2AYFV-SY201218WIRELESS MOUSE

Description:Wireless Mouse Model:BTS-060 Rating:3.7V-10Ma FCC ID:2AYFV-SY201218 FCC Statement:§ 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gener- ates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful in- terference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 3 Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 3 Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 3

32×20mm Description: Wireless Mouse Model: BTS-060 Rating：3.7V-10Ma FCC ID：2AYFV-SY201218 7mm

30mm 44mm 193mm 84mm 119mm

Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 1 Radiated Emission test below 1GHz Radiated Emission test Above 1GHz

1 Safety Human Exposure 1.1 Radio Frequency Exposure Compliance 1.1.1 Electromagnetic Fields RESULT: Pass Test Specification Test standard : FCC KDB Publication 447498 v06 FCC Part 2: Section 2.1091 For FCC: Measurement Record: The measured maximum specified power of the EUT is 85.96dBuV/m@3m (i.e. -9.87dBm) for general 2.4GHz, which is belong low power device, hence the EUT is excluded from RF Exposure evaluation according to FCC KDB publication 447498 D01: Mobile and Portable RF Exposure. Guidance v06.

Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 27 EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC& Compliance Test Report for Product name: WIRELESS MOUSE Model name: BTS-060 FCC ID: 2AYFV-SY201218 Test Report Number: EFGX20120089-IE-01-E01 Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 27 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 7 2.5 Test equipment utilized 8 2.6 Auxiliary Equipment Used during Test: 8 2.7 Test software information: 8 2.8 Test setup 9 2.9 Test results 11 3 Technical requirement and result 12 3.1 20 dB bandwidth 12 3.2 Radiated emission 16 Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 27 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : NINGBO SYLOON IMP & EXP CO., LTD Address : No.2, Zhenxing Road, Xiaogang, Ningbo, China Telephone : 0086 574 8623 5830 Fax : N/A 1.4 Details of manufacturer Name : NINGBO SYLOON IMP & EXP CO., LTD Address : No.2, Zhenxing Road, Xiaogang, Ningbo, China Telephone : 0086 574 8623 5830 Fax : N/A Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 27 1.5 Application details Date of receipt of application : 2020-12-14 Date of receipt of test item : 2020-12-14 Date of test : 2020-12-14 to 2020-12-21 Date of issue 2020-12-22 1.6 Test item Product type : WIRELESS MOUSE Model name : BTS-060 Brand : Hobby Lobby Serial number : N/A Ratings : Powered by AA battery Test voltage : 1.5 Vdc FCC ID : 2AYFV-SY201218 Additional information : N/A RadioTechnical data Frequency range : 2402MHz – 2480MHz Radio Tech. : 2.4G Proprietary Protocols Frequency channel : 40 Channels Modulation : GFSK Antenna type : PCB antenna Antenna gain : -4.26 dBi Radio module Type : 2.4G Proprietary Protocols Model : HS6210 Manufacturer : OnMicro 1.7 Test standards Test Standards FCC Part 15 Subpart C December 16, 2020 PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 27 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests performed. or The deviations as specified were ascertained in the course of the tests performed. 2.2 Test environment RF Conducted Enviroment Parameter Temperature Relative Humidity 101.2Kpa 24.6 62.6% Radiated Enviroment Parameter Temperature Relative Humidity 101.2Kpa 23.7 51.7% 2.3 Measurement uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncer- tainty in Measurement" (GUM) published by ISO. System Measurement Uncertainty Test Items Extended Uncertainty Uncertainty in conducted measurements 1.96dB Uncertainty for Conducted RF test RF Power Conducted: 1.16dB Frequency test involved: 1.05×10-7 or 1% Uncertainty for Radiated Spurious Emission 25MHz-3000MHz Horizontal: 4.46dB; Vertical: 4.54dB; Uncertainty for Radiated Spurious Emission 3000MHz-18000MHz Horizontal: 4.42dB; Vertical: 4.41dB; Uncertainty for Radiated Spurious Emission 18000MHz- 40000MHz Horizontal: 4.63dB; Vertical: 4.62dB; Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 7 of 27 2.4 Test mode The EUT was set at continuously transmitting mode (CH1, CH20, CH40) during the test. Channel List 1CH 2402 MHz 21CH 2442 MHz 2CH 2404 MHz 22CH 2444 MHz 3CH 2406 MHz 23CH 2446 MHz 4CH 2408 MHz 24CH 2448 MHz 5CH 2410 MHz 25CH 2450 MHz 6CH 2412 MHz 26CH 2452 MHz 7CH 2414 MHz 27CH 2454 MHz 8CH 2416 MHz 28CH 2456 MHz 9CH 2418 MHz 29CH 2458 MHz 10CH 2420 MHz 30CH 2460 MHz 11CH 2422 MHz 31CH 2462 MHz 12CH 2424…

Text truncated - open the document above for the full version.

Test Report No.: EFGX20120089-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 1 Radiated Emission test below 1GHz Radiated Emission test Above 1GHz
