2AXJ7-SOLO1-RBluetooth Wireless Earphone

CONTENTS | CONTENU | INHALT | INHOUD | CONTENIDO | CONTENUTI | CONTEÚDO | INDHOLD | SISÄLLYS | OBSAH | INNEHÅLL | ZAWARTOŚĆ [EN] QUICK START GUIDE [FR] GUIDE DE DÉMARRAGE RAPIDE [DE] SCHNELLSTARTANLEITUNG [NL] SNELSTARTGIDS [ES] GUÍA BÁSICA DE INICIACIÓN [IT] GUIDA RAPIDA [PT] GUIA RÁPIDO [DA] VEJLEDNING TIL HURTIG START [FI] PIKAOPAS [CZ] STUČNÁ ÚVODNÍ PŘÍRUČKA [SV] SNABBSTARTSGUIDE [PL] SKRÓCONA INSTRUKCJA OBSŁUGI 1 6 11 16 21 26 31 36 41 46 51 56 EN: QUICK START GUIDE LET’S STAY CHARGED TIP: 15 MINUTE QUICK CHARGE If you’re running low on power, charge your earbuds in the case for 15 minutes and get 2 hours extra play time while on the go 21 EN A voice prompt “Battery low” allows for 2 minutes play time before the earbud(s) powers down stating “Battery low, power off”. The Earbuds LED Light [2] will flash WHITE once and will then switch off. Charge the earbuds using the Portable Charging Case [5] . While charging, each Earbud LED Light [2] will be WHITE and once fully charged the LED Lights will turn off. Secure the earbuds by closing the lid. When the earbuds are placed inside the case and the lid is closed, the charge indicator light (7) WHITE for 4 seconds to indicate charging and then turn off. The Earbuds 2 5 2 7 ortable Charging Case st time pairing ONNECT ve both earbuds from the Portable Charging Case [5]. y will automatically dual pair together; a voice will prompt wer on, pairing” and a ‘Beep’ will sound. One of the Earbud s [2] will flash WHITE to indicate pairing mode. If the omatically dual pair together, tap each earbud [1] and [3] 4 times to power off and then place o the case. Remove the earbuds and they d automatically dual pair together. o the Bluetooth settings on your audio device and select ‘MIXX o 1’from the list. Once paired successfully you will “Connected” and the Earbud LED Light [2] will turn off. an now enjoy your music, watch a video or take a call hands l automatically reconnect to the last device they e paired with, confirming “Connected”. earbuds back in the Portable Charging Case (5) will er them off. (note – if the earbuds do not turn off, the battery ging case needs to be recharged – see ‘Let’s Stay ged.’ Note: If your earbuds and charge case do not have any power when you first unpack them, place the earbuds into the charge case and plug the charge case into a USB port using the USB C cable [8] provided. 8 ys connect the case via the USB C port [6] , to a suitable USB ger, computer USB port or a power bank using the USB C ging cable (8) supplied. Plug the supplied cable into the USB ge case. ge light indicator (7) will blink RED, on and off, to show the ging. LET’S STAY CHARGED TIP:15MINUTEQUICKCHARGE If you’re running low on power, charge your earbuds in the case for 15 minutes and get 2 hours extra play t while on the go 21 EN A voice prompt “Battery low” allows for 2 minutes pla before the earbud(s) powers down stating “Battery low, power off”. The Earbuds LED Light [2] will flash WHITE once and will then switch off. Char Portable Charging Case [5] . While charging, each Earbud LED Light [2] will be WHITE and once fully charged the LED Lights will turn off. Secure the earbuds by closing the lid. When the earbuds are placed inside the case and the lid is closed, the charge indicator light (7) WHITE for 4 sec to indicate charging and then turn off. The Portable Charging Case First time pairing LET’S CONNECT Remove both earbuds from the Portable Charging Case [5] . They will automatically dual pair together; a voice will prompt “Power on, pairing” and a ‘Beep’ will sound. One of the Earbud LED Lights [2] will flash WHITE to indicate pairing mode. If the earbuds do not automatically dual pair together, tap each earbud Touch Sensor [1] and [3] 4 times to power off and then place them both back into the case. Remove the earbuds and they should automatically dual pair together. Go to the Bluetooth settings on your audio device and select ‘MIXX StreamBuds Solo 1’ from the list. Once paired successfully you will hear “Connected” and the Earbud LED Light [2] will turn off. You can now enjoy your music, watch a video or take a call hands free. The earbuds will automatically reconnect to the last device they were paired with, confirming “Connected”. Placing both earbuds back in the Portable Charging Case (5) will power them off. (note – if the earbuds do not turn off, the battery in your charging case needs to be recharged – see ‘Let’s Stay Charged.’ 5 2 2 5 Note: If your earbuds and charge case do not have any power when you first unpack them, plac the charge case and plug the charge case int using the USB C cable [8] provided. Always connect the case via the USB C port [6] , to a suitable USB wall charger, computer USB port or a power bank using the USB C charging cable (8) supplied. Plug the supplied cable into the USB C port [6] on the charge case. The charge light indicator (7) will blink RED, on and off, to show the case is charging. 8 7 6 6 7 13 34 EN LET’S PLAY Power on Remove both earbuds from the case. They will automatically turn on and dual pair together. A voice prompt will state “Connected” as confirmation. To manually turn on, long press each Touch Sensor [1] and [3] for 3 seconds. Power off Place both earbuds in the case. This will automatically turn off the earbuds and the Bluetooth. Play / Pause Double tap either Touch Sensor [1] or [3] Increase Volume Single tap RIGHT Touch Sensor [3] Decrease Volume Single tap LEFT Touch Sensor [1] Previous Track Tap and hold LEFT Touch Sensor [1] Skip Track Tap and hold RIGHT Touch Sensor [3] Answer / End Call Double tap either Touch Sensor [1] or [3] . (Audio is picked up via the microphones [4] .) 13 3 1 1 3 31 e tap either Touch Sensor [1] or [3]to activate Siri e Assistant. oice Assist familiar ‘Beep’ will sound to confirm ou can now ask Siri or Google Assistant a tion or state a command. OOGLE SISTANT / SIRI oduct can be recycled. s bearing this symbol must NOT be thrown y with normal household wast…

