2AXJ5-SWC20PCB PACKAGE ASSY - SWC

NAMSUNG CO., LTD. 1 PRODUCT SPECIFICATION AND MANUAL 2020.07 THOR / SWC20 BUYER /PROJECT BUYER MODEL PCB PACKAGE ASSY – SWC PART No. COMPANY NAMSUNG Co,. MAKER/NATION NAMSUNG Co,./Republic of Korea DRAFT PART Research Center DRAFTER JEONG WOO SEOK TitleCertification Request Document Project Name SWC20Drawn2020-07- 20 Model Name Releas ed 2020-07- 20 Made by JEONG W.S Table of Contents 1.CONTENTS...............................................................................................................3 2.ELECTRONIC SPEC................................................................................................3 3.SPECIFICATION.......................................................................................................4 4.REPAIR OF UNIT & CIRCUIT EXPLANATION........................................................4 5.THE METHOD OF UNIT OPERATING.....................................................................5 6.THE SYSTEM OF EACH UNIT CODE DISCRIMINATION......................................6 TitleCertification Request Document Project Name SWC20Drawn 2020-07-20 Model Name Releas ed 2020-07-20 Made by JEONG W.S 1.Contents TYPE Wireless controller about wireless electronic equipment of specific low output radio station MODEL NAME USE Vehicle of AVN(Audio Video Navigation system) controller what use 433.92 MHz f requency SUMMARY 1. This equipment use semiconductor and integrated circuit, so it designs to get high reliability. 2. This equipment use oscillation circuit of crystal, so it designs to satisfy about legally frequency an allowable error and bandwidth of exclusive frequency. 3. The transmitter has each other specific identification code. 4. The power use Li-ion coin Battery (DC 3.0V) COMPOSITI ON 1. RF Transmitter part 2. Pattern Antenna 2. ELECTRONIC SPEC UNIT List TRANSMITTER(FOB) Rated voltageDC 3.0V Voltage range UNIT 2.1 ~ 3.6V ( except Battery influence) Operating Temperature range-20 ~ +60°C Storage temperature range-30 ~ +80°C Dark current Not relevant (Power Off in Normal State) TitleCertification Request Document Project Name SWC20Drawn 2020-07-20 Model Name Releas ed 2020-07-20 Made by JEONG W.S 3.Specification TYPETRANSMITTER ASSY – SWC NAME Equipment List Wireless controller about wireless electronic equipment of FrequencyTX: 433.920MHz Antenna Composition Pattern ANTENNA Oscillation method Crystal oscillation Modulation method FSK CommunicationOne-Way Communication Frequency multiplier 32 multiplier 4.Repair of Unit & Circuit Explanation 4.1 Repair of Unit Exchange an old unit. 4.2 Circuit Explanation If User presses specific Switch of transmitter, MCU makes inherent serial value and Encryption value, so it print what CPU make data, at the same time , RF IC get to be ENABLE. Printing data are falsified into TxIC and it synthesize through CRYSTAL. Compounded frequency is amplified by TxIC and it transmits through antenna from matching circuit diagram of output. TitleCertification Request Document Project Name SWC20Drawn 2020-07-20 Model Name Releas ed 2020-07-20 Made by JEONG W.S 5.The Method of Unit Operating 5.1SWC FunctionDescryption Volume Up SHORT PRESSING BUTTON less 0.5s -Volume Up Volume Down SHORT PRESSING BUTTON less 0.5s -Volume Down Seek Up SHORT PRESSING BUTTON less 0.5s -Seek Up Seek Down SHORT PRESSING BUTTON less 0.5s -Seek Down Source SHORT PRESSING BUTTON less 0.5s -Mode Change TitleCertification Request Document Project Name SWC20Drawn 2020-07-20 Model Name Releas ed 2020-07-20 Made by JEONG W.S 6. The System of Each Unit Code Discrimination 6.1 TRANSMISSION CODE <RF Transmit> Item bit Note preamble150 header41100 start bit210 Counter16 Seiral24 Data8 CRC88 Stop bit1 TitleCertification Request Document Project Name SWC20Drawn 2020-07-20 Model Name Releas ed 2020-07-20 Made by JEONG W.S FCC This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

SeMyeog 260, Seonggeo-gil, Seonggeo-eup Seobuk-gu , Chungcheongnam-do, Cheonan-si, South Korea 21072 Date: Sep 18, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AXJ5-SWC20 including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from SeMyeog “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, jaesun Lee / President

SeMyeog 260, Seonggeo-gil, Seonggeo-eup Seobuk-gu , Chungcheongnam-do, Cheonan-si, South Korea 21072 Date: Sep 18, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: 2AXJ5-SWC20 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SeMyeog hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SeMyeog temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, jaesun Lee / President

FCC ID : 2AXJ5-SWC20 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : 2AXJ5-SWC20 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : 2AXJ5-SWC20 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3

FCC ID: 2AXJ5-SWC20 Copyright Ⓒ 2020 DT&C Co., Ltd. SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label.

