2AYA6-ODY-1989PERSONAL CASSETTE PLAYER WITH BLUETOOTH

INSTRUCTION MANUAL Important Safety Instructions 1. WARNING：Please refer the information on exterior bottom enclosure for electrical and safety information before installing or operating the apparatus. 2. WARNING：To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus. 3. WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. 4. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. 5. Invisible laser radiation when open and interlocks defeated. Avoid exposure to beam of laser. 6. Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. 7. No naked flame sources, such as lighted candles, should be placed on the apparatus. 8. Attention should be drawn to environmental aspects of battery disposal. 9. Use of the apparatus in moderate climates. 10. The rating and marking information are located at the bottom of the unit. CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type TO PREVENT FIRE OR SHOCK HAZARD DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. The lightning with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of magnitude to constitute a risk of electric shock to persons. This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts. WARNING LABEL INFORMING OF RADIATION This label is placed inside the unit. As shown in the illustration. To warn against further measures on the unit. The equipment contains a laser radiating laser rays according to the limit of laser product of class 1. WARNING: DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD. 1. READ INSTRUCTIONS - All the safety and operating instructions should be read before the appliance is operated. 2. RETAIN INSTRUCTIONS - The safety and operating instruction should be retained for future reference. 3. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 4. FOLLOW INSTRUCTIONS - All operating instructions should be followed. 5. WATER AND MOISTURE - The appliance should not be used near water, for example, near a bathtub, washbowl, Kitchen sink, Landry tub, swimming pool or in a wet basement 6. VENTILATION - The appliance should be situated so that its location or position does not interfere with its proper ventilation. Do not place on bed, sofa, rug or similar surface that may block the ventilation openings, in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings. 7. HEAT - The appliance should be situated away from heat sources such as radiators, stoves, or other appliances (including amplifiers) that produce heat. 8. POWER SOURCE - The appliance should be connected to power supply only of the type described in the operating instructions or as marked on the appliance. 9. POWER CORD PROTECTION - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. 10. OBJECT and LIQUID ENTRY - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. 11. ESD WARNING - The display does not function properly or no reaction to operation of any the control may due to the electrostatic discharge. Switch off and unplug the set. Reconnect after a few seconds. 12. DAMAGE REQUIRING SERVICE - The appliance should be serviced by qualified service personnel when: a. The power-supply cord or plug has been damaged. b. Objects have fallen into, or liquid has been spilled into the appliance enclosure. c. The appliance has been exposed to rain. d. The appliance has been dropped, or the enclosure damaged. e. The appliance does not appear to operate normally. 13. SERVICING - The user should not attempt to service the appliance beyond that described in the user operating instructions. All other servicing should be referred to qualified service personnel. LOCATION OF CONTROLS 1. Cassette Door 2. Stop 3. Volume Knob 4. Fast Forward 5. Play 6. Stereo Headphone Jack 7. Line-Out Jack 8. Function Selector 9. Detachable Belt Clip 10. Battery Compartment 11. DC Jack INCLUDES Stereo Earphone Aux in 3.5mm plug to plug cable POWER SUPPLY 1. For battery power, this unit requires 2 x AA size batteries (Not included). 2. To power the device, plug the AC adapter 3V 600mA (Not included) into the AC power input on the rear of the unit and a standard power outlet POWER SOURCE Set the “FUNTION” switch to select different mode  OFF = TAPE MODE  ON = TAPE and BLUETOOTH MODE VOLUME Adjust the “VOLUME” knob to the desired volume level. CASSETTE 1. Switch to the “TAPE” mode. 2. Open the Cassette Door and inset the pre-recorded cassette tape with the exposed tape facing upwards 3. Close the Cassette Door 4. Press the “PLAY” button to do playback or pause playback temporarily 5. Press the “FAST FORWARD“ button to rapidly advance the tape. 6. Press the “STOP” button to switch off AUTO STOP To protect your cassette tapes and prevent unnecessary wear to the pinch roller of the cassette mechanism, this unit is equipped with an Automatic Stop System. When the tape ends during play or fast forwarding, the “PLAY” button will automatically release to stop the cassette from running. CASSETTE TAPE OPERATING TIP…

Text truncated - open the document above for the full version.

