2AXNA-SPECTL4Digital Night Vision Scope

USER MANUAL SPECTRUM LRF 4K DIGITAL DAY & NIGHT VISION RIFLE SCOPE WITH LASER RANGEFINDER © 2024 AGM Global Vision, LLC. All rights reserved. This documentation is subject to change without notice. No parts of this manual, in whole or in part, may be copied, photocopied, translated, or transmitted by any electronic medium or in machine-readable form without the prior written permission of AGM Global Vision, LLC. If you have questions that are not covered in this manual, or need service, contact AGM Global Vision customer support for additional information prior to returning a product. AGM Global Vision, LLC 173 West Main Street PO Box 962 Springerville, AZ 85938 Tel. 928.333.4300 [email protected] www.agmglobalvision.com EXPORT INFORMATION Buyer acknowledges that all products supplied by AGM Global Vision, LLC are subject to U.S. export control laws, including, but not limited to, the Export Administration Regulations, the International Economic Emergency Powers Act, and various U.S. embargoes and sanctions. AGM Global Vision products may not be exported, re-exported, or transferred contrary to U.S. export control laws. In particular, AGM Global Vision products may not be exported, re-exported, or transferred to prohibited countries, individuals, organizations, or entities, including but not limited to those individuals and entities listed on the List of Specially Designated Nationals and Blocked Persons administered or maintained by the U.S. Office of Foreign Assets Control (“OFAC”), the various lists maintained by the Bureau of Industry and Security of the Department of Commerce, and the U.S. State Department and Buyer represents and warrants that neither Buyer nor any of its officers, directors, or employees are on such lists. Distribution or resale by Buyer to such countries, individuals, organizations, or entities is expressly prohibited. Buyer has and will maintain a positive process to ensure compliance with this Section. 2024.05.08 3 SPECTRUM LRF 4K USER MANUAL FCC INFORMATION Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment complies with FCC/IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. FCC compliance: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. 4 AGM Global Vision EU CONFORMITY STATEMENT This product and - if applicable - the supplied accessories too are marked with “CE” and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info INDUSTRY CANADA ICES-003 COMPLIANCE This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. 5 SPECTRUM LRF 4K USER MANUAL LIST OF CONTENTS TITLE PAGE Safety Summary 6 1. GENERAL INFORMATION 8 1.1 System Description 8 1.2 Standard Components 10 1.3 Optional Equipment 11 1.4 Key Features 12 2. OPERATING INSTRUCTIONS 13 2.1 Basic Operations 13 2.2 Main Function 23 2.3 Client Software Introduction 39 3. MAINTENANCE 40 3.1 Maintenance 40 3.2 Troubleshooting 41 4. WARRANTY INFORMATION 43 4.1 Warranty Information and Registration 43 5. SPECIFICATIONS 46 5.1 Specifications 46 5.2 Reticle Parameters 48 6 AGM Global Vision SAFETY SUMMARY • Read and follow all instructions • Read all warnings • Only use the attachments/accessories specified by the manufacturer • All service must be provided by the manufacturer WARNING: This product contains natural rubber latex, which may cause potentially fatal allergic reactions! If you are allergic to latex, it is important that you strictly avoid exposure to products that contain it. WARNINGS AND CAUTIONS: Transportation • Keep the device in original or similar packaging while transporting it. • Keep all wrappers after unpacking them for future use. In case of any failur…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 4 External Photos for KSCR2405000838AT Test Model No.: AGM SPECTRUM LRF 4K Compliance Certification Services (Kunshan) Inc. Page: 2 of 4 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 4 Compliance Certification Services (Kunshan) Inc. Page: 4 of 4

