Ferri USER MANUAL English • Removable Magnetic Cap • Charging Port • Indicator Light • Button: On/Off (hold for 3 seconds) & Cycle Through Vibrations (one tap) Materials Weight Battery Charging Use Time Standby Waterproof ABS Plastic/Body-Safe Silicone 35g Li-Ion Rechargeable 60 Minutes up to 195 Minutes up to 100 Hours IPX7 Waterproof What's Included • (1) Bluetooth® Remote-Controlled Panty Vibrator • (1) USB Charging Cable • (1) User Manual • (1) Quick Setup Guide • (1) Storage Bag • (1) Extra Magnetic Cap Specifications Charging Turn off Ferri. The cable can be plugged into any USB port or USB/AC power adapter. It will take approximately 60 minutes to fully charge. Once it is fully charged, the solid red light will turn off. Note: The magnetic charger will only work if positioned correctly. If a solid red light doesn’t turn on, rotate the cable 180 degrees. Cleaning & Care • Clean Ferri before and after each use. • Clean with warm water and a mild soap (or sex toy cleaner). • Dry thoroughly before storing. Materials Weight Battery Charging Use Time Standby Waterproof ABS Plastic/Body-Safe Silicone 35g Li-Ion Rechargeable 60 Minutes up to 195 Minutes up to 100 Hours IPX7 Waterproof Usage Tips • Place Ferri inside your underwear and attach the magnetic cap on the outside. • To reduce the toy’s sound in quiet areas, change your toy’s maximum vibration in the app. • Use lube at your own discretion. Only use water-based lube, as silicone or oil-based lube may affect the silicone casing. • You can adjust the low, medium, and high levels to suit your needs. • Once in the programming mode in our app, you can store up to 10 patterns (that you create) in Ferri. Warning • DO NOT boil in water (the battery may explode or water could leak into the toy). • Keep away from extreme heat or cold. • Make sure your toy is recharged at least once every six months. • DO NOT use the toy while charging. • Please make sure you don’t attach the charging cable to any metal or stainless steel materials. Links Check out the newest guide/download links here. Our software is constantly updated. Online guide: www.lovense.com/guide App download: www.lovense.com/download If you have any feedback or need any additional assistance, use the contact form at www.lovense.com/contact. Someone from the Lovense team will normally reply within 12-24 hours. Usage Tips • Place Ferri inside your underwear and attach the magnetic cap on the outside. • To reduce the toy’s sound in quiet areas, change your toy’s maximum vibration in the app. • Use lube at your own discretion. Only use water-based lube, as silicone or oil-based lube may affect the silicone casing. • You can adjust the low, medium, and high levels to suit your needs. • Once in the programming mode in our app, you can store up to 10 patterns (that you create) in Ferri. Warning • DO NOT boil in water (the battery may explode or water could leak into the toy). • Keep away from extreme heat or cold. • Make sure your toy is recharged at least once every six months. • DO NOT use the toy while charging. • Please make sure you don’t attach the charging cable to any metal or stainless steel materials. Warranty Terms & Conditions LOVENSE warrants this product for a period of ONE (1) YEAR, after the date of original purchase, against defects due to faulty workmanship or materials. If you discover a defect and notify LOVENSE during the warranty period, LOVENSE will, at its discretion, replace the product free of charge. Visit www.lovense.com/warranty for detailed warranty and product return information. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver . -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction FCC ID: 2AXNT-FERRI

C5266091_X8_Ed.1 1/1 LetterofAuthorization HYTTOPTE.LTD. Company:HYTTOPTE.LTD. Address:160ROBINSONROAD#17-08,Singapore,Singapore068914 ProductName:LOVENSEFerri ModelNumber:Ferri FCCIdentifier:2AXNT-FERRI WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:XiaoxiaLiangDate:11/30/2020 Title:BEG Signatureofapplicant:

C5266091_X10_Ed.1 1/1 HYTTOPTE.LTD. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:11/30/2020 Subject:RequestforConfidentiality FCCID:2AXNT-FERRI ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo BlockDiagram Schematics TestReportNoNo TestSetupPhotosNo User’sManual InternalPhotos PartsList/TuneUp RFExposureInfo OperationalDescription CoverLetter(s)NoNo SDRSoftware/SecurityInfoNo Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, Signature: Name: XiaoxiaLiang11/30/2020 Title: BEG

1 - Page 1 of 4 - Report No.: MTi20102205-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. APPENDIX 1: EUT PHOTO Photo 1 (For model Ferri) Photo 2 1 - Page 2 of 4 - Report No.: MTi20102205-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 1 - Page 3 of 4 - Report No.: MTi20102205-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 1 - Page 4 of 4 - Report No.: MTi20102205-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Photo 7 ----END OF REPORT----

1cm 2cm LOVENSE Ferri Model: Ferri FCC ID: 2AXNT-FERRI

1 - Page 1 of 2 - Report No.: MTi20102205-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. APPENDIX 1: EUT PHOTO Photo 1 (For model Ferri) Photo 2 1 - Page 2 of 2 - Report No.: MTi20102205-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 ----END OF REPORT---- PCB antenna

