Instruction 1. Garage Door Lock A set garage door lock is including the lock box, wall console, outside panel and remote control, which is used for smart control of garage door. 1.1. Lock Box Function: Lock/ Unlock/ Adaptive remote control Delete all passwords and matched remote control:long press ”SETUP”&”LEARN” at the same time till the working indicator light flickering 2 times and beeps for one time. 1.2. Wall Console Function: 1. Lock/ Unlock 2. Close the auto lock function 3. Enable/disable other lock mode. Instructions 1. Press the button to open the lock. 2. Press “auto close” to stop this function. 3. Switch the button (bottom right) to the close status that will disable all other locking methods except the button on the wall console. 4. Switch the button (bottom right) to the open status that will enable all locking methods. 1.3.Outsidepanel Usercancontrollock/unlockbysettingpasswordontheoutsidepanelwhilealllocking methodsareenabled. Outside panel configuration (Configuration has completed before delivery.) 1. Short press “SETUP” button on the lock box, the working indicator light will turn to green and keep flickering slowly. 2. Press the “RESET” button on the outside panel with needle, till the keypad flickering slowly. 3. After con-fig successfully, keypad will light for 2 seconds. At the same time, the working indicator light of lock box will flickering twice and beeps. 4. If fail to con-fig, keypad light will turn off. Adding password on outside panel: 1. Short press “LEARN” button on lock box, the working indicator light will turn to yellow and keep flickering slowly for 30 seconds. 2. Enter a 6-digit password and press “#” to confirm. 3. After setting successfully, the working indicator light of lock box will flickering twice and beeps. Open the lock with outside panel. 1. Enter your 6-digit password and press “ENTER” to unlock. 1.4. Remote control User can control lock/unlock by using remote control while all locking methods are enabled. Remote control configuration (Configuration has completed before delivery.) 1. Short press “SETUP” button on the lock box, the working indicator light will turn to green and keep flickering slowly. 2. Press the “RESET” button on the remote control with needle, till the LED light keep flickering slowly. 3. After con-fig successfully, LED indicator light of remote control will turn on for 2 seconds. At the same time, the working indicator light of lock box will flickering twice and beeps. 4. If fail to con-fig, the LED indicator light will turn off. After con-fig successfully, user can press the remote control button to unlock. 2. APP download Android: iOS: Search “Bee space” in App Store. 3.APPinstruction 3.1.Register AfterdownloadedAPP,usercanregisteranewaccountonbelowloginpage. Enteryouremailaddressandclicktogettheverificationcode,thencheckyouremailand enterthecodetoclicknext. Settingyourname,passwordandagreetheserviceagreement,thenclicksignupsoasto completetheregistration. 3.2.AddingdevicesonAPP 3.2.1.Click“+”toadddevices. 3.2.2.Select“addmanually”. 3.2.3.Select“GarageLockKit”. 3.2.4.WiFiSelectWi-Finetworkthatyourmobilephone hasbeenconnected. 3.2.5.Press “SETUP” button on the lock box for 5 seconds till the working indicator light turn to blue and flickering slowly, then click “next”. 3.2.6.ConnectthehotspotfromlockboxontheWi-Fi settingpage. 3.2.7.AfterconnectedWiFi,thenbacktoAPPandclick “toconnect”. 3.2.8.LockBoxconnecttoNetwork. Click“addtohome” 3.2.9.Confirmthegatewayandaddittohomepage. 1.Whentheworkingindicatorlightturnstogreenand flickering. 2.Presssettingbutton,theworkingindicatorlightstop flickeringandkeepsgreen. 3.Clicknext. Click next. 3.3.UsingAPPtocontrolthelock. 3.3.1.Operationpage Usercanlock/unlockthegaragedoorlock,settingautocloseandchecktheoperation recordandalarmrecord. 3.3.2.Settingspage Usercancheckthegaragedoorlockinformation,aswellascheck/addotherdevices. FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: For Lock Box& Outside Panel This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. For Remote Control The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.
