2AY3Y-NTENormatec Elite

Normatec Elite EN Operating Instructions BG Оригинални Инструкции CS Původní Pokyny DA Oprindelige Anvisninger DE Originalanweisungen EL Οδηγίες λειτουργίας ES Instrucciones Originales ET Algsed Juhised FI Alkuperäiset Ohjeet FR Instructions D’origine HE הלעפה תוארוה HR Upute za rad HU Használati útmutató IT Istruzioni Originali LT P radinės Instrukcijos MS Arahan Asal NL Oorspronkelijke Instructies PL Instrukcja obsługi PT Instruções de funcionamento RO I nstrucțiuni Originale SK Návod na použitie SL Navodila za uporabo SV U rsprungliga Instruktioner ZH-TW 繁體中文 操作說明 TO REDUCE RISKS OF ELECTRIC SHOCK, FIRE, AND PERSONAL INJURY, OR PROPERTY DAMAGE, THIS DEVICE MUST BE USED IN ACCORDANCE WITH THE FOLLOWING WARNINGS, CAUTIONS, AND SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS - ORIGINAL INSTRUCTIONS Read the entire instruction manual before using the Normatec Elite. WARNING No modification of this ME system is allowed. If you experience severe pain, any unusual symptoms, or want to remove the device in an emergency during use: • Stop the device by pressing the Start/Stop or power button. • Remove the device from your limbs. • Promptly consult your licensed healthcare practitioner, as required. CAUTION • Do not attempt to take apart the device. The device has no user-serviceable parts. When service or repairs are required, please contact customer service at +1.949.565.4994. • Only use the charger provided with the device. Using a different charger may cause the device to operate incorrectly. • To avoid risk of electric shock, do not use the device near water, such as near a bathtub, kitchen sink, laundry tub, or swimming pool. • To avoid damage and risk of electric shock, never spill liquid of any kind on the device. • Do not place the device or charger where they could be damaged, present a fall hazard, or become an obstruction to others. • Keep the power inlet free of debris. • If the charger is damaged, the control unit is dropped or damaged, liquid is spilled on the device, or the device does not operate normally when the operating instructions are followed, turn the device off by pushing the control unit’s power button and then unplugging the device from the wall outlet. Contact customer service at +1.949.565.4994 for assistance. • Do not puncture or otherwise damage the device as this may cause it to operate incorrectly. • To avoid risk of strangulation, do not leave a baby or child unattended with the charger. • Choking hazard, small parts. Keep away from small children. • Do not leave the device or charger where they could be damaged by children, pets, pests, or liquids. If you suspect your control unit is damaged, contact customer service at +1.949.565.4994 for assistance. • Do not allow lint or dust to accumulate on the device. If lint or dust accumulates, wipe down the device with a dry cloth before use. • The IP22 classification means the control unit is protected against the ingress of vertically dripping water and the hazardous parts are protected against access to objects equal to or larger than 12.5 mm (1/2”). • The expected service life of the device and the integrated battery is 3 years. • Do not stand or walk while w earing the device. • The devic e is designed to be used by only one person at a time. • Product is to be used by adults only in good health. • Consult your physician before using this product if you are under the care of a physician or have a contraindication requiring the use of any medical device. • Consult your physician before using this product if you are experiencing inflammation, an infection, pain of unknown origin, bleeding (internal or external) at or near the site of application, or if you have a wound at or near the site of application. • Consult your physician before using this product on sensitive skin. • Consult your physician before using this product if you have any of the following conditions: • Acute pulmonary edema • Acute thrombophlebitis • Acute congestive cardiac failure • Acute infections • Deep vein thrombosis (DVT) • Episodes of pulmonary embolism • Wounds, lesions, or tumors at or near the site of application • Where increased venous and lymphatic return is undesirable • Bone fractures or dislocations at or near the site of application EN • Use by unconscious or incapacitated persons may be dangerous without supervision. • Make sure the power inlet on the control unit is easily accessible at all times in order to disconnect power if required. The Normatec Elite control unit contains a Li-ion battery. The battery must be complied with safely at an appropriate e-waste disposal or recycling facility. SAVE THESE INSTRUCTIONS LABELS The following labels and symbols appear on the control unit, attachments, and/or packaging. SymbolDescriptionLocation IP22Degree of protection against ingress of waterOn base of control unit Read instructions before use On base of control unit and attachment tag Level of protection type BF equipmentOn base of control unit Double insulationOn power adapter Direct currentOn base of control unit Alternating currentIn manual Manufacturer’s name and address On base of control unit and attachment tag Date of manufactureOn base of control unit Separate collection for waste electrical and electronic equipment On base of control unit Serial number of the consoleOn base of control unit Fragile, handle with careOn package Keep dry On package This side up On package Keep away from sunlight On package Transportation & storage humidity limitation On package Transportation & storage atmospheric pressure limitation On package Transportation & storage temperature limitation On package Place in and out of standby modeOn top of control unit Do not wash On attachment tag Do not dry clean On attachment tag Do not tumble dry On attachment tag Do not bleach On attachment tag Do not iron On attachment tag EU RF transmitter symbolIn manual FCC approved equipment authorizationOn control unit The Bluetooth figure markOn control unit…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name NormaTec Industries LP Address 480 Pleasant St. Watertown Massachusetts 02472 United States Grantee Code 2AY3Y FCC ID 2AY3Y-NTE Authorized Contact Name Steve Henderson Contact Email [email protected] Contact Phone 6176585857 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [ NormaTec Industries LP] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [ NormaTec Industries LP] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature:Date: Print Name: Steve Henderson Title: Director, Quality & Regulatory Systems *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database 11/08/2023

