2AXINFHT1008Hover Cross RTF

Instruction Manual Aircraft Type: Hybrid Hover Drone Materials: PP and EPP foam Width (Diagonal Shaft to Shaft): 3.94” (100mm) Total Width: 6.5” (165mm) Total Length: 6.5” (165mm) Height: 2.17” (55mm) Weight: 1.34 oz.(38g) Motors: 7mm coreless (4) Charger: Micro USB charge cord Internal Battery: 3.7V 300mAh (non-replaceable) Transmitter: 4-channel, 2.4GHz Flight Times: Over 6 minutes in drone mode Up to 12 minutes in hover mode Specifications 14+ AGE RECOMMENDATION: Not for children under 14 years. This is not a toy. Safety Precautions and Warnings • As the user of this product, you are solely responsible for operating in a way that does not endanger yourself and others or result in property damage • Always operate your product in open spaces away from full-size vehicles, traffic, and people, making sure to maintain a safe distance around your product to avoid injuries to people or damage to property. • Do not leave the product in direct sunlight or in hot spaces such as an automobile. • To avoid injury, do not fly near your face. Keep props away from your fingers, hair, eyes, or other body parts. • Do not fly toward people or animals. • This product is controlled by a radio signal subject to interference from many sources outside your control. Interference can cause momentary loss of control. • Always keep small parts and anything electrical out of the reach of children. • Avoid any water exposure to this product. Moisture causes damage to electronics. • Never place any portion of the model in your mouth as choking could cause serious injury. • Never operate your transmitter with low transmitter batteries and do not mix new and used batteries. • Batteries should be recycled or disposed of per state and local guidelines. • Always keep transmitter powered on while aircraft is powered. • Always keep aircraft in sight and under control. • WARNING: Do not fly if props become damaged or broken. Flying with damaged props could lead to damage or cause injury. Supplier’s Declaration of Conformity This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any inter- ference received, including interference that may cause undesired operation. Part Number Description FHT1000 HoverCross RTF, Red FHT1001 HoverCross RTF, Blue FHT1002 Propeller Set (4) Red; HoverCross FHT1003 Propeller Set (4) Blue; HoverCross FHT1004 Replacement Motor; HoverCross FHT1005 Decal Sheet, Red; HoverCross FHT1006 Decal Sheet, Blue; HoverCross FHT1007 USB Charge Cable; HoverCross FHT1008 2.4GHz Transmitter; HoverCross Replacement Parts pppppp iii Open the battery compartment and insert three AAA batteries Make sure that you match the polarities (+ and -) as marked inside Replace the cover and screw in place Installing Batteries %Place the HoverCross on a flat surface as in hover mode %Plug the mini USB on the charge cord as shown and the USB charger into a 5V USB power source %Green LED’s show while charging and turn off when charge is complete %Charging should take between 35 and 40 minutes %When the charge is complete, unplug both connectors %Use only the included USB charge cord Charging Instructions Charge Port On/Off %Press the On/Off button on the transmitter. Press and hold the On/Off button on the aircraft until the red LED on the aircraft begins to blink. When you remove your finger, the LED’s on the aircraft and the transmitter will turn solid red to show they are now paired. To arm the motors, move the left stick to the top until you hear one beep, then pull the stick all the way down until you hear a second beep. %In hover mode, press the Auto-Take Off/Land button or move the left stick up and the Hover Cross will begin to move forward. To take off in drone mode, press the Auto-Take Off/Land button and the unit will climb to an altitude of 1.5 to 2 meters and maintain a steady hover. %See the transmitter diagram for movements and control during operation. %If the HoverCross tends to “drift” in any direction during flight, use the trim buttons as shown in the transmitter diagram. Operating Instructions % % % Forward Backward Move Left Move Right Ascend Descend Rotate Right Rotate Left 360° Flips (R) Mode Flips (L) ON/OFF Trim Forward/Backward Trim Left/Right 3 Rates Slider Operating Instructions (cont.) %The HoverCross has 3 flying rates – beginner, intermediate, and expert. The slide switch shown in the transmitter diagram moves left to right in progression for the rates. The transmitter will beep to let you know which rate is currently being used – 1 beep for beginner, 2 for intermediate, and 3 for expert. It is recommended to start flights in beginner and progress as your flying skills increase. When flying aggressively in either Intermediate or Expert rates, you may notice the aircraft enter “protection” mode as it will pause for a moment to restabilize before continuing the flight. %To flip from one mode to another, press the L button on the top left of the transmitter. %For 360 flips in drone mode, press the R button on the top right of the transmitter and the right transmitter stick to the direction you want to flip. In hover mode this button initiates a jump. %To land the HoverCross in drone mode, either press the Auto-Take Off/Land button or slowly lower the left transmitter stick. To stop in hover mode, lower the left transmitter stick. %The calibration step is used to reset the gyro stabilization system of the HoverCross. It is important to use this process after a crash or whenever you find the unit is flying erratically. %First, turn on the transmitter. Then, place the HoverCross on a level surface in hover mode. Press the On/Off button to turn on the unit and then pair with the transmitter. %Move both transmitter sticks to the outside bottom simultaneously as shown in the diagram. %The red LED’s will flash quickly for a few seconds. When the flashing s…

