Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Feb 05, 2021
Application Purpose: Original Equipment
Date of Application: Feb 04, 2021
Equipment Note: Smart Phone
Frequency Range: 2545.00000000 - 2645.00000000
Company: HOYOS INTEGRITY CORPORATION
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Safety Information Guide Safety Information 21 Safety Information Safety Information The topics in this section will introduce the safety and use information. Please read before proceeding THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX. DO NOT ATTEMPT TO REMOVE THE BATTERY PACK. Important health information and safety precautions When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages. Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product. To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions. Electrical safety This product is intended for use when supplied with power from the designated battery or power supply unit. Other usages may be dangerous and will invalidate any approval given to this product. Safety precautions for proper grounding installation Warning: Connecting to improperly grounded equipment can result in an electric shock to your device. This product is equipped with a USB Cable for connecting with desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or notebook computer has an equipment grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances. Safety precautions for power supply unit Use the correct external power source A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of Safety Information 43 Safety Information power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product. This product should be operated only with the following designated power supply unit(s). Travel charge: Input: 100-240V, 50/60Hz, 0.5A. Output: 5V3A/9V2A/12V1.5A. Handle battery packs carefully This product contains a Lithium-ion polymer or Lithium-ion battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 113°F (45°C). The operating temperature for the phone is 14°F (-10°C) to 113°F (45°C). Warning: Battery is nonremovable. Do not attempt to remove the battery for danger of explosion. To reduce the risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 113°F (45°C), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or guide supplied with your product. Take extra precautions • Do not disassemble or open, crush, bend or deform, puncture or shred. • Do not short circuit a battery or allow metallic conductive objects to contact battery terminals. • Only use the USB cable provided with the phone or that bear the USB-IF logo or have completed the USB-IF compliance program. • Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazards. Safety Information 65 Safety Information • Device usage by children should be supervised. • Only use the battery for the system for which it is specified. • Only use the battery with a charging system that has been qualified with the system per CTIA Certification Requirement for Battery System Compliance to IEEE1725. The use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazards. • Promptly dispose of used batteries in accordance with local regulations. • Avoid dropping the phone. If the phone is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection. • Improper battery use may result in a fire, explosion, or other hazards. If the battery leaks: - Do not allow the leaking fluid to come into contact with skin or clothing. If already in contact, flush the affected area immediately with clean water and seek medical advice. - Do not allow the leaking fluid to come into contact with eyes. If already in contact, DO NOT rub; rinse with clean water immediately and seek medical advice. -Take extra precautions to keep a leaking battery away from fire as there is a danger of ignition or explosion. Safety precautions for direct sunlight Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 113°F (45°C), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage or overheat the product, or pose a risk to the vehicle. Prevention of hearing loss Permanent hearing loss may occur if earphones or headphones are used at high volume for prolonged periods of time. Safety Information 87 Safety Information Safety in aircraft Due to possible interference caused by this product to an aircraft's navigation system and its communications network, using this device's phone function on board an airplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off the RF on your phone by switching to Airplane Mode. Environment restrictions Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fueling areas, fuel storehous…

Text truncated - open the document above for the full version.

Cover Letter(s)

HOYOS INTEGRITY COPORATION PROPRIETARY & CONFIDENTIAL INFORMATION Statement We, _Hoyos Integrity Corporation declared that our device with FCC ID: 2AXQJH1U, IC :26642-H1U, is a multi-band mobile phone which supports: GSM850/900/1800/1900, WCDMA Band 1/2/5/8, LTE Band 2/4/5/12/17/66, Roaming bands 1/3/7/8/28/40/38/41(With Rx Div) WiFi 11a/11b/11g/11n/11ac, Bluetooth 4.2. However, LTE band 40 is not available in US market and Canada market, and will be disabled by software. By: Rick Boyd (Print name) Title: SVP Sales & Marketing On behalf of: Hoyos Integrity Corp. (Company Name) Telephone: +1-678-524-0162