UNITED STATES DESIGNATED AGENT LETTER Date: 2023-11-07 TO:Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 ApplicantU.S. designated agent Company Name:NormaTec Industries LPCompany Name:NormaTec Industries LP Grantee Code:2AY3YFRN:0027262146 Contact Name:Steve HendersonContact Name:Steve Henderson Address:480 Pleasant St. Watertown Massachusetts 02472 United States Address:480 Pleasant St. Watertown Massachusetts 02472 United States City/Province/Zip:City/Province/Zip: Telephone:6176585857Telephone:6176585857 Fax:Fax: Email:[email protected]:[email protected] Applicable Equipment: FCC ID: 2AY3Y-NTE ATTN: Director of Certification: We, NormaTec Industries LP understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, NormaTec Industries LP acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. ApplicantU.S. designated agent Name (Printed): Steve HendersonName (Printed): Steve Henderson Title: Director, Quality & Regulatory SystemsTitle: Director, Quality & Regulatory Systems Signature:Signature:

NormaTec Industries LP Date: 2023-11-07 TO:Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AY3Y-NTE To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with NormaTec Industries LP This authorization is valid until further written notice from the applicant. Print Name: Steve HendersonTitle: Director, Quality & Regulatory Systems Signature: On behalf of Company: NormaTec Industries LP Telephone: 6176585857 E-mail: [email protected]

NormaTec Industries LP Date: 2023-11--07 TO:Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: 2AY3Y-NTE LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby requests confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Print Name: Steve HendersonTitle: Director, Quality & Regulatory Systems Signature: On behalf of Company: NormaTec Industries LP Telephone: 6176585857 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 13 External Photos for SZCR2306001852ME FCC ID:2AY3Y-NTE SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 13 EUT Constructional Details (EUT Photos) Test model: JPN11-ST+ Combination 1 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 6 of 13 Test model: JPN11-ST+ Combination 2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 7 of 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 8 of 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 9 of 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 10 of 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 11 of 13 Model: JPN11-PT Model: JPN11-TL SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 12 of 13 Model: JPN11-PS Model: JPN11-SH SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 13 of 13 Model: JPN11-PH

NormaTec Industries, LP 480 Pleasant Street Watertown, MA 02472 USA Hecho en China Fabriqué en Chine 801714 Especificaciones eléctricas 12V , 2A Compresores dinámicos de aire This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-003(B)/NMB-003(B) Protected by patents: hyperice.com/patents IP22 440-00212 Rev A IFT: ############# Australian Sponsor Emergo Australia Level 20, Tower II Darling Park 201 Sussex Street Sydney NSW 2000, Australia