Text truncated - open the document above for the full version.

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Confidentiality v02 Page 1 of 1 Holi-Uprise Company Limited Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AXINFHT1008 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name 1. Block Diagram, 2. Schematics, 3. Operational Description 1. 2AXINFHT1008 -Block diagram 2. 2AXINFHT1008 -SCH 3. 2AXINFHT1008 -Operational description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for an initial period of xxxx (ie- “45”, “90” or “180”) days: Exhibit Type File Name N/A N/A Signature: Contact name: Zhou Qing Lin Company name: Holi-Uprise Company Limited Address: Rm 610, 6/F, Harbour Crystal Centre, 100 Granville Road, TST East, HK

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Authorization v02 Page 1 of 1 Holi-Uprise Company Limited Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020/9/21 SUBJECT: FCC Application for (FCC ID: 2AXINFHT1008) To Whom It May Concern: We, the undersigned, hereby authorize Alisa Feng in Shenzhen Huaxia Testing Technology Co., Ltd at 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen Huaxia Testing Technology Co., Ltd on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, (Must be signed by the person that is listed on the FCC Website) Signature: Contact name: Zhou Qing Lin Company name: Holi-Uprise Company Limited Address: Rm 610, 6/F, Harbour Crystal Centre, 100 Granville Road, TST East, HK

FCC ID: 2AXINFHT1008 FCC ID: 2AXINFHT1008 FCC ID: 2AXINFHT1008

FCC ID: 2AXINFHT1008 FCC ID: 2AXINFHT1008

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 RF Exposure Evaluation Report The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No.: CQASZ20200900977E-02 Applicant: Holi-Uprise Company Limited Address of Applicant: Rm 610, 6/F, Harbour Crystal Centre, 100 Granville Road, TST East, HK Equipment Under Test (EUT): EUT Name: Hover Cross RTF Model No.: FHT 1000 Brand Name: FLI GHT LAB TOYS FCC ID: 2AXINFHT1008 Standards: 47 CFR Part 1.1307 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2020-09-03 Date of Test: 2020-09-03 to 2020-09-17 Date of Issue: 2020-09-18 Test Result: PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By： ( Tiny You ) Reviewed By: (Sheek Luo) Approved By: (Jack Ai) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:2 of 6 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20200900977E-02 Rev.01 Initial report 2020-09-18 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:3 of 6 2 Contents Page 1 VERSION .....................................................................................................................................................................2 2 CONTENTS .................................................................................................................................................................3 3 GENERAL INFORMATION ......................................................................................................................................4 3.1 CLIENT INFORMATION ...............................................................................................................................................4 3.2 GENERAL DESCRIPTION OF EUT ...............................................................................................................................4 4 RF EXPOSURE EVALUATION ................................................................................................................................5 4.1 RF EXPOSURE COMPLIANCE REQUIREMENT ..............................................................................................................5 4.1.1 Standard Requirement .................................................................................................................................5 4.1.2 Limits ..............................................................................................................................................................5 4.2 EUT RF EXPOSURE EVALUATION .............................................................................................................................6 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:4 of 6 3 General Information 3.1 Client Information Applicant: Holi-Uprise Company Limited Address of Applicant: Rm 610, 6/F, Harbour Crystal Centre, 100 Granville Road, TST East, HK Manufacturer: Shenzhen Ho Li Chuang Electronic Co.,Ltd Address of Manufacturer: 201, 401, 501, Building A, 1, Xi Hu Tang Street, Pin Dong, Pin Di, Longgang District, Shenzhen 3.2 General Description of EUT Product Name: Hover Cross RTF Model No.: FHT 1000 Trade Mark: FLI GHT LAB TOYS Hardware Version: V2 Software Version: V2 Frequency Range: 2450MHz ~ 2470MHz Modulation Type: GFSK Number of Channels: 4 (declared by the client) Sample Type: Mobile Portable Fix Location Test Software of EUT: RF test (manufacturer declare) Antenna Type: Internal Antenna Antenna Gain: 0dBi Power Supply: 3XAAA battery:DC4.5V Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:5 of 6 4 RF Exposure Evaluation 4.1 RF Exposure Compliance Requirement 4.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 4.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:6 of 6 4.2 EUT RF Exposure Evaluation 1) For 2.4G eirp = pt x gt = (E x d) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, ---10 ((dBμV/m)/20) /10 6 , d = measurement distance in meters (m)---3m, So pt = (E x d) 2 /30 / gt The worst case (refer to report CQASZ20200900976E-01) is below: Antenna polarization: Horizontal Frequency (MHz) Level (dBuV/m) Polarization 2450 87.03 Peak 2450 83.82 Average For 240…

