2AXO6-F5B10F5 Bowling

F5Sports,Inc.·Page 1 of 2 F5BowlingSensor InstallationandSetupGuide F5Sports,Inc. TheF5sensorinstallsintothemiddlefingerholeofthebowlingball,regardlessofwhetherthebowlerisright-orleft-handed. Installationshouldbeperformedbyaqualifiedproshopoperatorusingadrillpress. WHATYOUWILLNEED F5sensor·innerreceivingsleeve·softouterreceivingsleeve(sizedtothegrip)·sleeveinstallationtool·sensorinsert/extraction tool·drillpressandbits·pitchgauges·vacuum·gripglue 1.PREPARETHEFINGERHOLE Iftheballisalreadydrilled 1.Removethemiddlefingergrip. 2.Checktheexistingpitcheswiththeappropriatepitchgauges,thensetthedrillpresstomatch. 3.Notetheoutsidediameterofthegripbeingusedandselectthematchingbitfromthetablebelow. 4.Centerthebitintheexistinghole. Iftheballisundrilled 1.Setthedrillpresstotheappropriatepitchesforthebowler. 2.Selectthebitthatmatchesthegripoutsidediameter. Then,inbothcases 1.Drillthefingerholetoadepthof25/8inches. 2.Removethebitandvacuumalldustfromthehole. GripoutsidediameterDrillbit Small7/8in. Standard31/32in. Large11/32in. 2.INSTALLTHESLEEVES 1.Selectthesoftouterreceivingsleevethatmatchesthegripoutsidediameter. 2.Presstheinnerreceivingsleeveintothesoftoutersleeve,aligningtheinnersleevetabswiththeslotsintheoutersleeve. 3.Fitthecombinedsleevesontotheinstallationtool—thetoolhasalignmentslotsthatmatewiththereceivingsleeve. 4.Pressthesleevesallthewaytothebottomofthehole. 3.INSTALLTHESENSOR 1.Inserttheinsert/extractiontoolintotheslotatthetopofthesensor. 2.Aligntheslotsinthesensortothetabdirectionspecifiedintheinstructionssuppliedwiththeinstallationtool. 3.Pressthesensorintothesleevesatthebottomofthehole. 4.Pressdownandrotatethetoolclockwiseuntilthetoolandtheslotarealigned,thenwithdrawthetool. 4.REINSTALLTHEGRIP 1.Placethefingergripbackintotheholeabovethesensorandsleeve.Trimthegripifneededsoitsitsflushwiththesurfaceof theball. F5Sports,Inc.·Page 2 of 2 2.Securethegripwithasmallamountofglue. WARNINGUseonlyasmallamountofglue—justenoughtoholdthegripinplace.Excessgluecanrundownpast thegripandlockthesensorintothehole. 5.PAIRTHESENSORWITHTHEAPP 1.OpentheF5Bowlingapponyoursmartphone. 2.Selectthe“Bowl”tab. 3.Holdthephonenearthebowlingball,closetothefingerholecontainingthesensor. 4.Waitfortheconnectionbuttontoshow“Taptoconnect.” 5.Taptheconnectionbutton. Thesensorisnowpairedandreadytouse. FCCCOMPLIANCESTATEMENT Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions: (1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,includinginterference thatmaycauseundesiredoperation. CAUTION:Thegranteeisnotresponsibleforanychangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor compliance.Suchmodificationscouldvoidtheuser’sauthoritytooperatetheequipment. NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15ofthe FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.This equipmentgenerates,uses,andcanradiateradiofrequencyenergy,andifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurina particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedetermined byturningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing measures: –Reorientorrelocatethereceivingantenna. –Increasetheseparationbetweentheequipmentandreceiver. –Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected. –Consultthedealeroranexperiencedradio/TVtechnicianforhelp. Thisequipmenthasbeentestedandmeetsapplicablelimitsforradiofrequency(RF)exposure. Productlabel