Text truncated - open the document above for the full version.

MIXX LIMITED Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 20, 2023 FCC ID: 2AXJ7-SOLO1-R Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing MIXX LIMITED certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing MIXX LIMITED certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Applicant: MIXX LIMITED Address: Unit 5 The Pavilions Brighton Road, Pease Pottage, RH11 9BJ United Kingdom Contact Person: JOHN WHITEHEAD Tel.: 44(0)7969 593402 Email: [email protected] Sincerely, Signature:

MIXX LIMITED 5 THE PAVILIONS, BRIGHTON ROAD PEASE POTTAGE, WEST SUSSEX, RH11 9BJ UNITED KINGDOM Date:19/9/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FRN: 0029972973 FCC ID:2AXJ7-SOLO1-R US Agent - Attestation Statement / Part 2.911(d)(7) MIXX LIMITED certifies, that as of 10 August 2023, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AXJ7-SOLO1-R MIXX LIMITED accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment with in the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of MIXX LIMITED for FCC ID: 2AXJ7-SOLO1-R Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles,IL,60174,USA Contact Person: Tim Payne Phone:708-571-3148 Email: [email protected] Sincerely, Company: MIXX LIMITED Designated Agent: FCC US Agent, LLC Company Representative: JOHN WHITEHEAD Designated Agent Representative: Tim Payne Signature: Signature: � � --i D �

