2AXTGBC03AI01BeraShield Charger

User manual • Product Name : BeraShield Charger• Model Name : BC03AI01• FCC ID: 2AXTGBC03AI01 User manual User manualFCC Compliance StatementThis device complies with part 15 of the FCC rules. Operation i s subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any inter ference received, including interference that may cause undesir ed operation. FCC Interference StatementThis equipment has been tested and found to comply with the lim its for a Class B digital device, pursuant to part 15 of the FC C Rules. These limits are designed to provide reasonable protection against ha rmful interference in a residential installation. This equipmen t generates, uses and can radiate radio freque ncy energy and, if not install ed and used in accordance with th e instructions, may cause harm ful interference to radio communications. However, there is no guar antee that interference will not occur in a particular installa tion. If this equipment does cause harmful interference to radio or televisio n reception, which can be determined by turning the equipment o ffand on, the user is encouraged to correct the interference by one o f the following measures: • Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different f rom which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any changes or modifications not expressly approved by the part y responsible for compliance coul d void the user's authority to operate this equipment. This transmitter must not be co‐located or oper ating in conjunction with any other antenna or transmitter. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled enviro nment. This equipment should be installed and operated with minimum distance 20 cm between the radiator a nd your body. This transmitter mu st not be co‐located or operat ing in conjunction with any other antenna or transmitter.

Smart Guardians Inc. #B-1425, 344, Yangcheon-ro, Gangseo-gu, Seoul 07791 South Korea Date: November 16, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. UL Verification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Chloe Lee/ Manager of KCTL Inc. and hereafter referred to as KCTL to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Chloe Lee/ Manager of KCTL Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KCTL as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sungsu Lee/ CEO Smart Guardians Inc.

Smart Guardians Inc. #B-1425, 344, Yangcheon-ro, Gangseo-gu, Seoul 07791 South Korea CONFIDENTIALITY REQUEST Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 November 16, 2020 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Smart Guardians Inc. requests confidentiality for the following products: FCC ID Number Product Title/Model 2AXTGBC03AI01 BeraShield Charger / BC03AI01 The following exhibits contain trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our product. This material is not customarily available to the general public and we request that it be withheld from public inspection. We request that the following information submitted be held permanent confidential treatment. Permanent Confidential Request -. Schematics -. Block Diagram -. Operational Description -. Antenna specification We also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give temporary confidentiality of commercially sensitive information prior to product release. Short-Term Confidential Request -. External Photos -. Internal Photos -. Test set-up photo -. User Manual If you have any questions, please feel free to contact me at the address shown below. Sincerely, Sungsu Lee/ CEO

http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval External photos of EUT http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval

Label Info. & Location

http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval Internal photos of EUT http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval Coil Antenna

verify No.938518141133 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0291-B Page (2) of (13) KCTL-TIR001-003/3 KP20-05594 REPORT REVISION HISTORY Date Revision Page No 2020-11-18 Originally issued - 2020-11-26 Updated 4 2020-12-02 Updated 1, 4, 5, 7-12 This report shall not be reproduced except in full, without the written approval of KCTL Inc. This document may be altered or revised by KCTL Inc. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KCTL Inc. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. Note. The report No. KR20-SRF0291-A is superseded by the report No. KR20-SRF0291-B. General remarks for test reports Nothing significant to report. KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0291-B Page (3) of (13) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 CONTENTS 1. General information ...................................................................................................... 4 2. Device information ........................................................................................................ 4 2.1. Accessory information ............................................................................................ 4 2.2 Equipment Approval Considerations ....................................................................... 5 3. RF Exposure ................................................................................................................. 6 3.1. FCC Regulation ...................................................................................................... 6 3.2. Test Set-up .............................................................................................................. 7 3.3. Test configuration (Description of test mode) .......................................................... 9 3.4. Test result ............................................................................................................. 10 4. Measurement Equipment ............................................................................................ 13 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0291-B Page (4) of (13) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 1. General information Client : Smart Guardians Inc. Address : #B-1425, 344, Yangcheon-ro, Gangseo-gu, Seoul 07791 South Korea Manufacturer : SHENZHEN UNIL ELECTRONICS TECHNOLOGY CO LTD Address : 2/F, B2 Building Huaxiayuan Industrial Zone, Fuping Road, Pingdi Town, Longgang District, Shenzhen City, China Laboratory : KCTL Inc. Address : 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Accreditations : FCC Site Designation No: KR0040, FCC Site Registration No: 687132 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 Industry Canada Registration No. : 8035A KOLAS No.: KT231 2. Device information Equipment under test : BeraShield Charger Model : BC03AI01 Frequency range 111 ㎑ ~ 129 ㎑ Modulation technique : AM Number of channels : 1 ch Power source : DC 5 V, DC 9 V Antenna specification : Coil Antenna Software version : Rev 1.0 Hardware version : Rev 1.0 Operation temperature : -20 °C ~ 50 °C 2.1. Accessory information Equipment Manufacturer Model Serial No. Power source AC/DC Adapter Dongguan Samsung Electro-mechanics Co., Ltd. EP-TA20KWK R37G2V66K91SE3 INPUT : AC 100- 240V 50-60 Hz OUTPUT : DC 9.0V 1.67A AC/DC Adapter PNTELECOM MCS-H05EP PA5Z0023385 INPUT : AC 100- 240V 50-60 Hz OUTPUT : DC 5.0V 1.8A C-type cable - - - - Wireless Charger SHENZHEN UNIL ELECTRONICS TECHNOLOGY CO LTD BC02AI01 - - KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0291-B Page (5) of (13) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 2.2 Equipment Approval Considerations Requirements of KDB 680106 Description (1) Power transfer frequency is less than 1 MHz. Operating frequency is 111 – 129 kHz (2) Output power from each primary coil is less than or equal to 15 watts. Maximum rated charging power is 15W. (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. The device only has a single coil capable of coupling to a single secondary coil in the client device. (4) Client device is placed directly in contact with the transmitter. The client device has to be placed directly in contact with the charger. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). This device must be powered to operate and therefore is considered a mobile charger, not a portable charger. (6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. The highest measured H field was 0.1499 A/m which is 9.2 % of the limit. KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0291-B Page (6) of (13) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 3. RF Exposure 3…

