2AY46-A18Aibner wireless chargers

封面 背面 Important Safety Instructions ·Avoid dropping. ·Do not disassemble. ·Do not expose to liquids. ·For the safest and fastest charge， use original or certified cables. ·This product is suitable for moderate li mates only. .The maximum ambient temperature during use of this product must not exceed 40°C. .Open fame sources, such as candles, must not be placed on this product. .Only use a dry cloth or brush to clean this product. FCC Statement This device complies with Part 15oftheFCC Rules.Operation is subject to the following two conditions; (1) This device may not cause harmful interference,and (2)this device must accept any interference received,including interference that may cause undesired operation. Warning: Changes or modi ications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to Part 15oftheFCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential in staH ation. This equipment generates, uses, and can radiate radiofrequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radiocommunications.However, there is no guarantee that interference wil not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures, (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.This equipment should be installed and operated with minimum distance of 20cm between the radiator&your body. Product Name:Wireless Charger Model:A 18 Shenzhen Aibner Electronics Co., Ltd 3rd floor, building 1, Nanyue United Industrial Zone, Longgang District, Shenzhen City, Guangdong Province, China Telephone:(86) 400-805-8882 IC Statement This device com les wth RSS 216 of Industry Canada,Operat in is sub ect to the condition that this device does not cause harmful interference. Input 5V=2A/9V=2A Output 10WMax Size 100x100x5mm/3.9x3.9x0.2in Weight 67g/2.4oz Declaration of Conformity Hereby,Shenzhen Aibner Electronics Co., Ltd declares that the product type A18isin compliance with Directive 2014/53/EU.The fulltext of the EU declaration of conformity is available at the following internet address. Specifications KG https://chaoliugongshi.tmall.com/ ES Indicador LED Estado Luz verde para 5S, luz azul para10 segundos, luego sal El azul se mantiene durante 15 segundos,luego sale Conectado al poder Cargando dispositivo móvil Luces azules y verdes parpadeando Detectados objetos metálicos u anormales Verde intermitente La protección contra sobretensiones significa que necesitacambiar al adaptador 5V / 9VDC No puede cargar su dispositivo de forma inalámbrica en estos escenarios: o utilizando un estuche con placa magnética / de hierro; o usando un estuche con un enchufe pop; o utilizando una funda protectora de teléfono ultra gruesa (> 6 mm). ·No coloque ningún objeto extraño entre su dispositivo y la superficie del cargador inalámbrico, incluidas las almohadillas de metal en un soporte para automóvil, tarjetas de crédito, llaves de puertas, monedas, metal o tarjetas NFC, que harán que la carga inalámbrica falle o provoquen sobrecalentamiento. ·Los cargadores inalámbricos hacen que la carga sea más conveniente que los cargadores con cable, pero limitada por la tecnología inalámbrica actual, su velocidad de carga es más lenta que la de los cargadores con cable. ·Las altas temperaturas reducirán la velocidad de carga y restringirán la energía, lo cual es un fenómeno común a todos los cargadores inalámbricos. Se recomienda que cargue su dispositivo en entornos con temperaturas inferiores a 25 ° C / 77 ° F ·Both the protective phone case and the position of your device on the wireless charger wil affect the charging speed.The farther it is placed from the center of the wireless charger,the slower the charging speed. will be. 0102 040608 10 12 14 16 1820 22 24 26 28 03 050709 11 13 15 17 1921 23 25 27 EN LED IndicatorStatus Green light for 5S, blue light for 10 seconds, then go out Connected to power Charging mobile device Blue and green lights flashing Metal or abnormal objects detected Flashing green Overvoltage protection means you need to switch to 5V/9VDC adapter ·You can not charge your device wirelessly in these scenarios： o using a case with a magnetic/iron plate； o using a case with a pop socket； o using an ultra-thick(>6mm) protective phone case. ·Do not place any foreign objects between your device and the wireless charger's surface,including metal pads on a car mount,credit cards, door keys,coins,metal,or NFC cards,which will make wireless charging fail or cause overheating. ·Wireless chargers make charging more convenient than wired chargers,but confined by current wireless technology, their charging speed is slower than that of wired chargers. ·High temperatures will reduce charging speed and restrict power， which is a phenomenon commontoall wireless chargers.It is recommended that you charge your device in environments with temperatures below 25°C/77°F ·Both the protective phone case and the position of your device on the wireless charger wil affect the charging speed.The farther it is placed from the center of the wireless charger,the slower the charging speed will be. Blue keeps on for 15 seconds, then goes out DE LED-Anzeige Status Blaue und gr…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/03/16 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AY46-A18 A18 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Junyun Li Company: Shenzhen Aibner Electronics Co., Ltd. Address: 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Phone: +86 0755-86595487 Fax: +86 0755-86595487 E-Mail: [email protected]

