2AXLK-IS4500RFID Module

RFID Ma RFID Manual_v1. 0 anual [IS-4500] ROKIT Healthcare Inc. Page. 1 / 9 RFID Manual_v1.0Rokit Healthcare, INC. Page. 2 / 9 Table of Contents 1. About This Manual 2. Copyright 3. Key Features 4. Safety Precautions 5. Product Components; Components / Tools / Name of Each Part 6. Installation 7. Maintenance 8. Product Specification 1. About This Manual This manual explains how to use IS-4500 and its key features. Be s ure to read carefully and thoroughly understand this manual before using the product. Be sure to keep this manual at hand for future reference. This manual can be used as a reference for customers who purchase products of Rokit healthcare or as training material for employees. The c ontent and the specification in this manual are subject to change without notice to improve performance of the product. Rokit healthcare is not responsible for any inaccuracies or typographical errors in this manual 2. Copyrights All programs, data files, and content of IS-4500 and this manual are protected by a non-disclosure agreement. Usage, copy, and distribution to third parties are strictly prohibited unless it is allowed explicitly by Rokit healthcare. Copyrights © 2020 All Rights Reserved by ROKIT Healthcare, INC. 3.Key Features IS-4500 is 13.56Mhz RFID Reader. 4.Safety Precautions Warning -Check the installation environment and performance of the product before using. To utilize the product effectively, read this manual first. Proceed to install and use accordingly. -Poor handling can damage the product. Handle with care when using or moving the product. This can result in electric shock, fire, failure, and injury. If the product gets damaged or needs repair, contact the customer service center. -Do not place under direct sunlight, near fire or in a place that generates heat. Heat may damage the product or cause it to catch on fire. RFID Manual_v1.0 ROKIT Healthcare, INC. Page. 3 / 9 -Do not use if the cable is damaged, and do not disconnect the power while using the product. -This can result in electric shock, fire, failure, and injury. -Be sure to keep conductive foreign substances, such as liquid, dust, or metal debris, away from the power supply or from collecting on the cable. Do not use excessive force or anything sharp on the power connector. The connection terminal may be corroded, or short-circuited temporarily and result in an explosion or fire. -Be sure to check the right battery type and replace a run-down battery with a new battery. Wrong handling may damage the product or cause explosion. Dispose of the wron-out battery properly in an appropriate way. -If there are any problems with the product, stop using immediately and contact the customer service center. Caution -Unauthorized installation, remodeling, repair, and disassembling are not recommended. This may result in damage to the product, and malfunctions due to unauthorized actions will void your warranty. -If installation assistance or repair are required, contact the customer service center. -Do not install or use the product in a dusty or dirty area. This may result in damage to the product or deteriorate performance. -Do not install or use the product in a place with magnetic strips or electromagnetic interference. This may result in damage to the product or deteriorate performance. -Check the wiring information and use appropriate cables. Do not attempt to connect a cable by force. This may result in damage to the product, cable, and the connector. -Do not install or use the product in a place with strong light exposure or direct sunlight. -The product’s quality might be reduced due to sunlight, halogen, or strong light exposure. -This product is not waterproof. Take precautions to avoid exposure to moisture. -Do not put things on top of the product or connect any unnecessary devices. Do not paint or place any stickers on this product. This may deteriorate performance or result in the product not functioning properly. -Do not scratch the surface, and keep it clean at all times. 5. Produ RFID b o Back RFID Manual_v1.0 uct Compon ody nents ROKIT Healthcare, INC .Page. 4 / 9 6. Instal Install th installati Interfac e Conne c J2 – TTL 1 2 3 4 5 J4 – US 1 2 3 4 RFID Manual_v1.0 llation he product ion and usag e cable shou ctor Pin L232 Port B to Serial P in a proper ge. uld less than Port r place whe 3m. re the cond GND GND TX RX 5V 5V D- D+ GND ROKIT Healthcare, INC. ditions and e D D D environment t are approp Page. 5 / 9 priate for Product - - PC B Use th e Tap the a 7. Maint To keep t the instru  RFID Manual_v1.0 t Componen PCB Top B Bottom e Product adequate card tenance the product in uctions below. It is recomm performance nts d to the produc n optimal cond mended that e. ct, the data of dition, regular you clean th the card will b maintenance he product re ROKIT Healthcare, INC. be transferred is recomme n egularly. If the to the host. nded. Manage e surface is d e your product dirty, it may a Page. 6 / 9 t following affect the RFID Manual_v1.0 ROKIT Healthcare, INC. Page. 7 / 9 8. Product Specification Please contact ROKIT Healthcare ([email protected]) for product details and inquires. ROKIT Healthcare Inc. 12F, 9, Digital-ro 10-gil, Geumcheon-gu (Highhill Bldg, Gasan- dong), Seoul, Republic of Korea, 08514 57.48dBuV/m FCC Warning statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer may void the user's authority to operate the equipment. IC Warning statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two condit…