Text truncated - open the document above for the full version.

verify No.020756655311 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0290-A Page (2) of (19) KCTL-TIR001-003/3 KP20-05594 REPORT REVISION HISTORY Date Revision Page No 2020-11-18 Originally issued - 2020-11-26 Updated 5, 7, 8, 10-13 This report shall not be reproduced except in full, without the written approval of KCTL Inc. This document may be altered or revised by KCTL Inc. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KCTL Inc. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. Note. The report No. KR20-SRF0290 is superseded by the report No. KR20-SRF0290-A. General remarks for test reports Nothing significant to report. KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0290-A Page (3) of (19) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 CONTENTS 1. General information ...................................................................................................... 4 2. Device information ........................................................................................................ 4 2.1. Accessory information ............................................................................................ 5 2.2. Frequency/channel operations ................................................................................ 5 3. Antenna requirement .................................................................................................... 6 4. Summary of tests .......................................................................................................... 7 5. Measurement uncertainty ............................................................................................. 7 6. Test results ................................................................................................................... 8 6.1. Field Strength of Fundamental and Spurious Emission .......................................... 8 6.2. 20㏈ Bandwidth .................................................................................................... 14 6.3. AC Conducted emission ....................................................................................... 16 7. Measurement equipment ............................................................................................ 19 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0290-A Page (4) of (19) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 1. General information Client : Smart Guardians Inc. Address : #B-1425, 344, Yangcheon-ro, Gangseo-gu, Seoul 07791 South Korea Manufacturer : SHENZHEN UNIL ELECTRONICS TECHNOLOGY CO LTD Address : 2/F, B2 Building Huaxiayuan Industrial Zone, Fuping Road, Pingdi Town, Longgang District, Shenzhen City, China Laboratory : KCTL Inc. Address : 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Accreditations : FCC Site Designation No: KR0040, FCC Site Registration No: 687132 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 Industry Canada Registration No. : 8035A KOLAS No.: KT231 2. Device information Equipment under test : BeraShield Charger Model : BC03AI01 Frequency range 111 ㎑ ~ 129 ㎑ Modulation technique : AM Number of channels : 1 ch Power source : DC 5 V, DC 9 V Antenna specification : Coil Antenna Software version : Rev 1.0 Hardware version : Rev 1.0 Operation temperature : -20 °C ~ 50 °C KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0290-A Page (5) of (19) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 2.1. Accessory information Equipment Manufacturer Model Serial No. Power source AC Adaptor Dongguan Samsung Electro-mechanics Co., Ltd. EP-TA20KWK R37G2V66K91SE3 INPUT : AC 100-240V 50-60 Hz OUTPUT : DC 9.0V 1.67A or DC 5.0V 2.0A C-type cable - - - - Test JIG (Load module) - - - - Wireless Charger SHENZHEN UNIL ELECTRONICS TECHNOLOGY CO LTD BC02AI01 - - 2.2. Frequency/channel operations This device contains the following capabilities: WPT Frequency (㎑) 111 ~ 129 Table 2.2.1 WPT KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0290-A Page (6) of (19) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 3. Antenna requirement Requirement of FCC part section 15.203: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section. - The transmitter has permanently attached Coil antenna (Internal antenna) on board. KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SRF0290-A Page (7) of (19) This test report shall not be reproduced, except in full, without the written approval KCTL-TIR001-003/3 KP20-05594 4. Summary of tests FCC Part section(s) Parameter Test results 15.209(a) Field Strength of Fundamental and Spurious Emission Pass 2.1049 20㏈ Bandwidth Pass 15.203 Antenna requirement Pass 15…

Text truncated - open the document above for the full version.

http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval Test setup photos -Part 15.209 (WPT) [DC 5 V] [DC 9 V] http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval - Conducted emission [DC 5 V] http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval [DC 9 V] http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval - MPE - EUT Side_A (Right) - EUT Side_B (Left) http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval - EUT Side_C (Rear) - EUT Side_D (Front) http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval - EUT Side_E (Top)