Compliance Certification Services (Kunshan) Inc. Page: 1 of 20 Internal Photos for KSCR2405000838AT Test Model No.: AGM SPECTRUM LRF 4K Compliance Certification Services (Kunshan) Inc. Page: 2 of 20 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 20 Compliance Certification Services (Kunshan) Inc. Page: 4 of 20 Compliance Certification Services (Kunshan) Inc. Page: 5 of 20 Compliance Certification Services (Kunshan) Inc. Page: 6 of 20 Compliance Certification Services (Kunshan) Inc. Page: 7 of 20 Compliance Certification Services (Kunshan) Inc. Page: 8 of 20 Compliance Certification Services (Kunshan) Inc. Page: 9 of 20 Compliance Certification Services (Kunshan) Inc. Page: 10 of 20 Compliance Certification Services (Kunshan) Inc. Page: 11 of 20 Compliance Certification Services (Kunshan) Inc. Page: 12 of 20 Compliance Certification Services (Kunshan) Inc. Page: 13 of 20 Compliance Certification Services (Kunshan) Inc. Page: 14 of 20 Compliance Certification Services (Kunshan) Inc. Page: 15 of 20 Compliance Certification Services (Kunshan) Inc. Page: 16 of 20 Compliance Certification Services (Kunshan) Inc. Page: 17 of 20 Compliance Certification Services (Kunshan) Inc. Page: 18 of 20 Compliance Certification Services (Kunshan) Inc. Page: 19 of 20 Compliance Certification Services (Kunshan) Inc. Page: 20 of 20

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083802 Page: 1 of 9 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2405000838AT FCC ID: 2AXNA-SPECTL4 Applicant: AGM Global Vision LLC Address of Applicant: 173 West Main Street, #962, Springerville, AZ 85938, USA Manufacturer: AGM Global Vision LLC Address of Manufacturer: 173 West Main Street, #962, Springerville, AZ 85938, USA Equipment Under Test (EUT): EUT Name: Digital Night Vision Scope Model No.: AGM Spectrum LRF 4K Standard(s) : FCC Rules 47 CFR §2.1093 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2024-05-13 Date of Test: 2024-05-23 to 2024-05-29 Date of Issue: 2024-06-05 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083802 Page: 2 of 9 Revision Record Version Description Date Remark 00 Original 2024-06-05 / Authorized for issue by: Tested By Eric_Liu/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083802 Page: 3 of 9 2 Contents Page 1 Cover Page .................................................................................................................................. 1 2 Contents ...................................................................................................................................... 3 3 General Information..................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................ 4 3.2 Details of E.U.T. .................................................................................................................... 4 3.3 Test Location ........................................................................................................................ 5 3.4 Test Facility ........................................................................................................................... 5 4 FCC Radiofrequency radiation exposure limits ......................................................................... 6 4.1 Blanket 1 mW Blanket Exemption .......................................................................................... 6 4.2 MPE-based Exemption .......................................................................................................... 6 4.3 SAR-based Exemption .......................................................................................................... 7 5 Measurement and Calculation .................................................................................................... 9 5.1 Maximum transmit power ...................................................................................................... 9 5.2 RF Exposure Calculation ....................................................................................................... 9 Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083802 Page: 4 of 9 3 General Information 3.1 General Description of E.U.T. Power supply: DC 5V by adapter Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 Channel Spacing: 5MHz Antenna Type: PCB SMT Antenna Antenna Gain: -2.87dBi (Provided by the manufacturer) Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083802 Page: 5 of 9 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g., max. internal working frequency, antenna gain, cable loss, etc) is provided by the applicant. (If applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (If applicable). 3. Sample source: sent by customer. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA Compliance…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083801 Page: 1 of 87 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: KSCR2405000838AT FCC ID: 2AXNA-SPECTL4 Applicant: AGM Global Vision LLC Address of Applicant: 173 West Main Street, #962, Springerville, AZ 85938, USA Manufacturer: AGM Global Vision, LLC Address of Manufacturer: 173 West Main Street, #962, Springerville, AZ 85938, USA Equipment Under Test (EUT): EUT Name: Digital Night Vision Scope Model No.: AGM Spectrum LRF 4K Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-05-13 Date of Test: 2024-05-23 to 2024-05-29 Date of Issue: 2024-06-05 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083801 Page: 2 of 87 Revision Record Version Description Date Remark 00 Original 2024-06-05 / Authorized for issue by: Tested By Eric_Liu/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083801 Page: 3 of 87 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Average Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240500083801 Page: 4 of 87 3 Contents Page 1 COVER PAGE ...................................................................................................................................... 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 5 4.1 Details of E.U.T. ................................................................................................................................. 5 4.2 Description of Support Units ............................................................................................................... 5 4.3 Measurement Uncertainty ................................................................................................................... 5 4.4 Test Location ...................................................................................................................................... 6 4.5 Test Facility ........................................................................................................................................ 6 4.6 Deviation from Standards ................................................................................................................... 6 4.7 Abnormalities from Standard Conditions ............................................................................................. 6 5 Equipment List .......................................................................................................................................... 7 6 Radio Spectrum Technical Requirement ................................................................................................. 8 6.1 Antenna Requirement .........................................................…

