematics Parts List/Tune up information Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. This proprietary information is not publicly available. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Stephen Baldry Chief Technical Officer 2AXFV-ELE0036801

29 Oxleigh Drive MALAGA, WA 6090 Ph 1300 725 627 ABN 40 151 895 699 14 September 2020 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement IWS Global Pty Ltd FCC ID: 2AXFV-ELE0036801 To Whom It May Concern: We, IWS Global Pty Ltd, hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number 2AXFV-ELE0036801 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 14 th September 2020. The Limited Agency Agreement expires on 31 st December 2020, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Stephen Baldry CTO

FUYL Tower Pro Control Module Model No.: ELE-00368-01 Input: 12-24Vdc 0.5A FCC ID: 2AXFV-ELE0036801 IC: 26455-ELE0036801 HVIN: 10349 Contains FCC ID: COF-WMBACBM25 Contains IC: 10293A-WMBACBM25 Batch: 220XX01 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. www.pclocs.com.au www.lockncharge.com

IWS Global Pty Ltd RF Exposure Exhibit SCOPE OF WORK EMC TESTING- FUYL Tower Pro Control Door, Models: ELE-00368-01 REPORT NUMBER 104360835MPK-011B ISSUE DATE August 11, 2020 REVISED DATE November 17, 2020 PAGES 10 DOCUMENT CONTROL NUMBER Non-Specific Radio Report Shell Rev. December 2017 MPK © 2017 INTERTEK Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for IWS Global Pty Ltd on FUYL Tower Pro Control Door Page 2 of 10 RF Exposure Exhibit (mobile devices) Report Number: 104360835MPK-011B Project Number: G104360835 Report Issue Date: August 11, 2020 Product Designation: Model Tested: FUYL Tower Pro Control Door ELE-00368-01 FCC ID: 2AXFV-ELE0036801 IC: 26455-ELE0036801 to 47CFR 2.1091 RSS-102 Issue 5 for IWS Global Pty Ltd Tested by: Client: Intertek 1365 Adams Court Menlo Park, CA 94025 USA IWS Global Pty Ltd 29 Oxleigh Drive Magala WA 6090, Australia Report prepared by: Report reviewed by: Hung Huynh / Project Engineer Krishna Vemuri / EMC Manager This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. REPORT NUMBER: 104360835MPK-011B Issued: August 11, 2020 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for IWS Global Pty Ltd on FUYL Tower Pro Control Door Page 3 of 10 Report No. 104360835MPK-011B Equipment Under Test: FUYL Tower Pro Control Door Trade Name: IWS Global Pty Ltd Model(s) Tested: ELE-00368-01 Applicant: IWS Global Pty Ltd Contact: Jeff Cross Address: IWS Global Pty Ltd 29 Oxleigh Drive Magala WA 6090 Country: Australia Tel. Number: 61892097900 Email: [email protected] Applicable Regulation: 47CFR 2.1091 RSS-102 Issue 5 REPORT NUMBER: 104360835MPK-011B Issued: August 11, 2020 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for IWS Global Pty Ltd on FUYL Tower Pro Control Door Page 4 of 10 TABLE OF CONTENTS 1.0 RF Exposure Summary ................................................................................................................... 5 2.0 RF Exposure Limits ........................................................................................................................ 5 3.0 Test Results (Mobile Configuration) ............................................................................................. 7 Appendix A: Power Density Calculation ................................................................................................... 9 4.0 Document History ......................................................................................................................... 10 REPORT NUMBER: 104360835MPK-011B Issued: August 11, 2020 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for IWS Global Pty Ltd on FUYL Tower Pro Control Door Page 5 of 10 1.0 RF Exposure Summary Test Reference FCC Reference Industry Canada Result Radio frequency Radiation Exposure Evaluation 47 CFR§2.1091 RSS-102 Issue 5 Complies 2.0 RF Exposure Limits In this document, we evaluate the RF Exposure to human body due the intentional transmission from the transmitter (EUT). The limits for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 and RSS-102 are followed. 2.1 FCC Limits According to FCC 1.1310 table 1: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 0.3 – 3.0 614 1.63 *100 6 3.0 – 30 1842/f 4.89/f *900/f 2 6 30-300 61.4 0.163 1.0 6 300 - 1500 ... ... F/300 6 1500 - 100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 0.3 – 1.34 614 1.63 *100 30 1.34 – 30 824/f 2.19/f *180/f 2 30 30 – 300 27.5 0.073 0.2 30 300 - 1500 ... ... F/ 1500 30 1500 - 100,000 ... ... 1.0 30 F = Frequency in MHz * = plane wave equivalent density REPORT NUMBER: 104360835MPK-011B Issued: August 11, 2020 Non-Specific Radio Report Shell Rev. December 2017 MPK EMC Report for IWS Global Pty Ltd on FUYL Tower Pro Control Door Page 6 of 10 2.2 Industry Canada Limits According to RSS-102, Industry Canada has adopted the SAR and RF field strength limits established in Health Canada’s RF exposure guideline, Safety Code 6. Table 4: RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range Electric Field Magnetic Field Power Density Reference Period (MHz) (V/m rms) (A/m rms) (W/m 2 ) (minutes) 0.003-10 83 90 - Instantaneous* 0.1-10 - 0.73/ ƒ - 6** 1.1-10 87/ ƒ 0.5 - - 6** 10-20 27.46 0.0728 -2 6 20-48 58.07/ ƒ 0.25 0.1540/ ƒ 0. 25 8.944/ ƒ0.5 6 48-300 22.06 0.05852 1.291 6 300-6000 3.142 ƒ 0.3417 0.008335 ƒ 0.3417 0.02619 ƒ 0.6834 6 6000-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10-4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note: ƒ is frequency in MHz. * Based on nerve stimulation (NS). ** Based on specific absorption rate (SAR). REPORT NUMBER: 104360835MPK-011B Issued: August 11, 2020 Non-Specific Radio Report Shell Rev. Decembe…