Rich Gate Asia Pacific Enterprise Limited Model difference declaration letter Differences Description We Rich Gate Asia Pacific Enterprise Limited state: Product： PERSONAL CASSETTE PLAYER WITH BLUETOOTH Model Name： ODY-1989, RA435B The electrical circuit design, layout, components used and internal wiring for above models are identical, only different in model name and appearance. Sincerely, Signature: Name： Aries Ma Title: Director Date： Nov 12, 2020

C5266091_X8_Ed.1 1/1 Rich Gate Asia Pacific Enterprise Limited Company: Rich Gate Asia Pacific Enterprise Limited Address: Unit 20B, 2/F, Corporation Park, 11 On Lai Street, Shatin, New Territories Product Name: PERSONAL CASSETTE PLAYER WITH BLUETOOTH Model Number: ODY-1989, RA435B FCC Identifier: 2AYA6-ODY-1989 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Sincerely, Signature: Name： Aries Ma Title: Director Date: Nov 10, 2020

C5266091_X10_Ed.2 1/1 Rich Gate Asia Pacific Enterprise Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: Nov 10, 2020 Subject: Request for Confidentiality FCC ID: 2AYA6-ODY-1989 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name： Aries Ma Title: Director

Page 1 of 3 Report No.:FCS202010011 External photos Photo 1 Photo 2 Page 2 of 3 Report No.:FCS202010011 Photo 3 Photo 4 Page 3 of 3 Report No.:FCS202010011 Photo 5 Photo 6

Label and Label Location FCC ID: 2AYA6-ODY-1989 L*W: 10mm*5mm White label and black font

Page 1 of 2 Report No.:FCS202010011 Internal photos Photo 1 Photo 2 Page 2 of 2 Report No.:FCS202010011 Photo 3 Antenna Photo 4 U1 AB5325U

FCC Test Report Report No: FCS202010011W01 Issued for Applicant: Rich Gate Asia Pacific Enterprise Limited Address: Unit 20B, 2/F, Corporation Park, 11 On Lai Street, Shatin, New Territories Product Name: PERSONAL CASSETTE PLAYER WITH BLUETOOTH Brand Name: ODYSSEY Model Name: ODY-1989 Series Model: RA435B FCC ID: 2AYA6-ODY-1989 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page 2 of 32 Report No.: FCS202010011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : Rich Gate Asia Pacific Enterprise Limited Address ................................. : Unit 20B, 2/F, Corporation Park, 11 On Lai Street, Shatin, New Territories Manufacture's Name .............. : Dongguan City Wangniudun Yinghui Electronics Factory Address ................................. : Chijiaoluduan Zhengzhong Road Wangniudun Town Dongguan City, China Product Description Product Name ....................... : PERSONAL CASSETTE PLAYER WITH BLUETOOTH Brand Name ........................ : ODYSSEY Model Name .......................... : ODY-1989 Series Model ......................... : RA435B Test Standards ...................... : FCC Rules and Regulations Part 15 Subpart C, Section 249 Test Procedure ...................... : ANSI C63.10:2013 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ............................. : Date (s) of performance of tests : Nov 13, 2020~Nov 25, 2020 Date of Issue ............................ : Nov 25, 2020 Test Result ................................ : Pass Tested by : (Scott Shen) Reviewed by : (Duke Qian) Approved by : (Kait Chen) Page 3 of 32 Report No.: FCS202010011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Revision History Rev. Issue Date Effect Page Contents 00 Nov 25, 2020 All Initial Issue Page 4 of 32 Report No.: FCS202010011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1. SUMMARY OF TEST RESULTS FCC Part 15.249,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.205(a), 15.209(a), 15.249(a), 15.249(c) Radiated Spurious Emission PASS -- 15.209 Field strength of fundamental PASS 15.249(d) Band Edge Emission PASS -- 15.215(c) 20dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) All tests are according to ANSI C63.10-2013 Page 5 of 32 Report No.: FCS202010011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1.1 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.71dB 2 Unwanted Emissions, conducted ±2.98 dB 3 Conducted Emission (9KHz-150KHz) ±4.13 dB 4 Conducted Emission (150KHz-30MHz) ±4.74 dB 5 All emissions,radiated(<1G) 30MHz-1000MHz ±3.2 dB 6 All emissions,radiated (1GHz -18GHz) ±3.66 dB 7 All emissions,radiated (18GHz -40GHz) ±4.31 dB Page 6 of 32 Report No.: FCS202010011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name PERSONAL CASSETTE PLAYER WITH BLUETOOTH Model Name ODY-1989 Series Model RA435B Model Difference The electrical circuit design, layout, components used and internal wiring for above models are identical, only different in model name and appearance. Channel List Please refer to the Note 2. BT Frequency:2402-2480MHz Modulation: GFSK Channel number: 79CH Power Supply DC 3V(2*1.5AA) or DC 5V by adapter output. Hardware version number N/A Software version number N/A Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 7 of 32 Report No.: FCS202010011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. Channel List 3. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A HF PCB antenna N/A 1.0dBi Antenna Page 8 of 32 Report No.: FCS202010011W01 Flux Compliance Service Laboratory Room 105 Floor B…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.:FCS202010010 Blow 1GHz for radiated emission test setup Above 1GHz for radiated emission test setup Page 2 of 2 Report No.:FCS202010010 Conducted emission test setup