FCC ID : 2AXJ5-SWC20 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : 2AXJ5-SWC20 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : 2AXJ5-SWC20 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID : 2AXJ5-SWC20 Copyright Ⓒ 2020, DT&C Co., Ltd. View 4 <Antenna>

Report No.: DRTFCC2009-0294 FCC ID: 2AXJ5-SWC20 TRF-RF-218(02)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 16 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2009-0294 Sep. 18, 2020 Initial issue JaeHyeok Bang JaeJin Lee Report No.: DRTFCC2009-0294 FCC ID: 2AXJ5-SWC20 TRF-RF-218(02)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 16 CONTENTS 1. General Information .................................................................. 4 1.1. Testing Laboratory ................................................................. 4 1.2. Testing Environment .............................................................. 4 1.3. Measurement Uncertainty ..................................................... 4 1.4. Description of EUT ................................................................ 5 2. Information about test items .................................................... 6 2.1 Operating mode ..................................................................... 6 2.2 Tested frequency .................................................................... 6 2.3 Auxiliary equipment ................................................................ 6 2.4 EMI Suppression Device(s)/Modifications .............................. 6 3. Test Report ................................................................................ 7 3.1 Summary of tests ................................................................... 7 3.2 Transmitter requirements........................................................ 8 3.2.1 20 dB ................................................................................. 8 3.2.2 Automatically deactivate ..................................................... 9 3.2.3 Field strength of fundamental and spurious emissions ..... 10 3.2.4 AC power line conducted emission................................... 13 3.2.5 Antenna requirement ........................................................ 14 APPENDIX I ................................................................................. 15 APPENDIX II ................................................................................ 16 Report No.: DRTFCC2009-0294 FCC ID: 2AXJ5-SWC20 TRF-RF-218(02)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 16 1. General Information 1.1. Testing Laboratory DT&C Co., Ltd. The 3 m test site and conducted measurement facility used to collect the radiated data are located at the 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 17042. The test site complies with the requirements of § 2.948 according to ANSI C63.4-2014. - FCC & IC MRA Designation No. : KR0034 - ISED #: 5740A www.dtnc.net Telephone : + 82-31-321-2664 FAX : + 82-31-321-1664 1.2. Testing Environment Ambient Condition ▪ Temperature +21 °C ~ +23 °C ▪ Relative Humidity 35 % ~ 38 % 1.3. Measurement Uncertainty The measurement uncertainties shown below were calculated in accordance with requirements of ANSI C63.4- 2014. All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a 95 % level of confidence. Test items Measurement uncertainty Radiated emission (1 GHz Below) 4.9 dB (The confidence level is about 95 %, k = 2) Radiated emission (1 GHz ~ 18 GHz) 5.1 dB (The confidence level is about 95 %, k = 2) Report No.: DRTFCC2009-0294 FCC ID: 2AXJ5-SWC20 TRF-RF-218(02)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 16 1.4. Description of EUT FCC Equipment Class Part 15 Security / Remote Control Transmitter EUT PCB PACKAGE ASSY – SWC Model Name SWC20 Hardware version 1.0 Software version 1.0 Power Supply DC 3 V Frequency Band 433.92 MHz Modulation Type FSK Antenna type PCB Pattern Antenna Report No.: DRTFCC2009-0294 FCC ID: 2AXJ5-SWC20 TRF-RF-218(02)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 6 / 16 2. Information about test items 2.1 Operating mode Operating Mode 1 This device was tested with continuous TX mode for field strength and 20dB Bandwidth measurements. Operating Mode 2 Normal operating mode was used for measurement the deactivation measurement. 2.2 Tested frequency Mode Frequency(MHz) Transmitting mode 433.92 - - 2.3 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note - - - -. - 2.4 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None Report No.: DRTFCC2009-0294 FCC ID: 2AXJ5-SWC20 TRF-RF-218(02)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 7 / 16 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Test Condition Status Note 1 15.231(b) Field strength of fundamental and spurious emissions Radiated C Note 3 15.205 15.209 General Field Strength Limits (Restricted Bands and Radiated Emission Limits) C Note 3 15.231(a) Deactivation Conducted C 15.231(c) 20dB bandwidth C 15.207 AC Power Line Conducted Emission AC Line Conducted NA Note 4 15.203 Antenna Requirements - C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: For radiated emission tests below 30 MHz were performed on semi-anechoic chamber which is correlated with OATS. Note 3: This test item was performed in each axis and the worst case data was reported. Note 4: This device is used Battery for power supplying only. Therefore this test item was not performed. Report No.: DRTFCC2009-0294 FCC ID: 2AXJ5-SWC20 TRF-RF-218(02)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 8 / 16 3.2 Transmitter requirements 3.2.1 20 dB - Procedure: The transmitter output is connected to the Spectrum Analyzer and used following test procedure of ANIS C63.10- 2013. RBW: 1 % to 5 % of the OBW VBW: Approximately three times the RBW Detector: Peak Trace: Max hold Sweep: Auto couple - Measurement Data: Comply Frequency (MHz) 20dB Ban…