F5 Sports, Inc. 4410 Providence Lane, STE C Winston Salem, NC 27106 Date: 08/24/26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXO6-F5B10 Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Part 2.911(d)(5)(i) F5 Sports, Inc. certifies that the equipment for which authorization is sought is not “covered” equipment and does not contain anti-virus software or cybersecurity software prohibited from receiving an equipment authorization pursuant to 47 CFR 2.903, KDB 986446 D01 Covered Equipment Guidance, and FCC Covered List (www.fcc.gov/supplychain/coveredlist). Part 2.911(d)(5)(ii) F5 Sports, Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signature: Steven Cukiernik Chief Technology Officer

F5 Sports, Inc. 4410 Providence Lane, STE C Winston Salem, NC 27106 Date: 08/24/26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXO6-F5B10 FRN: 0030033294 US Agent – Attestation Statement / Part 2.911(d)(7) To whom it may concern, F5 Sports, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, F5 Sports, Inc.is our designated U.S. agent for service of process for the above referenced FCC ID. F5 Sports, Inc. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. F5 Sports, Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: F5 Sports, Inc. FRN: 0030033294 Address: 4410 Providence Lane, STE C, Winston Salem, NC 27106 Contact Person: Steven Cukiernik Tel.: (336) 499-7390 Email: [email protected] Sincerely, Company: F5 Sports, Inc. Designated Agent: F5 Sports, Inc. Company Representative: Steven Cukiernik Designated Agent Representative: Steven Cukiernik Signature: Signature:

F5 Sports, Inc. 4410 Providence Lane, STE C Winston Salem, NC 27106 Date: 08/24/26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXO6-F5B10 Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: ☒Block Diagram ☐Tune-Up Information ☒Operational Description ☐Security Information ☒Schematics ☐Software Defined Radio (SDR) Information ☒Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: Steven Cukiernik Chief Technology Officer

F5 Sports, Inc. 4410 Providence Lane, STE C Winston Salem, NC 27106 Date: 08/24/26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AXO6-F5B10 Declaration of Authorization To whom it may concern, I, the undersigned, hereby authorize, Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) on our behalf shall have the same effects as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Signature: Steven Cukiernik Chief Technology Officer

ReferenceNo.:WTX26X08228032WPage2of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EXHIBIT2-EUTEXTERNALPHOTOGRAPHS EUTView1 EUTView2 ReferenceNo.:WTX26X08228032WPage3of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EUTView3 EUTView4 ReferenceNo.:WTX26X08228032WPage4of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EUTView5 EUTView6

ReferenceNo.:WTX26X08228032WPage1of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT1-PRODUCTLABELING ProposedFCCIDLabelFormat Specifications:Duetotheproduct'ssizing,thelabelisintheproductmanualandontheexteriorofthe packaging. ProposedLabelLocationonEUT FCCIDLabel Location

Reference No.: WTX26X08228032WPage 5 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTX26X08228032WPage 6 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Solder Board-Component View 3 Reference No.: WTX26X08228032WPage 7 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View Antenna

WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn RFEXPOSUREREPORT ReferenceNo.......................:WTX26X08228032W002 FCCID....................................:2AXO6-F5B10 Applicant...............................:F5Sports,Inc. Address.................................:4410ProvidenceLane,STEC,WinstonSalem,NC27106 Manufacturer........................:ThesameasApplicant Address ................................. :ThesameasApplicant ProductName......................:F5Bowling ModelNo... ............................ :TWB-100 Standards..............................: FCCRulePart1.1307 KDB447498D04 DateofReceiptsample ..... :2026-08-03 DateofTest...........................:2026-08-04to2026-08-11 DateofIssue ........................ :2026-08-18 ReportFormNo................... : WTX_Part1_1307W Result.....................................:Pass Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbe reproduced,exceptinfull,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithout specificstampoftestinstituteandthesignaturesofapprover. PreparedBy: WaltekTestingGroup(Shenzhen)Co.,Ltd. Address:1/F.,Room101,Building1,HongweiIndustrialPark,Liuxian2ndRoad, Block70Bao'anDistrict,Shenzhen,Guangdong,China Tel.:+86-755-33663308Fax.:+86-755-33663309Email:[email protected] Testedby:Approvedby: MikeShi/ProjectEngineerJasonSu/Manager WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn 1GeneralInformation GeneralDescriptionofEUT ProductName:F5Bowling TradeName/ ModelNo.:TWB-100 AddingModel(s):/ RatedVoltage: Chargingport:DC5V Battery:DC3.7V BatteryCapacity:50mAh PowerAdapter:/ EquipmentType:Portabledevice TechnicalCharacteristicsofEUT BluetoothVersion:V5.0(LEmode) FrequencyRange:2402-2480MHz RFOutputPower:3.31dBm(Conducted) DataRate:1Mbps Modulation:GFSK QuantityofChannels:40 ChannelSeparation:2MHz TypeofAntenna:CeramicAntenna AntennaGain:-2dBi 2TestFacility Addressofthetestlaboratory Laboratory:WaltekTestingGroup(Shenzhen)Co.,Ltd. Address:1/F.,Room101,Building1,HongweiIndustrialPark,Liuxian2ndRoad,Block70Bao'anDistrict, Shenzhen,Guangdong,China FCC–RegistrationNo.:125990 WaltekTestingGroup(Shenzhen)Co.,Ltd.EMCLaboratoryhasbeenregisteredandfullydescribedina reportfiledwiththeFCC(FederalCommunicationsCommission).TheacceptanceletterfromtheFCCismain tainedinourfiles.TheDesignationNumberisCN5010,andTestFirmRegistrationNumberis125990. IndustryCanada(IC)RegistrationNo.:11464A The3mSemi-anechoicchamberofWaltekTestingGroup(Shenzhen)Co.,Ltd.hasbeenregisteredby CertificationandEngineeringBureauofIndustryCanadaforradioequipmenttestingwithRegistrationNo.: 11464AandtheCABidentifierisCN0057. WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn 3RFExposureExemption Accordingto§1.1307(b)(3)andKDB447498D04InterimGeneralRFExposureGuidancev01,system operatingundertheprovisionsofthissectionshallbeoperatinginamannerthatthepublicisnotexposedto radiofrequencyenergylevelinexcesslimitformaximumpermissibleexposure. OptionA:FCCRulePart1.1307(b)(3)(i)(A):Theavailablemaximumtime-averagedpowerisnomorethan 1mW,regardlessofseparationdistance. OptionB:FCCRulePart1.1307(b)(3)(i)(B):Theavailablemaximumtime-averagedpoweroreffective radiatedpower(ERP),whicheverisgreater,islessthanorequaltothethresholdP th (mW)describedinthe followingformula.P th isgivenby: OptionC:FCCRulePart1.1307(b)(3)(i)(C):Theminimumseparationdistance(Rinmeters)fromthebodyof anearbypersonforthefrequency(finMHz)atwhichthesourceoperates,theERP(watts)isnomorethanthe calculatedvalueprescribedforthatfrequency.Rmustbeatleastλ/2π,whereλisthefree-spaceoperating wavelengthinmeters. SingleRFSourcesSubjecttoRoutineEnvironmentalEvaluation RFSourcefrequency(MHz)ThresholdERP(watts) 0.3-1.341,920R 2 1.34-303,450R 2 /f 2 30-3003.83R 2 300-1,5000.0128R 2 f 1,500-100,00019.2R 2 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn ForMultipleRFsources:FCCRulePart1.1307(b)(3)(ii): (A)Theavailablemaximumtime-averagedpowerofeachsourceisnomorethan1mWandthereisa separationdistanceoftwocentimetersbetweenanyportionofaradiatingstructureoperatingandthe nearestportionofanyotherradiatingstructureinthesamedevice,exceptifthesumofmultiplesourcesis lessthan1mWduringthetime-averagingperiod,inwhichcasetheymaybetreatedasasinglesource (separationisnotrequired). (B)InthecaseoffixedRFsourcesoperatinginthesametime-averagingperiod,orofmultiplemobileor portableRFsourceswithinadeviceoperatinginthesametimeaveragingperiod,ifthesumofthe fractionalcontributionstotheapplicablethresholdsislessthanorequalto1asindicatedinthefollowing equation. 4CalculatedResult RadioAccess Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-AveragedPower ERP (MHz)(dBm)(dBi)(%)(dBm)(dBm) BluetoothLE24023.31-21004.00-0.15 Frequency Option Min.DistanceMax.PowerExposureLimit Ratio Result (MHz)(cm)(dBm)(mW)(mW)Pass/Fail 2402B0.54.002.512.7880.90Pass Note:1.Time-AveragedPower=OutputPower*DutyCycle;ERP=Time-AveragedPower+Antenna gain-2.15dB 2.OptionA,BandCrefersasclause1.2. 3.ForoptionB,Max(time-averagedpower,effectiveradiatedpower(ERP))convertstoMax.Power.For optionC,ERPconvertstoMax.Power; 4.ForoptionB,P th (mW)convertstoExposureLimit(mW);ForoptionC,ERP(W)convertstoExposure Limit(mW). 5.Ratio=Tune-UpERP(mW)/ExposureLimit(mW) ModeforSimultaneousMulti-bandTransmission: RadioAccess Technology Ratio1Ratio2 Simultaneous Ratio Limit Result Pass/Fail ------------ Result:Pass

WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 1 of 48 TESTREPORT ReferenceNo.......................:WTX26X08228032W001 FCCID....................................:2AXO6-F5B10 Applicant...............................:F5Sports,Inc. Address.................................:4410ProvidenceLane,STEC,WinstonSalem,NC27106 Manufacturer........................:ThesameasApplicant Address.................................:ThesameasApplicant ProductName......................:F5Bowling ModelNo...............................:TWB-100 Standards..............................:FCCPart15.247 DateofReceiptsample .....: 2026-08-03 DateofTest...........................:2026-08-04to2026-08-11 DateofIssue ........................: 2026-08-18 TestReportFormNo.......... : WTX_Part15_247W TestResult............................:Pass Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbe reproduced,exceptinfull,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithout specificstampoftestinstituteandthesignaturesofapprover. PreparedBy: WaltekTestingGroup(Shenzhen)Co.,Ltd. Address:1/F.,Room101,Building1,HongweiIndustrialPark,Liuxian2ndRoad, Block70Bao'anDistrict,Shenzhen,Guangdong,China Tel.:+86-755-33663308Fax.:+86-755-33663309Email:[email protected] Testedby:Approvedby: MikeShi/ProjectEngineerJasonSu/Manager ReferenceNo.:WTX26X08228032W001 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 2 of 48 TABLEOFCONTENTS 1.GENERALINFORMATION........................................................................................................................................4 1.1PRODUCTDESCRIPTIONFOREQUIPMENTUNDERTEST(EUT)............................................................................4 1.2TESTSTANDARDS.....................................................................................................................................................5 1.3TESTMETHODOLOGY...............................................................................................................................................5 1.4TESTFACILITY..........................................................................................................................................................5 1.5EUTSETUPANDTESTMODE.................................................................................................................................6 1.6MEASUREMENTUNCERTAINTY.................................................................................................................................7 1.7TESTEQUIPMENTLISTANDDETAILS......................................................................................................................8 2.SUMMARYOFTESTRESULTS.............................................................................................................................12 3.ANTENNAREQUIREMENT.....................................................................................................................................13 3.1STANDARDAPPLICABLE.........................................................................................................................................13 3.2EVALUATIONINFORMATION....................................................................................................................................13 4.POWERSPECTRALDENSITY...............................................................................................................................14 4.1STANDARDAPPLICABLE.........................................................................................................................................14 4.2TESTSETUPBLOCKDIAGRAM...............................................................................................................................14 4.3TESTPROCEDURE..................................................................................................................................................14 4.4SUMMARYOFTESTRESULTS/PLOTS....................................................................................................................14 5.DTSBANDWIDTH......................................................................................................................................................15 5.1STANDARDAPPLICABLE.........................................................................................................................................15 5.2TESTSETUPBLOCKDIAGRAM...............................................................................................................................15 5.3TESTPROCEDURE..................................................................................................................................................15 5.4SUMMARYOFTESTRESULTS/PLOTS....................................................................................................................15 6.RFOUTPUTPOWER................................................................................................................................................17 6.1STANDARDAPPLICABLE.........................................................................................................................................17 6.2TESTSETUPBLOCKDIAGRAM...............................................................................................................................17 6.3TESTPROCEDURE..................................................................................................................................................17 6.4SUMMARYOFTESTRESULTS/PLOTS....................................................................................................................17 7.FIELDSTRENGTHOFSPURIOUSEMISSIONS.................................................................................................18 7.1STANDARDAPPLICABLE........................................................................................................................…