Text truncated - open the document above for the full version.

保密信息，未经授权禁止扩散 Jiangmen Chongda Circuit Technology Co., Ltd. HM-63105 REV1.0 Antenna Specification V1.0 Address: No. 363, Lianhai Road, Jianghai District, Jiangmen City, Guangdong Province, China Author Reviewer Approver 密级级别： 内部公开 保密信息，未经授权禁止扩散 第 1 页 Table of Content 1. Antenna Characteristic Specification ........................................................................................................ 2 1.1 Antenna Structure .............................................................................................................................. 2 1.2 Antenna Technical Parameters and Interface ..................................................................................... 2 2. Antenna Test Conditions .......................................................................................................................... 2 2.1 Test Equipment .................................................................................................................................. 2 2.2 Test Result ......................................................................................................................................... 3 Return Loss (S11) ................................................................................................................................................. 3 Antenna Efficiency ............................................................................................................................................... 4 Antenna 2D Radiation Pattern ............................................................................................................................. 4 Revision History ........................................................................................................................................... 5 密级级别： 内部公开 保密信息，未经授权禁止扩散 第 2 页 1. Antenna Characteristic Specification This specification describes the physical characteristics and electrical performance of the following 2.4 GHz Wi-Fi antennas. Figure 1.Antenna Actual Effect Picture 1.1 Antenna Structure The antenna is mainly composed of SMT on the PCB. 1.2 Antenna Technical Parameters and Interface Design Specifications Typical Units Form PCB SMT(ANT PCB03) \ Frequency 2400-2500 MHz Gain High channel：-3.30 dBi Medium channel：-2.87 dBi Low channel：-4.18 dBi Antenna Efficiency 16 % VSWR < 2 \ Polarization Linear Polarization \ Axial Ratio \ \ Radiation pattern Omnibearing \ impedance 50 ohm Power handling 33 dBm Interface \ \ Overall dimensions 18.1mm*4.4mm*3.6mm \ Weight \ \ Operation Temp. -30-70 °C Storing Temp. -30-70 °C 2. Antenna Test Conditions 2.1 Test Equipment Antenna Vector Network Analyzer ROHDE&SCHWARZ ZNB 20 密级级别： 内部公开 保密信息，未经授权禁止扩散 第 3 页 Figure 2.Vector Network Analyzer 2.2 Test Result Return Loss (S11) Figure 4.Return Loss The yellow curve in the figure above shows that the antenna syntony is realized well, and the resistance condition matches well. 密级级别： 内部公开 保密信息，未经授权禁止扩散 第 4 页 Antenna Efficiency Antenna 2D Radiation Pattern 2400MHz-2450MHz-2500MHz Phi=0 deg Phi=90 deg Frequency(MHz)efficiency(%) 240014.6 241017.32 242016.62 243018.53 244019.87 245020.07 246018.86 247016.8 248014.66 249012.36 250010.34 密级级别： 内部公开 保密信息，未经授权禁止扩散 第 5 页 Theta=90 deg Revision History Revision Content Date Author V1.0 First Edition Apr. 24, 2024 Zhu Wentao

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Appendix Photographs of Test Setup for KSCR2405000838AT Test Model No.: AGM SPECTRUM LRF 4K Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Spurious Emissions Below 1GHz Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 Radiated Spurious Emissions Above 1GHz Conducted Peak Output Power