54.6 9.7

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 15 Internal Photos for SZCR2306001852ME FCC ID:2AY3Y-NTE SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 15 EUT Constructional Details (EUT Photos) Test model: JPN11-ST+ Combination 1 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 5 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 6 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 7 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 8 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 9 of 15 Test model: JPN11-ST+ Combination 2 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 10 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 11 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 12 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 13 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 14 of 15 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 15 of 15 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR230600185204 Page: 1 of 13 Keny Xu EMC Laboratory Manager 1 Cover page RF Exposure Report Application No.: SZCR2306001852ME Applicant: NormaTec Industries LP Address of Applicant: 480 Pleasant St. Ste A200 Watertown Massachusetts 02472 United States Manufacturer: NormaTec Industries LP Address of Manufacturer: 480 Pleasant St. Ste A200 Watertown Massachusetts 02472 United States Factory: Ryder Electronics (XinFeng) Ltd. Address of Factory: East Shuidong Avenue, Industrial Park, Xinfeng County, Ganzhou City, Jiangxi Province, China 341600 Equipment Under Test (EUT): EUT Name: Normatec Elite Model No.: JPN11-SH, JPN11-ST, JPN11-TL, JPN11-PH, JPN11-PS, JPN11-PT ♣ ♣ Please refer to section 4 of this report which indicates which model was actual tested and which were electrically identical. Trade Mark: FCC ID: 2AY3Y-NTE Standards: FCC Rules 47 CFR §2.1093 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-10-30 Date of Test: 2023-11-02 to 2023-11-15 Date of Issue: 2023-11-17 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR230600185204 Page: 2 of 13 2 Version Revision Record Version Chapter Date Modifier Remark 01 2023-11-17 Original Authorized for issue by: Leo Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR230600185204 Page: 3 of 13 3 Contents Page 1 COVER PAGE ........................................................................................................................................ 1 2 VERSION ................................................................................................................................................ 2 3 CONTENTS ............................................................................................................................................ 3 4 GENERAL INFORMATION ..................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF E.U.T. ...................................................................................................... 4 4.2 DETAILS OF EUT ............................................................................................................................... 4 4.3 SEPARATION DISTANCE...................................................................................................................... 7 4.4 TEST LOCATION ................................................................................................................................ 8 4.5 TEST FACILITY .................................................................................................................................. 8 4.6 DEVIATION FROM STANDARDS ............................................................................................................ 8 4.7 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................... 8 4.8 OTHER INFORMATION REQUESTED BY THE CUSTOMER .......................................................................... 8 5 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .................................................................. 9 5.1 BLANKET 1 MW BLANKET EXEMPTION.................................................................................................. 9 5.2 MPE-BASED EXEMPTION.................................................................................................................... 9 5.3 SAR-BASED EXEMPTION .................................................................................................................. 10 6 MEASUREMENT AND CALCULATION ................................................................................................ 12 6.1 MAXIMUM TRANSMIT POWER ............................................................................................................. 12 6.2 RF EXPOSURE CALCULATION ........................................................................................................... 13 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR230600185204 Page: 4 of 13 4 General Information 4.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 4.2 Details of EUT Power supply: BPI Lithium Ion Battery: DC 7.2V 5000mAh rechargeable battery Hixon Lithium Ion Battery: DC 7.38V 4800mAh rechargeable battery DC 12V from adapter input AC 120V/60Hz Adapter 1 Model: DZ048CHL120400H Input:100-240V~50-60Hz 1.5A Output:12.0V ⎓ 4.0A 48.0W Adapter 2 Model: SMS-01120400-S68 Input:100-240V ~ 50-60Hz 1.5A MAX Output:12.0V ⎓ 4.0A 48.0W MAX Cable(s): Adapter 1 DC cable: 310cm unshielded Adapter 2 DC cable: 300cm unshielded For BT: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.0 LE Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: -2.99dBi For 433MHz: Operation Frequency 433.92MHz Channel Numbers: 1 Modulation Type: GFSK Antenna Type: Helical Antenna Antenna Gain: -8.94dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR230600185204 Page: 5 of 13 Declaration of EUT Family Grouping: Model No.: JPN11-SH, JPN11-ST, JPN11-TL, JPN11-PH, JPN11-PS, JPN11-PT Only the model JPN11-ST was tested, since according to the declaration from the applicant, the electrical circuit design, PCB layout, components used and internal wiring and functions were identical for the above models, with difference on Model No. and the leg sizes. Remark: The product comes with different Air compressor, Solenoid Valves, adapters, pressure sensor and batteries, all the Configurations h…