Text truncated - open the document above for the full version.

2.4 GHz SMD, Above Metal, Low Profile Mini Chip Antenna P/N 2450AT42E0100 This antenna will generally have a metal layer directly underneath for proper operation, exceptions may apply. Detail Specification: Page 1 of 8 1 L ±± 2 W ±± 3 T ±± 4 a ±± b ±± C https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2021 Johanson Technology, Inc. All Rights Reserved Average Gain (dBi typ.)-5.0 (YZ-V) High Frequency Ceramic Solutions -2.0 (YZ-V) Feeding Point 5.6 typ. (4.5 min.) 10/28/2021 2450AT42E0100 2400 - 2480 +5°C to +35°C Total average radiated efficiency on PCB feature on "Mounting Considerations 1" ( orderable EVB p/n: 2450AT42E0100-EB1SMA) is ~30% In 50 2,000 -40 to +85°C 2 max. (CW) mm 5.00 NC 1 0.197 0.0790.008 Terminal Configuration Part Number Explanation Suffix = S Suffix = E Mechanical Specifications Evaluation Board Packing Style Johanson Technology, Inc. reserves the right to make design changes without notice. GND Ver. 4.0 1.500.0590.200.008 0.0120.30 maxmax All sales are subject to Johanson Technology, Inc. terms and conditions. 0.200.020 1 Make sure to have Pin 2 soldered to its PCB land pad but not connected to GND or input, it must be NC (or floating). Recommended Storage Conditions and Period for unused Product on T&R Humidity 45 - 75% RH 18 months max. 0.20 0.20 This antenna was designed in mind for small coin cell, wearable, IoT, 2.4 BLE, 802.11, ISM, Zigbee, etc. applications in close-range networks where metal or a battery/display covers the entire length or side of the PCB or encasement must be present directly under the antenna and there's no room for usual/typical antenna metal clearance. 0.500.008 1.500.200.0590.008 0.008 2.00 GND E.g. 2450AT42E0100S E.g. 2450AT42E0100E General Specifications P/N Suffix 2450AT42E0100-EB1SMA (comes with 1 female SMA connector) Bulk (loose pcs.) T & R Part Number Frequency (MHz) Peak Gain (dBi typ.) Return Loss (dB) Impedance (Ω) This antenna is specifically designed for PCBs that have 0.5-1mm of total thickness Operating Temp Power Capacity (W) Reel Quantity (pcs./reel) Antenna mounts directly above or below the metal layer of PCB. No antenna clearance required ever again! b T a b    L W c Top View Bottom View Side View 2.4 GHz SMD, Above Metal, Low Profile Mini Chip Antenna P/N 2450AT42E0100 This antenna will generally have a metal layer directly underneath for proper operation, exceptions may apply. Detail Specification: Page 2 of 8 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2021 Johanson Technology, Inc. All Rights Reserved Ver. 4.0 High Frequency Ceramic Solutions Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. 10/28/2021 Mounting Considerations 1 *Line width should be designed to match 50ohm characteristic impedance, depending on PCB material and thickness. A coplanar waveguide trace is recommended for best results. For this particular antenna It is recommended that the designer leave available slots for the matching network, even if all slots won't be used, this will prepare the PCB for the unpredictable final mass production version of the matching circuit. The antenna matching network values above are used when antenna is mounted