2AYDU-TYZQ003AIntelligent Electromagnetic Resistance Direct Driver Bike Trainer

使用说明书 产品名称：全智能电磁直驱自行车骑行台 Intelligent Electromagnetic Resistance Direct Driver Bike Trainer TY-ZQ003-A Catalogue Cautions--------------------------------------------- ----- Disclaimer------------------------------------------------- Product specifications--------------------------------------- Installation instructions ------------------------------------- Confirmation of bicycle model ---------------------------------------------- Assembly of bike trainer ---------------------------------------------------- Level of bike trainer -------------------------------------------------------- Assembly of bicycle hub----------------------------------------------------- Assembly of bike ----------------------------------------------------------- Intelligent cycling ------------------------------------------- Maintenance------------------------------------------------------------ storage and cleaning ----------------------------------------------------------- Maintenance ------------------------------------------------------------------ Troubleshooting --------------------------------------------- Product specifications-------------------------------------------------- Cautions Thank you for purchasing this product. Before use, please read this manual carefully and follow the instructions in it for installation, operation and use to ensure that your car runs well and is not damaged, and to prevent and avoid unnecessary accidents and injuries. ●Before use, please carefully check that the bolts fixing the feet of this product are securely fastened and that the bolts connecting the movable support tube to the trainer body are securely fastened. ●Before use, please confirm that this product is placed stably on a solid ground, with the four foot pads on the bottom touching the ground simultaneously to ensure that the product is stable and does not shake. ●Before starting your training, please make sure to confirm your health condition. It is recommended that you consult a doctor to find out if you can engage in cycling. ●If you feel unwell during use (such as physical exhaustion, weakness, pain, chest tightness, discomfort or abnormal pulse, etc.), please stop using it immediately and take a short rest. If you continue to feel unwell, it is recommended that you seek medical attention immediately. ●This product must not be used by individuals with physical, sensory or mental impairments (including children), or by those lacking relevant experience or knowledge, without supervision or guidance. ●Please do not allow children to use this product as a toy without supervision to avoid danger or injury. ● Please pay attention to whether your clothes are too long. Avoid letting your clothes or accessories on them affect your cycling to prevent danger. ●When using this product, please ensure there is sufficient space around you. Make sure there are no obstacles, children, pets or any potentially dangerous items (furniture, tables and chairs, etc.) around you. Avoid accidental contact with the moving parts of the bicycle and the bike trainer to prevent accidents. ●When using this product to ride while standing, please be extremely careful. Do not stand while rocking the bike to avoid falling or damaging it. ●Please do not disassemble or modify this product by yourself ●Please use original accessories. If this product malfunctions, please contact an authorized dealer for handling. Disclaimer ●The manufacturer shall not be held responsible for any malfunctions of third-party vendor software/applications/devices, etc. At the same time, it shall not be held liable for any damage to the bike trainer caused by any software not developed or recommended by the manufacturer. ●Users must carefully read this manual before using this product, fully follow the installation steps, methods and inspection requirements in this manual to install and inspect this product, and use this product in accordance with the warning requirements. If this product is used in violation of the warning requirements, resulting in temporary or permanent physical damage (whether direct or indirect) to the user or property loss, the manufacturer shall not be held responsible. List of components NO Name Quantity Diagram A Trainer Body 1 B Base tube 2 C Bolt M8*65 4 D Cap nut M8 4 E Flat Washers φ8 4 F Left axle 1 G Spacer 1 H Flywheel gasket 1 I Wheel mount 1 J Power Adapter 1 K Power cable 1 L Remote control 1 M Rear Skewer 1 N Allen wrench CRV-5 1 Q Allen wrench CRV-4 1 P Open wrench 12-14 1 Notice: The factory does not come with Shaft sleeve and flywheels due to the differences among bicycles! If necessary, you need to purchase separately! Installation Instructions Step 1: Confirm the bicycle Before starting to use the bike trainer, please first confirm the specifications of the bicycle and the type of rear hub, and prepare the flywheel that matches the bicycle. Step 2: Assemble the bike trainer 2-1 Open the box, check all the accessories and their quantities against the accessory list 2-2 Installation of Base tube As shown in Figure 1, Trainer Body is placed on the workbench, Two bolts simultaneously pass through the fixed square holes on the base tube and are inserted into the installation holes on the Trainer Body. (Note: Ensure that the square necks on the bolts are completely inserted into the fixed square holes on the base tube. Press the semi-round heads of the bolts with your hand.) Place one Flat Washer on each of the two bolt heads, tighten the nuts, and use an open-end wrench to secure the nuts firmly. Fix the other base tube to the movable support tube in the same way. Note: The nuts connecting the base tube to the Trainer Body and the movable support tube must be tightened firmly! Step 3: Level the bike trainer After the base pipe is installed, as shown in Figure 2, place the bike trainer on a solid and flat ground. Level it by rotating the base sleeves on the base pipe until all four base sleeves are in full contact with the ground si…

Text truncated - open the document above for the full version.

Jinhua Unisky Tools Co.,Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 9/28/2025 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2AYDU-TYZQ003A FRN of applicant: 0030264113 Per section 2.911(d)(7) of the FCC rules, [Jinhua Unisky Tools Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Herland International Trading Inc FCC Registration Number (FRN): 0036324101 Physical U.S. Company Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Contact Person: Jianfeng Gao Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Li Jinwei Title: Technician Company Name: Jinhua Unisky Tools Co.,Ltd. Date: 9/28/2025 Agent Signed (if different from Applicant): Signed: Printed name: Jianfeng Gao Title: Manager Company Name: Herland International Trading Inc Date: 9/28/2025

Jinhua Unisky Tools Co.,Ltd. Covered Equipment Certification Attestation Letter 9/28/2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AYDU-TYZQ003A Jinhua Unisky Tools Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Jinhua Unisky Tools Co.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Jinhua Unisky Tools Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). <Signature>: Name: Li Jinwei Title: Technician Company: Jinhua Unisky Tools Co.,Ltd. Date: 9/28/2025

Jinhua Unisky Tools Co.,Ltd. 2025-9-28 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature>: Name: Li Jinwei Title: Technician Company: Jinhua Unisky Tools Co.,Ltd.

Jinhua Unisky Tools Co.,Ltd. 2025-9-28 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen DL Testing Technology Co., Ltd.（101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China）to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Jinhua Unisky Tools Co.,Ltd.（118 Tianyu Rd., Zhuma Industrial Park, Wucheng District, Jinhua, 321000, Zhejiang, China） <Signature>: Name: Li Jinwei Title: Technician Company: Jinhua Unisky Tools Co.,Ltd.

Jinhua Unisky Tools Co.,Ltd. 2025-9-28 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AYDU-TYZQ003A Product Name: Intelligent Electromagnetic Resistance Direct Driver Bike Trainer Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>: Name: Li Jinwei Title: Technician Company: Jinhua Unisky Tools Co.,Ltd.

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 60*70mm Model.: TY-ZQ003-A FCC ID: 2AYDU-TYZQ003A Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) BT ANT 433.92RX ANT Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2AYDU-TYZQ003A RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation For BT Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK -4.88 0.3251 0.00005 1.0 PASS Remark: antenna gain=-1.2dBi

Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-250822068R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 32 FCC Part 15C Test Report FCC ID: 2AYDU-TYZQ003A Applicant: Jinhua Unisky Tools Co.,Ltd. Address: 118 Tianyu Rd., Zhuma Industrial Park, Wucheng District, Jinhua, 321000, Zhejiang, China Manufacturer: Jinhua Unisky Tools Co.,Ltd. Address: 118 Tianyu Rd., Zhuma Industrial Park, Wucheng District, Jinhua, 321000, Zhejiang, China Product Name: Intelligent Electromagnetic Resistance Direct Driver Bike Trainer Trade Mark: UNISKY Model Number: TY-ZQ003-A Date of Receipt: Aug. 22, 2025 Test Date: Aug. 22, 2025 - Sep. 05, 2025 Date of Report: Sep. 05, 2025 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10-2020+Cor.1-2023 Test Result: Pass Report Number: DLE-250822068R Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-250822068R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 32 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 21 3.3.1 TEST REQUIREMENT: 21 3.3.2 TEST PROCEDURE 21 3.3.3 DEVIATION FROM TEST STANDARD 21 3.3.4 TEST SETUP 22 3.3.5 EUT OPERATING CONDITIONS 22 4 . PEAK OUTPUT POWER 25 4.1 APPLIED PROCEDURES / LIMIT 25 4.1.1 TEST PROCEDURE 25 4.1.2 DEVIATION FROM STANDARD 25 4.1.3 TEST SETUP 25 4.1.4 EUT OPERATION CONDITIONS 25 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-250822068R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 32 Table of Contents Page 4.1.5 TEST RESULTS 26 5 . POWER SPECTRAL DENSITY TEST 28 5.1 APPLIED PROCEDURES / LIMIT 28 5.1.1 TEST PROCEDURE 28 5.1.2 DEVIATION FROM STANDARD 28 5.1.3 TEST SETUP 28 5.1.4 EUT OPERATION CONDITIONS 28 5.1.5 TEST RESULTS 28 6 . 6DB BANDWIDTH TEST 30 6.1 APPLIED PROCEDURES / LIMIT 30 6.1.1 TEST PROCEDURE 30 6.1.2 DEVIATION FROM STANDARD 30 6.1.3 TEST SETUP 30 6.1.4 EUT OPERATION CONDITIONS 30 6.1.5 TEST RESULTS 30 7 . ANTENNA REQUIREMENT 32 7.1 STANDARD REQUIREMENT 32 7.2 EUT ANTENNA 32 8 . TEST SEUUP PHOTO 32 9 . EUT PHOTO 32 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-250822068R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 32 1.. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(c) Radiated Spurious Emission PASS 15.205 Band Edge Emission PASS 15.247(b) Peak Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1. MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz 9 Power Spectral Density ±0.3dBm Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-250822068R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 32 2.. GENERAL INFORMATION 2.1. GENERAL DESCRIPTION OF EUT Product Name: Intelligent Electromagnetic Resistance Direct Driver Bike Trainer Trade Mark: UNISKY Model Number: TY-ZQ003-A Model Difference N/A Operation Frequency: 2402~2480MHz Channel numbers: 40 Channels Channel separation: 1MHz Modulation technology: GFSK Antenna Type: Internal Antenna Antenna gain: -1.2dBi Power supply: DC 12V from adapter Adapter: MODEL: XVE073-1200500 INPUT: 100-240VAC 50/60Hz 1.5A Max OUTPUT: DC12.0V/5.0A 60W Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. 2. Channel Lis Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 14 2430 28 2458 01 2404 15 2432 29 2460 02 2406…

Text truncated - open the document above for the full version.

1. Antenna Specification ItemSpecification NameUAC119-A0 Antenna W orking Frequency Range2.4-2.5GHz Max PK Gain 2400MHz:-1.2dBi 2450MHz:-1.3dBi 2500MHz:-1.4dBi VSWR2.0 Max P olarizationLinear TypePCB Impedance50Ω Size 22.8*9.68mm ManufacturerShengXianZhiKongCo.,Ltd Address Zhongxing Hotel (Qianhai HOP International), No. 19, Xinghua 1st Road(Extension),Haiwang Community, Xin'an Street, Bao'an District, Shenzhen, 2101 Phi=0 Phi=90 Theta=90

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Conducted Measurement Photos ※※※※※ END OF REPORT ※※※※※