This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen Microtest Co., Ltd. Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. RF EXPOSURE REPORT FCC ID: 2AXNT-FERRI Date of issue: Nov. 24, 2020 Report Number: MTi20102205-1E2 Sample Description: LOVENSE Ferri Model(s): Ferri Applicant: HYTTO PTE. LTD. Address: 160 ROBINSON ROAD #17-08 Singapore 068914 Date of Test: Nov. 04, 2020 to Nov. 24, 2020 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 4- Report No.: MTi20102205-1E2 TEST RESULT CERTIFICATION Applicant’s name: HYTTO PTE. LTD. Address: 160 ROBINSON ROAD #17-08 Singapore 068914 Manufacture's name: Shenzhen Love Sense Technology Co., Ltd Address: Room 13, 2nd floor Pingshan Industrial Zone, Pingshan 1st Rd, Taoyuan St, Nanshan, Shenzhen, Guangdong, China, 518055 Product name: LOVENSE Ferri Model and/or type reference: Ferri Serial Model: N/A RF Exposure Procedures: KDB 447498 D01 v06 This device described above has been tested by Shenzhen Microtest Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Tested by: Danny Xu Nov. 24, 2020 Reviewed by: Leo Su Nov. 24, 2020 Approved by: Tom Xue Nov. 24, 2020 - Page 3 of 4- Report No.: MTi20102205-1E2 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following (also illustrated in Appendix B): 1) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·(f(MHz)/150)]} mW, for 100 MHz to 1500 MHz 2) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz c) For frequencies below 100 MHz, the following may be considered for SAR test exclusion (also illustrated in Appendix C): 1) For test separation distances > 50 mm and < 200 mm, the power threshold at the corresponding test separation distance at 100 MHz in step b) is multiplied by [1 + log(100/f(MHz))] 2) For test separation distances ≤ 50 mm, the power threshold determined by the equation in c) 1) for 50 mm and 100 MHz is multiplied by ½ 3) SAR measurement procedures are not established below 100 MHz. - Page 4 of 4- Report No.: MTi20102205-1E2 When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any SAR test results below 100 MHz to be acceptable. 2. SAR Test Exclucsion Thresholds We use 5mm as separation distance to calculated. Bluetooth DTS: Transmit Frequenc y (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Max tune- up Result 1g SAR power(dBm) calculation 2.402 GFSK -1.769 -1±1 0 0.3100 3 2.440 -1.111 -1±1 0 0.3124 3 2.480 -1.196 -1±1 0 0.3150 3 Conclusion: For the max result: 0.3150≤ 3.0 for 1g SAR, No SAR is required. ----END OF REPORT----

This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen Microtest Co., Ltd. Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Test Report FCC ID: 2AXNT-FERRI Date of issue: Nov. 24, 2020 Report number: MTi20102205-1E1 Sample description: LOVENSE Ferri Model(s): Ferri Applicant: HYTTO PTE. LTD. Address: 160 ROBINSON ROAD #17-08 Singapore 068914 Date of test: Nov. 04, 2020 to Nov. 24, 2020 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 45 - Report No.: MTi20102205-1E1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Table of Contents 1. GENERAL INFORMATION ................................................................................................................................... 5 1.1. DESCRIPTION OF EUT ................................................................................................................................................... 5 1.2. OPERATION CHANNEL LIST .............................................................................................................................................. 5 1.3. TEST CHANNEL LIST ....................................................................................................................................................... 6 1.4. ANCILLARY EQUIPMENT LIST ........................................................................................................................................... 6 1.5. DESCRIPTION OF SUPPORT UNITS .................................................................................................................................... 6 2. SUMMARY OF TEST RESULT S .......................................................................................................................... 7 3. TEST FACILITIES AND ACCREDITATIONS ...................................................................................................... 8 3.1. TEST LABORATORY ........................................................................................................................................................ 8 3.2. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 3.3. MEASUREMENT UNCERTAINTY ........................................................................................................................................ 8 3.4. TEST SOFTWARE ........................................................................................................................................................... 8 4. EQUIPMENT LIST ................................................................................................................................................. 9 5. TEST RESULT ....................................................................................................................................................... 9 5.1. ANTENNA REQUIREMENT ............................................................................................................................................. 10 5.1.1 Standard Requirement ...................................................................................................................................... 10 5.1.2 EUT Antenna ..................................................................................................................................................... 10 5.2. PEAK OUTPUT POWER TEST ......................................................................................................................................... 11 5.2.1 Limit .................................................................................................................................................................. 11 5.2.2 Test setup .......................................................................................................................................................... 11 5.2.3 Test Procedure ................................................................................................................................................... 11 5.2.4 Te s t Results ........................................................................................................................................................ 11 5.3. CONDUCTED EMISSION ................................................................................................................................................ 14 5.3.1 Limits ................................................................................................................................................................. 14 5.3.2 Te s t Setup .......................................................................................................................................................... 14 5.3.3 Te s t Procedure ................................................................................................................................................... 15 5.3.4 Te s t Results ........................................................................................................................................................ 15 5.4. RADIATED SPURIOUS EMISSION ...................................................................................................................................... 20 5.4.1 Limits ................................................................................................................................................................. 20 5.4.2 Te s t Setup .....................…