on Johanson's evaluation board. The matching values on client’s PCB will be different. To order a pre-tuned 50 Ω EVB with a female SMA connector you see here Click here: https://www.johansontechnology.com/request-a-sample Reference p/n: 2450AT42E0100-EB1SMA Ground Plane (where other SMD components will be mounted) 30mm 6.26mm 50mm 50Ω Feed Line 3mm Top View Bottom View Ground Want the layout file? Send us a message at: https://www.johansontechnology.com/ask-a-question p/n: 2450AT42E0100-EB1SMA Matching circuit Metal bottom GND plane to be placed directly underneath yellow soldemask zone, covering entire area. 1.5 nH Matching circuit 1.5mm 0.3mm 2mm 1.5mm 0.6mm 1.0mm 0.6mm 0.5mm 0.63mm 0.63mm Floating pad 3mm 6.26mm     * 3.3 nH 2.0 pF 2.4 GHz SMD, Above Metal, Low Profile Mini Chip Antenna P/N 2450AT42E0100 This antenna will generally have a metal layer directly underneath for proper operation, exceptions may apply. Detail Specification: Page 3 of 8 Return Loss https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2021 Johanson Technology, Inc. All Rights Reserved All sales are subject to Johanson Technology, Inc. terms and conditions. Johanson Technology, Inc. reserves the right to make design changes without notice. Ver. 4.0 High Frequency Ceramic Solutions Typical Electrical Characteristics (T=25 °C) 10/28/2021 2.22.42.62.82.03.0 -15 -10 -5 -20 0 freq, GHz dB(S(1,1)) m118 m122 m123 m118 freq= dB(S(1,1))=-11.343 2.440GHz m122 freq= dB(S(1,1))=-5.691 2.400GHz m123 freq= dB(S(1,1))=-5.746 2.480GHz The designer should not be highly concerned of the fact that the antenna only demonstrates a -5dB S11 level at the band edges. The antenna has sufficient gain at the band edges to satisfy the applications and uses a high dielectric constant ceramic giving it some detuning resilience to capacitivel loading effects. This antenna is designed for close proximity applications such as the ones mentioned on page 1. 2.4 GHz SMD, Above Metal, Low Profile Mini Chip Antenna P/N 2450AT42E0100 This antenna will generally have a metal layer directly underneath for proper operation, exceptions may apply. Detail Specification: Page 4 of 8 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2021 Johanson Technology, Inc. All Rights Reserved Typical Radiation Patterns @ 2.44GHz (T=25 °C) Johanson Technology, Inc. reserves the right to make design changes without notice. Ver. 4.0 High Frequency Ceramic Solutions 10/28/2021 All sales are subject to Johanson Technology, Inc. te…

Text truncated - open the document above for the full version.

ReferenceNo.:WTX26X08228032WPage8of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EXHIBIT4-TESTSETUPPHOTOGRAPHS RadioTestSetupView RadiationEmissionTest Setup(Below30MHz) ReferenceNo.:WTX26X08228032WPage9of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn RadiationEmissionTest Setup(30MHzto1GHz) RadiationEmissionTest Setup(closeup) ReferenceNo.:WTX26X08228032WPage10of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn RadiationEmissionTest Setup(1GHzto18GHz) RadiationEmissionTest Setup(Above18GHz) ReferenceNo.:WTX26X08228032WPage11of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn RadiationEmissionTest Setup(closeup) *****ENDOFREPORT*****