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev: 0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ROKIT HEALTHCARE Inc. Address 12F, 9, Digital-ro 10-gil, Geumcheon-gu (Highhill Bldg, Gasan-dong), Seoul, Republic of Korea, 08514 Grantee Code 2AXLK FCC ID 2AXLK-IS4500 Authorized Contact Name Jungho Park Contact Email [email protected] Contact Phone +82 10 9399 2351 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has r ead, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:08-Oct-2020 Print Name: Jungho Park Title: Department Manager

Cover Letter-Modular Approval FCC ID: 2AXLK-IS4500 Date: Oct. 8, 2020 Gentlemen: There’s an IS-4500 that would like to have your authorization as a modular approval. The specific product as below, IS-4500 with its designed features and specified description, meets special requirements for Full modular approval on FCC KDB996369 by cross-reference list below. Company ROKIT HEALTFCARE Inc. Model Name IS-4500 Model Number IS-4500 FCC ID 2AXLK-IS4500 Requirement of FCC KDB996369 Comply（Y/N） 1. The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. Please see the Schematic Diagram. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the test report. 5. The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test board, Please see test report and setup photo 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2AXLK-IS4500” or “Contains FCC ID: 2AXLK-IS4500” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Thank you. Sincerely, By: __Jungho Park Title: Department Manager On behalf of: R OKIT HEALTHCARE Inc. Telephone: +82 10 9399 2351

Date: 08-Oct-2020 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: 2AXLK-IS4500 To whom it may concern: We, the undersigned, hereby authorize <<ILRS(International Licensing Research Solutions>> to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with <<ROKIT HEALTHCARE Inc.>>. This authorization is valid until further written notice from the applicant. Name (Printed):Jungho Park Title: Department Manager Signature: On behalf of Company: Telephone: +82 10 9399 2351

To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: ROKIT HEALTHCARE Inc. 12F, Gasan High-heel Bldg., 9, Digital-ro 10-gil, Geumcheon-gu, Seoul, Republic of Korea 08514 Regarding: Confidentiality Request regarding application for FCC ID 2AXLK-IS4500 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual Sincerely, Jungho Park Department Manager ROKIT HEALTHCARE Inc.

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

Internal photos of EUT Internal view of EUT Top view of Main PCB Bottom view of Main PCB View of Antenna Loop Coil Antenna