Shenzhen Aibner Electronics Co., Ltd. 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Tel: +86 0755-86595487 Fax: +86 0755-86595487 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-03-22 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AY46-A18 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name:Junyun Li Company:Shenzhen Aibner Electronics Co., Ltd. Address:29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Phone:+86 0755-86595487 Fax:+86 0755-86595487 E-Mail:[email protected]

FCC ID: 2AY46-A18

FCC ID: 2AY46-A18

FCC ID: 2AY46-A18 Antenna

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No......................: FCC ID............................................ : GTS20210312006-1-1-2 2AY46-A18 Compiled by ( position+printed name+signature)..:File administrators Jimmy Wang Supervised by ( position+printed name+signature)..:Test Engineer Aaron Tan Approved by ( position+printed name+signature)..: Manager Jason Hu Date of issue.....................................:Mar. 13, 2021 Representative Laboratory Name.:Shenzhen Global Test Service Co., Ltd. Address...................................................: No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name............................: Shenzhen Aibner Electronics Co., Ltd. Address............................................: 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Test specification...........................: Standard...........................................: FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator..................................:Shenzhen Global Test Service Co.,Ltd. Master TRF.......................................:Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description.....................: Aibner wireless chargers Trade Mark.......................................: N/A Manufacturer....................................: Shenzhen Aibner Electronics Co., Ltd. Model/Type reference.......................: A18 Listed Models ..................................: N/A Modulation Type...............................: ASK Operation Frequency........................: From 110KHz~205KHz Rating...............................................:DC 5V/2A or 9V/2A Result...............................................: PASS Report No.: GTS20210312006-1-1-2 Page 2 of 12 T E S T R E P O R T Test Report No. :GTS20210312006-1-1-2 Mar. 13, 2021 ____________________________________________________________________________________ Date of issue Equipment under Test: Aibner wireless chargers Model /Type : A18 Listed Models: N/A Applicant : Shenzhen Aibner Electronics Co., Ltd. Address: 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Manufacturer : Shenzhen Aibner Electronics Co., Ltd. Address: 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210312006-1-1-2 Page 3 of 12 Contents 1SUMMARY.............................................................................4 1.1General Remarks4 1.2Product Description4 1.3Description of the test mode4 1.4Special Accessories5 1.5Modifications5 2TEST ENVIRONMENT ...............................................................6 2.1Address of the test laboratory6 2.2Test Facility6 2.3Environmental conditions6 2.4Summary of measurement results7 2.5Statement of the measurement uncertainty7 2.6Equipments Used during the Test7 3TEST CONDITIONS AND RESULTS.............................................8 3.1Applicable Standard8 3.2Limit8 3.3Test Setup8 3.4Measurement Procedure9 3.5Test Result of E and H field Strength9 3.6Equipment Approval Considerations11 3.7Conclusion11 4TEST SETUP PHOTOS OF THE EUT..........................................12 Report No.: GTS20210312006-1-1-2 Page 4 of 12 1SUMMARY 1.1General Remarks Date of receipt of test sample:Mar. 01, 2021 Testing commenced on:Mar. 02, 2021 Testing concluded on:Mar. 12, 2021 1.2Product Description Product Name: Aibner wireless chargers Model/Type reference: A18 Hardware version: YM-W50-L-C-10W Software version: V1.0 Test samples ID: GTS20210312006-1-1# Power supply: DC 5V/2A or 9V/2A Operation frequency: 110KHz - 205KHz Modulation type:ASK Antenna type:Loop coil antenna 1.3Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 10W) Record Mode 2AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 7.5W) Record Mode 3AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 5W) Record Mode 4AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 10W) Pre-tested Mode 5AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 7.5W) Pre-tested Mode 6AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 5W) Pre-tested Note: All test modes were pre-tested, but we only recorded the worst case in this report. Report No.: GTS20210312006-1-1-2 Page 5 of 12 1.4Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is listed as follow: DescriptionManufacturerModelTechnical ParametersCertificateProvided by AdapterUGREENCD137 Input: 100-240V~, 50/60Hz, 0.5A Output: 5V2A / 9V2A / 12V 2A CE/FCClaboratory Wireless charger tester / SW-MK- 89898 Full Protocol Wireless Chager Tester, 5W / 7.5W / 10W / 15W four gear switchable CE/FCClaboratory ////// ////// 1.5Modifications No modifications were implemented to meet testing criteria. Report No.: GTS20210312006-1-1-2 Page 6 of 1…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT Report Reference No......................: FCC ID............................................ : GTS20210312006-1-1 2AY46-A18 Compiled by ( position+printed name+signature)..:File administrators Jimmy Wang Supervised by ( position+printed name+signature)..:Test Engineer Aaron Tan Approved by ( position+printed name+signature)..: Manager Jason Hu Date of issue.....................................:Mar. 13, 2021 Representative Laboratory Name.:Shenzhen Global Test Service Co., Ltd. Address............................................: No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name............................: Shenzhen Aibner Electronics Co., Ltd. Address............................................: 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Test specification...........................: Standard...........................................: FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 TRF Originator..................................:Shenzhen Global Test Service Co.,Ltd. Master TRF.......................................:Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description.....................:Aibner wireless chargers Trade Mark.......................................:N/A Manufacturer....................................:Shenzhen Aibner Electronics Co., Ltd. Model/Type reference.......................:A18 Listed Models ..................................:N/A Modulation Type...............................:ASK Operation Frequency........................:From 110KHz~205KHz Rating...............................................:DC 5V/2A or 9V/2A Result...............................................:PASS Report No.: GTS20210312006-1-1 Page 2 of 23 T E S T R E P O R T Test Report No. :GTS20210312006-1-1 Mar. 13, 2021 ____________________________________________________________________________________ Date of issue Equipment under Test: Aibner wireless chargers Model /Type : A18 Listed Models: N/A Applicant : Shenzhen Aibner Electronics Co., Ltd. Address: 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Manufacturer : Shenzhen Aibner Electronics Co., Ltd. Address: 29C, Building 2, Zhenyeluan Valley,No.81 Baohe Road, Longgang District,Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210312006-1-1 Page 3 of 23 Contents 1TEST STANDARDS..................................................................4 2SUMMARY.............................................................................5 2.1General Remarks5 2.2Product Description5 2.3Description of the test mode5 2.4Special Accessories6 2.5Modifications6 3TEST ENVIRONMENT ...............................................................7 3.1Address of the test laboratory7 3.2Test Facility7 3.3Environmental conditions7 3.4Summary of measurement results8 3.5Statement of the measurement uncertainty8 3.6Equipments Used during the Test8 4TEST CONDITIONS AND RESULTS............................................10 4.1AC Power Conducted Emission10 4.2Radiated Emission13 4.3Occupied Bandwidth17 4.4Antenna Requirement18 5TEST SETUP PHOTOS OF THE EUT..........................................19 6PHOTOS OF THE EUT............................................................20 Report No.: GTS20210312006-1-1 Page 4 of 23 1TEST STANDARDS The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C (Section 15.207): Conducted limits. FCC Rules and Regulations Part 15 Subpart C (Section 15.209): Radiated emission limits; general requirements. ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: GTS20210312006-1-1 Page 5 of 23 2SUMMARY 2.1General Remarks Date of receipt of test sample:Mar. 01, 2021 Testing commenced on:Mar. 02, 2021 Testing concluded on:Mar. 12, 2021 2.2Product Description Product Name: Aibner wireless chargers Model/Type reference: A18 Hardware version: YM-W50-L-C-10W Software version: V1.0 Test samples ID: GTS20210312006-1-1# Power supply: DC 5V/2A or 9V/2A Operation frequency: 110KHz - 205KHz Modulation type:ASK Antenna type:Loop coil antenna 2.3Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 10W) Record Mode 2AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 7.5W) Pre-tested Mode 3AC/DC Adapter (9V/2A) + EUT + Wireless charger tester (Load 5W) Pre-tested Mode 4AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 10W) Pre-tested Mode 5AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 7.5W) Pre-tested Mode 6AC/DC Adapter (5V/2A) + EUT + Wireless charger tester (Load 5W) Pre-tested Note: All test modes were pre-tested, but we only recorded the worst case in this report. Report No.: GTS20210312006-1-1 Page 6 of 23 2.4Special Accessories Follow auxiliary equipment(s) test…

Text truncated - open the document above for the full version.

FCC ID: 2AY46-A18
