2AXK8-SP16-1Bluetooth Headset

Instruction Manual 1. Ensure the phone's wireless function is turned off. Remove the earbuds from the charging case—the indicator lights will flash red/blue alternately. Wait for 5 seconds after removal, then the earbuds will automatically enter TWS mode (dual-ear mode). Upon successful connection, one earbud's light will flash red/blue alternately while the other's turns off. 2. Turn on the wireless function of the phone and connect to "SP16". After successful connection, the earbuds' indicator light will turn off. (If only one earbud has sound, first turn off your phone’s wireless function, delete the paired device "SP16", place the earbuds back into the charging case, and then proceed to Step 1.) Connection Method: 1. Short press: Play/Pause, answer calls, end calls; long press to reject incoming calls. 2. Double-tap left/right earbud touch area: Previous/Next Track. 3. Triple-tap left/right earbud touch area: Volume down/Volume up. 4. Long press the earbud touch area for 1.5 seconds: Activate Siri. 5. Press and hold the touch control area for about 3 seconds: Power on/off. Touch Control Function: Touch Control Area The power delivered by the charger must be between min 2.5 Watts required by the radio equipment, and max 10 Watts in order to achieve the maximum charging speed. 2.5 - 10 W FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. English （英文）

Rev 1/26/2023 Dongguan Baolifeng Electronic Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12-31-2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AXK8-SP16-1 [Dongguan Baolifeng Electronic Technology Co., Ltd] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Dongguan Baolifeng Electronic Technology Co., Ltd] certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24- 886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Binbiao Liang Rev 1/26/2023 Dongguan Baolifeng Electronic Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12-31-2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AXK8-SP16-1 [Dongguan Baolifeng Electronic Technology Co., Ltd] ce8rtifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Binbiao Liang

Dongguan Baolifeng Electronic Technology Co., Ltd U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: December 31, 2025 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2AXK8-SP16-1 Dongguan Baolifeng Electronic Technology Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, CLF Import and Export Limited (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. CLF Import and Export Limited ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: CLF Import and Export Limited FRN: 0033489683 Address: 1312 17th Street #692, Denver, CO 80202, United States Signature: Contact Person: David Chen Tel: +1 949 254 2565 Email: [email protected] Applicant Company Name: Dongguan Baolifeng Electronic Technology Co., Ltd FRN: 0029986940 Address: 4/F, Mingxin Science Park, 138 Qiqiao Road, Qishi Town, Dongguan City, China Signature: Contact Person: Binbiao Liang Tel: +86-15099927722 Email: [email protected]