天线测试报告 Antenna Test Report 深圳美师傅科技有限公司 Shenzhen Li Tongchuang Technology Co., Ltd. 217, A3(A4) Huichao Building, Yintian Industrial Zone, Yantian Community, Xixiang Street, Baoan District, Shenzhen Vector network Analyzer & Integrated meter Agelent Techmologies E5071B & R&S CMW500 Darkroom Atenlab M3 Test engineer Chaofan Liu Temperature25°C Humidity65%（RH） Antenna View (13mm*7mm) Antenna Type:FPCB Antenna L KINGSOFT YoSong ANT S11 parameter Summary Band 2400-2500(MHz) 2400 2450 2483 R.L(dB)-8.7-15.5-19.1 VSWR 2.1 1.4 1.2 R KINGSOFT YoSong ANT S11 parameter Summary Band 2400-2500(MHz) 2400 2450 2483 R.L(dB)-14.6-24.8-12.5 VSWR 1.4 1.1 1.6 L R KINGSOFT ANT EIRP&EIS parameter Summary BT 2.4G (L) BT 2.4G (R) channel 0 39 78 0 39 78 TRP (dBm） 2.12 1.83 0.78 0.59 1.48 1.13 TIS（dBm） -85.8-85.03-83.87-84.94-85.2-84.39

MIXX LIMITED Date: September 20, 2023 Product Model Number: MIXX StreamBuds Solo 1, SBSO-01-XX-XXX FCC ID: 2AXJ7-SOLO1-R To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: JOHN WHITEHEAD Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: 44(0)7969 593402 On behalf of: MIXX LIMITED

MIXX LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 20, 2023 Subject; Request for Confidentiality FCC ID: 2AXJ7-SOLO1-R To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: JOHN WHITEHEAD Title: Manager

MIXX LIMITED Model Difference Statement Dear Sir/Madam, Added models SBSO-01-XX-XXX basis of the original product MIXX StreamBuds Solo 1. The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, -XX-XXX stands for means different colors, declared by the manufacturer. Sincerely, Name: JOHN WHITEHEAD Title: Manager Company name: MIXX LIMITED Address: Unit 5 The Pavilions Brighton Road, Pease Pottage, RH11 9BJ United Kingdom

FCC ID: 2AXJ7-SOLO1-R External

Page 1 of 1 Label and Information FCC Label Sample FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

FCC ID: 2AXJ7-SOLO1-R Internal BT ANT

- Page 1 of 9 - Report No.: HB20231110001E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com RF EXPOSURE Test Report Product: Bluetooth Wireless Earphone Trade Mark: MIXX Model Number: MIXX StreamBuds Solo 1 FCC ID: 2AXJ7-SOLO1-R Prepared for MIXX LIMITED Unit 5 The Pavilions Brighton Road, Pease Pottage, RH11 9BJ United Kingdom Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 9 - Report No.: HB20231110001E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ..................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................. 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 ANCILLARY EQUIPMENT .............................................................................................................................................. 5 2 TEST FACILITIES AND ACCREDITATIONS .............................................................................................................. 6 2.1 TEST LABORATORY ..................................................................................................................................................... 6 2.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 6 2.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 6 2.4 TEST SOFTWARE ........................................................................................................................................................ 6 3 LIST OF TEST EQUIPMENT .................................................................................................................................. 7 4 RF EXPOSURE .................................................................................................................................................... 8 4.1 STANDALONE SAR TEST EXCLUSION CONSIDERATIONS........................................................................................................ 8 4.1.1. Limit ............................................................................................................................................................ 8 4.1.2. Test Procedures ........................................................................................................................................... 8 4.1.3. Test Result ................................................................................................................................................... 9 - Page 3 of 9 - Report No.: HB20231110001E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com TEST RESULT CERTIFICATION Applicant’s Name ................. : MIXX LIMITED Address ................................. : Unit 5 The Pavilions Brighton Road, Pease Pottage, RH11 9BJ United Kingdom Manufacturer's Name .......... : Shenzhen Kingvie Technology Co., Ltd Address ................................. : 201, 301, No.2 Building, 84# Fuqian Rd., Fumin Community, Fucheng Street, Longhua District, Shenzhen City Product description Product name ........................ : Bluetooth Wireless Earphone Model Number ....................... : MIXX StreamBuds Solo 1 Standards ............................. : FCC CFR 47 PART 1 , 1.1310 Test procedure ..................... : KDB 447498 D01 v06 This device described above has been tested by Shenzhen HongBiao Certification& Testing Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the EMC requirements. And it is applicable only to the tested sample identified in the report. Date of Test ........................................... : Date (s) of performance of tests ............. : September 12, 2023 ~ September 27, 2023 Test Result .............................................. : Pass Testing Engineer : ( Z o e Su) Technical Manager : ( G a r y Lu) Authorized Signatory : (L e o S u) - Page 4 of 9 - Report No.: HB20231110001E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Revision History Revised No. Date of Issue Description 01 September 28, 2023 Original - Page 5 of 9 - Report No.: HB20231110001E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com 1 General Description 1.1 Description of EUT Product name: Bluetooth Wireless Earphone Model name: MIXX StreamBuds Solo 1 Series Model: SBSO-01-XX-XXX Different of series model: The color of appearance and model name of series models listed are different from the main model, bu…

Text truncated - open the document above for the full version.

-Page 1 of 50 -Report No.: HB20231110001E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Test Report Product: Bluetooth Wireless Earphone Trade Mark: MIXX Model Number: MIXX StreamBuds Solo 1 FCC ID: 2AXJ7-SOLO1-R Prepared for MIXX LIMITED Unit 5 The Pavilions Brighton Road, Pease Pottage, RH11 9BJ United Kingdom Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 50 - Report No.: HB20231110001E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ..................................................................................................................................... 6 1.1 DESCRIPTION OF EUT ................................................................................................................................................. 6 1.2 TEST MODE .............................................................................................................................................................. 6 1.3 OPERATION CHANNEL LIST .......................................................................................................................................... 6 1.4 TEST SETUP .............................................................................................................................................................. 7 1.5 ANCILLARY EQUIPMENT .............................................................................................................................................. 7 2 SUMMARY OF TEST RESULT ............................................................................................................................... 8 3 TEST FACILITIES AND ACCREDITATIONS .............................................................................................................. 9 3.1 TEST LABORATORY ..................................................................................................................................................... 9 3.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 9 3.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 9 3.4 TEST SOFTWARE ........................................................................................................................................................ 9 4 LIST OF TEST EQUIPMENT .................................................................................................................................10 5 TEST ITEM AND RESULTS ...................................................................................................................................12 5.1 ANTENNA REQUIREMENT .......................................................................................................................................... 12 5.1.1 Standard Requirement ............................................................................................................................. 12 5.1.2 Test Result ................................................................................................................................................. 12 5.2 CONDUCTED EMISSION ............................................................................................................................................. 13 5.2.1 Limits ........................................................................................................................................................ 13 5.2.2 Test Procedures ......................................................................................................................................... 13 5.2.3 Test Setup ................................................................................................................................................. 14 5.2.4 Test Result ................................................................................................................................................. 14 5.3 RADIATED EMISSION ................................................................................................................................................ 17 5.3.1 Limits ........................................................................................................................................................ 17 5.3.2 Test Procedures ......................................................................................................................................... 17 5.3.3 Test Setup ................................................................................................................................................. 17 5.3.4 Test Result ................................................................................................................................................. 18 5.3.5 Radiated Band Edge ................................................................................................................................. 23 5.4 PEAK OUTPUT POWER .............................................................................................................................................. 24 5.4.1 Limit ................................................................................................................................…

Text truncated - open the document above for the full version.

FCC ID: 2AXJ7-SOLO1-R Radiated Emission Below 1GHz (Right ear) Radiated Emission Above 1GHz (Right ear) Conducted emission
