2AYB76961373-Piece CD Shelf system with Digital PLL FM Stereo Radio and Bluetooth Wireless Technology

MODEL: MM451 PLEASE READ BEFORE OPERATING THIS EQUIPMENT. OWNER'S MANUAL BLUETOOTH 50 WATT CD SHELF SYSTEM LIMITED WARRANTY FCC STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. INFORMATION: This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. Modifications not authorized by the manufacturer may void users authority to operate this devices. 1 2 3 Depending on the quality of the disc, and the condition of the recording, some CD-R/CD-RW discs may not be playable. 1.Always place the compact disc in the disc tray with the label facing upward. (Compact discs can be played only on one side). 2.To move a disc from its storage case, press down on the center of the case and lift the disc out, holding it carefully by the edges. 3.If the disc becomes dirty, wipe the surface from the center hole outward towards the outer edge with a soft, dry cloth. 4.Never use such chemicals as record spray, antistatic sprays or fluid, benzine or thinner to clean the discs. Such chemicals will do irreparable damage to the disc's plastic surface. 5.Discs should be returned to their cases after use to avoid serious scratches that could cause the laser pick up to skip. 6.Do not expose discs to direct sunlight or high humidity and temperature for extended periods. Long exposure to high temperatures will warp the discs. 7.Printable CD-R and CD-RW discs are not recommended, as the label side might be sticky and damage the unit. 8.Use a soft oil-based felt-tipped pen to write the information on the label side. Never use a ball-point or hard-tipped pen, as this may cause damage to the recorded side. 9.Do not use CDs with an irregular shape (octagonal, heart-shaped, business card size, etc). CDs of this sort can damage the unit. 10.If you have any doubts of using CD-R/CD-RW disc, read the precautions supplied with the disc, or contact the disc manufacturer directly. How to remove the discHow to hold the discHow to clean the disc CARE AND MAINTENANCE MAIN UNIT 1.IR 2.STANDBY 3.PHONES JACK 4.AUX IN JACK 5.SOURCE BUTTON 6.BALANCE KNOB 7.STOP BUTTON 8./ TUN - BUTTON 9.TREBLE KNOB 10 / PAIR BUTTON 11./ TUN+ BUTTON 12.BASS KNOB 1 3.CLK SET, MEM/PROG BUTTON 14.REPEAT / M- BUTTON BONK EMULOV.5 1 NOTTUB +M.6 1 17.LCD DISPLAY 18.EJECT/ENTER BUTTON 19.CD COMPARTMENT 20 & 21. VOLUME (VU) METER 24. FM ANTENNA 22. SPEAKER SOCKET 3.PHONES JACK 23. DC JACK SCAN 4 22 23 24 1 2 3 10 11 12 13 14 15 16 17 18 19 20 21 5 6 4 7 8 9 LOCATION OF CONTROLS PHONES 50 0 100% 20 10 7 5 3 1 0 2 1 3 50 0 100 % 20 10 7 5 3 1 0 2 1 3 ST FM MHz DC 15V 1. FM BUTTON: Set the unit to FM radio mode 2. STANDBY BUTTON: Set the unit to ON/ STANDBY 3. CD BUTTON: Set the unit to CD mode 4. PROG BUTTON: CD program playback 5. MEM BUTTON: Radio memory 6. REPEAT BUTTON: Set playback to repeat. 7 & 18. TUN- / , TUN+ / : Adjust the frequency in FM mode. Skip tracks backward or forward in CD mode. 8 & 20. VOL -/+ : Adjust the volume level 9. CLK SET BUTTON: Set clock timer 10. BT BUTTON: Set the unit to Bluetooth mode. 11. MUTE BUTTON: Mute the unit sound 12. AUX BUTTON: Set the unit to AUX mode. 13 & 14. MEM+/- BUTTON: Choose the preset location for the corresponding station. 15. OPEN/CLOSE BUTTON: In CD mode, open and close CD tray. 16. SCAN BUTTON: Scan available FM radio station and store in memory. 17. PLAY / PAUSE: Pause and resume playback 19. STOP BUTTON: Stop playback 21. NUMERIC BUTTON: Direct key in the CD play track no. 22. PAIR BUTTON: Pairing Bluetooth device 5 REPEAT OPEN/ CLOSE CDFM MEMMEMMEM PAIRCLK SET PROG BT SCAN AUX TUNTUN 5 6 4 10 3 2 1 7 8 9 11 12 13 14 15 16 17 18 19 20 21 22 REMOTE CONTROLS 6 The Remote Control Unit can operate the unit from a distance about 8M. When operating the remote control unit, point it towards the front panel of the unit. •Even if the remote control unit is operated within the effective range, remote control operation may be impossible if there are any obstacles between the unit and the remote control. • If the remote control unit is operated near other appliances which generate infrared rays, or if other remote control devices using infrared rays are used nearthe unit, it may operate incorrectly. Conversely, the other appliances may operate incorrectly. BATTERY REPLACEMENT If the distance required between the remote control unit and main unit decreases, the …

Text truncated - open the document above for the full version.