2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ Application: WLAN, 802.11b/g, Bluetooth, WLAN, etc... Features SMD, high reliability, ultra Impact, Omni-directional... Part number Information RANT1608F245C04 (A) (B) (C) (D)(E) (F) Electrical Specification Dimension and Terminal Configuration No.Terminal Name 1Feeding/GNG 2GND/Feeding (A)Product TypeSMD Antenna (B) Size Code 1.6x0.8mm( ± 0.1mm) (C) MaterialHigh K material (D) Frequency2.4 ~ 2.5GHz (E) Feeding modePIFA & Single Feeding (F) Antenna typeType=04 Working Frequency Range2400 ~2500 MHz Bandwidth120 MHz (Min.) Peak Gain2.7 dBi (Typ.) Impedance50 Ohm Return loss10 dB ( Min) PolarizationLinear Azimuth BeamwidthOmni-directional Operation Temperature( °C )-40 ~85 °C Resistance to Soldering Heats 10sec. ( @ 280 °C ) TerminationNi / Au (Leadless) Dimension (mm) L 1.60±0.10 W 0.80 ± 0.10 T 0.80 ± 0.10 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ 1 Evaluation BoardReference PCB DimensionAntenna Layout Reference Unit :mm Electrical Characteristics Return Loss & Radiation ELECTRICAL CHARACTERISTICSS11 Radiation Electrical Characteristics Freque ncy Effic Percen Gain 2400-1.64 72.27% 2.38 2450-1.33 75.34%2.7 2500-1.59 72.98% 2.59 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ Taping Specifications Reel and Taping Specification Reel Specification TYPESIZEABCD 16087” 4K/Reel 4.0±0.5 4.0±213.5±0.5178±2 Tapping Specification PackagingTypeABWEFGHTψDP Paper Type 1608 1.90±0.20 3.50±0.20 8.0±0.20 1.75±0.10 3.5±0.05 4.0±0.10 2.0±0.05 0.75±0.10 1.50±0.10 4.0±0.1 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1608 SMD Antenna: RANT1608F245C04 _ Reliability Table Test ItemProcedure Requirements Ceramic Type Remark (Reference) Electrical Characterization Fulfill the electrical specification User Spec. Thermal Shock 1. Preconditioning: 50 ± 10°C/ 1 hr , then keep for 24 ± 1 hrs at room temp. 2. Initial measure: Spec: refer Initialspec. 3. Rapid change of temperature test: -30°Cto +85°C; 100 cycles; 15 minutes at Lower category temperature; 15 minutes at Upper category temperature. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 107 Temperature Cycling 1. Initial measure: Spec: refer Initialspec. 2. 100 Cycles (-30°Cto +85°C), Soak Mode=1 (2 Cycle/hours). 3. Measurement at 24 ± 2Hours after testcondition. No Visible Damage. Fulfill the electrical specification. JESD22 JA104 High Temperature Exposure 1. Initial measure: Spec: refer Initialspec. 2. Unpowered; 500hours @ T=+85°C. 3. Measurement at 24 ± 2 hours aftertest. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Low Temperature Storage 1. Initial measure: Spec: refer Initialspec. 2. Unpowered: 500hours @ T=-30°C. 3. Measurement at 24 ± 2 hours aftertest. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Solderability (SMD Bottom Side) Dipping method: a. Temperature: 235 ±5°C b. Dipping time: 3 ±0.5s The solder should cover over 95% of the critical area of bottom side. IEC 60384-21/22 4.10 Soldering Heat Resistance (RSH) Preheating temperature: 150 ± 10°C. Preheating time: 1~2 min. Solder temperature: 260 ± 5°C. Dipping time: 5 ± 0.5s No Visible Damage.IEC 60384-21/22 4.10 Vibration5g's for 20 min., 12 cycles each of 3 orientations Note: Use 8"X5" PCB .031" thick 7 secure points on, one long side and 2 secure points at corners of opposite sides. Parts mounted within 2" from any secure point. Test from 10-2000 Hz. No Visible Damage.MIL-STD-202 Method 204 Mechanical Shock Three shocks in each direction shall be applied along the three mutually perpendicular axes of the test specimen (18 shocks) Peak value: 1,500g’s Duration: 0.5ms Velocity change: 15.4 ft/s Waveform: Half-sine No Visible Damage.MIL-STD-202 Method 213 Humidity Bias 1. Humidity: 85% R.H., Temperature:85 ± 2 °C. 2. Time: 500 ± 24hours. 3. Measurement at 24 ± 2hrs after testcondition. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 Method 106 Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen. 2.4GHz 1 6 0 8 SMD Antenna: RANT1608F245C04 _ Board Flex (SMD) 1. Mounting method: IR-Reflow. PCB Size (L:100 × W:40 × T:1.6mm) 2. Apply the load in direction of the arrow until bending reaches 2 mm. No Visible Damage.AEC-Q200 005 AdhesionForce of 1.8Kg for 60 seconds. No Visible Damage Magnification of 20X or greater may be employed for inspection of the mechanical integrity of the device body terminals and body/terminal junction. AEC-Q200 006 Physical Dimension Any applicable method using x10 magnification, micrometers, calipers, gauges, contour projectors, or other measuring equipment, capable of determining the actual specimen dimensions. In accordance with specification. JESD22 JB100 Revision History RevisionDateContent 12019/03/01 New Datasheet 22020/02/22 Add 2D radiation characteristic Add: Room 707, Bui l di ng F, Tongan Zhi chuangyuan, xi xi ang st r eet , Baoan Di st r i ct , Shenzhen.