Text truncated - open the document above for the full version.

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 RF Exposure Evaluation Report The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No.: CQASZ20200900977E-02 Applicant: Holi-Uprise Company Limited Address of Applicant: Rm 610, 6/F, Harbour Crystal Centre, 100 Granville Road, TST East, HK Equipment Under Test (EUT): EUT Name: Hover Cross RTF Model No.: FHT 1000 Brand Name: FLI GHT LAB TOYS FCC ID: 2AXINFHT1008 Standards: 47 CFR Part 1.1307 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2020-09-03 Date of Test: 2020-09-03 to 2020-09-17 Date of Issue: 2020-09-18 Test Result: PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By： ( Tiny You ) Reviewed By: (Sheek Luo) Approved By: (Jack Ai) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:2 of 6 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20200900977E-02 Rev.01 Initial report 2020-09-18 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:3 of 6 2 Contents Page 1 VERSION .....................................................................................................................................................................2 2 CONTENTS .................................................................................................................................................................3 3 GENERAL INFORMATION .......................................................................................................................................4 3.1 CLIENT INFORMATION ................................................................................................................................................4 3.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................4 4 RF EXPOSURE EVALUATION ................................................................................................................................5 4.1 RF EXPOSURE COMPLIANCE REQUIREMENT ..............................................................................................................5 4.1.1 Standard Requirement .................................................................................................................................5 4.1.2 Limits ..............................................................................................................................................................5 4.2 EUT RF EXPOSURE EVALUATION ..............................................................................................................................6 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:4 of 6 3 General Information 3.1 Client Information Applicant: Holi-Uprise Company Limited Address of Applicant: Rm 610, 6/F, Harbour Crystal Centre, 100 Granville Road, TST East, HK Manufacturer: Shenzhen Ho Li Chuang Electronic Co.,Ltd Address of Manufacturer: 201, 401, 501, Building A, 1, Xi Hu Tang Street, Pin Dong, Pin Di, Longgang District, Shenzhen 3.2 General Description of EUT Product Name: Hover Cross RTF Model No.: FHT 1000 Trade Mark: FLI GHT LAB TOYS Hardware Version: V2 Software Version: V2 Frequency Range: 2450MHz ~ 2470MHz Modulation Type: GFSK Number of Channels: 4 (declared by the client) Sample Type: Mobile Portable Fix Location Test Software of EUT: RF test (manufacturer declare) Antenna Type: Internal Antenna Antenna Gain: 0dBi Power Supply: 3XAAA battery:DC4.5V Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:5 of 6 4 RF Exposure Evaluation 4.1 RF Exposure Compliance Requirement 4.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 4.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where nd distance are rounded to the nearest mW and mm before calculation 17 The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200900977E-02 Page:6 of 6 4.2 EUT RF Exposure Evaluation 1) For 2.4G eirp = pt x gt = (E x d) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, ---10 ((dBμV/m)/20) /10 6 , d = measurement distance in meters (m)---3m, So pt = (E x d) 2 /30 / gt The worst case (refer to report CQASZ20200900977E-01) is below: Antenna polarization: Horizontal Frequency (MHz) Level (dBuV/m) Polarization 2450 87.03 Peak 2450 83.82 Average For 2450MHz wireless: Field strength = 87.03dBμV/m @3m Ant. gain 0dBi; so Ant numeric gain=1 So pt={[10 (87.03/20) /10 …

Text truncated - open the document above for the full version.

FCC ID: 2AXINFHT1008 1 Photographs 1.1 Radiated Emission Test Setup 9kHz~30MHz 30MHz~1GHz: FCC ID: 2AXINFHT1008 Above 1GHz:
