2AYBO-SPSG1BTBluetooth Speaker

Portable Wireless Speaker SP-SG1BT website : us.jvc.com Instruction Manual Notice: * Please read Instruction Manual carefully and keep it for your records. Package includes: • SP-SG1BT (Bluetooth Speaker) × 1pcs • Strap × 1pcs • USB-C to USB-A Cable (12 inch / 300mm) × 1pcs • Instruction Manual • Warranty Card Specifications: • Bluetooth Version 5.3 • Output: Max. 5W/4Ω • Battery Capacity: 500mAh • True Wireless Stereo by 2pcs of SP-SG1BT • SIRI Control • Voice Support and Notification Beep • Hands Free Calling • Auto Off ( 5min. After Disconnect Bluetooth ) • Bluetooth Working Distance: 33 ft / 10m °C04～01- /F °401～41 :erutarepmeT noitarepO • • Size: φ2.5 × 3.2 inch / φ64 × 81㎜ Note: * Above operation can be processed on Bluetooth devices synchronously. Safety Instructions: • Never disassemble SP-SG1BT in an attempt to make any repair as this could result in electrical shock, burns, or product failure. • Use extra caution in high temperatures. • Do not expose SP-SG1BT to direct heat or flame. • SP-SG1BT is Not covered under Warranty when the product has metal rust, surface spoiling and any other natural oxidation. • Damage, shock, and/or injury can occur if these Warnings are not heeded. • SP-SG1BT may become warm while charging. • Make sure to always Turn both SP-SG1BT and power outlet Off completely before unplugging it. • Make sure SP-SG1BT has plenty of ventilation. • Do not press the buttons too hard as it could damage SP-SG1BT. • Only use dry cloth to keep SP-SG1BT clean from dust. • Do not use chemicals on SP-SG1BT. • Never try to repair SP-SG1BT yourself, take it to a Certified Technician. Trying to remove panels or repairing it yourself could lead to Electric shock. When it is not in use, make sure it is correctly Turned Off and stored in a Cool Dry place. • Do not insert Foreign Objects into SP-SG1BT. • Avoid dropping SP-SG1BT, as harsh impacts could Damage it. Power On/Off and Pairing: • Place SP-SG1BT within 33 feet for the Bluetooth-enabled device. • Press and hold the Power button for 2sec. The Blue LED will flash rapidly to indicate that SP-SG1BT is in Bluetooth Pairing Mode; You will hear the Voice Support “The Bluetooth device is ready to pair”. Bluetooth Pairing : • On your Bluetooth enabled Device (Smartphone, Tablet, Media Player) navigate to the Bluetooth setting menu, Turn On the Bluetooth feature, and search for “JVC SP-SG1BT”,Type Password “0000” or “1234” if requested. • You will hear the Voice Support “The Bluetooth Device is connected successfully”, and the Blue LED Indicator is instantly ON when connected. You can start playing the music on your Devices now. The Blue LED Indicator is Flashing during playing. The Blue LED Indicator is ON during Pause Music. • SP-SG1BT will be automatically reconnected to the last Paired Bluetooth Device when Powered On again. TWS (True Wireless Stereo) Connection / Disconnection: [ Without Bluetooth Paired SP-SG1BT and Device ] • Please make sure that the Bluetooth of both SP-SG1BTs are in “The Bluetooth device is ready to pair” state when starting TWS connecting. • Place 2pcs of SP-SG1BT together, then Power On both 2 units. • Double-Click “Power Button” on One of SP-SG1BT, It will connect 2 units, as True Wireless Stereo with Notification Beep. • To Disconnect TWS, Double-Click Power Button again, it will disconnect. [ With Bluetooth Paired 1 of SP-SG1BT and Device ] • Operation is same as above except below. • Please Double-Click Power Button by Bluetooth Paired SP-SG1BT when you connect TWS. However , it might take more time to connect than “Without Bluetooth Paired SP-SG1BT and Device”. * Please do not Bluetooth Pair each SP-SG1BT and Device separately. It will not connect TWS for all above conditions. SIRI: • Double-Click “＋” Button will Activate SIRI. • Double-Click “＋” Button again will Deactivate SIRI. • Google Assistant and other Voice Assistants are not Compatible. Power Control: • SP-SG1BT will Power Off automatically if not connected within 5 minutes after being Powered On. • Low Battery Notification Beep will occur when the battery is lower than 20%. Charging: • Connect to the USB-C Charging Port located under the Silicone Cover. • Connect the USB-A (lager end of the Cable) to your Computer’s USB Port or an AC adaptor. (Not included) • While Power On, Notification Beep will occur when you connect Cable to charge Battery. • The LED Indicator will Turn RED and flashing while charging and goes off when fully charged. WARNING FOR BATTERY Please do not handle the battery in the following manners. It can lead to an explosion or leakage of flammable liquids and gases. • Dispose in fire, discard, crush or cut • Leave in extremely high temperature environment • Leave in extremely low pressure environment For USA and CANADA: This device complies with part 15 of FCC Rules and lnnovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme à la partie 15 des règles de la FCC et aux normes des CNR d’lnnovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l' appareil doit accepter tout brouillage subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with FCC/ISED radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the lSED radio frequency (RF) Exposure rules as this equipment has very low levels of RF energy. FunctionButtonOperation Power On❶PowerPress & Hold ( 2 sec.) Power Off❶PowerPress & Hold ( 3.5 sec.) Volume Up❷＋Short Press Volume Down❸－Short Press …

Text truncated - open the document above for the full version.

Rev 1/26/2023 JVCKENWOOD USA Corporation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06-01-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AYBO-SPSG1BT JVCKENWOOD USA Corporation (“the applicant” ) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Yuji Kanayama Rev 1/26/2023 JVCKENWOOD USA Corporation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06-01-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AYBO-SPSG1BT JVCKENWOOD USA Corporation (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Yuji Kanayama

Rev 1/26/2023 JVCKENWOOD USA Corporation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06-01-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2AYBO-SPSG1BT JVCKENWOOD USA Corporation (“the applicant” ) certifies that, as of th e dat e of th e filing of the application, we desig nate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0030227490 Name: JVCKENWOOD USA Corporation Address: 4001 Worsham Ave, Long Beach, CA, 90808, USA Contact Person: Yuji Kanayama Tel.: (+1) 310-761-8252 Email: [email protected] Sincerely, JVCKENWOOD USA Corporation Yuji Kanayama

JVCKENWOOD USA Corporation Date: June 1, 2023 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AYBO-SPSG1BT Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description Schematics.pdf Block Diagram.pdf Operational Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, JVCKENWOOD USA Corporation Signature Yuji Kanayama / Sales Planning Manager Typed name and Title

JVCKENWOOD USA Corporation FCC ID: 2AYBO-SPSG1BT POWER OF ATTORNEY Date: June 1, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on May 31, 2024. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, JVCKENWOOD USA Corporation are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, JVCKENWOOD USA Corporation Signature Yuji Kanayama / Sales Planning Manager Typed name and Title

JVCKENWOOD USA Corporation Date: 2023-06-01 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AYBO-SPSG1BT To Whom It May Concern: This letter is to statement that Bluetooth Speaker / SP-SG1BT has been tested according to FCC Part 15B by Waltek Testing Group Co., Ltd. (Test Report No.: WTF23D05104055W001). And the SDOC file, meeting the requirements of the FCC regulations, would been provided when the device is sold by the responsible party in US. The service will not be sold until the SDOC is provided. If the sale does not have an SDOC, all responsibility is the responsibility of the applicant. Sincerely, Signature Yuji Kanayama Sales Planning Manager JVCKENWOOD USA Corporation

Appendix- SP-SG1BT-Photos Page 3 of 9 2. Photographs –Constructional Details 2.1. EUT – External View Model SP-SG1BT FCC ID: 2AYBO-SPSG1BT Appendix- SP-SG1BT-Photos Page 4 of 9 Appendix- SP-SG1BT-Photos Page 5 of 9 Appendix- SP-SG1BT-Photos Page 6 of 9