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001187 Page:2of29 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) Table of contents Page 1. General Information -----------------------------------------------------------------------------------3 2. Radiated Emissions -----------------------------------------------------------------------------------6 3. Frequency Stability ------------------------------------------------------------------------------------18 4. 20㏈Bandwidth & Occupied Bandwidth -------------------------------------------------------23 5. AC Power Line Conducted Emissions ------------------------------------------------------------25 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001187 Page:3of29 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible athttp://www.sgs.com/en/Terms-and-Conditions.aspx. Phone No.: +82 31 688 0901 Fax No.: +82 31 688 0921 1.2. Details of Applicant Applicant:ROKIT Healthcare Inc. Address:12F, 9, Digital-ro 10-gil, Geumchon-gu, Seoul, Republic of Korea, 08514 Contact Person:Park, Jung-ho Phone No.:+82 2 867 0182 1.3. Details of Manufacturer Applicant:Same as applicant Address:Same as applicant 1.4. Description of EUT Kind of Product RFID Module Model Name IS-4500 Serial Number RF100GA001 Power Supply DC 5 V Frequency Range 13.56㎒(NFC) Modulation Technique ASK Number of Channel 1 channel Antenna Type Loop coil Antenna H/W Version 1.0 S/W Version 1.0 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001187 Page:4of29 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.5. Test Equipment List EquipmentManufacturerModelS/NCal. Date Cal. Interval Cal. Due Signal GeneratorR&SSMBV100A259067Jun. 03, 2020AnnualJun. 03, 2021 Spectrum AnalyzerAgilentN9020AMY53421758Sep. 11, 2019AnnualSep. 11, 2020 Spectrum AnalyzerR&SFSV30103100Jun. 18, 2020AnnualJun. 18, 2021 DC Power SupplyAgilentU8002AMY53150029Jun. 04, 2020AnnualJun. 04, 2021 Temperature Chamber ESPEC CORP.PL-1J15000793Jun. 02, 2020AnnualJun. 02, 2021 Low Pass FilterMini-CircuitsNLP-1200+V9500401023-2Jun. 01, 2020AnnualJun. 01, 2021 PreamplifierH.P.8447F2944A03909Aug. 07, 2019AnnualAug. 07, 2020 Loop Antenna Schwarzbeck Mess-Elektronik FMZB 15191519-039 Aug. 22, 2019 Biennial Aug. 22, 2021 Bilog Antenna Schwarzbeck Mess-Elektronik VULB 9163396 Mar. 21, 2019 Biennial Mar. 21, 2021 Test ReceiverR&SESU26100109 Feb. 18, 2020 Annual Feb. 18, 2021 Antenna Mast Innco systems GmbH MM4640-XP-ET MA4640/536/ 38330516/L N.C.R.N/AN.C.R. Turn Table Innco systems GmbH DS 1200 SN/AN.C.R.N/AN.C.R. Controller Innco systems GmbH CONTROLLER CO3000-4P CO300/963/ 38330516/L N.C.R.N/AN.C.R. Anechoic ChamberSY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N/AN.C.R.N/AN.C.R. Coaxial CableRFONE PL520-NMNM-4M (4 m) 20200324001May 06, 2020 Semi- annual Nov. 06, 2020 Coaxial CableRFONE PL520-NMNM-10M (10 m) 20200324001May 06, 2020 Semi- annual Nov. 06, 2020 Coaxial CableRosenbergerLA1-C006-1500131014 10/20Feb. 23, 2020 Semi- annual Aug. 23, 2020 Test ReceiverR&SESCI 7100911Feb. 19, 2020AnnualFeb. 19, 2021 Two-Line V-NetworkR&SENV216100190May 08, 2020AnnualMay 08, 2021 Shield RoomSY Corporation L × W × H (6.5 m × 3.5 m × 3.5 m) N/AN.C.R.N/AN.C.R. 1.6. Information of Software for test - Using the software of ISReaderPro-Rokithealthcare (Version 1.6) to testing of EUT. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001187 Page:5of29 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 1.7. Summary of Test Results The EUT has been tested according to the following specifications: Applied standard : FCC Part15 subpart C and IC RSS-210 Issue 10, RSS-Gen Issue 5 Section in FCCSection in ICTest item(s)Result 15.225(a)(b)(c)(d) 15.209 RSS-210 Annex B Section B.6 RSS-Gen Section 8.9 Radiated Emission, Spurious Emission and Field Strength of Fundamental Complied 15.225(e) RSS-210 Annex B Section B.6 RSS-Gen Section 6.11 Frequency StabilityComplied 15.215(c) RSS-Gen Section 6.7 20㏈Bandwidth & Occupied Bandwidth Complied 15.207 RSS-Gen Section 8.8 AC Power Line Conducted EmissionsComplied 1.8.Sample Calculation Where relevant, the following sample calculation is provided: Field strength level (㏈㎶/m) = Measured level (㏈㎶) + Antenna factor (㏈) + Cable loss (㏈) - amplifier (㏈) 1.9. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the apparatus: ParameterUncertainty Occupied Bandwidth ±9.66㎑ AC Conducted Emission ± 0.76㏈ Radiated Disturbance, 9㎑to 30㎒ ±3.59㏈ Radiated Disturbance, below 1㎓ ±5.88㏈ Uncertainty figures are valid to a confidence level of 95 %. 1.10. Test Report Revision RevisionReport NumberDate of IssueDescription 0F690501-RF-RTL0011872020.09.22Initial SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number:F690501-RF-RTL001187 Page:6of29 RTT5041-19(2020.03.02)(2) A4(210 mmx297 mm) 2. Radiated Emissions 2.1. Test Setup The diagram below shows the test setup that is utilized to make the measurements for emission from 9㎑to 30㎒. The diagram below shows the test setup that is utilized to make the measurements for emission from 30㎒ to 1㎓. SGS …

Text truncated - open the document above for the full version.

Test setup photos of EUT 1. Orthogonal plane of EUT - The testing was set in the three orthogonal planes and measured for each position (X, Y, Z). X-axis Y-axis Z-axis 2. Photo of Radiated Spurious Emission Test (Below 1㎓) 3. Photos of AC Power line emission test 4. Photo of Conducted Test