Dongguan Baolifeng Electronic Technology Co., Ltd Date: December 31, 2025 Product Model Number: SP16 FCC ID: 2AXK8-SP16-1 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Binbiao Liang Contact Listed on FCC Wesbite Title: Sales Manager Email: [email protected] Telephone: +86-15099927722 On behalf of: Dongguan Baolifeng Electronic Technology Co., Ltd

Dongguan Baolifeng Electronic Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: December 31, 2025 Subject; Request for Confidentiality FCC ID: 2AXK8-SP16-1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Binbiao Liang Title: Sales Manager

Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report Annex A. EUT External Photos Model: SP16 EUT View 1 EUT View 2 Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report EUT View 3 EUT View 4 (Left earphone) Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report EUT View 5 EUT View 6 Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report EUT View 7 EUT View 8 Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report EUT View 9

Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report Annex D. Label and Information FCC Label Sample Label Size:0.6cm*0.2cm FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report Annex B. EUT Internal Photos Model: SP16 EUT Internal View 1 EUT Internal View 2 SMD Antenna Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report EUT Internal View 3 EUT Internal View 4

FCC ID: 2AXK8-SP16-1 RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For BR+EDR Max Conducted Power(dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 2.79 2(±1) 3 1.995 2402 5 0.6183 3.0 So a SAR test is not required

Report No: SSP25120450-1E FCC Test Report Page 1 of 46 FCC TEST REPORT FCC ID: 2AXK8-SP16-1 Report No. : SSP25120450-1E Applicant : Dongguan Baolifeng Electronic Technology Co., Ltd Product Name : Bluetooth Headset Model Name : SP16 Test Standard : FCC Part 15.247 Date of Issue : 2025-12-25 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: SSP25120450-1E FCC Test Report Page 2 of 46 Test Report Basic Information Applicant..................................: Dongguan Baolifeng Electronic Technology Co., Ltd Address of Applicant...............: 4/F, Mingxin Science Park, 138 Qiqiao Road, Qishi Town, Dongguan City, China Manufacturer..........................: Dongguan Baolifeng Electronic Technology Co., Ltd Address of Manufacturer........: 4/F, Mingxin Science Park, 138 Qiqiao Road, Qishi Town, Dongguan City, China Product Name.........................: Bluetooth Headset Brand Name.............................: - Main Model..............................: SP16 Series Models..........................: - Test Standard..........................: FCC Part 15 Subpart C ANSI C63.4-2014 ANSI C63.10-2020 Date of Test .............................: 2025-12-18 to 2025-12-23 Test Result...............................: PASS Tested By ................................: (Coke Huang) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: SSP25120450-1E FCC Test Report Page 3 of 46 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................6 1.3 Compliance Standards ...........................................................................................................................................7 1.4 Test Facilities ........................................................................................................................................................7 1.5 List of Measurement Instruments ..........................................................................................................................8 1.6 Measurement Uncertainty .....................................................................................................................................9 2. Summary of Test Results ........................................................................................................................................... 10 3. Antenna Requirement ............................................................................................................................................... 11 3.1 Standard and Limit.............................................................................................................................................. 11 3.2 Test Result .......................................................................................................................................................... 11 4. Conducted Emissions ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 13 5. Radiated Emissions ................................................................................................................................................... 16 5.1 Standard and Limit.............................................................................................................................................. 16 5.2 Test Procedure.................................................................................................................................................... 16 5.3 Test Data and Results .......................................................................................................................................... 18 6. Band-edge Emissions(Radiated) ............................................................................................................................... 22 6.1 Standard and Limit.............................................................................................................................................. 22 6.2 Test Procedure.................................................................................................................................................... 22 6.3 Test Data and Results .......................................................................................................................................... 22 7. Frequency Hopping System ..................…

Text truncated - open the document above for the full version.

Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report Annex C. Test Photos Conducted Emission Test View 1 Radiated Emission Test View Below 1GHz Report No: SSP25120450-1E FCC ID: 2AXK8-SP16-1 Annex of Test Report Radiated Emission Test View Above 1GHz