SOLAR BRIGHT INDUSTRIAL LIMITED Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AYB7696137 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, July 26, 2021 Jim Wong SOLAR BRIGHT INDUSTRIAL LIMITED

SOLAR BRIGHT INDUSTRIAL LIMITED Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: July 26, 2021 SUBJECT: FCC Application for FCC ID: 2AYB7696137 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD.on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Jim Wong SOLAR BRIGHT INDUSTRIAL LIMITED

External Photos

Internal Photos BT ANT

FCC ID: 2AYB7696137 Portable device According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate. Maximum measured transmitter power: Mode Transmit Frequency (GHz) Max Conducted Power (dBm) tune up maximum power(dBm) Result calculation 1-g SAR 8DPSK 2.402 1.59 2.0 0.5 3 Conclusion: For the max result : 0.5 ≤ 3.0 for 1-g SAR extremity SAR, No SAR is required. Signature: Date: 2021.7.26 NAME AND TITLE (Please print or type): Lisa Wang/Manager COMPANY (Please print or type): Shenzhen EMTEK Co.,Ltd./Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China

Report No.ES210609034W Page 1 of 63 Ver.1.0 $印章$ TEST REPORT Product Name ： 3-Piece CD Shelf system with Digital PLL FM Stereo Radio and Bluetooth Wireless Technology Model Number ： MET137，MM451, MD137 FCC ID ： 2AYB7696137 Prepared for : SOLAR BRIGHT INDUSTRIAL LIMITED Address : FLAT/RM 4, 7F SHING YIP INDUSTRIAL BUILDING, 19-21 SHING YIP STREET, KWUN TONG, KL., HONG KONG. Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES210609034W Date(s) of Tests : June 12, 2021 to July 02, 2021 Date of issue : July 03, 2021 Report No.ES210609034W Page 2 of 63 Ver.1.0 Table of Contents TEST REPORT ....................................................................................................................................................... 1 1 TEST RESULT CERTIFICAT I O N ................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ................................................................................................................. 4 3 SUMMARY OF TEST RESULT ....................................................................................................................... 5 4 TEST METHODOLOGY ................................................................................................................................. 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED .................................................................................................. 6 4.3 DESCRIPTION OF TEST MODES ........................................................................................................... 7 4.4 TEST SOFTWARE .................................................................................................................................... 7 5 FACILITIES AND ACCREDITATIONS .......................................................................................................... 8 5.1 FACILITIES............................................................................................................................................... 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ........................................................................... 8 6 TEST SYSTEM UNCERTAINTY .................................................................................................................... 9 7 SETUP OF EQUIPMENT UNDER TEST ...................................................................................................... 10 7.1 RADIO FREQUENCY TEST SETUP 1 ................................................................................................... 10 7.2 RADIO FREQUENCY TEST SETUP 2 ................................................................................................... 10 7.3 CONDUCTED EMISSION TEST SETUP .............................................................................................. 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ............................................................... 13 7.5 SUPPORT EQUIPMENT......................................................................................................................... 13 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS .............................................................................. 14 8.1 STANDARD APPLICABLE ........................................................................................................................... 14 8.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ......................................................................... 14 8.3 EQUAL HOPPING FREQUENCY USE ............................................................................................................ 15 8.4 FREQUENCY HOPPING SYSTEM ................................................................................................................. 15 9 TEST REQUIREMENTS ................................................................................................................................ 16 9.1 20DB BANDWIDTH ............................................................................................................................... 16 9.2 CARRIER FREQUENCY SEPARATION ............................................................................................... 22 9.3 NUMBER OF HOPPING FREQUENCIES ............................................................................................. 28 9.4 AVERAGE TIME OF OCCUPANCY (DWELL TIME) .......................................................................... 30 9.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER ......................................................................... 33 9.6 CONDUCTED SUPRIOUS EMISSION ................................................................................................. 39 9.7 RADIATED SPURIOUS EMISSION ...................................................................................................... 46 9.8 CONDUCTED EMISSION TEST ........................................................................................................... 59 9.9 ANTENNA APPLICATION .................................................................................................................... 62 Report No.ES210609034W Page 3 of 63 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : SOLAR BRIGHT INDUSTRIAL LIMITED Address : FLAT/RM 4, 7F SHING YIP INDUSTRIAL BUILDING, 19-21 SHING YIP STREET, KWUN TONG, KL., HONG KONG. Manufacturer : SOLAR BRIGHT INDUSTRIAL LIMITED Address : FLAT/RM 4, 7F SHING YIP INDUSTRIAL BUILDING, 19-21 SHING YIP STREET, KWUN TONG, KL., HONG KONG. EUT : 3-Piece CD Shelf system with Digital PLL FM Stereo Radio and Bluetooth Wireless Technology Model Name : MET137，MM451, MD137 Trademark : MET，MAGNAVOX, Craig, MODERN Measurement Proced…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS 1.1. Photos of Conducted Emission Measurement 1.2. Photos of Radiation Emission Measurement Spurious Emission Test Setup (Below 1GHz) Spurious Emission Test Setup (Above 1GHz) ----------------The end----------------