Label Sample and Location Label Size: 28.5*28.5mm Location

Appendix- SP-SG1BT-Photos Page 7 of 9 2.2. EUT – Internal View Model SP-SG1BT FCC ID: 2AYBO-SPSG1BT Appendix- SP-SG1BT-Photos Page 8 of 9 Appendix- SP-SG1BT-Photos Page 9 of 9 ANT

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 8 TEST REPORT Reference No. .................... : WTF23D05104055W003 FCC ID ................................ : 2AYBO-SPSG1BT Applicant ............................ : JVCKENWOOD USA Corporation Address .............................. : 4001 Worsham Ave, Long Beach, CA 90808, USA Manufacturer ..................... : Dongguan G.K Technology Co., Ltd Address .............................. : Room 401, No.7 Dong'Er Street, Xinfa South Road, Wusha, Chan g'an Town, Dongguan, 523860 Guangdong, P.R. China Product ............................... : Bluetooth Speaker Model(s). ............................ : SP-SG1BT Standards........................... : 47CFR FCC Part 2 Subpart J Section 2.1093 Date of Receipt sample .... : 2023-06-14 Date of Test ....................... : 2023-06-14 to 2023-06-19 Date of Issue ...................... : 2023-07-06 Test Result ......................... : Pass Remarks: The re sult s shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Estel Qian / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTF23D05104055W003 Page 2 of 8 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2. Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2. CONTENTS ............................................................................................................................................... 2 3. REVISION HISTORY ................................................................................................................................. 3 4. GENERAL INFORMATION ....................................................................................................................... 4 4.1. GENERAL DESCRIPTION OF E.U.T.................................................................................................... 4 4.2. DETAILS OF E.U.T. ......................................................................................................................... 4 4.3. TEST FACILITY ................................................................................................................................ 5 4.4. SUBCONTRACTED ........................................................................................................................... 5 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 5. TEST SUMMARY ...................................................................................................................................... 6 6. RF EXPOSURE ......................................................................................................................................... 7 6.1. PROCEDURES AND REQUIREMENTS ................................................................................................. 7 6.2. CALCULATION METHOD ................................................................................................................... 7 6.3. TEST RESULT ................................................................................................................................. 8 Reference No.: WTF23D05104055W003 Page 3 of 8 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 3. Revision History Test Report No. Date of Receipt Sample Date of Test Date of Issue Purpose CommentApproved WTF23D05104055W003 2023-06-14 2023-06-14 to 2023-06-19 2023-07-06 Original - Valid Reference No.: WTF23D05104055W003 Page 4 of 8 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 4. General Information 4.1. General Description of E.U.T. Product: Bluetooth Speaker Model(s): SP-SG1BT Bluetooth Version: V5.3(BLE is not supported) Hardware Version: V1.3 Software Version: V1.5 4.2. Details of E.U.T. Operation Frequency: 2402~2480MHz Max. RF output power: -1.27dBm Type of Modulation: GFSK, π/4DQPSK Antenna installation: Inverted F Antenna Antenna Gain: -0.68dBi Ratings: DC 5V, 1A from type-C USB port or DC 3.7V from battery Battery: DC 3.7V 500mAh, 1.85Wh Accessory: USB cable USB type A plug to USB type C plug, length 50cm Note: for more details, please refer to user manual and EUT photos. Reference No.: WTF23D05104055W003 Page 5 of 8 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 4.3. Test Facility The test facility has a test site registered with the following organizations: ISED CAB identifier: CN0013. Test Firm Registration No.: 7760A. Waltek Testing Group Co., Ltd. Has been registered and fully described in a report filed with the Industry Canada. The acceptance letter from the Industry Canada is maintained in our files. Registration number 7760A, October 15, 2016. FCC Designation No.: CN1201. Test Firm Registration No.: 523476. Waltek Testing Group Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. Registration number 523476, September 10, 2019. 4.4. Subcontracted Whether parts of tests for the product have been subcontracted to other labs: Yes No If Yes, list the related test items and lab information: Test Lab: N/A Lab address: N/A Test items: N/A 4.5. Abnormalities from Standard Conditions None. Reference No.: WTF23D05104055W003 Page 6 of 8 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 5. Test Summary Test Items Test Requirement Result Maximum Permissible Exposure (Exposure of Humans t…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.73dBi -0.84dBi -0.68dBi -6.15dBi -3.70dBi -2.32dBi MAX. Gain -0.68dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dBi) Frequency (MHz) MaxMinAvg 2400-1.73178-30.0815-8.48713 2450-0.845801-38.5605-7.88012 2500-0.685586-24.0318-6.79139 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dBi) Frequency (MHz) MaxMinAvg 2400-6.1530-24.1420-13.0295 2450-3.7054-26.5836-10.6700 2500-2.32122-30.4301-9.70536 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 60 TEST REPORT Reference No. .................... : WTF23D05104055W002 FCC ID ................................ : 2AYBO-SPSG1BT Applicant ............................ : JVCKENWOOD USA Corporation Address .............................. : 4001 Worsham Ave, Long Beach, CA 90808, USA Manufacturer .................... : Dongguan G.K Technology Co., Ltd Address .............................. : Room 401, No.7 Dong'Er Street, Xinfa South Road, Wusha, Chang'an Town, Dongguan, 523860 Guangdong, P.R. China Product ............................... : Bluetooth Speaker Model(s). ............................ : SP-SG1BT Standards........................... : FCC 47CFR Part 15.247 Date of Receipt sample .... : 2023-06-14 Date of Test ....................... : 2023-06-14 to 2023-06-19 Date of Issue ...................... : 2023-07-06 Test Result ......................... : Pass Remarks: The re sults shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Estel Qian / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTF23D05104055W002 Page 2 of 60 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 4 4 GENERAL INFORMATION ....................................................................................................................... 5 4.1 General Description of E.U.T. ....................................................................................................... 5 4.2 Details of E.U.T. ............................................................................................................................ 5 4.3 Channel List .................................................................................................................................. 6 4.4 Test Facility ................................................................................................................................... 7 4.5 Subcontracted ............................................................................................................................... 7 4.6 Abnormalities from Standard Conditions ...................................................................................... 7 4.7 Test Mode ..................................................................................................................................... 7 5 TEST SUMMARY ...................................................................................................................................... 8 6 EQUIPMENT USED DURING TEST ......................................................................................................... 9 6.1 Equipments List ............................................................................................................................ 9 6.2 Description of Support Units ....................................................................................................... 10 6.3 Measurement Uncertainty .......................................................................................................... 10 6.4 Test Equipment Calibration ........................................................................................................ 10 7 CONDUCTED EMISSION ....................................................................................................................... 11 7.1 E.U.T. Operation ......................................................................................................................... 11 7.2 EUT Setup .................................................................................................................................. 11 7.3 Measurement Description ........................................................................................................... 11 7.4 Conducted Emission Test Result ............................................................................................... 12 8 RADIATED SPURIOUS EMISSIONS ..................................................................................................... 14 8.1 EUT Operation ............................................................................................................................ 14 8.2 Test Setup .................................................................................................................................. 15 8.3 Spectrum Analyzer Setup ........................................................................................................... 16 8.4 Test Procedure ........................................................................................................................... 17 8.5 Corrected Amplitude & Margin Calculation................................................................................. 17 8.6 Summary of Test Results ........................................................................................................... 18 9 CONDUCTED SPURIOUS EMISSIONS ................................................................................................. 24 9.1 Test Procedure ..............................................…

Text truncated - open the document above for the full version.

Appendix- SP-SG1BT-Photos Page 1 of 9 1. Test Setup photos Model SP-SG1BT FCC ID: 2AYBO-SPSG1BT 1.1 Photograph – Conducted Emission Test Setup For Conducted Emission Test Site 1# 1.2 Photograph – Radiated Emissions For 9kHz-30MHz Test Site 2# Appendix- SP-SG1BT-Photos Page 2 of 9 For 30MHz-1000MHz Test Site 2# For Above 1GHz Test Site 1#
